Instruction

Manual

(Ver. 1.01) English

COLOR CAMERA MODULE

FCB-IX47/IX47P

FCB-IX470/IX470P

FCB-IX47/IX47P

FCB-IX470/IX470P

Table of Contents

OUTLINE..................................................................................................................... 1

SPECIFICATIONS ...................................................................................................... 1

DIMENSIONS ............................................................................................................. 2

PIN ASSIGNMENT ..................................................................................................... 3

FUNCTIONS................................................................................................................ 4

CONTROL METHODS ............................................................................................... 13

INSTALLATION ......................................................................................................... 16

ECLIPSE ...................................................................................................................... 17

HANDLING PRECAUTIONS .................................................................................... 18

VIBRATIONAL SPECIFICATIONS .......................................................................... 19

INITIAL VALUE AND BACKUP .............................................................................. 20

MODE CONDITIONS ................................................................................................. 21

COMMAND LIST ....................................................................................................... 23

Table of Contents .............................................................................................. 24

VISCA™/RS-232C ............................................................................... 25

COMMAND LIST................................................................................. 34

FCB-IX47/IX47P

FCB-IX470/IX470P

OUTLINE

The FCB-IX47/P and FCB-IX470/P are color camera modules which incorporate an 18×optical zoom lens, a 4×digital zoom and

a 1/4" Super HAD CCDTM.

Including a field memory, the FCB-IX47/P and FCB-IX470/P can, in addition to normal video mode, continuously output a

frozen picture, achieve slow speed shuttering with increased sensitivity, achieve mirror inversion and allow various ‘Picture

Effects’ and ‘Digital Effects’, thanks to a newly developed Digital Signal Processor.

In the FCB-IX470/P models, the internal IR cut filter may be removed by remote control, giving IR sensitivity. A built-in IR

lighting by LED may also be added. Combined use produces a minimum sensitivity of ‘0 lx’.

All models have position preset function to save and recall up to 6 shooting conditions, and extensive control is possible via

analog and VISCA™/RS-232C, with optional on screen display.

SPECIFICATIONS

Image sensor

Picture elements

H. resolution

Lens

Digital zoom

Angle of view (H)

Min. working distance

Sync system

Min. sensitivity

S/N ratio

Back light

compensation

Electronic shutter

White balance

Gain

Aperture

Preset

Battery back-up

Video output

Storage temp./humidity

Operating temp./humidity

Power

Weight

Dimensions

(W ×H ×D) (mm)

1/4'' Super HAD CCDTM

768 (H) ×494 (V) 752 (H) ×582 (V)

more than 470 TVL more than 460 TVL

18×zoom f = 4.1 to 73.8 mm (F1.4 to F3.0)

4×(72×with optical zoom)

approx. 48°(wide end) approx. 2.7°(tele end)

10 mm (wide end) 800 mm (tele end)

Internal

FCB-IX47 FCB-IX470P

FCB-IX470 FCB-IX47P

more than 50 dB

ON/OFF

1/4 to 1/10,000 sec., 20 steps 1/3 to 1/10,000 sec., 20 steps

Auto, ATW, Indoor, Outdoor, One Push WB, Manual WB

Auto/Manual (–3 to 18 dB, 8 steps)

16 steps

6 positions

approx. 6 months (fully charged)

VBS: 1.0 Vp-p (Sync Negative) and Y/C

–20 to +60°C/20 to 95%

0 to +50°C/20 to 80%

6 to 12 Vdc/2.8 W (active motors), 4.2 W (active motors and IR LED ON)

205 g 220 g 205 g 220 g

51.2 ×57.8 ×92.4 52.3 ×58.8 ×92.4 51.2 ×57.8 ×92.4 52.3 ×58.8 ×92.4

3 lx (F1.4) 0 lx (F1.4)

IR CUT OFF

IR LED ON

0.2 lx (F1.4)

IR CUT OFF

IR LED OFF 3 lx (F1.4) 0 lx (F1.4)

IR CUT OFF

IR LED ON

0.2 lx (F1.4)

IR CUT OFF

IR LED OFF

* “Super HAD CCDTM” is a trademark of Sony Corporation.

