SMC Networks SMC Barricade Plus SMCBR14VPN Manuel utilisateur

Broadband Router SMCBR14VPN

Barricade™ VPN 4-port Broadband Router

www.smc.com

The Barricade™ VPN 4-Port Broadband Router

(SMCBR14VPN) is the perfect solution for creating

secure Virtual Private Networking tunnels and sharing

the Internet connection with multiple computers. Along

with the VPN functionality, this Router has several

Advanced Features including DMZ hosting, Port

Forwarding, extensive system logging, and two user

accounts. The Barricade VPN has an integrated

10/100Mbps Auto-Sensing Switch to connect up to 4

wired computers or easily expand your network by

adding a switch to one of the LAN ports.

This Barricade VPN 4-Port Broadband Router allows a

user to create secure VPN tunnel connections to a corpo-

rate network from a home or remote office location. This

new VPN Router has both an integrated VPN Server and

VPN client to support multiple VPN connections using

IPSec, PPTP, and L2TP protocols. The Barricade VPN

provides new VPN features like a Dynamic VPN function.

This feature allows a user to configure a VPN connection

on a Dynamic IP connection and when the IP Address

changes, the VPN configuration will be updated to use

the new IP Address automatically.

The Barricade VPN supports a 10/100Mbps WAN port for

use with high-speed Internet connections as well as a

COM port for use with an external dial-up or ISDN

modems. The dial-up modem port can be used as the

main internet connection or as a fail-over option if your

broadband service goes down. For network protection,

this Router has an Advanced SPI Firewall to protect your

computers from DoS (Denial of Service) Attacks like Ping

of Death, SYN Flood, Land Attacks, and IP Spoofing.

By combining all of these features into our new stackable

chassis the Barricade VPN 4-Port Broadband Router is

the ideal solution for both the corporate user who works

from home and the advanced power user looking for

more features and performance.

FEATURES

Four high-speed 10/100 Mbps auto-sensing LAN ports

10/100Mbps WAN port and COM port for external

Dial-Up or ISDN modem connections

Integrated VPN Server and Client supporting PPTP,

IPSec, and L2TP protocols

Supports multiple IPSec, PPTP, and L2TP Virtual

Private Network (VPN) Tunnels

Network filters based on Time/Date, URL, IP Address,

Port, and MAC Address

Robust Stateful Packet Inspection (SPI) Firewall

with Advanced System Logging

Easily configured with any Web Browser using

the New and Improved Web-based Interface

Protect your network with the Advanced

Stateful Packet Inspection (SPI) Firewall

Manage your network access with content filter

options based on Time, Date, Port, and MAC Address

Flexible – supports port range mappings to support

a wide range of popular applications

Security – multiple VPN tunnels provide convenient and secure

remote access for telecommuters and travelers attempting to

gain access to their corporate network resources

Platform independent – works with Windows, Mac, and Linux

BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMCBR14VPN

NETWORK INTERFACE

• 4 - 10/100Mbps Auto-sensing

Ethernet RJ-45 LAN Ports

• 1 - 10/100Mbps Auto-sensing

Ethernet RJ-45 WAN Port

• 1 - DB-9 Male COM port

SECURITY FEATURES

• Stateful Packet Inspection (SPI)

•NAT

• Denial of Service (DoS)

• IP / Port / MAC Address / URL Filtering

• Email Alerts

• Multiple Management Accounts

ROUTER FEATURES

• Port Forwarding

• Special Applications

• DDNS

• Syslog Server

MANAGEMENT FEATURES

• SNMP

• System Logging

• Remote Management

VPN FEATURES

• IPSec Support (40)

• Built-in PPTP and L2TP VPN Server

• Dynamic VPN

• IP Authentication Header (AH)

• IP Encapsulating Security Payload (ESP)

• Internet Key Exchange (IKE) authentication

and Key Management with Main and Aggressive modes

• Authentication (MD5 / SHA-1)

• NULL/DES/3DES Encryption Algorithm and their use with

IPSec Internet Security

• Association and Key

LEDs

• Power

•Status

• 1 - WAN (10M /100M)

• 4 - LAN (10M /100M)

DIMENSIONS

• 8.9 x 1.5 x 5.5 in

• 22.6 x 3.81 x 13.9 cm

WEIGHT

• 0.8 lbs

•0.36 kg

OPERATING

• Temperature: 0~40o C / 32~104o F

• Humidity 10%~90% non-condensing

STORAGE

• Temperature: -20~70oC / -4~158o F

• Humidity: 0~95% non-condensing

POWER REQUIREMENTS

• 100-110 VAC, 5 Volt ± 5% / 2.5 A

STANDARDS

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100Base-TX Fast Ethernet

• IEEE 802.3x Flow Control

COMPLIANCES - EMC/SAFETY

•FCC

•CE

•VCCI

• UL

WARRANTY

• Limited Lifetime

North America

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information

www.smc.com
