Spypoint LINK-MICRO-S-LTE Manuel utilisateur

v.1.0

LINK-MICRO-S-LTE

QUICK START GUIDE

ENGLISH

In the box

NOTE: MicroSD memory card is sold separately.

1x LINK-MICRO-LTE camera

1x Antenna holder

1x Installation strap

1x Quickstart guide

1x SIM card that is preactivated and inserted in the camera

1x USB Micro USB cable

1x LIT-10 lithium battery pack

User manual, latest rmware, and FAQ available at:

support.spypoint.com

Components

SIM card slot

Slot for installation strap

Locking latch

Cable lock hole

12V jack

Standard ¼’’20 tripod mount

Solar panel

Antenna

Detection lens

MicroSD card slot

Light sensor

Delay light

Photo lens

LED

ON/OFF switch

"STATUS" light

Lithium battery outlet

ENGLISH

CHARGING THE LITHIUM BATTERY

•Remove the lithium battery pack from the camera.

•Using the Micro USB cable, recharge the battery pack for about 12 hours.

•Once the lithium pack is fully charged, the red light will turn green.

HOW YOUR CAMERA USES SEVERAL POWER SOURCES

1. Your camera’s main source of power is the lithium battery pack (#LIT-10, included)

and oers longer battery life, roughly doubling that of standard AA batteries.

•The solar panel’s sole function is to recharge the lithium battery and will

operate when solar energy is detected.

•When the lithium battery pack power level becomes insucient, the

camera shuts down.

•The solar panel will continue recharging the lithium battery pack until the

power level is sucient. At this point, your camera will automatically turn

on and resume with your congured settings.

2. Moreover, the camera was designed to recognize and use a primary power

source other than the lithium battery pack:

•As soon as you plug an external 12V battery (#BATT-12V, sold separately)

into your camera, it becomes your camera’s new primary power source.

The lithium battery pack will only be used once the 12V battery is depleted.

•Simply plug the 12V cable into the 12V jack of the camera and connect the

other end to the 12V battery.

USING AN EXTERNAL 12V BATTERY

• Using an external 12V battery source does not recharge the lithium battery pack.

•The solar panel will not recharge an external 12V battery.

Getting started

Do not insert AA batteries into the lithium battery

compartment, as this could damage the camera.

ENGLISH

FORMATTING YOUR M

icro

SD CARD

Before inserting the MicroSD card into your camera, it must be reformatted via a

computer to ensure proper functionality.

Memory card is sold separately. Whether you choose to use a MicroSD card you

previously used in another device or a brand new one you've just bought, its

capacity must not exceed 32 GB and it must be reformatted. Do no use the‘’Quick

format’’option.

INSERTING A M

icro

SD CARD

•Ensure the camera is turned o.

•Insert a MicroSD memory card (up to 32 GB capacity) into the MicroSD card

slot with the label facing up.

•The card is inserted correctly when a click is heard.

This lithium battery is compatible with all SPYPOINT LINK-MICRO cameras and the CELL-LINK.

Getting started

LIT-10 BATTERY SPECIFICATIONS

Charging time ≈ 12 hours (with USB cable)

Operating temperature

(-30 °C to+50 °C) (-22 °F to+122 °F)

Storage temperature

(-40 °C to+60 °C) (-40 °F to+140 °F)

Voltage 3.7 Volts 10200mAh

Capacity 10200mAh

SPYPOINT hereby declares that this product is in compliance with the essential re-

quirements and other relevant provisions of Directive 2004/108/EC. The user can

obtain a copy of the Declaration of Conformity by e-mail at [email protected].

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

Operation is subject to the following two conditions:

1. This device must not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired operation.

ENGLISH

SPYPOINT APP

Follow these steps:

1. On Google Play

or the App Store

, search for "SPYPOINT app."

2. Download and install the app on your smartphone or tablet.

3. S

tart the app. Select "ACTIVATE A DEVICE." In the list, select "LINK-MICRO-S-LTE"

then follow the steps.

4. When complete, a conrmation email will be sent to you with a generated password.

5. Log in to the SPYPOINT app using your email and password.

ACTIVATING YOUR CAMERA

You must activate your camera through the free SPYPOINT

app or the SPYPOINT.COM website.

FINDING THE ACTIVATION CODE

The activation code is located inside the camera case behind

the battery holder.You will need this unique code to activate

the LINK-MICRO-S-LTE.

ENGLISH

SPYPOINT.COM website

Follow these steps:

1. On the SPYPOINT.COM website, select "MY ACCOUNT" in the top navigation menu.

On the displayed page, select "Register," ll out the required elds, then log in.

