SMC Networks SMC8024L2 Manuel de programmation

TigerSwitch 10/100/1000

Managed Ethernet Switch

◆24 auto-MDI/MDI-X 10/100/1000BASE-T ports

◆4 ports shared with 4 SFP transceiver slots

◆Non-blocking switching architecture

◆Spanning Tree Protocol

◆Up to eight LACP or static 8-port trunks

◆Layer 2/3/4 CoS support through four priority queues

◆Full support for VLANs

◆IGMP multicast filtering and snooping

◆Support for jumbo frames up to 9 KB

◆Manageable via console, Web, SNMP/RMON

Management Guide

SMC8024L2

38 Tesla

Irvine, CA 92618

Phone: (949) 679-8000

TigerSwitch 10/100/1000

Installation Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

April 2006

Pub. # 150000022900H

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no

responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third

parties which may result from its use. No license is granted by implication or otherwise under any patent or

patent rights of SMC. SMC reserves the right to change specifications at any time without notice.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

Trademarks:

SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are trademarks of SMC

Networks, Inc. Other product and company names are trademarks or registered trademarks of their

respective holders.

IMITED

ARRANTY

Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be

free from defects in workmanship and materials, under normal use and service, for the

applicable warranty term. All SMC products carry a standard 90-day limited warranty from

the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion,

repair or replace any product not operating as warranted with a similar or functionally

equivalent product, during the applicable warranty term. SMC will endeavor to repair or

replace any product returned under warranty within 30 days of receipt of the product.

The standard limited warranty can be upgraded to a Limited Lifetime* warranty by registering

new products within 30 days of purchase from SMC or its Authorized Reseller. Registration

can be accomplished via the enclosed product registration card or online via the SMC Web

site. Failure to register will not affect the standard limited warranty. The Limited Lifetime

warranty covers a product during the Life of that Product, which is defined as the period of

time during which the product is an “Active” SMC product. A product is considered to be

“Active” while it is listed on the current SMC price list. As new technologies emerge, older

technologies become obsolete and SMC will, at its discretion, replace an older product in its

product line with one that incorporates these newer technologies. At that point, the obsolete

product is discontinued and is no longer an “Active” SMC product. A list of discontinued

products with their respective dates of discontinuance can be found at:

http://www.smc.com/index.cfm?action=customer_service_warranty.

All products that are replaced become the property of SMC. Replacement products may be

either new or reconditioned. Any replaced or repaired product carries either a 30-day limited

warranty or the remainder of the initial warranty, whichever is longer. SMC is not responsible

for any custom software or firmware, configuration information, or memory data of

Customer contained in, stored on, or integrated with any products returned to SMC pursuant

to any warranty. Products returned to SMC should have any customer-installed accessory or

add-on components, such as expansion modules, removed prior to returning the product for

replacement. SMC is not responsible for these items if they are returned with the product.

Customers must contact SMC for a Return Material Authorization number prior to returning

any product to SMC. Proof of purchase may be required. Any product returned to SMC

without a valid Return Material Authorization (RMA) number clearly marked on the outside

of the package will be returned to customer at customer’s expense. For warranty claims within

North America, please call our toll-free customer support number at (800) 762-4968.

Customers are responsible for all shipping charges from their facility to SMC. SMC is

responsible for return shipping charges from SMC to customer.

WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS

WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR

REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC’S OPTION. THE

FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN

LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,

EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE,

INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR

AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER

LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE OR USE OF ITS PRODUCTS. SMC SHALL NOT BE LIABLE

UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THE

ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY

CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER

INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR

ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY

ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT

OR TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR

INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE

DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR

OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE

SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR

INTERRUPTION OF ITS PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED

RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES

OR THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR

CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS AND EXCLUSIONS

MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS, WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS

WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS.

