SOLTEK SL-75KIV Manuel utilisateur

SL-75KIV

USER MANUAL V1.2

• AMD Athlon ThunderbirdTM, and DuronTM processors are trademarks of AMD Corporation.

• VIA, KT- 33A, VT8363A and VT82C686B are trademarks of VIA Corporation.

NOTICE

his Users’ Guide & Technical Reference is to help system

manufacturers and end-users set up and install the mainboard.

Every effort has been made to ensure that the information in this

manual is accurate. Soltek Computer Inc. is not responsible for print-

ing or clerical errors. Information in this document is subject to

change without notice and does not represent a commitment on the

part of Soltek Computer Inc.

No part of this manual may be reproduced, transmitted, translated

into any language in any form or by any means, electronic or

mechanical, including photocopying and recording, for any purpose

without the express written permission of Soltek Computer Inc.

Companies and products mentioned in this manual are for identifi-

cation purpose only. Product names appearing in this manual may

or may not be registered trademarks or copyrights of their respec-

tive companies.

Soltek Computer inc. Provides this manual “As is “ without war-

ranty of any kind, either express or implied, including but not limited

to the implied warranties or conditions of merchantability or fitness

for a particular purpose. In no event shall Soltek Computer inc. be

liable for any loss or profits, loss of business, loss of use or data,

interruption of business, or for indirect, special, incidental, or con-

sequential damages of any kind, even if Soltek Computer inc. has

been advised of the possibility of such damages arising from any

defect or error in this manual or product.

Product Model : SL-75KIV

Manual Revision : V1.2

Release Date : Jul 2001

SOLTEK AROUND THE WORLD

SOLTEK COMPUTER INC.

Address : 7F, No. 306-3, Ta-Tung Rd, Sec. , Hsi-Chih, Taipei-

Hsien, Taiwan, R.O.C.

Telephone : 886-2-2642-9060

Fax : 886-2-2642-9065

E-mail : [email protected]

Web site : http://www.soltek.com.tw

SOUL TECHNOLOGY EUROPE B.V.

Address : Sydneystraat 52-54 3047 BP Rotterdam, the Nether-

lands

Telephone : 3 - 0-2457492

Fax : 3 - 0-2457493

E-mail : [email protected]

Web site : http://www.soultech-europe.com

75KIV

C O N T E N T

CHAPTER 1 INTRODUCTION .................................... 8

- MAINBOARD SPECIFICATION .................................................... 9

- - PROCESSOR ..................................................................................... 9

- -2 CHIPSET ............................................................................................. 9

- -3 ADVANCED HIGH PERFORMANCE DRAM CONTROLLER............. 9

- -4 FULL FEATURED ACCELERATED GRAPHICS PORTS (AGP)

CONTROLLER .................................................................................... 9

- -5 MULTI-I/O FUNCTION ........................................................................ 9

- -6 EXPANSION SLOTS ......................................................................... 0

- -7 AWARD BIOS V6.0, SUPPORTING ................................................. 0

- -8 SOUND CONTROLLER .................................................................... 0

- -9 POWER MANAGEMENT .................................................................. 0

- - 0 FORM FACTOR ..............................................................................

- - HARDWARE MONITORING ...........................................................

- - 2 OTHERS .........................................................................................