2. Select the + sign on the far right of the page; in the list, select "LINK-MICRO-S-LTE"

then follow the steps.

3. When complete, a conrmation email will be sent to you with a generated password.

4. Log in to the MY ACCOUNT section of the SPYPOINT website using your

email and password.

ACTIVATING YOUR CAMERA

NOTE: You can activate additional cameras and switch

between them in the SPYPOINT app or website.

CHOOSING A PHOTO TRANSMISSION

PLAN FOR YOUR CAMERA

Select a photo transmission plan via the app or website.

1. Upon activating your camera, you will automatically benet from

our FREE monthly plan.

2. After your 30 days are up, you can select a new plan better suited

to your needs among the ones we oer or;

3. Keep your FREE monthly plan and continue receiving up to 100

photo transfers per month.

ENGLISH

Both the SPYPOINT app and website let you congure all the camera settings remotely.

They also provide basic information on your camera – such as: cellular signal

strength, battery level, and MicroSD card space used. This information is based

upon the latest connection with your camera.

New settings take eect every time the camera connects with app or website.

Below are the most basic settings you will congure.

BASIC PHOTO SETTINGS

Delay: Allows you to set the time interval between each detection before the

camera records the next photo or video.

Multishot: Allows you to set the number of photos per detection (up to 3) with a

5-second delay between each photo.

Sensitivity: Allows you to set the detection sensitivity of the camera.

Camera name: Allows you to name each owned camera with a 30-character limit.

CELLULAR SETUP

First transfer time: Allows you to choose the time when the camera makes its

rst transfer of the day.

Transfer frequency: Allows you to choose the number of daily transfers.

ADVANCED OPTIONS/CONFIGURATION

Schedule: Allows you to set the period of operation for each day of the week.

For a 24-hour operation mode, both the start and stop times must be 12 AM.

CONFIGURING YOUR CAMERA

NOTE:

Camera transfers are set by default to every 4 hours from midnight.

For a complete list of specifications, features,

and settings, visit our LINK-MICRO-S-LTE page at

www.spypoint.com.

ENGLISH

FIRST TIME SETUP

1. Turn on the camera.

2. The green "STATUS" light will ash while searching for a signal (can take a few minutes).

3. The "STATUS" light will light up in one of the following 3 colors:

Red: Insucient signal.

Orange: Acceptable signal.

Green: Optimal signal.

4. When the top right light ashes red, 30 seconds remain before the photo mode is

turned on. This allows you to leave the area without being photographed.

5. The camera is ready for use when all the lights turn o.

6. If the light is red during step 3, you should:

•Turn your camera o and then back on.

•Retry while pointing the antenna at dierent angles.

•Try moving it to a spot with better signal.

•Try our #CA-01 long-range cellular antenna (sold separately), which could help

improve signal strength.

STARTING YOUR CAMERA

1. Mount the camera using the installation strap.

2. The camera should be at the same height as the animal’s mid-body.

3. The targeted animal should be at 25 feet/7.5 meters away from the camera.

4. For brighter pictures at night, ensure you have elements in the background

to reect the IR ash.

INSTALLING YOUR CAMERA

ENGLISH

ONLY USE ORIGINAL SPARE PARTS AND ACCESSORIES.

If one day your camera has been used so intensively that it has to be replaced, or if

you no longer have any use for it, you are obliged to dispose of it at a recycling center.

Information on return points for your electrical appliance can be obtained from

your local waste disposal company or from your local administrative offices.

Electrical appliances not only contain valuable recyclable raw materials, but also

substances which, if disposed of improperly, can affect public health and the

environment. Help ensure that valuable raw materials are recycled when you return

your old appliance to a central collection point.

The WEEE (Waste Electrical and Electronic Equipment Directive ) symbol

represents

the obligation that the labeled camera to be sent to a separate center for the proper

recycling of electrical and electronic equipment.

FREQUENCY RANGE:

800/ 850/ 900/ 1900/ 2100MHz

MAXIMUM TRANSMISSION POWER:

FREQUENCY

GSM850

EGSM900

DCS1800

PCS1900

GSM850 (8-PSK)

EGSM900 (8-PSK)

DCS1800 (8-PSK)

PCS1900 (8-PSK)

UMTS 2100

UMTS 1900

UMTS 900

UMTS 850

UMTS 800

DISPOSAL

FREQUENCY

MAX.

33DBM±2DB

30DBM±2DB

27DBM±3DB

26DBM±3DB

24DBM+1.7/3.7DB
