Telis®1 Chronis RTS

Included:

A. Telis 1 Chronis RTS

B. Wall mount with screw cover

C. Screw kit

D. 2 -LR03 AAA batteries

Part Number:

1811243

The Telis 1 Chronis RTS remote control and timer provides control of a single or a group

of window coverings in the same room. The Telis 1 Chronis RTS can be used in manual

or automatic mode. Manual mode controls the window coverings paired with the

remote control. Automatic mode allows you to control window coverings paired with

the remote control, using preprogrammed factory settings. Operators can customize

the daily and weekly schedules in the “work” program.

Caution: To avoid damaging the product:

1. Do not drop or strike.

2. Keep away from moisture and liquid.

3. Do not clean with abrasive cleaning products or solvents. Only use a soft, damp cloth.

4. Keep out of the reach of children.

2 x LR03

AAA 1.5v Batteries

page 1 of 8

Introduction

E. Red indicator light

F. Selection button

G. Arrow buttons

H. Up/Switch On/Open/Retract

window coverings

I. “my” button

Stop/Go to favorite “my” position

J. Down/Switch O/Close/Extend

window coverings

K. Programming (PROG) button

L. Battery compartment cover

LCD Screen M. Automatic mode indicator

N. Current time

O. Set mode active: SET

P. Low battery symbol

Q. Days of the week (work or daily/rest or weekend

programming is not displayed in daily programming):

Mo = Monday, Tu = Tuesday, We = Wednesday,

Th = Thursday, Fr = Friday, Sa = Saturday, Su = Sunday

R. Programmed automatic commands (Time 1 and Time 2)

S. Time selected for executing command in automatic mode.

In manual mode, “OFF” is displayed

T. or commands

page 2 of 8

Battery Installation

Wall Mount

1. Select a location for the wall mount.

2. Mark the screw locations (vertical spacing: 40 mm).

3. Attach the wall mount with the included screws

(use anchors if required).

Note: The use of digitally connected appliances

(e.g. Hi-Fi radio headphones) operating on the same

frequency may cause interference and reduce

product performance.

1. Remove the battery cover on back of remote control.

2. Insert 2 AAA (LR3) batteries as indicated inside the compartment.

3. Replace the battery cover.

Replace the batteries when the battery symbol (U) appears on

the display.

Note: If there is no power supply for an extended time

(batteries are depleted or removed), the settings of the

remote control transmitter will need to be reprogrammed.

However, the automatic orders are saved in memory.

Never use rechargeable batteries.

Caution: Never install the Telis 1 Chronis RTS

on or near metal surfaces as this may reduce

the signal range.

page 3 of 8

Programming the remote control

After battery installation, remote control automatically opens the

settings mode, starting with “Year” ﬂashing on the screen. If there is

no power supply for an extended time (batteries are depleted or

removed) selecting automatic mode will activate the “settings” mode.

Settings mode follows this order:

Figure A

1. “YEAR” (current year)

2. “MONTH” (number of the current month)

3. “DAY” (number of the current day)

4. “TIME” (current hour)

5. “TIME” (minutes)

6. “AREA” (country of residence)*

7. “WORK” (daily/weekend)**

Press the arrow buttons (G) to modify settings

(press and hold the button to scroll through the list faster).

To save a setting and move to the next, brieﬂy press the selection

button (F).

Exit the settings mode any time by pressing and holding the

selection button (F). Saved settings will remain.

* “AREA” (country of residence)

Note: The Telis 1 Chronis RTS is pre-programmed at the factory to

automatically switch between summer and winter conditions based

on the country of residence. Select the location of residence such as

the United States (US). Select “OFF” to deactivate automatic time

change functions (daylight savings) and make the change manually.

** “WORK” (daily/weekend)

1. Select the workdays you want to program using the

arrow buttons (G).

2. Brieﬂy press the selection button (F) to conﬁrm the setting; by

default, the days not circled will be vacation or weekend days.

Exit the settings mode any time by pressing and holding the selection

button (F). Saved settings will remain.

Figure A

KPROG

Program

button on

back

Set-Up

The Telis 1 Chronis RTS screen switches automatically to sleep mode after two minutes of inactivity.

When the screen is o or in sleep mode, press any button to turn it on. When editing settings, pressing and

holding the selection button (F) allows you to return to manual or automatic mode.

Only saved settings are retained.

