ST STM32Cube Manuel utilisateur

Quick Start Guide

STM32Cube function pack for STEVAL-

STWINBX1 evaluation kit for high speed

datalogging and ultrasound processing

(FP-SNS-DATALOG2)

Version 1.0

Agenda

1Hardware and Software overview

3Documents & Related Resources

2Setup & Demo Examples

1- Hardware and Software overview

STEVAL-STWBXCS1

STWIN.box development kit - STEVAL-STWINBX1

Hardware Overview

STWIN.box - SensorTile Wireless Industrial Node

The STWIN.box (STEVAL-STWINBX1) is a development kit and reference design that simplifies prototyping and testing

of advanced industrial sensing applications in IoT contexts such as condition monitoring and predictive maintenance.

It is an evolution of the original STWIN kit (STEVAL-STWINKT1B) and features a higher mechanical accuracy in the

measurement of vibrations, an improved robustness, an updated BoM to reflect the latest and best-in-class MCU and

industrial sensors, and an easy-to-use interface for external add-ons.

The STWIN.box kit consists of an STWIN.box core system, a 480mAh LiPo battery, an adapter for the ST-LINK

debugger (STEVAL-MKIGIBV4), a plastic case, an adapter board for DIL 24 sensors and a flexible cable.

Key Features

•Multi-sensing wireless platform for vibration monitoring and ultrasound detection

•Built around STWIN.box core system board with processing, sensing, connectivity, and expansion capabilities

•Ultra-low power Arm® Cortex®-M33 with FPU and TrustZone at 160 MHz, 2048 kBytes Flash memory (STM32U585AI)

•MicroSD card slot for standalone data logging applications

•On-board Bluetooth® low energy v5.0 wireless technology (BlueNRG-M2), Wi-Fi (EMW3080) and NFC (ST25DV04K)

•Wide range of industrial IoT sensors: Ultra-wide bandwidth (up to 6 kHz), low-noise, 3-axis digital vibration sensor (IIS3DWB),

3D accelerometer + 3D gyro iNEMO inertial measurement unit (ISM330DHCX) with Machine Learning Core, High-

performance ultra-low-power 3-axis accelerometer for industrial applications (IIS2DLPC), Ultra-low power 3-axis

magnetometer (IIS2MDC), Dual full-scale, 1.26 bar and 4 bar, absolute digital output barometer in full-mold package

(ILPS22QS), Low-voltage, ultra low-power, 0.5°C accuracy I²C/SMBus 3.0 temperature sensor (STTS22H), Industrial grade

digital MEMS microphone (IMP34DT05), Analog MEMS microphone with frequency response up to 80 kHz (IMP23ABSU)

•Expandable via a 34-pin FPC connector

Latest info available at

https://www.st.com/en/evaluation

-tools/steval-stwinbx1.html

STWIN.box development kit - STEVAL-STWINBX1

Hardware Overview

STWIN.box - SensorTile Wireless Industrial Node

The STEVAL-STWINBX1 development kit includes:

•The STEVAL-STWBXCS1 STWIN.box core system (main board);

•A plastic case with M3 bolts;

•A 480 mAh 3.7 V LiPo battery;

•The STEVAL-MKIGIBV4 ST-LINK adapter with programming cable;

•The STEVAL-C34DIL24 adapter board for DIL24 sensors with the

STEVAL-FLTCB01 flexible cable.

STEVAL-STWBXCS1 Plastic Box STEVAL-C34DIL24

STEVAL-FLTCB01

Flex cable

STEVAL-MKIGIBV4

STLINK Adapter (V2, V2.1)

LiPo-752535

480mAh

STWIN.box Modular platform expansion - STEVAL-C34KAT1

Hardware Overview

Vibrometer and Temperature Sensors Expansion Board

STWIN.box expansion with Vibrometer (IIS3DWB) and Temperature

(STTS22H) sensors

•Optimal high frequency performance (up to 6kHz)

•Exposed pad on bottom side for thermal coupling

•34-pin slave connector, compatible with STWIN.box and other ST

Evaluation boards

•34-pin flex cable included

•4x fixing holes

STEVAL-C34AT01

STEVAL-FLTCB01

Flex cable

FP-SNS-DATALOG2

Software Overview

Software Description

The FP-SNS-DATALOG2 function pack for STEVAL-STWINBX1 represents an

evolution of FP-SNS-DATALOG1 and provides a comprehensive solution for saving

data from any combination of sensors and microphones configured up to the

maximum sampling rate.. It natively supports STEVAL-STWINBX1 with its external

addons (STEVAL-C34KAT1, STEVAL-C34DIL24).

The package also includes an example of ultrasound condition monitoring

(UltrasoundFFT) that calculates the FFT of the IMP23ABSU analog microphone

signal and streams the result to aPC GUI via USB.

Key features

•High-rate (up to 6 Mbit/s) data capture software suite:

•Dedicated Python SDK, ready-to-use for integration into any data science design flow

•Compatible with ST BLESensor app for system setup and real-time control

•Allow to setup MLC (Machine Learning Core) or ISPU (Intelligent Sensor Processing Unit)

•Synchronized timestamping and labelling mechanisms common to all sensors

•Generic FFT library middleware to enable frequency domain analysis

•Firmware modular examples based on eLooM (Embedded Light Object Oriented

framework for STM32) to enable code reusability at application level

•Based on STM32Cube software development environment for STM32

microcontrollers

•Based on AzureRTOS

Overall Software Architecture

Hardware STEVAL-STWINBX1

evaluation kit

STM32Cube Hardware Abstraction Layer (HAL)

Middleware

Hardware

Abstraction

parson AzureRTOS

BlueNRG-2 Sensor

Streaming

STM32 Generic

FFT Library

STM32 BLE

Manager

eLooM Framework

Application

FP-SNS-DATALOG2

Digital

Processing

Units - DPU PnPL Manager

Sensor

Manager Application

Specific Code

EMData

Tag Manager

DATALOG2 demonstration

•Based on STM32U5 AzureRTOS

•ThreadX, FileX, USBX

•USBX WCID Streaming class and PC DLL

•SD Card

•Full control of acquisition via BLE app

•Control via PnP-Like commands

Optimized STM32 FW Supports streaming of all Sensors at Full data rate

BLE

USB

BLE

USB

Device configuration (Device Template/PnPL) Raw Data streaming

Card

PnPL

STWIN.box Device Model

PnPL Parser

Sensor

Manager

Engine

Sensors

JSON

config file

Card

Python SDK

Real-time Plot GUI

•Based on AzureRTOS ecosystem

•ThreadX instead of FreeRTOS

•FileX instead of FatFS

•USBX

•Based on eLooM (Embedded Light Object Oriented framework for STM32) firmware components to enable

code reusability at application level (in common to FP-AI-MONITOR1, FP-AI-MONITOR2, FP-AI-PREDMNT2,

FP-AI-PDMWBSOC1)

•SensorManager

•EMData

•PnPL Manager

•DPU –Digital Processing Units

•IStream interfaces to standardize communication channels (USB, Sdcard, BLE)

•Updated and refactored PythonSDK, compatible also with DATALOG1

•New Real Time Plot GUI available only for DATALOG2

•Standardized and updated device configuration through Device Templates and PnP-Like protocols to enable

Platform Virtualization

DATALOG2 vs DATALOG1
