Managed Switch SMC8708L2

TigerSwitch™ 10G

Standalone 8-port XFP 10G Managed Layer 2 switch

www.smc.com

The TigerSwitch 10G 10-Gigabit Ethernet switch delivers

flexibility, wire-speed performance, superior port density,

and a complete standard Layer 2 feature set to address

low-cost and high performance switching requirements

of enterprise and SMB customers.

Only 1 rack unit (1RU) high, the TigerSwitch 10G is an

excellent choice to deliver 10 Gigabit Over fiber within

the wiring closet and server farm, and backbone. The

TigerSwitch 10G is easy to configure and maintain. It

offers a cost effective and high-performance Layer 2

solution for enterprise network deployments.

Each TigerSwitch 10G ships with a complete standard

Layer 2 feature set including 802.1Q VLANs, 802.1p,

DSCP, TCP/UDP port based QoS, 802.1D Spanning Tree

Protocol, 802.1w Rapid Spanning Tree Protocol, 802.1S

(Multiple Spanning Tree), 802.3x-based flow control,

BootP/DHCP, TFTP, Generic VLAN Registration Protocol

(GVRP), Internet Group Management Protocol (IGMP)

Snooping, and port mirroring. With support for eight

queues per port based on 802.1p, the TigerSwitch 10G

provides critical Quality of Service (QoS) features for

next-generation applications such as Voice over IP and

streaming audio or video.

With an easy-to-use, industry-standard Command Line

Interface (CLI), Telnet based interface,and Web-based

GUI including secure access using SSH/SSL, the

TigerSwitch 10G is easy and secure to configure, deploy

and maintain.

The TigerSwitch 10G 10-GbE switches are well-suited to

enterprise wiring closet, data center, and backbone

deployments. Enterprise customers wanting to future-

proof their network with 10-GbE can deploy the

TigerSwitch 10G 10-GbE switches in their network.

FEATURES

High port density 10G switch in 1U box

Full wire-speed switching performance

Priority queuing

VLAN with GVRP

IGMP

LACP for link aggregation

Port mirroring

Port and system security

SNMP, RMON, spanning tree algorithm

Supports up to 8 XFP 10G ports

Non-blocking 160Gbps switch fabric for maximum

switching performance

Eight levels of priority, with weighted fair queuing, ensures

smooth transmission of vital data

Supports VLANs based on tags, ports, or protocol, plus support

for automatic GVRP LAN registration for maximum security and

bandwidth efficiency.

IGMP allows multicast traffic transmission to registered

users only.

Port trunking group links between switches, increases bandwidth

for dedicated link

Rate limiting to prevent monopoly of bandwidth from

a single user

Security control and authentication such as SSH, SSL, HTTP,

802.1x to ensure a secure network.

BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMC8708L2

PORTS

• SMC8708L2: 8 10G-BASE ports

• Built-in Network Management

NETWORK INTERFACE

• XFP Transceiver slots supporting SR, LR and ER XFP.

• Multimode fiber cable; 62.5/125 or 50/125 microns

• Singlemode fiber cable: 9/125 micron

Switch fabric

• 160Gbps

• 120Mpps

Buffer Architecture

• 8Mbytes

SWITCHING DATABASE

• 16K MAC address entries

LED

• System: Power, RPU , Diag,

• Port: Link/activity, XFP Module

WEIGHT

• 5.84kg

• 12.87lbs

DIMENSION

• 440 x 415 x 43 mm

• 17.3 x 16.3 x 1.8 in

TEMPERATURE

• Operating: 0 to 50 °C

32 to 122 °F

• Storage: -40 to 70 °C

• -40 to 158 °F

HUMIDITY

• Operating: 5% to 95% (non-condensing)

AC Input

• 100 to 240 V, 50-60 Hz, 2A

POWER SUPPLY

• Internal, auto-ranging transformer: 100 to 240 VAC, 50 to 60 Hz

• External, supports connection for redundant power supply

Power Consumption

• 150 Watts maximum

Maximum Current

• 2.00 A @ 100 VAC

• 1.00 A @ 240 VAC

MTBF

• 47271 hours at 50 degrees celcius

SWITCH FEATURES

• Spanning Tree Protocol (802.1D, .1w, .1s)

• Forwarding Mode

• Store-and-forward

• VLAN Support

• Up to 255 groups; port-based or with 802.1Q

• VLAN tagging, GVRP for automatic VLAN learning

• 802.1v (Protocol based Vlans)

• Quality of Service

• Supports four levels of priority with flexible classification

and prioritization

• MultiLink Trunking (LACP)

• Port Mirroring

• TACACS+ client authentication

• HTTPS and SSL

• SSH for Telnet sessions

• Rate limiting

• Static port security

• Jumbo Frame support

MANAGEMENT FEATURES

• In-Band Management

• Telnet, SLIP, Web-based HTTP, or SNMP manager

• Out-of-Band Management

• RS-232 DB-9 console port

• Software Loading

• TFTP in-band or Xmodem out-of-band

• MIB Support

• MIB II (RFC 1213), Bridging MIB (RFC 1493), Ethernet-Like

MIB (RFC 1643), RMON MIB (RFC 1757), SMC’s private MIB

RMON SUPPORT

• Groups 1,2,3, 9 (Statistics, History, Alarm, Event)

Standards

• IEEE802.3 Ethernet, IEEE802.3u Fast Ethernet,

• IEEE802.1D Spanning Tree Protocol and traffic priorities,

• IEEE802.1p Priority tags

• IEEE802.1Q VLAN

• IEEE802.1ac VLAN tagging

• IEEE802.1ad Link aggregation control protocol

• IEEE802.1w Rapid Spanning Tree

North America

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information

www.smc.com
