IM-P006-07 CTLS Issue 12 1

1. Safety information

2. General product information

3. Installation

4. Commissioning

5. Maintenance

6. Spare parts

7. Fault finding

Printed in GB

0060026/12

DP143, DP143G, DP143H

and DP163, DP163G, DP163Y

Pilot Operated Pressure Reducing Valves

Installation and Maintenance Instructions

IM-P006-07

CTLS Issue 12

IM-P006-07 CTLS Issue 12

IM-P006-07 CTLS Issue 12 3

Safe operation of these products can only be guaranteed if they are properly installed,

commissioned, used and maintained by qualified personnel (see Section 1.11) in compliance

with the operating instructions. General installation and safety instructions for pipeline and plant

construction, as well as the proper use of tools and safety equipment must also be complied with.

1.1 Intended use

Referring to these Installation and Maintenance Instructions, name-plate and Technical Information

Sheet, check that the product is suitable for the intended use/application.

The products listed below comply with the requirements of the Pressure Equipment Directive (PED)

and carry the mark when so required. The products fall within the following Pressure

Equipment Directive categories:

Product Group 2

Gases

DP143 and all derivatives

DN15 - DN32 SEP

DN40 - DN80 1

DP163 and all derivatives

DN15 - DN32 SEP

DN40 - DN80 1

i) The products have been specifically designed for use on steam, air and inert industrial gases

which are in Group 2 of the above mentioned Pressure Equipment Directive. The products’ use

on other fluids may be possible but, if this is contemplated, Spirax Sarco should be contacted

to confirm the suitability of the product for the application being considered.

ii) Check material suitability, pressure and temperature and their maximum and minimum values.

If the maximum operating limits of the product are lower than those of the system in which it

is being fitted, or if malfunction of the product could result in a dangerous overpressure or

overtemperature occurrence, ensure a safety device is included in the system to prevent such

over-limit situations.

iii) Determine the correct installation situation and direction of fluid flow.

iv) Spirax Sarco products are not intended to withstand external stresses that may be induced by

any system to which they are fitted. It is the responsibility of the installer to consider these

stresses and take adequate precautions to minimise them.

v) Remove protection covers from all connections and protective film from allname-plates, where

appropriate, before installation on steam or other high temperature applications.

1.2 Access

Ensure safe access and if necessary a safe working platform (suitably guarded) before attempting

to work on the product. Arrange suitable lifting gear if required.

1.3 Lighting

Ensure adequate lighting, particularly where detailed or intricate work is required.

1. Safety information

IM-P006-07 CTLS Issue 12

1.4 Hazardous liquids or gases in the pipeline

Consider what is in the pipeline or what may have been in the pipeline at some previous time.

Consider: flammable materials, substances hazardous to health, extremes of temperature.

1.5 Hazardous environment around the product

Consider: explosion risk areas, lack of oxygen (e.g. tanks, pits), dangerous gases, extremes of

temperature, hot surfaces, fire hazard (e.g. during welding), excessive noise, moving machinery.

1.6 The system

Consider the effect on the complete system of the work proposed. Will any proposed action (e.g.

closing isolation valves, electrical isolation) put any other part of the system or any personnel

at risk?

Dangers might include isolation of vents or protective devices or the rendering ineffective of

controls or alarms. Ensure isolation valves are turned on and off in a gradual way to avoid system

shocks.

1.7 Pressure systems

Ensure that any pressure is isolated and safely vented to atmospheric pressure. Consider double

isolation (double block and bleed) and the locking or labelling of closed valves. Do not assume

that the system has depressurised even when the pressure gauge indicates zero.

1.8 Temperature

Allow time for temperature to normalise after isolation to avoid danger of burns.

1.9 Tools and consumables

Before starting work ensure that you have suitable tools and/or consumables available. Use only

genuine Spirax Sarco replacement parts.

1.10 Protective clothing

Consider whether you and/or others in the vicinity require any protective clothing to protect against

the hazards of, for example, chemicals, high/low temperature, radiation, noise, falling objects, and

dangers to eyes and face.

1.11 Permits to work

All work must be carried out or be supervised by a suitably competent person.

Installation and operating personnel should be trained in the correct use of the product according

to the Installation and Maintenance Instructions.

Where a formal 'permit to work' system is in force it must be complied with. Where there is no such

system, it is recommended that a responsible person should know what work is going on and,

where necessary, arrange to have an assistant whose primary responsibility is safety.