FCB-IX47/IX47P

FCB-IX470/IX470P

DIMENSIONS

Unit: mm

FCB-IX47/IX47P

FCB-IX470/IX470P

Unit: mm

FCB-IX47/IX47P

FCB-IX470/IX470P

PIN ASSIGNMENT

DC IN (6 to 12 V)

GND

CN501 (Power)

Connector Position

FCB-IX47/IX47P FCB-IX470/IX470P

GND

C OUT

GND

Y OUT

GND

VBS OUT

CN301 (Video out)

INT

OFF

EXT

Internal battery

No backup

External battery (3.1 V)

SW (Memory backup)

BATT IN (3.1 V)

GND

CN705 (Backup)

TXD IN

DTR IN

DSR IN

RXD IN

TXD OUT

DTR OUT

DSR OUT

RXD OUT

GND

CN802

(RS-232C)

GND

KEY AD0

KEY AD1

KEY AD2

KEY AD3

KEY AD4

KEY AD5

KEY AD6

AF ON LED

DIGITAL ZOOM POS

OPTICAL ZOOM POS

CN805

(External control)

Supplied Accessories

There are five cables packed in the shipping unit carton.

Type of connectors : JST

CN501 (Power) : Camera side S2B-ZR-SM3A-TF Cable side housing ZHR-2

CN705 (Ext. battery) : Camera side S3B-ZR-SM3A-TF Cable side housing ZHR-3

CN301 (Video) : Camera side S6B-ZR-SM3A-TF Cable side housing ZHR-6

CN802 (RS-232C) : Camera side S10B-ZR-SM3A-TF Cable side housing ZHR-10

All receptacles are SZH-003T-P0.5

Type of connector : Molex

CN805 (External control) : Camera side 52689-1240 FFC (0.5 mm pitch)

CN501 CN301

TELE

CN805

FAR SW

WIDE

AF ON/OFF

NEAR CN802 CN705

CN501 CN301

TELE

CN805

FAR SW

WIDE

AF ON/OFF

NEAR CN802 CN705

IR LED IR cut filter

FCB-IX47/IX47P

FCB-IX470/IX470P

Basic/Extended Control

Basic control of the camera module functions can be done using the built-in keyboard.

In this mode, user can control zoom (fixed speed), manual focus (fixed speed), and switch AutoFocus ON/OFF.

Shutter speed is fixed 1/60s (1/50s), white balance, iris and gain are automatic.

Extended control of the camera module functions is possible by analog connections (refer to SW-JIG) and by VISCA™/

RS-232C.

Zoom

The FCB-IX47/P and FCB-IX470/P use an 18×zoom lens as well as a 4×digital zoom.

• Optical 18×, f = 4.1 to 73.8 mm (F 1.4 to F 3.0)

The horizontal angle of view is approximately 48°(wide end) to 2.7°(tele end).

The digital zoom is automatically switched ON at the tele end of 18×optical zoom range, with a progressive effect from 1 to

4, giving a total maximum 72×zoom ratio. Digital zoom increases the picture element size and reduces the resolution.

Extended control of zoom:

• Direct zoom position

• Zoom speed selection (8 speeds)

• Digital zoom can switched ON/OFF

FUNCTIONS

FCB-IX47/IX47P

FCB-IX470/IX470P

FUNCTIONS

Focus

The minimum focus distance is 10 mm at optical wide end and 800 mm at optical tele end, and is independent of digital zoom.

The AutoFocus (AF) function adjusts automatically the focus position to maximise the high frequency content of the picture

in a center measurement area, considering the high luminance and strong contrast components.

NOTE

: AVOID 24-hour continuous use of the autofocus. This may cause lens malfunction.

