Spypoint LINK-EVO Manuel utilisateur

QUICK START GUIDE

v.1..7

LINK-EVO

LINK-EVO-V (US ONLY)

& COMPARABLES*

ENGLISH

In the box

Note: Memory card and batteries are sold separately.

1x Camera

1x Mounting brackets

1x Installation strap

1x Quick start guide

1x Micro SIM card is preactivated and inserted in the camera

User manual, latest rmware & FAQ available at:

www.support.spypoint.com

Components

Slot for installation strap

Locking latch

Cable lock hole

12V jack

Tripod mount

Battery door push button

Antenna

LEDs

Photo lens

Light sensor

Test light

Signal meter

ON / OFF Switch

SD card slot

Detection lens

Battery case &

Micro SIM card reader

Steel security boxes may reduce the

wireless functionalities of the product.

* Specs and features may dier across comparable models. Refer to website or

packaging for full details.

ENGLISH

CAMERA BASIC

REMOVE THE CAMERA FROM THE MOUNTING BRACKET

• Push the tab to release the camera from the mounting bracket.

• Remove the camera.

FINDING THE SIM ID

The SIM ID number can be found in the battery case. You will need

this number to complete the registration of the LINK-EVO camera

and connect to the application.

ENGLISH

CHOOSE A POWER SOURCE

Be sure to insert the AA batteries according to the polarity

indications (+) and (-).

To ensure maximum performance of the camera and prevent battery

leak, we recommend the use of new batteries. Use ONLY Lithium

batteries or ONLY Alkaline batteries. Rechargeable AA batteries are

not recommended as the lower voltage they produce can cause

operational issues.

In order to get best results and longer battery life, we recommend

the use of an external 12V source.

INSERT THE MEMORY CARD

Insert an SD/SDHC memory card (up to 32 GB capacity) in the card

slot with the label side facing upward. The card is inserted correctly

when a click is heard. Always ensure that the camera power is OFF

before inserting an SD card.

We suggest to format your SD card if it’s been in another

electronic device.

Lithium or Alkaline batteries

DC 12V

12V power

source



ENGLISH

GETTING STARTED

INSTALL THE FREE

SPYPOINT LINK APP

The SPYPOINT LINK App lets you connect and control your camera

remotely using a smartphone or tablet. Features include viewing

your camera status, pictures, full camera control and more.

Install the free App

1. Make sure you have a data package with either your smartphone

 ortabletoraWiconnection.

2. To install the App, you can either:

 ●GetitonGooglePlayTM (Google Play is a trademark of Google Inc)

 ●DownloadontheAppStoreTM (App Store is a trademarks of Apple Inc.)

3. Search for the SPYPOINT LINK App from SPYPOINT.

4. Install the App on your smartphone or tablet.

Run the SPYPOINT LINK APP

Start the app and it will walk you through a few questions. Press the

buttonatthebottomofthescreenonceyouhavenished.Youwill

thenreceiveanemailconrmingtheactivation.

Once in the app, you will have the following 4 options at the bottom:

Account

Selectthedataplanandmodifyyourproleinformations.

Status

See general informations like the cellular signal strengh,

battery level or percentage of space used on your SD card.

Note: If you don’t have a smartphone or a tablet, please contact

our customer service to activate your camera.

Call us at our toll free number: 1-888-779-7646

ENGLISH

Settings

Modify the mode of the picture settings, the synchronisation

frequency & all others

Photos

Let you see your pictures by date, month and years. Also

let you share or download the photo.

SETTING THE APP

The LINK App let you congure all the camera’s settings.Theses

new settings will take effect the next time the LINKcamera connects

to update it’s status. Here are the most important settings, there is

more are available in the app.

BASIC SETTINGS

Mode - PHOTO

Delay: Sets the time interval between each detection before

the camera records the next photo.

Multi-shot: Takesupto 2consecutiveshots ateach detection,with

a 5 second delay between each photo.

Mode - TIME LAPSE

Interval: Thisoption allows the cameratotakephotos at regular

preset intervals without detection.

Mode - VIDEO

Delay: Sets the time interval between each detection before

the camera records the next video.

Photorst: When this option is enabled, a photo is taken

immediately before each video.

Video lenght: Allows the user to select the duration of the recording.

Note: If you have more than one camera, it will let you select

the camera name with the white bar with a scrolling menu at

the top of the screen

ENGLISH

TRANSFER SETTINGS

First transfer time: Allows the user to choose at what time of

the day the camera communicates for the

  rsttime.

Transfer frequency: Allows the user to choose the number of

synchronizations that the camera performs

daily.

ADVANCED OPTIONS

Night mode: Allows the user to set the best option for photos.

Schedule: Allows the user to set the period of operation of the

camera for each day of the week. The start and stop

time are the hours during which the camera is in

action and can record pictures or videos. For an

activation of 24 hours, the same start and stop time

must enter 00h00 or 12 AM.

illumination modes comparison* (Night modes)

* Available for photos only

optimal

MODE

IR-boost

MODE

Blur reduction

Battery life

Flash range









ENGLISH

START THE CAMERA

We strongly suggest to slow format your SD card in

a computer, even more if it has been used in another

electronic device.

1. Turn the camera ON

Use the ON/OFF switch to turn the camera ON.

2. All lights ashing - Searching for signal

The signal search can take few minutes to process. If only

1bluebarisashing,thenetworktestwasunsuccessful.

Get outside or near a window to maximize signal strength

and restart the camera. This operation might need to be

repeated as the SPYPOINT SIM card and services are powered by mul-

tiple providers. The network modem will manoeuvre to ensure stron-

gest signal strength by searching for the best tower available (cell

network).

3. Solid blue bars - Signal strength

Once the network test is completed, blue bars will

stabilize showing the signal strength. Note that signal

bars displayed on the camera can differentiate of those

shown on other cellular devices as there is no industry standards

andpracticetolabelDBMvaluestoaspecicnumberofbars.

4. Red light ashing (30 s) - Installation delay

Thetestlightinfrontofthecamerawillashfor30secondstoallow

the user to leave the area without being photographed or recorded.

5. All lights OFF - Camera ready

The camera has sent a picture and updated its status in the LINK

app with it’s latest information. The camera is now ready to take

pictures and transmit them to your LINK app upon the next synch.

Synchs are set by default to every 4 hours from midnight.

ENGLISH

IMPORTANT

BEFORE THE END OF THE 30-DAY FREE TRIAL

In the LINK app, go activate your plan under the Account tab.

For more details about the available plans, look at the Account

tab in the App or follow the link below. If you choose not to

activate a plan, note that you’ll still be able to transmit/receive

pictures with our FREE monthly plan. It will allow you to

transmit/receive up to 100 photos per month with a photo his-

tory of the last 7 days.

WWW.SPYPOINT.COM/PLANS

INSTALLATION OF THE CAMERA

Install the camera with or without the mounting bracket

Recommended installation height:

The camera should be installed at the same height as the animal’s

mid-body.

Ideal installation for quality pictures & videos:

The targeted animal should be 25 feet / 7.5m away from the camera

forabettereldofview.

To get brighter pictures at night , you should have elements in the

backgroundtoreectbacktheIRashtothecamera.

Note that the camera should not directly be facing the sun to avoid

back lighting and false detection.
