SMC Networks FieldServer FS-8700-130 Note de version

Driver Version:

1.03

Document Revision:

FieldServer

FS-8700-130 Notifier NCA2-NFS2-3030

Driver Manual

(Supplement to the FieldServer Instruction Manual)

APPLICABILITY & EFFECTIVITY

Effective for all systems manufactured after March 2015

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Contact Information

Contact Information:

Thank you for purchasing the FieldServer.

Please call us for Technical support of the FieldServer product.

Contact Information:

Sierra Monitor Corporation

1991 Tarob Court

Milpitas, CA 95035

Contact number:

+1 408 262-6611

+1 800 727-4377

Email: info@sierramonitor.com

Website: www.sierramonitor.com

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Table of Contents

TABLE OF CONTENTS

Notifier NCA2/NFS2-3030 Description...............................................................................................41

Driver Scope of Supply .......................................................................................................................422.1 Supplied by FieldServer Technologies for this driver.....................................................................4

Hardware Connections........................................................................................................................533.1 Hardware Connection Tips / Hints..................................................................................................6

Data Array Parameters........................................................................................................................74

Configuring the FieldServer as a Notifier NCA2/NFS2-3030 Client ................................................855.1 Panel Status - Memory Mapping ....................................................................................................8

5.2 Client Side Connection Parameters .............................................................................................10

5.3 Client Side Node Parameters.......................................................................................................11

5.4 Client Side Map Descriptor Parameters.......................................................................................12

5.4.1 FieldServer Related Map Descriptor Parameters .................................................................12

5.4.2 Driver Related Map Descriptor Parameters ..........................................................................12

5.4.3 Map Descriptor Example: Standard example........................................................................13

Configuring the FieldServer as a Notifier NCA2/NFS2-3030 Server.............................................146

Appendix A. Useful Information ..............................................................................................................15

Appendix A.1. Node Status .....................................................................................................................15

Appendix A.2. FieldServer Synchronization............................................................................................15

Appendix A.3. Driver Limitations and Exclusions....................................................................................15

Appendix B. Troubleshooting..................................................................................................................16

Appendix B.1. Connection Tips & Hints ..................................................................................................16

Appendix B.2. Networking Tips...............................................................................................................16

Appendix C. Reference.............................................................................................................................17

Appendix C.1. Notifier NCA2/NFS2-3030 Message Types Recognized.................................................17

Appendix C.2. System Trouble Messages..............................................................................................18

Appendix C.3. Error Messages ...............................................................................................................22

LIST OF FIGURES

Figure 1 - Connection Diagram .............................................................................................................................5

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Page 4 of 23

NOTIFIER NCA2/NFS2-3030 DESCRIPTION1

The NCA2/NFS2-3030 Serial driver allows the FieldServer to record data from Notifier NCA2 or NFS2-

3030 panels over RS-232 as per NFS2-3030/NCA-2 EIA-232 Protocol & Data Formats 53219 Rev A

1/3/2008. There is no active polling by this driver; the communications are one-way through the panel's

printer or CRT port. The FieldServer acts as a Client; receives messages and records the status of a

Panel. The panel MUST output messages in160 characters ASCII format in English.

This driver is not capable of emulating a Notifier NCA2 or NFS2-3030 panel.

The NCA2 controls all the devices (e.g. 3030, 640 panels) connected on the Notifier network. Each Fire

Alarm Panel on Network is considered as a Node. 240 Nodes can exist on one network. NFS2-3030 can

exist on a network or be self-standing.

NCA2 interacts with other Fire Alarm Panels, records the status of the panels and sends the events to

printer and CRT ports. FieldServer captures these events in text form, parses and stores them in Data

Arrays. These Data Arrays can be monitored by third party tools. Since the FieldServer does not actively

poll for data, the accuracy and timeliness of the stored data is limited to the frequency of update

messages that the Notifier Fire Panel issues.

If a networked panel does not send the 'CLEARED' message for latched points via the NCA2 it is not

possible to detect cleared points unless a system reset is done. It is possible to configure the FieldServer

to clear on reset message from NCA2. See Appendix A.2 for more detail.

Please note that the FieldServer can be configured with a large number of points. The point limits

purchased with the FieldServer prevent the entire database from being accessed in any one application.

It is therefore strongly advisable to ensure that only the point addresses of interest are configured, and

that the FieldServer is purchased with the correct point count.

The types of Notifier messages supported by this driver are summarized in Section 5.1. A detailed table

presented in Appendix C.1 shows each type of NCA2/NFS2-3030 message the FieldServer recognizes

and the effect that it has on the status of the points in the Data Array.

Max Nodes Supported

FieldServer Mode

Nodes

Comments

Client

This Driver cannot be used as a Client.