Post 'warning notices' if necessary.

IM-P006-07 CTLS Issue 12 5

1.12 Handling

Manual handling of large and/or heavy products may present a risk of injury. Lifting, pushing,

pulling, carrying or supporting a load by bodily force can cause injury particularly to the back.

You are advised to assess the risks taking into account the task, the individual, the load and the

working environment and use the appropriate handling method depending on the circumstances

of the work being done.

1.13 Residual hazards

In normal use the external surface of the product may be very hot. If used at the maximum permitted

operating conditions the surface temperature of some products may reach temperatures of 300 °C.

Many products are not self-draining. Take due care when dismantling or removing the product from

an installation (refer to 'Maintenance instructions').

1.14 Freezing

Provision must be made to protect products which are not self-draining against frost damage in

environments where they may be exposed to temperatures below freezing point.

1.15 Disposal

Unless otherwise stated in the Installation and Maintenance Instructions, this product is recyclable

and no ecological hazard is anticipated with its disposal providing due care is taken.

1.16 Returning products

Customers and stockists are reminded that under EC Health, Safety and Environment Law, when

returning products to Spirax Sarco they must provide information on any hazards and the precautions

to be taken due to contamination residues or mechanical damage which may present a health,

safety or environmental risk. This information must be provided in writing including Health and

Safety data sheets relating to any substances identified as hazardous or potentially hazardous.

Warning

If this product is not used in the manner specified by this IMI, then the protection provided

may be impaired.

IM-P006-07 CTLS Issue 12

These instructions relate to the use of the DP143

(Section 2.1) and DP163 (Section 2.2) pilot operated

pressure reducing valves on steam applications but can be

used as a guide when the valve is used on compressed air

applications. The DP143G and DP163G are recommended

for compressed air applications, both having a nitrile seal

for the main valve and pilot valve assemblies.

Note: For additional information see the relevant Technical

Information Sheet.

2.1 DP143, DP143G and DP143H

2.1.1 Description

The DP143, DP143G and DP143H pilot operated pressure

reducing valves have been manufactured using cast steel.

Available types

DP143 Suitable for steam applications

DP143G Is a soft seal version available for

compressed air and inert industrial

gases.

Note: It is not recommended for

oxygen service.

DP143H Is a high temperature version for use up

to 350 °C.

Sizes and pipe connections

DN15LC - Low Capacity version, DN15, DN20, DN25, DN32, DN40, DN50 and DN80.

Standard flanges: EN 1092 PN25 and PN40, BS 10 Table 'J' and ASME 300.

Available on request: ASME 150 and JIS 20.

2. General product information

IM-P006-07 CTLS Issue 12 7

100

200

300

350

10 17.2 20 26 30 40

2.1.2 Pressure/temperature limits

Pressure bar g

Temperature °C

A B

Steam

saturation

curve

EGC

The product must not be used in this region.

Use the high temperature DP143H version in this region.

A-D-EFlanged EN 1092 PN40, ASME 300 and BS 10 Table J.

A-B-CFlanged ASME 150.

F-GDP143G limited to 120 °C @ 26 bar g.

Note: Two colour coded pressure adjustment springs are available for the following downstream pressure

ranges:

Red 0.2 bar g to 17 bar g

Grey 16.0 bar g to 24 bar g

Body design conditions PN40

Maximum design pressure

A-D-E40 bar g @ 40 °C

A-B-C17.3 bar g @ 40 °C

Maximum design temperature 350 °C @ 24 bar g

Minimum design temperature 0°C

Maximum upstream pressure for saturated steam service

A-D-E28 bar g

A-B-C14 bar g

Maximum operating temperature

DP143 300 °C @ 25 bar g

DP143G 120 °C @ 26 bar g

DP143H 350 °C @ 24 bar g

Minimum operating temperature

Note: For lower operating temperatures consult Spirax Sarco.

0°C

Maximum differential pressure

A-D-E28 bar

A-B-C14 bar

Designed for a maximum cold hydraulic test pressure of: 60 bar g

Note: With internals fitted, test pressure must not exceed: 40 bar g

IM-P006-07 CTLS Issue 12

2.2 DP163, DP163G and DP163H

2.2.1 Description

The DP163, DP163G and DP163Y pilot operated

pressure reducing valves have been manufactured

using stainless steel.

Available types

DP163 Suitable for steam applications

DP163G Is a soft seal version available for compressed

air and inert industrial gases.

