SnowEx SP-325 Mode d'emploi

This document supersedes all editions with an earlier date.

September 15, 2014

Lit. No. 43826, Rev. 01

SP-325, SP-575X and SP-1075X

Tailgate Spreaders

Owner's Manual and Installation Instructions

Original Instructions

This Parts List is for SnowEx single-stage tailgate spreaders with

serial numbers 140502300135 and higher (Model SP-325), 140718300683 and higher (Model SP-575X) and

140722300276 and higher (Model SP-1075X).

CAUTION

Read this manual before installing or

operating the spreader.

Lit. No. 43826, Rev. 01 3 September 15, 2014

TABLE OF CONTENTS

PREFACE....................................................................4

OWNER'S INFORMATION FORM.............................4

SAFETY INFORMATION............................................5

LOADING....................................................................9

Material Weights...................................................9

Certiﬁcation...........................................................9

Determining Vehicle Payload..............................10

MOUNTING THE SPREADER ................................. 11

Receiver Hitch Mount Installation ....................... 11

License Plate Installation....................................12

INSTALL ELECTRICAL HARNESSES....................13

HARNESS & CONTROL DIAGRAMS .....................15

OPERATING THE SPREADER................................17

Starting and Stopping Motor...............................17

Adjusting Spinner Speed ....................................17

Alarm Codes.......................................................18

Spreading Tips....................................................18

MAINTENANCE........................................................19

Lubrication ..........................................................19

After Each Use....................................................19

At the End of Each Season or after

Extended Storage............................................19

Storage ...............................................................19

TROUBLESHOOTING..............................................20

Lit. No. 43826, Rev. 01 4 September 15, 2014

PREFACE

This manual has been prepared to acquaint you with

the safety information, operation and maintenance of

your new tailgate spreader. Please read this manual

carefully and follow all recommendations. This will

help ensure proﬁtable and trouble-free operation of

your spreader. Keep this manual accessible. It is a

handy reference in case minor service is required.

When service is necessary, bring your spreader to

your distributor. They know your spreader best and are

interested in your complete satisfaction.

NOTE: This spreader is designed to spread

snow and ice control materials only. Do not use

it for purposes other than those speciﬁed in

this manual.

Warranty Registration

Follow the directions on the SnowEx Warranty

Registration and Customer Survey form included in

the spreader literature kit.

The registration form is also available online at

www.snowexproducts.com. Under "Product Info"

select "SnowEx Warranty" and click to download the

form.

OWNER'S INFORMATION

Owner's Name: ______________________________________________________________________

Date Purchased: _____________________________________________________________________

Distributor Name: __________________________________________ Phone:_________________

Distributor Address:___________________________________________________________________

Vehicle Model:_____________________________________________ Year: __________________

Spreader Model: _________________________ Serial #:__________________________________

Spreader Weight:_____________________lb/kg

Lit. No. 43826, Rev. 01 5 September 15, 2014

SAFETY DEFINITIONS

NOTE: Indicates a situation or action that can lead

to damage to your spreader and vehicle or other

property. Other useful information can also be

described.

SAFETY INFORMATION

WARNING/CAUTION LABELS

Please become familiar with the Warning and Caution

labels on the spreader.

NOTE: If labels are missing or cannot be read, see

your sales outlet.

CAUTION

Indicates a potentially hazardous situation

that, if not avoided, may result in minor or

moderate injury. It may also be used to alert

against unsafe practices.

WARNING

Indicates a potentially hazardous situation

that, if not avoided, could result in death or

serious personal injury.

Model SP-1075X Only

Model SP-325 Only

Lit. No. 43826, Rev. 01 6 September 15, 2014

SERIAL NUMBER LABEL

Model No. SP0000

Serial No. 000000000000SP0000

Manuf. 2014

Madison Heights, MI 48071 U.S.A.

1-800-725-8377 trynexfactory.com

Code Deﬁnition

YY 2-Digit Year

MM 2-Digit Month

DD 2-Digit Day

LL 2-Digit Location Code

XXXX 4-Digit Sequential Number

ZZZZZZ Assembly Part Number

Model No. SP0000E

Manuf. 2014

Madison Heights, MI 48071 U.S.A.

1-800-725-8377 trynexfactory.com

Serial No. YYMMDDLLXXXXZZZZZZ

SAFETY INFORMATION

Lit. No. 43826, Rev. 01 7 September 15, 2014

SAFETY INFORMATION

SAFETY PRECAUTIONS

Improper installation and operation could cause

personal injury and/or equipment and property

damage. Read and understand labels and the

Owner's Manual before installing, operating or making

adjustments.

WARNING

• Driver to keep bystanders minimum of

25 feet away from operating spreader.

• Before working with the spreader, secure all

loose-ﬁtting clothing and unrestrained hair.

• Before operating the spreader, verify all

safety guards are in place.

• Before servicing the spreader, wait for

auger and spinner to stop.

• Do not climb into or ride on spreader.

