INSTALLATION MANUAL

1st Edition

RGB SQ PROCESSOR BOARD

HKSR-5803SQ

ADVANCED HQ PROCESSOR BOARD

HKSR-5803HQ

HKSR-5803SQ/5803HQ

!WARNING

This manual is intended for qualified service personnel only.

To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so. Refer all servicing to

qualified service personnel.

!WARNUNG

Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

1-1 (E)

HKSR-5803SQ/5803HQ

Section 1

Installation

Purpose of this manual

This manual is an installation manual of RGB SQ Proces-

sor Board HKSR-5803SQ and Advanced HQ Processor

Board HKSR-5803HQ.

This manual is intended for system and service engineers,

so describes information regarding installation.

Related manual

Besides this installation manual, the following manual is

available for HKSR-5803SQ and HKSR-5803HQ.

.Maintenance Manual (available on request)

This manual describes the information for the mainte-

nance of this unit and the information that premises the

parts level service.

If this information is required, please contact your local

Sony Sales Office/Service Center.

1-1. Specifications

General

HKSR-5803SQ

Dimensions (w/h)

SQ-20 Board: 155 x90 mm

Mass SQ-20 Board: approx. 70 g

Power requirements +3.3 V dc: 840 mA

+1.5 V dc: 1800 mA

Power consumption approx. 5.5 W

HKSR-5803HQ

Dimensions (w/h)

DLP-27 Board: 155 x90 mm

Mass DLP-27 Board: approx. 70 g

Power requirements +3.3 V dc 850 mA

+1.5 V dc: 1800 mA

Power consumption approx. 5.5 W

1-2. Installation Overview

Components

HKSR-5803SQ is composed of the following items:

.SQ-20 Board

.Hexagonal support 7 mm (4 pcs)

.PSW2.6 x5.8 (8 pcs)

.Installation manual

HKSR-5803HQ is composed of the following items:

.DLP-27 Board

.Hexagonal support 7 mm (4 pcs)

.PSW2.6 x5.8 (8 pcs)

.Installation manual

Applicable models

SRW-5800

Installations of HKSR-5803SQ or HKSR-5803HQ

The HKSR-5803SQ comprises the SQ-20 board.

Mount the SQ-20 board on the HPR-22 board.

The HKSR-5803HQ comprises the DLP-27 board.

Mount the DLP-27 board on the HPR-22 board.

Attach and adjust the HKSR-5803SQ or HKSR-5803HQ

properly, following the procedures in Section 1-3 and later.

1-2 (E) HKSR-5803SQ/5803HQ

1-3. Installation Procedure

1. Turn off the power of the VTR.

2. Fully loosen the two fixing screws, and then slide the

two knobs on the upper lid (front) assembly each to the

inside. (Move the knobs to the outside to fix the upper

lid (front) assembly.)

3. Remove the upper lid (front) assembly in the arrow

direction.

Knob

Upper lid (front) assembly

Fixing screw

Removal

Installation

4. Fully loosen the two fixing screws, and then remove

the upper lid (rear) assembly in the arrow direction.

5. Raise the eject levers of the HPR-22 board in the

arrow direction, and then pull out the board slowly

upward.

Fixing screw

Upper lid (rear)

assembly

Protrusion

Square hole

Fixing screw

HPR-22 board

Eject lever

1-3 (E)

HKSR-5803SQ/5803HQ

HPR-22 board

SQ-20 board

DLP-27 board

PSW2.6 x5.8

(Supplied accessory)

PSW2.6 x5.8

(Supplied

accessory)

PSW2.6 x5.8

(Supplied

accessory)

PSW2.6 x5.8

(Supplied

accessory)

Hexagonal

supports (7 mm)

(Supplied

accessory)

Hexagonal

supports (7 mm)

(Supplied

accessory)

HPR-22 board

PSW

2.6 x6

PSW

2.6 x6

PSW2.6 x6

Shield plate

6. Remove the six screws to detach the shield plate from

the HPR-22 board.

7. Attach four 7 mm hexagonal supports (accessory) to

the HPR-22 board with four screws (accessory).

8. Connect the SQ-20 board or DLP-27 board to the

HPR-22 board and secure it with four screws (accesso-

ry).

Shield plate

HPR-22 board PSW2.6 x6

PSW

2.6 x6

PSW

2.6 x6

9. Reattach the shield plate to the HIF-22 board with six

screws.

1-4 (E) HKSR-5803SQ/5803HQ

EXIT

OPTION BOARD INFORMATION

HKSR-5001 Board –––––––––

HKSR-5802 Board –––––––––

HKSR-5803 Board

INSTALLED (SQ)

OPTION INFO

FUNC

INFO

DIAG

ALT F5 F6 F7 F8 F9 F10

DIAG

ALT F5 F6 F7 F8 F9 F10

ROM

VER

ERR

LOG

OPTION

INF MAINTE

EXEC EXIT

OPERATION 1105HOURS[ 1105H]

DRUM RUNNING

238HOURS[

238H]

TAPE HOURS

153HOURS[

153H]

THREADING 4048TIMES[

4048T]

MAINTENANCE INFORMATION DISPLAY

1-4. Confirming Identification of

Optional Board

Confirmation Procedure

1. On the HOME menu, press the DIAG button while

pressing the [SFT] (shift) key.

The MAINTENANCE INFORMATION menu

appears.

2. Press [F5] (OPTION INF).

The OPTION INFORMATION menu appears.

3. Check that “INSTALLED (SQ)” (HKSR-5803SQ) or

“INSTALLED (HQ)” (HKSR-5803HQ) is displayed

for the HKSR-5803 board.

For more information on the maintenance mode, refer to

Section 3 of the VTR Maintenance Manual Volume 1.

HPR-22 board

Eject lever

APR

HPR-22 board

DVP

HIF

HPR

10. Securely insert the HPR-22 board into the “HPR” slot

to tightly connect the board to the connector on the

motherboard, while pressing down the two eject

levers.

HKSR-5803SQ/5803HQ

The material contained in this manual consists of

information that is the property of Sony Corporation.

Sony Corporation expressly prohibits the duplication of

any portion of this manual or the use thereof for any

purpose other than the operation or maintenance of the

equipment described in this manual without the express

written permission of Sony Corporation.

Le matériel contenu dans ce manuel consiste en

informations qui sont la propriétéde Sony Corporation.

Sony Corporation interdit formellement la copie de

quelque partie que ce soit de ce manuel ou son emploi

pour tout autre but que des opérations ou entretiens de

l’équipement àmoins d’une permission écrite de Sony

Corporation.

Das in dieser Anleitung enthaltene Material besteht aus

Informationen, die Eigentum der Sony Corporation sind.

Die Sony Corporation untersagt ausdrücklich die

Vervielfältigung jeglicher Teile dieser Anleitung oder den

Gebrauch derselben für irgendeinen anderen Zweck als

die Bedienung oder Wartung der in dieser Anleitung

beschriebenen Ausrüstung ohne ausdrückliche

schriftliche Erlaubnis der Sony Corporation.

Printed in Japan

Sony Corporation 2007. 10 08

HKSR-5803SQ (SY)

HKSR-5803HQ (SY) J, E

3-286-478-01