Note: It is not recommended for oxygen

service.

DP163Y Having a lower rate pressure control spring is

suitable for steriliser/autoclave applications

2.2.2 Sizes and pipe connections

DN15LC - Low Capacity version, DN15, DN20, DN25, DN32, DN40, DN50 and DN80.

Standard flanges: EN 1092 PN25 and PN40, BS 10 Table 'J' and ASME 300.

Available on request: ASME 150 and JIS 20.

IM-P006-07 CTLS Issue 12 9

0 10 18.9 26 30 36.4 40

100

150

200

250

Pressure bar g

Temperature °C

2.2.3 Pressure/temperature limits

A B D

G EC

Steam

saturation

curve

The product must not be used in this region.

A-D-EFlanged EN 1092 PN40, BS 10 Table J and ASME 300.

A-B-CFlanged ASME 150.

F-GDP163G limited to 120 °C @ 26 bar g.

Note: Two colour coded pressure adjustment springs are available for the following downstream

pressure ranges:

Red 0.2 bar g to 17 bar g

Grey 16.0 bar g to 21 bar g

Yellow 0.2 bar g to 3.0 bar g (DP163Y only)

Body design conditions PN40

Maximum design pressure

A-D-E36.4 bar g @ 20 °C

A-B-C18.9 bar g @ 20 °C

Maximum design temperature 250 °C @ 24 bar g

Minimum design temperature -10 °C

Maximum upstream pressure for saturated steam service

A-D-E25 bar g

A-B-C14 bar g

Maximum operating temperature

A-D-E250 °C @ 24 bar g

A-B-C250 °C @ 12.1 bar g

Minimum operating temperature

Note: For lower operating temperatures consult Spirax Sarco.

0°C

Maximum differential pressure

A-D-E25 bar

A-B-C14 bar

Designed for a maximum cold hydraulic test pressure of: 60 bar g

Note: With internals fitted, test pressure must not exceed: 40 bar g

IM-P006-07 CTLS Issue 12

Fig. 1

Balance pipe assembly

Pressure adjustment spring

Note: Before actioning any installation observe the 'Safety information' in Section 1.

3.1 Supply (Figure 1)

The DP143 and DP163 pilot operated pressure reducing valves are supplied ready for fitting. The pressure

adjusted spring will be the one most suitable for the downstream pressure quoted on the order but will not

be pre-set.

3. Installation

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Spirax Sarco Unité de contrôle

Spirax Sarco

Spirax Sarco M80i ISO Manuel utilisateur

Spirax Sarco

Spirax Sarco SafeBloc DBB3 Manuel utilisateur

Spirax Sarco

Spirax Sarco PF5 Series Manuel utilisateur

Spirax Sarco

Spirax Sarco DLV7 Manuel utilisateur

Spirax Sarco

Spirax Sarco MST21 Series Manuel utilisateur

Spirax Sarco

Spirax Sarco DP27T Manuel utilisateur

Spirax Sarco

Spirax Sarco HL 17 Manuel utilisateur

Spirax Sarco

Spirax Sarco DN15 Manuel utilisateur

Spirax Sarco

Spirax Sarco M10HPi ISO Series Manuel utilisateur

Spirax Sarco

Spirax Sarco M10S Manuel utilisateur

Spirax Sarco

Spirax Sarco SRV2S Manuel utilisateur

Spirax Sarco

Spirax Sarco DP27S Manuel utilisateur

Spirax Sarco

Spirax Sarco HV3 Manuel utilisateur

Spirax Sarco

Spirax Sarco SRV66HC Manuel utilisateur

Spirax Sarco

Spirax Sarco SRV66 Manuel utilisateur

Spirax Sarco

Spirax Sarco ABV21i Manuel utilisateur

Spirax Sarco

Spirax Sarco 25E Manuel utilisateur

Spirax Sarco

Spirax Sarco TD3-3 Manuel utilisateur

Spirax Sarco

Spirax Sarco GKE 10 Mode d’emploi

Spirax Sarco

Spirax Sarco MSC-125 Manuel utilisateur

Spirax Sarco

Spirax Sarco UIB45 Manuel utilisateur

Spirax Sarco

Spirax Sarco 58 Manuel utilisateur

Spirax Sarco

Spirax Sarco SX100e Fiche technique

Spirax Sarco

Spirax Sarco DCV1 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