Programming

Continued On Next Page

page 4 of 8

Figure B

Telis 1 Chronis RTS

Programming the days of the week

In automatic mode, the Telis 1 Chronis RTS sends automatic commands to one or more window coverings for

each day of the week.

These automatic commands include:

• The same settings for every day of the week (factory setting).

• Settings divided into two groups of days - workday and weekend. Five workdays have the same

operating times each day. The two weekend or rest days operate on the same schedule, which diers

from the workday schedule.

The preset mode can be deactivated at any time by pressing and holding the selection button (F).

Saved settings will remain.

Modify presets:

• To set the current time for window covering operation, see section “Quick setting of an

automatic command”.

• To set a speciﬁc time for window covering operation, see

section “Editing an automatic order”.

Quick setting of an automatic command

1. Using the selection button (F), switch to automatic mode.

2. Press the arrow keys (G) to navigate to the open or close setting

you wish to edit (settings for all days or for groups of days if work

or weekend days have been conﬁgured).

3. Press and hold the Up and Down buttons (H/J) for more than

10 seconds the open or close function to modify a command. “SET”

is displayed on the screen, and the order ﬂashes 3 times. Release the

button when “SET” disappears from the screen. The desired open or

close operation will occur at that time automatically.

• To quickly store another automatic order, repeat the procedure

starting at step 1.

Programming Continued

page 5 of 8

Pairing or Deleting a Window Covering to another

RTS Transmitter - Figure B

Pairing or Deleting a window covering is performed in manual mode.

1. Press and hold the PROG button on the window covering control

unit until the window covering moves up and down or jogs. The

programming mode is active for 2 minutes.

2. Press the (PROG) programming button (K) on the Telis 1 Chronis

remote control. The window covering moves up and down or jogs

and is assigned to or deleted from the Telis 1 Chronis remote.

The procedure for pairing or deleting a window covering to the Telis 1

Chronis RTS is the same. It is done only in manual mode.

1. Press and hold the PROG button on the window covering control

unit until the window covering jogs. The programming mode is active

for 2 minutes.

2. Press the (PROG) programming button (K) on the Telis 1 Chronis

remote control. The window covering moves or jogs and is assigned

to or deleted from the Telis 1 Chronis remote.

Continued On Next Page

Programming Continued

Deleting an automatic command

1. Using the selection button (F), switch to automatic mode.

2. Press the arrow keys (G) to select the open or close order that you

wish to edit (settings for all days or for groups of days if work or weekend

days have been conﬁgured).

3. Press and hold the selection button (F) until "SET" appears on the

screen: "Automatic command programming" mode is activated

and "EDIT" ﬂashes.

4. Press one of the arrow buttons (G) to change menu until

"Delete" ﬂashes.

5. Brieﬂy press the selection button (F) to conﬁrm the deletion.

Exit "EDIT" mode and return to automatic mode.

• To delete another automatic command, repeat steps 1-5.

page 6 of 8

Continued On Next Page

Figure C

F11:00

07:30 G

yEAR

2021

7 Sec.

Setting the general parameters

of the remote control

transmitter,refer back to

section 4.

Modifying the general settings of the Telis 1 Chronis remote control

Figure C

1. Using the selection button (F), switch to automatic mode.

2. Press and hold the selection button (F) until "SET" and "YEAR" appear on the screen. The

"settings” mode is activated. The year ﬂashes. This is the ﬁrst setting to program.

3. Follow the steps in the section “Programming the remote control”.

Operation

To activate or deactivate the function:

Figure D

1. Using the selection button (F), switch to automatic mode.

2. Press both arrow buttons (G) simultaneously. The ( ) symbol appears on the screen. The

"simulated presence" function is activated.

3. Press both arrow buttons (G) simultaneously. The ( ) symbol disappears from the screen. The

"simulated presence" function is deactivated.

Figure D

F11:00

07:30 G

EDIT

20 :00

14:00

20:12

To switch from manual to automatic mode or from automatic to manual mode,

brieﬂy press the selection button (F).

Manual mode

The manual mode of the Telis 1 Chronis RTS is used to:

• Send an occasional order to the window coverings.

• Deactivate automatic command programming.

Manual control

Brieﬂy press the Up, “my” or Down button corresponding to the desired function.

Automatic mode

The automatic mode of the Telis 1 Chronis RTS is used to:

• Automatically control the window covering, using programmed settings for times or days of the week.