-2 MOTHERBOARD LAYOUT --- 75KIV ......................................... 2

-3 CHIPSET DIAGRAM--- 75KIV .................................................... 3

CHAPTER 2 HARDWARE SETUP............................ 15

2- CPU INSTALLATION .................................................................. 6

2-2 MEMORY INSTALLATION .......................................................... 8

2-3 HDD/FDD INSTALLATION .......................................................... 9

2-4 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE... 2

2-4- INFORMATION ON AMD SOCKET 462 PROCESSOR ................... 2

2-4-2 CPU EXTERNAL FREQUENCY SETTING (BY SW ) ...................... 22

2-4-3 PROCESSOR CORE VOLTAGE SELECT (BY SW2 DIP -DIP6) .... 23

2-4-4 FREQUENCY RATIO SELECT (BY SW3 DIP -DIP5) ...................... 24

2-5 JUMPER SETTING FOR DEVICES ON BOARD: ...................... 25

2-5- JUMPER JBAT FOR CLEARING CMOS DATA: ............................. 25

Content

2-5-2 USB SELECT (BY JP 3/JP 5) ....................................................... 26

2-5-3 USB2 HEADER SELECT (BY JP 2/JP 4) ...................................... 26

2-5-4 USB WAKE UP (BY JUSB ) ............................................................. 27

2-5-5 ONBOARD AC97 CODEC SELECT (BY JCOD ) ............................ 27

2-6 CONNECTORS CONFIGURATIONS ......................................... 28

2-6- ONBOARD FAN CONNECTOR (FAN /FAN2/FAN3)........................ 28

2-6-2 WAKE ON LAN (WOL ) .................................................................... 29

2-6-3 CD-ROM AUDIO CONNECTOR (CD-IN /CD-IN2) ........................... 29

2-6-4 THERMAL SENSOR CONNECTOR (RT2) ....................................... 30

2-6-5 COMPLEX HEADER J2&J3 ............................................................. 3

2-6-6 CHASSIS PANEL CONNECTOR ..................................................... 32

2-6-7 ATX POWER SUPPLY CONNECTOR ............................................. 33

2-6-8 PS/2 MOUSE AND PS/2 KEYBOARD ............................................. 33

2-6-9 COMMUNICATION AND NETWORKING RISER SLOT (CNR) ........ 34

2-6- 0 SECOND USB HEADER (USB2) .................................................... 35

2-6- IRQS DESCRIPTION FOR VARIOUS DEVICES ............................ 36

CHAPTER 3 SOFTWARE SETUP ............................ 38

ABOUT SUPPORT CD ..................................................................... 38

3- VIA CHIPSET DRIVER INSTALLATION (4-IN- DRIVER) ......... 39

3-2 AC97 AUDIO CODEC DRIVER INSTALLATION ........................ 42

3-3 HARDWARE MONITOR INSTALLATION ................................... 44

CHAPTER 4 BIOS SETUP ........................................ 47

THE BIOS ......................................................................................... 47

4- WHAT IS BIOS SETUP ............................................................... 48

4-2 HOW TO RUN BIOS SETUP ...................................................... 48

4-3 WHAT IS CMOS ......................................................................... 48

4-4 WHAT IS POST .......................................................................... 48

4-5 BIOS UPGRADE......................................................................... 48

4-5- BEFORE UPGRADING BIOS ........................................................... 49

4-5-2 UPGRADE PROCESS ...................................................................... 49

75KIV

4-6 BIOS SETUP--- CMOS SETUP UTILITY.................................... 53

4-6- STANDARD CMOS SETUP .............................................................. 54

4-6-2 ADVANCED BIOS FEATURES ......................................................... 57

4-6-3 ADVANCED CHIPSET FEATURES .................................................. 62

4-6-4 INTEGRATED PERIPHERALS ......................................................... 67

4-6-5 POWER MANAGEMENT SETUP ..................................................... 7

4-6-6 PNP / PCI CONFIGURATION ........................................................... 78

4-6-7 SMARTDOC ANTI-BURN SHIELD ................................................... 82

4-6-8 FREQUENCY/VOLTAGE CONTROL ................................................ 85

4-6-9 LOAD OPTIMIZED DEFAULTS......................................................... 86

4-6- 0 SET SUPERVISOR / USER PASSWORD ...................................... 88

4-6- SAVE & EXIT SETUP ...................................................................... 89

4-6- 2 EXIT WITHOUT SAVING ................................................................ 89

APPENDICES ................................................................. 91

APPENDICES- TECHNICAL TERMS INTRODUCTION ............... 92

APPENDICES-2 IDENTIFYING BIOS VERSION AND BIOS PART

NUMBER............................................................... 93

APPENDICES-3 IDENTIFYING MAINBOARD \ MODEL NUMBER .. 95

Content

Motherboard

Support CD

User’s Manual

Bundled Bonus Pack CD

Bundled Bonus Pack Manual

Temperature Sensor Cable

ATA66/ 00 IDE Cable

RS232 Cable

FDD Cable

ITEMLIST CHECKUP

75KIV

CHAPTER 1

INTRODUCTION

• This chapter briefly introduces the characteristics of this mainboard. It

includes the information regarding the chipset, CPU types, built-in

functions and layout. Users will have more ideas about mainboards after

reading this chapter.

NJN=MAINBOARD SPECIFICATION

NJO=MAINBOARD LAYOUT

NJP=CHIPSET DIAGRAM

THIS CHAPTER CONTAINS THE FOLLOWING TOPICS :

Chapter 1 Introduction

1-1 MAINBOARD SPECIFICATION

1-1-1 PROCESSOR

• Supporting AMD Athlon Thunderbird processors up to .5GHz.

• Supporting AMD Athlon Duron processors up to .2GHz.

• Supporting AMD Athlon4 processors.

• Supporting processor VID (voltage ID) and FID (frequency ID) auto detection.

• Supporting AMD Athlon processor with 200 and 266MHz Front Side bus.

1-1-2 CHIPSET

• North Bridge VIA VT8363A (KT- 33A) system controller High Performance

Athlon CPU Interface.