Server

Each FieldServer port can connect to only 1 Notifier panel port

DRIVER SCOPE OF SUPPLY2

2.1 Supplied by FieldServer Technologies for this driver

FieldServer Technologies PART #

Description

FS-8917-16

Pigtail cable for RJ45 Port

FS-8700-130

Driver Manual

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Page 5 of 23

Figure 1 - Connection Diagram

HARDWARE CONNECTIONS3

The FieldServer is connected to the Notifier NCA2/NFS2-3030 Fire Panel as shown in the following

connection drawing.

Configure the Notifier Panel according to manufacturer’s instructions.

FieldServer

FieldServer Part #

8917-16

Pigtail for RJ45

Port

RJ45

Connection to TB5 Printer

Port.

Notifier NCA2/NFS2-3030

Connect to one of the RS-232

Ports on the FieldServer

CTX CRX REFPTX PRX REF

TB5

Printer CRT

Rx (Brown)

Tx (Orange/White)

Com (Blue/White)

Connector Pinouts

TB5 CRT

Function

Receive

Reference

Transmit

CRX

REF

CTX

TB5 Printer

Function

Receive

Reference

Transmit

PRX

REF

PTX

RJ-45

Function

Transmit

Com

Receive

Wire Color

Orange/white

Blue/white

Brown

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Page 6 of 23

3.1 Hardware Connection Tips / Hints

The FieldServer should preferably be connected to the TB5 Printer port. It is theoretically

possible to connect to the TB5 CRT port, but this has not been fully tested.

The Panel’s port must be enabled and set to 80 Columns Not Supervised.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Page 7 of 23

DATA ARRAY PARAMETERS4

Data Arrays are “protocol neutral” data buffers for storage of data to be passed between protocols. It is

necessary to declare the data format of each of the Data Arrays to facilitate correct storage of the relevant

data.

Section Title

Data_Arrays

Column Title

Function

Legal Values

Data_Array_Name

Provide name for Data Array

Up to 15 alphanumeric

characters

Data_Array_Format

Provide data format. Each Data Array can only

take on one format.

FLOAT, BIT, UInt16, SInt16,

Byte, Packed_Byte,

Swapped_Byte

Data_Array_Length

Number of Data Objects. Must be larger than the

data storage area required by the Map

Descriptors for the data being placed in this

array.

1-10, 000

Example 1

// Data Arrays

Data_Arrays

Data_Array_Name

, Data_Format

, Data_Array_Length

DA_SYS_N2

, Sint16

, 508

DA_N2L01D

, BIT

, 1749

DA_N2L01D_T

, Sint16

, 159

DA_N2L01M

, BIT

, 1749

DA_N2L01M_T

, Sint16

, 159

DA_N2_PANEL

, BIT

, 1056

DA_N2_PANEL_T

, Sint16

, 96

DA_N2_BELL_T

, Sint16

, 4

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Page 8 of 23

CONFIGURING THE FIELDSERVER AS A NOTIFIER NCA2/NFS2-30305CLIENT

The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order

to enable the FieldServer for Notifier NCA2/NFS2-3030 communications, the driver independent

FieldServer buffers need to be declared in the “Data Arrays” section, the destination device addresses

need to be declared in the “Client Side Nodes” section, and the required data from Notifier Panels needs

to be mapped in the “Client Side Map Descriptors” section. Details on how to do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.

For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration

Manual. The information that follows describes how to expand upon the factory defaults provided in the

configuration files included with the FieldServer (See “.csv” sample files provided with the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer to

receive information from a Notifier Panel.

5.1 Panel Status - Memory Mapping

The primary purpose of this driver is to record the status of devices connected to the Notifier panel by

interpreting the text messages sent to the printer or CRT port. Not all messages will be interpreted, as

many messages do not directly pertain to device status, or are not currently supported. The following

subset of event messages is recognized:

Active Events:

FIRE ALARM

SECURITY ALARM (LIFE)

LIFE CRITICAL ALARM

MEDICAL EMERGENCY

SECURITY ALARM

CRITICAL PROCESS

SUPERVISORY

TROUBLE/ FAULT

DISABLED

PREALARM

ACTIVE

ON/ OFF

This Driver divides the memory into various types. Each location in each memory type is assigned an

address. It is therefore possible to map an address to a particular offset in a Data Array and make it

accessible for reading by other connected devices. The address structure is provided in Table 1.

Most of these addresses will only contain binary information to represent an active or inactive state.

