SOYO SY-K7ADA Manuel utilisateur

SY-K7ADA XP

Motherboard

****************************************************

AMD®Athlon/Duron

Processor supported

ALI MAGIK1 AGP/PCI Motherboard

266/200 MHz Front Side Bus supported

ATX Form Factor

****************************************************

User's Manual

SOYO™ SY-K7ADA XP

Trademarks:

Soyo is the registered trademark of Soyo Computer Inc. All trademarks are the

properties of their owners.

Product Rights:

All names of the product and corporate mentioned in this publication are used for

identification purposes only. The registered trademarks and copyrights belong to

their respective companies.

part of this manual may be reproduced, transmitted, transcribed, translated into any

other language, or stored in a retrieval system, in any form or by any means, such

as by electronic, mechanical, magnetic, optical, chemical, manual or otherwise,

without permission in writing from Soyo Computer Inc.

Disclaimer:

Soyo Computer Inc. makes no representations or warranties regarding the contents

of this manual. We reserve the right to amend the manual or revise the

specifications of the product described in it from time to time without obligation to

notify any person of such revision or amend. The information contained in this

manual is provided to our customers for general use. Customers should be aware

that the personal computer field is subject to many patents. All of our customers

should ensure that their use of our products does not infringe upon any patents. It is

the policy of Soyo Computer Inc. to respect the valid patent rights of third parties

and not to infringe upon or to cause others to infringe upon such rights.

Restricted Rights Legend:

Use, duplication, or disclosure by the Government is subject to restrictions set

forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer

Software clause at 252.277-7013.

About This Guide:

This Quick Start Guide can help system manufacturers and end users in setting up

and installing the Motherboard. Information in this guide has been carefully

checked for reliability; however, to the correctness of the contents there is no

guarantee given. The information in this document is subject to amend without

notice.

For further information, please visit our Web Site on the Internet. The address is

"http://www.soyo.com.tw".

Edition: November 2001

Version 1.0

K7ADA XP SERIAL

CTest ed To Co mpl y

With FCC Standards

FOR HOME OR OFFICE USE

POST CONSUMER

RECYCLED PAPER

100%

Table of Contents SY-K7ADA XP

iii

Table of Contents

CHAPTER 1 MOTHERBOARD DESCRIPTION ................................1

1-1 INTRODUCTION...............................................................1

1-2 KEY FEATURES................................................................1

1-3 ELECTROSTATIC DISCHARGE PRECAUTIONS..........4

1-4 SY-K7ADA XP MOTHERBOARD LAYOUT...................5

1-5 SY-K7ADA XP MOTHERBOARD COMPONENTS....................6

1-6 MICROPROCESSOR.........................................................8

1-7 CHIPSET ............................................................................9

1-8 HARDWARE MONITOR.................................................12

1-9 WAKE ON LAN TECHNOLOGY ...................................13

CHAPTER 2 HARDWARE INSTALLTION........................................14

2-1 PREPARATIONS..............................................................14

2-2 UNPACKING THE MOTHERBOARD ...........................15

2-3 INSTALLATION GUIDE .................................................16

2-3.1 CPU Installation .....................................................17

2-3.2 DDR SDRAM Memory Module Installation............20

2-3.3 Motherboard Connector ..........................................22

2-3.4 Jumper Setting.........................................................36

2-3.5 The synchronous/asynchronous clock mode between

CPU and memory interface setting ...................................................38

2-3.6 CPU Vcore adjustment (VJ1) ..................................38

2-3.7 CMOS Clearing (JP5) .............................................39

2-3.8 Power On ................................................................40