* SMC will provide warranty service for one year following discontinuance from the active

SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans,

and cables are covered by a standard one-year warranty from date of purchase.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

vii

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Configuring the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Using the Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Navigating the Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Web Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Displaying Status Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Showing Port Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Displaying System Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Setting the Switch’s IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Configuring the Logon Password . . . . . . . . . . . . . . . . . . . . . . . . . 18

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Static MAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Counter Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Configuring Rate Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Port Mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Cable Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Trunks Membership . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Trunk Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Trunk Rate Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

LACP Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

LACP Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

VLAN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

viii

QOS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

RSTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

802.1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

IGMP Snoop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Diagnosing Switch Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Changing a PC’s IP Address . . . . . . . . . . . . . . . . . . . . .59

Software Specifications . . . . . . . . . . . . . . . . . . . . . . . . . .61

Software Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Management Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Management Information Bases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

EATURES

AND

ENEFITS

NTRODUCTION

The Tiger Switch SMC8024L2 is a high performance managed switch that

delivers performance and control to your network. It provides 24

full-duplex 1000BASE-T ports that significantly improve network

performance and boost throughput using features configured through the

web interface. With 48 Gigabits of throughput bandwidth, these switches

provide the quickest solution to meeting the growing demands on your

network.

Features and Benefits

• User friendly web-management interface

• Supports Qos, Spanning Tree, IGMP, VLANs and trunk configuration

• Store-and-forward switching ensures error-free transmission

• Half- and full-duplex flow control prevents packets from being dropped

under heavy loading

• Plug-and-play—optional configuration using web interface

• “At-a-glance” LEDs for port and system status monitoring

• Desktop or rack installation

NITIAL

ONFIGURATION

NITIAL

ONFIGURATION

To make use of the management features of your Tiger Switch, you must

first configure it with an IP address that is compatible with the network it

is being installed in. For simplicity, this should be done before you

permanently install the switch in the network.

The following procedure is recommended:

1. Place your Tiger Switch close to the PC that you will use to configure

it. It will help if you can see the front panel of the switch while

working on your PC.

2. Connect the Ethernet port of your PC to any port on the front panel

of your Tiger Switch. Connect power to the switch and verify that you

have a link by checking the front-panel LEDs. (See the Hardware

Description on page 2 for more information on the LEDs.)

3. The default IP address of the switch is 192.168.2.10 and the subnet

mask is 255.255.255.0. If your PC has a different IP address from the

switch but is on the same subnet (i.e. the PC and switch both have

addresses that start 192.168.2.x ) you can skip directly to step 4.

Otherwise, you must set your PC’s IP address manually. If you are

unfamiliar with this process, see “Changing a PC’s IP Address” on

page 7.

4. Open your web browser and enter the address http://192.168.2.10. If

your PC is properly configured, you will see the login page of your

Tiger Switch. If you do not see the login page, please check your IP

address and repeat step 3.

5. Enter the default password "smcadmin" and click on the Login

button.

Autres manuels pour SMC8024L2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SMC Networks Changer

SMC Networks

SMC Networks SMCGS26C-SMART - FICHE TECHNIQUE Instructions d'utilisation et de sécurité

SMC Networks

SMC Networks EZ Switch SMC8504T Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC8126PL2-F Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC6726AL2 Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC8124PL2 Manuel utilisateur

SMC Networks

SMC Networks SMC6724L3 Manuel utilisateur

SMC Networks

SMC Networks SMC6724L2GLSC Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC6128PL2 Manuel utilisateur

SMC Networks

SMC Networks 6726L3 - FICHE TECHNIQUE Guide d'installation

SMC Networks

SMC Networks Edge-core ES4704BD Manuel utilisateur

SMC Networks

SMC Networks IS1000 Series Manuel utilisateur

SMC Networks

SMC Networks PFMC7501-L Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC8728L2 Manuel utilisateur

SMC Networks

SMC Networks SMC8612XL3 F 1.0.1.3 Manuel utilisateur

SMC Networks

SMC Networks PF3W5 Series Manuel utilisateur

SMC Networks

SMC Networks ZSE3 Manuel utilisateur

SMC Networks

SMC Networks TigerStack III SMC6824MPE Manuel utilisateur

SMC Networks

SMC Networks ZSE20 Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC8608SX Manuel utilisateur

SMC Networks

SMC Networks TigerSwitch SMC8648T Manuel utilisateur

SMC Networks

SMC Networks D-H7A2*-588 Manuel

SMC Networks

SMC Networks SMCGS501 - FICHE TECHNIQUE Instructions d'utilisation et de sécurité

SMC Networks

SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Manuel utilisateur

SMC Networks

SMC Networks D-F6# Series Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