Where multiple troubles are associated with a single device the addressed register corresponding to that

device will be incremented as a counter for each trouble message and decremented when a trouble is

cleared. These addresses should preferably be stored in SINT16 format in the Data Array.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Page 9 of 23

Parameter

Addresses

For each SLC loop per Node

Memory Type : Detector ; Module

Fire Alarm

1 –159

Security Life

160 –318

Life Critical

319 –477

Medical Emergency

478 –636

Security Alarm

637 –795

Critical Process

796 –954

Supervisory

955 - 1113

Disabled

1114 –1272

Prealarm

1273 –1431

Active

1432 –1590

ON/OFF

1591 –1749

Memory Type : Detector_Trouble; Module_Trouble

Troubles/Faults

1 –159

Parameter

Addresses

For each Node

Memory Type : Node_Trouble

Troubles/Faults

1 –508

Memory Type : Panel

Panel (Maximum12 Boards and 8 Panel circuits per Board )

Hardware address memory address

Board 1 panel 1 1

Board 1 panel 2 2

Board 2 panel 1 9

-----

Board 12 panel 8 96

)

Fire Alarm

1 –96

Security Life

97 - 192

Life Critical

193 - 288

Medical Emergency

289 - 384

Security Alarm

385 - 480

Critical Process

481 - 576

Supervisory

577 - 672

Disabled

673 - 768

Prealarm

769 - 864

Active

865 - 960

ON/OFF

961 - 1056

Memory Type : Panel_Trouble

Troubles/Faults

1–96

Memory Type : Bell_Trouble

Troubles/Faults

1-4

Table 1 –Memory Mapping Address Structure.

FS-8700-130 Notifier NCA2-NFS2-3030 Manual

Page 10 of 23

5.2 Client Side Connection Parameters

Section Title

Connections

Column Title

Function

Legal Values

Port

Specify which port the device is connected to

the FieldServer

P1-P81

Protocol

Specify protocol used

nfs2-nca; nca2; nfs2-3030

Baud*

Specify baud rate

CRT Port

4800; 9600; 19200; 38400; 57600;

(Vendor limitation)

Printer Port

9600 (Vendor limitation)

Parity*

Specify parity

None (Vendor limitation)

Data_Bits*

Specify data bits

8(Vendor limitation)

Stop_Bits*

Specify stop bits

1(Vendor limitation)

Example

// Client Side Connections

Connections

Port

, Protocol

, Baud

, Stop_Bits

, Parity

, nfs2-nca

, 9600

, 1

, None

Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports

available on specific hardware.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels SMC Networks Porte

SMC Networks

SMC Networks SMC8511 Manuel utilisateur

SMC Networks

SMC Networks LEC-GEN1 Manuel utilisateur

SMC Networks

SMC Networks D3G0804W Manuel utilisateur

SMC Networks

SMC Networks EZ Connect SMC8014-TES Manuel utilisateur

SMC Networks

SMC Networks ProtoAir FPA-W34 Guide de l'utilisateur

SMC Networks

SMC Networks SMCD3G Manuel utilisateur

SMC Networks

SMC Networks EliteConnect SMCWHSG14-G Manuel utilisateur

SMC Networks

SMC Networks FieldServer FS-EZX-MOD-BAC Guide de l'utilisateur

SMC Networks

SMC Networks FieldServer FS-EZX-MOD-BAC Guide de l'utilisateur

SMC Networks

SMC Networks FieldServer QuickServer FS-QS-2 F Series Guide de l'utilisateur

SMC Networks

SMC Networks SMCWTVG Manuel utilisateur

SMC Networks

SMC Networks EZ Connect SMC8014WG-SI Manuel utilisateur

SMC Networks

SMC Networks EliteConnect SMCWHSG14-G Manuel utilisateur

SMC Networks

SMC Networks EX510-GMJ1 Series Manuel utilisateur

SMC Networks

SMC Networks SMC TigerAccess SMC-VIP04 Manuel utilisateur

SMC Networks

SMC Networks SMC8414-2PD-SIP Manuel utilisateur

SMC Networks

SMC Networks DOCSIS 3.0 Commercial Cable Modem Gateway... Manuel utilisateur

SMC Networks

SMC Networks EX500-GPR1A-X8 Series Manuel utilisateur

SMC Networks

SMC Networks FieldServer FS-QS-2X10 Guide de l'utilisateur

SMC Networks

SMC Networks SMCD3GNV3 Manuel utilisateur

SMC Networks

SMC Networks 56-EX500-GPR1A Series Manuel utilisateur

SMC Networks

SMC Networks EZ Connect Commercial Cable Modem Gateway... Manuel utilisateur

SMC Networks

SMC Networks FieldServer FS-QS-2XX0 Guide de l'utilisateur

SMC Networks

SMC Networks FieldServer BACnet Explorer Guide de l'utilisateur

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