All of these settings are performed via RS-232C control. If not using the RS-232C, white balance, iris and gain adjustments

will be carried out automatically, and the shutter speed will be fixed at 1/60 seconds.

Extended control of focus:

• Direct focus position

• Minimum focus distance limitation

• Manual focus speed selection (8 speeds)

• AutoFocus can be set to High or Low mode

• One Push AF can be achieved in manual focus mode

• HIGH AF : High reaction speed of AF. Use this mode when shooting fast moving objects. Recommended as optimum

mode for normal NON-CONTINUOUS use.

• LOW AF : Better focus stability. In low luminance conditions, AF stops operation even when brightness changes,

enabling stable images.

White Balance

• Auto : Auto Tracing White Balance with limitations on R and B gain (3200 to 6000 K), to avoid fixing single

color scenes as ‘white’

• ATW : Auto Tracing White Balance (2000 to 10000 K)

• Indoor : 3200 K

• Outdoor : 5800 K

• One Push WB : One Push White Balance*

• Manual WB : Manual control of R and B gain, 256 steps each

* The One Push White Balance mode is a fixed white balance mode that may be automatically readjusted only on request of

the user (One Push Trigger), assuming that a white subject, in correct lighting conditions, and occupying more than 1/2 of

the image, is submitted to the camera.

Selecting the One Push White Balance mode recalls the white balance data computed at the latest One Push Trigger, if the

camera has been left in power ON state, or if the lithium backup battery has been switched ON in charged condition.

FCB-IX47/IX47P

FCB-IX470/IX470P

FUNCTIONS

Automatic Exposure Mode

This mode is set to “Full Auto” at shipment. Altogether 9 modes are available including this one.

•Full Auto : Auto Iris and Gain, Fixed Shutter (FCB-IX47/470: 1/60 sec., FCB-IX47P/470P: 1/50 sec.)

•Shutter Priority*: Variable Shutter Speed, Auto Iris and Gain

(1/4 or 1/3 to 1/10,000 sec., 20 steps, std. shutter 16 steps, slow shutter 4 steps)

•Iris Priority : Variable Iris (F1.4 to Close, 18 steps), Auto Gain and Shutter

•Gain Priority : Variable Gain (–3 dB to 18 dB, 18 steps), Auto Iris and Fixed Shutter

•Manual : Variable Shutter, Iris and Gain

•Bright : Variable Iris and Gain (Closed to F1.6, 17 steps at 0 dB: F1.4, 7 steps form 0 to 18 dB)

•Iris Auto : Variable Gain and Shutter

•Shutter Auto : Variable Iris and Gain

•Gain Auto : Variable Iris and Shutter

* Flicker can be eliminated by setting shutter to

→1/100s for NTSC models used in countries with 50 Hz power supply frequency

→1/120s for PAL models used in countries with 60 Hz power supply frequency

AE – Shutter priority

The shutter can be set freely by the user to a total of 20 steps – 16 high speeds and 4 low speeds. When the slow shutter is set,

the speed can be 1/30s (1/25s), 1/15s (1/12s), 1/8s (1/6s), 1/4s (1/3s) for NTSC (PAL) models. The picture output is read at

normal rate from the memory. The memory is updated at low rate from the CCD. AF capability is low.

In high speed mode, the shutter can be set up to 1/10000s.

The iris and gain are set automatically, according to the brightness of the subject.

10000

6000

4000

3000

2000

1500

1000

725

500

350

Data NTSC PAL

10000

6000

3500

2500

1750

1250

1000

600

425

300

250

180

125

100

Data NTSC PAL

215

150

120

100

FCB-IX47/IX47P

FCB-IX470/IX470P

AE – Iris priority

The iris can be set freely by the user to 18 steps between F1.4 and Close.

The gain and shutter are set automatically, according to the brightness of the subject.

F1.4

F1.6

F2.4

F2.8

F3.4

F4.8

F5.6

Data Setting

value

AE – Gain priority

The gain can be set freely by the user to 8 steps between –3 dB and +18 dB.

