SSV RMG/941L Manuel utilisateur

Remote Maintenance Gateway

RMG/941(L,N)

with DNP/9535

First Steps

SSV Software Systems GmbH

Dünenweg 5

D-30419 Hannover

Phone: +49 (0)511/40 000-0

Fax: +49 (0)511/40 000-40

Emai : sa [email protected]

Document Revision: 1.0

Date: 2019-12-13

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D oc u m e n t R e v i s i o n 1 . 0

CONTENT

INTRODUCTION ............................................................................................................... 3

1.1

Checklist ................................................................................................................................. 3

1.2

Conventions ........................................................................................................................... 3

SAFET GUIDELINES ..................................................................................................... 4

REQUIRED EQUIPMENT ................................................................................................. 5

SIM CARD ......................................................................................................................... 6

CONNECTIONS ................................................................................................................ 7

5.1

LTE/NB-IoT Antenna .............................................................................................................. 7

5.1

Ethernet Link .......................................................................................................................... 8

5.2

erial Port COM2 ................................................................................................................... 9

5.3

Power upply ....................................................................................................................... 10

OPERATION ................................................................................................................... 11

6.1

Booting the RMG/941 .......................................................................................................... 11

6.2

Accessing the V/WebUI .................................................................................................... 11

6.3

Using the V/WebUI .......................................................................................................... 12

6.4

Accessing the V/WebUI with DHCP enabled ................................................................... 13

6.5

RMG/941N: Checking NB-IoT Connection ........................................................................... 15

6.6

RMG/941L: LTE Modem Configuration ............................................................................... 16

6.7

RMG/941L: WAN Configuration .......................................................................................... 17

6.8

RMG/941L: Firewall Configuration ...................................................................................... 18

6.9

LAN1 Configuration .............................................................................................................. 19

6.10

Access via Telnet .................................................................................................................. 20

6.11

Access via FTP ...................................................................................................................... 21

6.12

erial Console via COM1 ( ervice Port) ............................................................................... 23

TECHNICAL DATA ......................................................................................................... 24

PINOUT SCREW TERMINALS ....................................................................................... 24

HELPFUL LITERATURE ................................................................................................ 25

CONTACT ............................................................................................................................. 25

DOCUMENT HISTOR ......................................................................................................... 25

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

1 INTRODUCTION

This documentation gives you an overview about the initial operation and the first steps of

use with the RMG/941.

1.1 Checklist

ompare the content of your RMG/941(L,N) start-up package with the checklist below.

If any item is missing or appears to be damaged, please contact SSV!

 Remote Maintenance Gateway RMG/941(L,N)

 1x LTE/NB-IoT antenna (only for RMG/941L and RMG/941N)

 Adapter cable with power and RS232 connector

 Plug-in power supply

 Screwdriver

IMPORTANT!

You will need further equipment to operate the RMG/941. Please refer to chapter 3.

1.2 Conventions

Convention

sage

bold

Important terms

monospace

Filenames, Pathnames, program code, command

lines

Table 1: Conventions used in this document

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

2 SAFETY GUIDELINES

Please read the ollowing sa ety guidelines care ully! In case o property or personal

damage by not paying attention to this manual and/or by incorrect handling, we do not

assume liability. In such cases any warranty claim expires.

• The power supply should be in immediate proximity to the device.

• The power supply must provide a stable output voltage between 11 – 28 VD . The out-

put power should be at least 2.5 W.

• Please pay attention that the power cord or other cables are not squeezed or damaged

in any way when you set up the device.

• Do NOT turn on the power supply while connecting any cables, especially the power

cables. This could cause damaged device components! First connect the cables and

THEN turn the power supply on.

• The installation of the device should be done only by qualified personnel.

• Discharge yourself electrostatic before you work with the device, e.g. by touching a

heater of metal, to avoid damages.

• Stay grounded while working with the device to avoid damage through electrostatic

discharge.

• The case of the device should be opened only by qualified personnel.

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

3 REQUIRED EQUIPMENT

To operate the RMG/941 the following hardware is required:

• one Ethernet cross-over cable or two Ethernet patch cables and a switch.

To operate the RMG/941L the following hardware is required:

• a valid SIM card with an appropriate mobile tariff. Please refer to chapter 4 to see how

the SIM card is inserted.

The RMG/941N comes with a preinstalled SIM card for NB-IoT.

To configure the RMG/941(L,N) a computer with the following features is required:

• Windows 7 or higher

• Web browser (e.g. Firefox, hrome)

• Telnet/SSH client (e.g. TeraTerm)

• FTP client (e.g. FileZilla)

• 10/100 Mbps Ethernet network controller and T P/IP configuration

• D-ROM drive

RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

4 SIM CARD

The internal SIM card of the RMG/941L and RMG/941N can be changed through the slot on

the backside.

To remove the SIM card just push it gently with a screw driver until you hear a soft "click".

The SIM card is ejected a few millimeters and can be pulled out easily.

Figure 1: Removing the SIM card

To insert the SIM card just push it by hand as deep as possible into the slot.

Please note:

Pay attention to the correct orientation of the SIM card like shown in ig. 2!

Then use a screw driver to push it gently further into the slot until you here a soft "click".

Figure 2: Inserting the SIM card

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

5 CONNECTIONS

For a quick and easy start with the RMG/941 there are a few cable connections necessary.

The following chapters describe how these connections have to be made.

5.1 LTE/NB-IoT Antenna

onnect the LTE/NB-IoT antenna with the RMG/941(L,N) like shown in ig. 3 and place it

where the LTE/NB-IoT signal strength is high.

Figure 3: Connecting the LTE/NB-IoT antenna

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

5.1 Ethernet Link

The Ethernet link between the P and LAN1 of the RMG/941 can be made on two ways:

• Direct with an Ethernet cross-over cable like shown in ig. 4.

• With two standard Ethernet patch cables over a hub or switch like shown in ig. 5.

Figure 4: Ethernet link with cross-over cable

Please note:

For the Ethernet connection in ig. 4 it is required to use a cross-over cable. Do not

use an ordinary patch cable. Both types of cables are in most cases visual indistin-

guishable. But the internal wiring is fully different. Mixing up these types of cables

leads to LAN errors. Hence pay attention to the label of the cable or packing.

Figure 5: Ethernet link with hub or switch

The IP address of the LAN1 interface is ex-factory set to 192.168.0.126.

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

5.2 Serial Port CO 2

You can create an RS485 serial link on port OM2 of the RMG/941.

Figure 6: Serial link on COM2

Terminal

Signal

Serial Port

RS485 RX /TX+

Serial Port

RS485 RX /TX

Signal

Ground

Table 2: Screw terminals COM2

Please note:

The RS485 (officially called TIA/EIA-485-A) connection between your RMG/941 and

the field devices needs termination resistors on both ends for proper operation. The

RMG/941 does not o er internal termination resistors. Please make sure, that the

RS485 cable connection is equipped with external termination resistors.

Remote Maintenance Gateway RMG/941(L,N) – First Steps

D o c u m e n t R e v i s i o n 1 . 0

5.3 Power Supply

The RMG/941 needs a supply voltage of 11 – 28 VD to work.

onnect the cables of an appropriate power supply to provide the system with the neces-

sary power like shown in ig. 7.

Figure 7: Power supply or the RMG/941

Terminal

Sign

Vin (11 .. 28 VD )

GNDin

Table 3: Screw terminal power

CAUTION!

Providing the RMG/941 with a higher voltage than the regular 11 – 28 VD could cause

damaged device components!

Do NOT turn on the power supply while connecting it with the RMG/941. This could cause

damaged device components! First connect the power supply and THEN turn it on.