2-3.9 Quick BIOS Setup....................................................41

2-3.10 Troubleshooting at First Start ...............................42

2-3.11 Power Off..............................................................45

CHAPTER 3 BIOS SETUP UTILITY ..................................................46

3-1 SOYO COMBO SETUP ...................................................49

Table of Contents SY-K7ADA XP

3-2 ADVANCED BIOS FEATURES ......................................54

3-3 ADVANCED CHIPSET FEATURES ...............................59

3-4 INTEGRATED PERIPHERALS.......................................62

3-5 POWER MANAGEMENT SETUP ..................................66

3-6 PNP/PCI CONFIGURATION SETUP..............................70

3-7 PC HEALTH STATUS ......................................................74

3-8 LOAD FAIL-SAFE DEFAULTS ......................................76

3-9 LOAD OPTIMIZED DEFAULTS.....................................77

3-10 SUPERVISOR PASSWORD ............................................78

3-11 USER PASSWORD ..........................................................79

3-12 IDE HDD AUTO DETECTION .......................................80

3-13 BOOT MENU ...................................................................81

CHAPTER 4 DRIVER INSTALLATION.............................................82

Motherboard Description SY-K7ADA XP

Chapter 1

MOTHERBOARD DESCRIPTION

1-1 INTRODUCTION

The SY-K7ADA XP AGP/PCI Motherboard is a high-performance Socket

462 ATX form-factor system board. Using ALI Chipset technology. This

Motherboard is fully compatible with industry standards and adds many

technical enhancements.

1-2 KEY FEATURES

 CPU SUPPORT

The SY-K7ADA XP supports THE FOLLOWING AMD® CPUs:

 Supports 200MHz Front Side Bus DDR(Double Data Rate) transfer

on Athlon(750MHz~1.2GHz)/ Duron(600MHz~850MHz)

 Supports 266MHz Front Side Bus DDR (Double Data Rate) transfer

on Athlon(1GHz~1.2GHz)

 Supports 266MHz Front Side Bus DDR (Double Date Rate) transfer

on Athlon Palomino(1500+~1800+)

New released AMD Socket 462 CPUs will very likely be supported by the

SY-K7ADA XP as well.

 CPU SETTINGS

The SY-K7ADA XP provides the user with a very complete and

convenient CPU setting environment. The CPU settings are all adjusted

through the DIP switch.

 CPU Frequency

The SY-K7ADA XP supports an incredible wide range of CPU frequency

settings:

600,650,700,750,800,850,900,950,1000+MHz.

This gives the SY-K7ADA XP an overwhelming overclocking potential.

Motherboard Description SY-K7ADA XP

 CPU Multiplier

 EXPANDABILITY

The SY-K7ADA XP provides all the standard expansion slots, and many

more additional expansion features:

 Expansion slots

 1 x 32-bit bus master AGP slot

 5 x 32-bit bus master PCI slots

 Enhanced IO

 Floppy disk controller

 2x EIDE controllers with support for up to 4 Ultra DMA

33/66/100 devices

 Standard/EPP/ECP parallel port

 2x 16550 compatible serial ports

 IrDA compatible infrared port

 6x USB (Universal Serial Bus) connectors

 PS/2 mouse connector

 PS/2 keyboard connector

Motherboard Description SY-K7ADA XP

 ADVANCED FUNCTIONS

The SY-K7ADA XP supports advanced functions such as:

 Wake-On-LAN

Supports Wake-On-LAN (Some advanced network cards can

wake the system up over the network, the WOL connector is

provided by the SY-K7ADA XP to support this function).

 Multiple boot

The SY-K7ADA XP supports booting from devices such as CD-ROM,

FLOPPY DRIVE & HDD, LS120, SCSI, ZIP.

 Power on by modem or alarm

If the SY-K7ADA XP system is in suspend mode, it can be switched

back on through the modem or RTC alarm function. This opens a lot

of possibilities, such as remote access that switches the system on

only after the modem receives a call.

 FAIL SAFE

The SY-K7ADA XP comes with added functionality to make managing

the system easy and safe

 Hardware Monitor

The integrated Hardware Monitor IC and Hardware doctor software

enables the user to monitor system voltages, temperatures and FAN speeds.

This makes sure that the user is in full control of the system

 SOYO Bonus Pack CD-ROM

 COMPLIANCE

The SY-K7ADA XP complies with all important industry standards. The

following underlines the reliability of the SY-K7ADA XP, a motherboard

to trust.

 PC99, ACPI compliant

 USER FRIENDLY

 SOYO Combo Setup

 Jumperless design

 You can set up the following options through the BIOS setup

Motherboard Description SY-K7ADA XP

 CPU FSB frequency

 PCI clock

 AGP Clock

 SDRAM Clock

 HANDLING THE MOTHERBOARD

To avoid damage to your Motherboard, follow these simple rules while

unpacking:

 Before handling the Motherboard, ground yourself by grasping an

unpainted portion of the system's metal chassis.