WARNING

Overloading could result in an

accident or damage. Do not exceed

GVWR or GAWR ratings as found on

the driver-side door cornerpost of

the vehicle. See Loading Section to determine

maximum volumes of spreading material.

WARNING

Do not install the control for this product in

the deployment path of an air bag. Refer to

vehicle manufacturer's manual for air bag

deployment area(s).

CAUTION

During the hopper spreader installation

we recommend the addition of an OSHA

compliant Backup Alarm. This alarm is

required for OSHA governed employers.

CAUTION

• Do not operate a spreader in need of

maintenance.

• Before operating the spreader, reassemble

any parts or hardware removed for cleaning

or adjusting.

• Before operating the spreader, remove

materials such as cleaning rags, brushes,

and hand tools from the spreader.

• While operating the spreader, use auxiliary

warning lights, except when prohibited by law.

CAUTION

Disconnect electric and/or hydraulic power

and tag out if required before servicing or

performing maintenance.

CAUTION

DO NOT leave unused material in

hopper. Material can freeze or solidify,

causing unit to not work properly.

Empty and clean after each use.

NOTE: Lubricate grease ﬁttings after each use.

Use a good quality multipurpose grease.

PERSONAL SAFETY

• Remove ignition key and put the vehicle in park or

in gear to prevent others from starting the vehicle

during installation or service.

• Wear only snug-ﬁtting clothing while working on

your vehicle or spreader.

• Do not wear jewelry or a necktie, and secure long

hair.

• Wear safety goggles to protect your eyes from

battery acid, gasoline, dirt and dust.

• Avoid touching hot surfaces such as the engine,

radiator, hoses and exhaust pipes.

• Always have a ﬁre extinguisher rated BC handy,

for ﬂammable liquids and electrical ﬁres.

Lit. No. 43826, Rev. 01 8 September 15, 2014

FIRE AND EXPLOSION

Be careful when using gasoline. Do not use gasoline

to clean parts. Store only in approved containers away

from sources of heat or ﬂame.

CELL PHONES

A driver's ﬁrst responsibility is the safe operation of

the vehicle. The most important thing you can do

to prevent a crash is to avoid distractions and pay

attention to the road. Wait until it is safe to operate

Mobile Communication Equipment such as cell phones,

text messaging devices, pagers or two-way radios.

VENTILATION

BATTERY SAFETY

CAUTION

Batteries normally produce explosive gases

which can cause personal injury. Therefore,

do not allow ﬂames, sparks or lit tobacco

to come near the battery. When charging or

working near a battery, always cover your

face and protect your eyes, and also provide

ventilation.

• Batteries contain sulfuric acid which burns

skin, eyes and clothing.

• Disconnect the battery before removing or

replacing any electrical components.

WARNING

Vehicle exhaust contains lethal fumes.

Breathing these fumes, even in low

concentrations, can cause death. Never

operate a vehicle in an enclosed area without

venting exhaust to the outside.

WARNING

Gasoline is highly ﬂammable and gasoline

vapor is explosive. Never smoke while

working on vehicle. Keep all open ﬂames

away from gasoline tank and lines. Wipe up

any spilled gasoline immediately.

SAFETY INFORMATION

Recommended Fastener Torque

Chart (ft-lb)

Size Torque

SAE

Grade 2 SAE

Grade 5 SAE

Grade 8

1/4-20 6 9 13

5/16-18 11 18 28

3/8-16 19 31 46

3/8-24 24 46 68

7/16-14 30 50 75

1/2-13 45 75 115

9/16-12 66 110 165

5/8-11 93 150 225

3/4-10 150 250 370

7/8-9 150 378 591

1-8 220 583 893

Metric Grade 8.8 (ft-lb)

Size Torque Size Torque

M 6 7 M 12 60

M 8 17 M 14 95

M 10 35 M 16 155

These torque values apply to fasteners

except those noted in the instruction.

CAUTION

Read instructions before assembling.

Fasteners should be ﬁnger tight until

instructed to tighten according to torque

chart. Use standard methods and practices

when attaching spreader including proper

personal protective safety equipment.

TORQUE CHART

Lit. No. 43826, Rev. 01 9 September 15, 2014

This Manual covers vehicles which have been

recommended for carrying the hopper spreader.

Please see your local dealer for proper vehicle

applications.

MATERIAL WEIGHTS

CERTIFICATION

WARNING

Overloading could result in an accident or

damage. Do not exceed GVWR or GAWR

as found on the driver-side cornerpost of

vehicle.

WARNING

New untitled vehicle installation of a spreader

requires National Highway Trafﬁc Safety

Administration altered vehicle certiﬁcation

labeling. Installer to verify that struck load of

snow or ice control material does not exceed

GVWR or GAWR rating label and complies

with FMVSS.

CAUTION

Read and adhere to manufacturer's

ice-control material package

labeling including Material Safety

Data Sheet requirements.

Lit. No. 43826, Rev. 01 10 September 15, 2014

DETERMINING VEHICLE PAYLOAD

1. Install the hopper spreader and optional

equipment according to the instructions.