• South Bridge VIA VT82C686B.

1-1-3 ADVANCED HIGH PERFORMANCE DRAM

CONTROLLER

• Supporting PC 33 and PC 00 SDRAM and Virtual Channel Memory (VCM)

SDRAM up to 3 DIMMs.

• 64-bit data width and 3.3V DRAM interface.

• Supporting up to .5 GB memory space.

• Supporting Different DRAM types used in mixed combinations.

• PCI-2.2 compliant, 32 bit 3.3V PCI interface with 5V tolerant inputs.

1-1-4 FULL FEATURED ACCELERATED GRAPHICS PORTS

(AGP) CONTROLLER

• Synchronous and pseudo-synchronous with the host CPU bus with optimal

skew control PCI AGP Mode 33MHz/66MHz/ 00MHz DDR 3x synchronous.

• Supporting 66MHz x, 2x and 4x modes for AD and SBA signaling.

• AGP v2.0 compliant.

1-1-5 MULTI-I/O FUNCTION

• Two UARTs for complete Serial Ports.

• One dedicated IR connector supporting:

--A third serial port dedicated to IR function either through the two complete serial

ports or the third delicated port Infrared-IrDA (HPSIR) and ASK( Amplitude Shift

Keyed) IR.

75KIV

• Multi-mode parallel connector supporting:

--Standard mode, ECP and EPP.

• Floppy Disk connector supporting:

--Two FDDs with drive swap function.

• Universal Serial Bus connector supporting:

--USB v . and Intel Universal HCI v . compatible.

--2 built-in USB connectors, in addition to one internal USB header which requires

a USB cable to support 2 more optional USB ports.

• PS/2 keyboard connector.

• PS/2 Mouse connector.

1-1-6 EXPANSION SLOTS

• Three PCI bus Master slots.

• One CNR slot.

• One AGP 4x mode slot.

• Three DIMM slots.

1-1-7 AWARD BIOS V6.0, SUPPORTING

• Plug & Play V .0.

• Flash Memory for easy upgrade.

• Year 2000 compliant.

• BIOS writing protection.

• SMARTDOC ANTI-BURN SHIELD.

• RedStorm Overclocking Tech.

1-1-8 SOUND CONTROLLER

• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio

Controller with Codec onboard.

1-1-9 POWER MANAGEMENT

• ACPI .0 compliant (Advanced Configuration and Power Interface).

• APM V .2 compliant (Advanced power management).

• Supporting ACPI suspend STR mode (Suspend To RAM) and POS mode

(Power On Suspend).

• Supporting Wake On LAN (WOL) & Wake On Modem.

• Supporting real time clock (RTC) with date alarm, month alarm, and cen

Table des matières

Autres manuels SOLTEK Carte mère

SOLTEK

SOLTEK SL-63AV Manuel utilisateur

SOLTEK

SOLTEK SL-XP865G-3IG Manuel utilisateur

SOLTEK

SOLTEK SL-65FVB Manuel utilisateur

SOLTEK

SOLTEK SL-75DRV3/75DRV3+ Manuel utilisateur

SOLTEK

SOLTEK SL-85DIR3 Manuel utilisateur

SOLTEK

SOLTEK SL-85LIR Manuel utilisateur

SOLTEK

SOLTEK 85MR3 Manuel utilisateur

SOLTEK

SOLTEK SL-65LIV-T Manuel utilisateur

SOLTEK

SOLTEK SL-65ME-T Manuel utilisateur

SOLTEK

SOLTEK B9A-FGR Manuel utilisateur

SOLTEK

SOLTEK SL-52D2 Manuel utilisateur

SOLTEK

SOLTEK SL-85LIR3 Manuel utilisateur

SOLTEK

SOLTEK KT333A Manuel utilisateur

SOLTEK

SOLTEK SL-65GS Manuel utilisateur

SOLTEK

SOLTEK SL-PM800I-R Manuel utilisateur

SOLTEK

SOLTEK SL-67EB Plus Manuel utilisateur

SOLTEK

SOLTEK SL-85DRV3 Manuel utilisateur

SOLTEK

SOLTEK SL-85SID Manuel utilisateur

SOLTEK

SOLTEK SL-85DIV Manuel utilisateur

SOLTEK

SOLTEK SL-65MIE Manuel utilisateur

SOLTEK

SOLTEK NV400-64 Manuel utilisateur

SOLTEK

SOLTEK SL-PM800I Manuel utilisateur

SOLTEK

SOLTEK SL-65LIV Manuel utilisateur

SOLTEK

SOLTEK SL-63AV Manuel d'utilisation et d'entretien

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