Example of programming for a day: at 6:45 AM, up command to open all products on the ground ﬂoor to

take advantage of the sunlight; at 8:00 PM, a down command for all the end-products to protect

the house from the cold.

• Programming automatic commands for each day of the week

(see section “Programming the days of the week”).

• In automatic mode, the current time and the next scheduled automatic command are displayed.

• To view all the automatic commands programmed, scroll from one command to the next using the

arrow buttons (G).

• To stop an automatic command that is currently being executed, press the Stop/my button.

You can also press the Up, “my” or Down buttons in automatic mode.

page 7 of 8

Simulated presence function

In automatic mode, the “Simulated Presence” or “Vacation Mode” function randomly changes the times

preprogrammed window covering operations occur. By varying the closure or opening of window coverings

by 0 to 30 minutes, it simulates your presence in the home while on vacation.

Note: Exit the settings mode any time by pressing and holding

the selection button (F). Saved settings will remain.

Troubleshooting

Observation

The window covering does

not react at all when a button

on the Telis 1 Chronis RTS

is pressed.

A window covering stops

during activation.

The command is being sent at a

dierent time than the

programmed time.

One or more window coverings

systematically does not respond

to a programmed automatic

command.

Possible Causes

The batteries are low.

The remote control

transmitter is not

programmed.

External radio equipment

is interfering with the

radio reception.

The motor(s) or receiver(s)

are in thermal shut-o

mode.

The window covering has

encountered an obstacle.

Another control device is

sending a command to

the motor or receiver

The "Simulated presence"

function is activated.

A signal from another

automatic device in your

home is causing interference.

Solution

Replace the batteries.

See section "Adding/ deleting

a Telis 1 Chronis RTS".

Turn o any nearby radio

appliances.

Wait for the motor to cool

down, then press the desired

button again.

Remove the obstacle

and try again.

Wait until activation of the

window covering has ﬁnished,

then try again.

Deactivate "Simulated presence"

function.

Change the programmed time

of the automatic command.

This device is FCC certiﬁed and complies with part 15 of the FCC rules.

RTS compatibility: RTS transmitters are capable of operating any RTS motor.

page 8 of 8

BATTERY RECYCLING OR DISPOSAL

Discard batteries and electrical components

following local codes or regulations. Recycle

batteries and electrical components with

designated electronic recycle centers.

Note: Visit https://store.somfysystems.com/ to

purchase an additional or replacement product.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SOMFY Télécommande

SOMFY

SOMFY Telis 4 Soliris RTS Manuel utilisateur

SOMFY

SOMFY Terminal 3600 W Manuel utilisateur

SOMFY

SOMFY Telis 4 Soliris RTS Manuel utilisateur

SOMFY

SOMFY Rollixo Optimo RTS Manuel utilisateur

SOMFY

SOMFY Telis Soliris RTS Manuel utilisateur

SOMFY

SOMFY KEYTIS INTERIOR Manuel utilisateur

SOMFY

SOMFY Situo 1 RTS Manuel utilisateur

SOMFY

SOMFY INTEO TELIS 1 RTS Manuel utilisateur

SOMFY

SOMFY Telis 1 Lounge Manuel utilisateur

SOMFY

SOMFY Telis 16 RTS Manuel utilisateur

SOMFY

SOMFY nina Manuel utilisateur

SOMFY

SOMFY Telis 1 io Manuel utilisateur

SOMFY

SOMFY Telis 1 RTS Pure Manuel utilisateur

SOMFY

SOMFY SITUO 1 VARIATION Manuel utilisateur

SOMFY

SOMFY Situo 1 io Manuel utilisateur

SOMFY

SOMFY INTEO TELIS 1 RTS Manuel utilisateur

SOMFY

SOMFY Telis 5 Modulis RTS Silver 1810663 Manuel utilisateur

SOMFY

SOMFY KEYGO Manuel utilisateur

SOMFY

SOMFY Situo 1 io Manuel utilisateur

SOMFY

SOMFY 5014984 Manuel utilisateur

SOMFY

SOMFY CENTRALIS RECEIVER Manuel utilisateur

SOMFY

SOMFY Harmoic Design System II Manuel utilisateur

SOMFY

SOMFY Telis 6 Chronis RTS Guide d'installation

SOMFY

SOMFY Telis 6 Chronis RTS Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