 Remove the Motherboard from its anti-static packaging. Hold the

Motherboard by the edges and avoid touching its components.

 Check the Motherboard for damage. If any chip appears loose, press

carefully to seat it firmly in its socket.

Warning: Do not apply power if the Motherboard appears

damaged. If there is damage to the board, contact your dealer

immediately.

1-3 ELECTROSTATIC DISCHARGE PRECAUTIONS

Make sure to ground yourself before handling the Motherboard or other

system components. Electrostatic discharge can easily damage the

components. Note that you must take special precautions when handling

the Motherboard in dry or air-conditioned environment.

To protect your equipment from electrostatic discharge, take the following

precautions:

 Do not remove the anti-static packaging until you are ready to install.

 Ground yourself before removing any system component from its

protective anti-static packaging. (To ground yourself, grasp the expansion

slot covers or other unpainted portions of the computer chassis.)

 Frequently ground yourself while working or use a grounding strap.

 Handle the Motherboard by its edges and avoid touching its

components.

Motherboard Description SY-K7ADA XP

1-4 SY-K7ADA XP MOTHERBOARD LAYOUT

PRT

PS/2 KB

ConnectorPS/2 Mouse

Connector

ATX Power

AOUT

AIN

AMIC

AGAME

COMA

COMB

USB 1_2

SDRAM

□

M1647

AGP Slot

Lithium

Battery

JP1

RJ2

RJ3

CDIN1

PCI Slot #5

Flash BIOS

PCI Slot #1

PCI Slot #4

PCI Slot #3

PCI Slot #2

FLP

IDE 1

IDE 2

□

M1535D+

FJ1

RJ1

VJ2

VJ1

ALi

JP5

JP10

WOL

Header

12 3 4 5 910

1112 13 14 15 16 17 18 19 20

Sigmatel

STAC9700

ALi

M5879

ALi

M5819

Back Panel SY-K7ADA XP Platform

Motherboard Description SY-K7ADA XP

1-5 SY-K7ADA XP MOTHERBOARD COMPONENTS

SDRAM

□

BC DE

QRSTU

Autres manuels pour SY-K7ADA

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SOYO Carte mère

SOYO

SOYO SY-K7V DRAGON Plus Manuel utilisateur

SOYO

SOYO SY-D6IGA Manuel d'utilisation et d'entretien

SOYO

SOYO SY-5EH5 Manuel d'utilisation et d'entretien

SOYO

SOYO SY-7IWB Manuel utilisateur

SOYO

SOYO SY-7VCA Manuel utilisateur

SOYO

SOYO SY-7IWM Manuel utilisateur

SOYO

SOYO SY-D6IBA2 Manuel utilisateur

SOYO

SOYO 6KB Manuel d'utilisation et d'entretien

SOYO

SOYO SY-7IZM Manuel d'utilisation et d'entretien

SOYO

SOYO DRAGON Lite SY-KT333 Manuel utilisateur

SOYO

SOYO SY-K7VTA PRO Manuel utilisateur

SOYO

SOYO 5ehm Manuel utilisateur

SOYO

SOYO SY-6VZA Manuel utilisateur

SOYO

SOYO SY-P4I Fire DRAGON Manuel utilisateur

SOYO

SOYO SY-P4I875P DRAGON 2 V1.0 Manuel utilisateur

SOYO

SOYO 82430 TX Manuel d'utilisation et d'entretien

SOYO

SOYO SC-6TBxE Manuel utilisateur

SOYO

SOYO SY-6BA+ Manuel utilisateur

SOYO

SOYO Super 7 SY-5EMA+ Manuel d'utilisation et d'entretien

SOYO

SOYO SY-7VMA-B Manuel utilisateur

SOYO

SOYO SY-K7VIA Manuel utilisateur

SOYO

SOYO SY-5EHM Manuel d'utilisation et d'entretien

SOYO

SOYO 486 PCI/VESA Manuel d'utilisation et d'entretien

SOYO

SOYO SY-P4X400 DRAGON Lite Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