2. Install or attach any other equipment that will be

on the vehicle while the hopper spreader will be in

use (step bumper, trailer hitch, snowplows, etc.).

Fill gas tanks.

3. Obtain the Gross Vehicle Weight Rating (GVWR),

Front Gross Axle Weight Rating (FGAWR) and

Rear Gross Axle Weight Rating (RGAWR) from

the certiﬁcation label located inside the driver-side

door jamb or door.

4. With the occupants in the truck for normal hopper

spreader operation, weigh the vehicle to obtain

gross vehicle weight (GVW).

5. Subtract the GVW from the GVWR to determine

the available material payload.

6. Obtain the weight per cubic yard (lb/cu ft) of

the desired material. Divide the weight into the

payload to determine the maximum volume of

material that can be carried.

WARNING

Overloading could result in an accident or

damage. Do not exceed GVWR or GAWR

ratings as found on the driver-side door

cornerpost of the vehicle. See Loading

Section to determine maximum volumes of

spreading material.

7. Compare the maximum volume to determine the

maximum height of the material in the hopper

spreader.

8. Fill the hopper with the material to the calculated

height. Reweigh the vehicle with occupants

and verify the GVW, Front Gross Axle Weight

and Rear Gross Axle Weight are less than the

vehicle's ratings.

9. Repeat Steps 7 and 8 for each type of material.

Material Density

(lb/ft3)

Rock Salt – Dry 80–90

Sand/Salt Mix – Dry 95–120

A 1:1 ratio is recommended for salt/sand mix

to prevent material from freezing.

Weight of spreader and mount must be added to

struck material weight to determine total spreader

weight.

WARNING

Do not overload vehicle. Use chart below

to calculate weight of material. Weights of

material are an average for dry materials.

CAUTION

Never use wet materials or materials with

foreign debris with any of these spreaders.

These units are designed to handle dry, clean,

free ﬂowing material.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SnowEx Épandeur

SnowEx

SnowEx Sidewalk-Pro SD-95 Mode d'emploi

SnowEx

SnowEx HELIXX Manuel utilisateur

SnowEx

SnowEx Precision Pro SP-1675 Manuel utilisateur

SnowEx

SnowEx VX-4200 Manuel utilisateur

SnowEx

SnowEx SP-7550 Manuel du propriétaire

SnowEx

SnowEx SP-9500X Manuel utilisateur

SnowEx

SnowEx V-Pro 32200 Manuel utilisateur

SnowEx

SnowEx SP-2200 Manuel utilisateur

SnowEx

SnowEx Bulk Pro SP-1575 Mode d'emploi

SnowEx

SnowEx V-Maxx G2 Manuel utilisateur

SnowEx

SnowEx V-Pro 32300 Manuel utilisateur

SnowEx

SnowEx SP-85 Manuel du propriétaire

SnowEx

SnowEx VX-4210 Manuel utilisateur

SnowEx

SnowEx SP-100 Manuel du propriétaire

SnowEx

SnowEx HELIXX Manuel utilisateur

SnowEx

SnowEx SP-3000 Manuel utilisateur

SnowEx

SnowEx Bulk Pro 1575 Manuel utilisateur

SnowEx

SnowEx V-Pro SP-2000 Manuel utilisateur

SnowEx

SnowEx SP-7000 Manuel utilisateur

SnowEx

SnowEx HELIXX Manuel utilisateur

SnowEx

SnowEx SP-1675 Manuel utilisateur

SnowEx

SnowEx Super Maxx SP-9300XH Mode d'emploi

SnowEx

SnowEx Renegade S150A Manuel utilisateur

SnowEx

SnowEx Vee Pro 3000 Manuel utilisateur

Manuels Épandeur populaires d'autres marques

PEQUEA

PEQUEA GT-100 Manuel utilisateur

Herculano

Herculano H2RS9 Manuel utilisateur

Epoke

Epoke SKE8 Manuel utilisateur

GEA

GEA EL44 Fiche technique

Boss Snowplow

Boss Snowplow TGS 800 Manuel utilisateur

Fisher

Fisher EMERSON 168 Series Manuel utilisateur

Fisher

Fisher POLY-CASTER 78601 Manuel utilisateur

TurfEx

TurfEx RS7200 Manuel du propriétaire

Ferris

Ferris Pathfinder Series Manuel utilisateur

Fayat Group

Fayat Group DYNAPAC S100 Guide de dépannage

Art's-Way Manufacturing

Art's-Way Manufacturing X700 Manuel d'installation et d'exploitation

EASTMAN

EASTMAN CR 500 Manuel utilisateur

Nogueira

Nogueira RoyalFlow-600 Manuel utilisateur

Buyers

Buyers TGS05B Manuel utilisateur

Magnum

Magnum V-BOX PV Series Supplément

Meyer's

Meyer's VB280 Manuel utilisateur

Kramer

Kramer VM-400HDCP Manuel utilisateur

H&S

H&S 5134 Manuel utilisateur