The shutter speed is fixed and the iris is set automatically, according to the brightness of the subject.

18 dB

15 dB

12 dB

9 dB

6 dB

3 dB

0 dB

–3 dB

Data Setting

value

AE – Manual

The shutter speed (20 steps), iris (18 steps) and gain (8 steps) can be set freely by the user.

F6.8

F9.6

F11

F14

F16

F19

F22

Data Setting

value

FUNCTIONS

FCB-IX47/IX47P

FCB-IX470/IX470P

AE – Bright

The bright control function adjusts both gain and iris using an internal law, according to a brightness level freely set by the

user. Exposure is controlled by gain when dark and by iris when bright.

As both gain and iris are fixed, they are used when exposing at a fixed camera sensitivity. When switching from the automatic

exposure mode or shutter priority automatic exposure mode to the bright mode, the latest state before switching is kept as start

value.

When switching from the shutter priority automatic exposure mode to the bright mode, the bright mode control can be used

while maintaining the shutter speed set in the shutter priority automatic exposure mode. When switched to the shutter priority

automatic exposure mode, automatic exposure is started at the maintained shutter speed (both iris and gain are automatic).

AE – Shutter Auto

The iris and gain are set freely by the user, and the shutter changes automatically according to the brightness of the subject.

Slow shutter is disabled.

AE – Iris Auto

The gain and shutter are set freely by the user, and the iris changes automatically according to the brightness of the subject.

AE – Gain Auto

The iris and shutter are set freely by the user, and the gain changes automatically according to the brightness of the subject.

F1.4

F1.6

F2.4

F2.8

F3.4

Data Iris Gain

18 dB

15 dB

12 dB

9 dB

6 dB

3 dB

0 dB

F4.8

F5.6

F6.8

F9.6

F11

F14

F16

F19

F22

Data Iris Gain

0 dB

FUNCTIONS

Controlled by gain

Dark Bright

Controlled by IRIS

IRIS curve

Bright limit which controllable for this unit

Gain curve

MIN

MAX

Gain

OPEN

IRIS

Autres manuels pour FCB-IX47

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Unité de contrôle

Sony

Sony HDCU2000 Manuel utilisateur

Sony

Sony HXCU-FB80 4K/HD Manuel utilisateur

Sony

Sony CCP-6224 CCP-6324 MKS-8010B MKS-8011AMKS-8013A MKS-8014A MKS-8015A MKS-8017AMKS-8018A MKS-8019A MKS-8020A... Manuel utilisateur

Sony

Sony SX-M700 Manuel utilisateur

Sony

Sony HDCU3300 HD Manuel utilisateur

Sony

Sony CCU-M5A Manuel utilisateur

Sony

Sony CCU-TX50 Manuel utilisateur

Sony

Sony HSCU300RF Manuel utilisateur

Sony

Sony FCB-CX20DP Manuel utilisateur

Sony

Sony HDCU3100 Manuel utilisateur

Sony

Sony BKNW-26 Manuel utilisateur

Sony

Sony BC05 Manuel utilisateur

Sony

Sony XC-55 Manuel utilisateur

Sony

Sony SVRM-911 Manuel utilisateur

Sony

Sony FCB-EV7100 Manuel utilisateur

Sony

Sony MVS-6000 Manuel utilisateur

Sony

Sony CBK-UPG02 Manuel utilisateur

Sony

Sony BVE-700 Manuel utilisateur

Sony

Sony CCU-550A Manuel utilisateur

Sony

Sony DSBK-1501 Manuel utilisateur

Sony

Sony DCU-8000 Manuel utilisateur

Sony

Sony BVE-700 Manuel utilisateur

Sony

Sony BKM-17R Manuel utilisateur

Sony

Sony FCB-EV7300 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

Flyron

Flyron FN-BC04 Manuel utilisateur
