IP SURVEILLANCE CAMERA

IAN 281517

IP-ÜBERWACHUNGSKAMERA

Montage-, Bedienungs- und Sicherheitshinweise

105x148mm

Version 1.5

MONITOROVACIA IP KAMERA

Pokyny pre montáž, obsluhu a bezpečnostné

pokyny

BEZPEČNOSTNÍ IP KAMERA

Pokyny k montáži, obsluze a bezpečnostní pokyny

IP SURVEILLANCE CAMERA

Assembly, operating and safety instructions

IP ELLENŐRZŐ KAMERA

Szerelési, használati és biztonsági tudnivalók

GB Assembly, operating and safety instructions Page 5

HU Szerelési, használati és biztonsági tudnivalók Oldal 25

CZ Pokyny k montáži, obsluze a bezpečnostní pokyny Strana 47

SK Pokyny pre montáž, obsluhu a bezpečnostné pokyny Strana 67

DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 87

Before reading, unfold both pages containing illustrations and familiarise yourself with all

functions of the device.

Olvasás előtt kattintson az ábrákat tartalmazó mindkét oldalra és végezetül ismerje meg a

készülék mindegyik funkcióját.

Před čtením si odklopte obě dvě strany s obrázky a potom se seznamte se všemi funkcemi

přístroje.

Pred čítaním si odklopte obidve strany s obrázkami a potom sa oboznámte so všetkými

funkciami prístroja.

Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie

sich anschließend mit allen Funktionen des Gerätes vertraut.

100x148mm

5GB

List of pictograms used............................................ Page 6

Introduction....................................................................... Page 7

Intended use............................................................................ Page 7

Parts Description...................................................................... Page 8

Technical Data ........................................................................ Page 8

Scope of delivery.................................................................... Page 9

Safety instructions....................................................... Page 10

Trademark notices....................................................... Page 13

Installing the camera................................................. Page 13

Connecting the camera .......................................................... Page 15

Camera setup.......................................................................... Page 16

Changing passwords and configuring the camera on

the WLAN network................................................................. Page 17

Using the camera.................................................................... Page 18

Troubleshooting ............................................................ Page 20

Cleaning and Care....................................................... Page 21

Disposal................................................................................ Page 21

Warranty and Service.............................................. Page 22

Warranty Declaration............................................................. Page 22

Service address....................................................................... Page 22

Notes on Conformity................................................. Page 23

6 GB

List of pictograms used

Read the instructions!

Safety instructions

Directions for use

Dust- and hose-proof

DANGER: This symbol with wording "DANGER" indicates

a hazard which may result in

serious injuries or death

not observed

. To avoid the da

nger, follow

the instruction.

WARNING: This symbol with the wording "WARNING"

indicates a hazard which may result in injuries or property

damage if not observed. To avoid the danger, follow the

instruction.

Keep out of reach of children!

Dispose of the packaging and the product in an environ-

mentally compatible manner!

7GB

IP Surveillance Camera

Introduction

Congratulations on the purchase of your new product. In

doing so you have chosen a top-quality product. Familiarise

yourself with the product before using it for the ﬁrst time. Care-

fully read the following instructions for use with installation, operating

and safety information. The product also includes a tutorial CD provid-

ing more information on the special function of the camera, including

connecting it to a PC. Only use the product as indicated and for the

speciﬁed areas of application. Both instructions for use (Quick start

guide, instructional CD and instructions for use) are part of this product.

Keep these for future reference. If you pass the product on to anyone

else, please be sure to also include all documentation.

Intended use

This camera fall into the category information technology. The product

is suitable for use indoors or in protected outdoor areas and is for the

surveillance of garages, car parks, house entrances, etc. This camera

features a night vision function with 6 infrared LEDs for a clear image

in the dark. It also features a built-in Mikrophone for recording ambi-

ent noise. Transmission is sent to a router, from where it can be ac-

cessed and controlled via app. Any use other than previously described or

modifying the product is prohibited and will result in damage. The

manufacturer is not liable for any damages caused by improper use.

This product is not intended for commercial use.

8 GB

Parts Description

Before reading, unfold the page containing the illustrations and famil-

iarise yourself with all functions of the device.

1Camera

2Mounting bracket

3WLAN aerial

4Tutorial CD

5Wall plug (ø 5 mm)

6Screws

7Power supply

8Ethernet cable (see Fig. B)

9RJ-45 connection element

10 RESET button (see Fig. B)

11 SD slot (for Mikro SD card max. 32GB Class 10 - not included)

(see Fig. B)

12 Quick start guide

13 Decal for marking the area under surveillance

14 Installation, operating and safety information

Technical Data

Camera:

Device type: Surveillance Camera WLAN Outdoor

IP66

Dimensions: approx. 6 x 11cm (ø x d), approx.

6 x 15.5cm (ø x d) (with WLAN aerial

and sun screen)

Image sensor: 2 megapixel CMOS

Focal length: 3.6mm

9GB

Resolution (horizontal TV lines): 1280 x 720 pixel

Picture angle: H 60°, V 43° + /-5 °

Detection range

Motion detector: 90° x 5m

Infrared range (night vision

mode black/white): 6 IR LEDs up to 8m range

Operating temperature: -10°C – +50°C

Humidity during use: 40–80% RH

Storage temperature: -10°C – ~+60 °C

Humidity during storage: 20–90% RH

Connections: Ethernet (10/ 100 Base-T/ Base-TX);

WLAN IEEE 802.11b/ g/ n

Frequency: 2.4 GHz

Protection class: IP66 (dust- and hose-proof)

Weight: approx. 540g (camera with base,

aerial and sun screen)

Cable length: 0.66cm

Power supply (for dry indoor use only):

Model/type: KSAS7R50500150HE

Manufacturer: Kuantech (Beihai) Co., Ltd

Input voltage/frequency: 100–240V~, 50 /60 Hz

Input current: 0.25A

Output voltage: 5V DC

Output current: 1.5A

Protection class: II/

Scope of delivery

Remove all parts from packaging and dispose of all packaging material.

Please contact customer service if parts are missing or damaged.

10 GB

1 Camera

1 Mounting bracket

1 WLAN aerial

1 Power supply

1 Mounting kit

1 Tutorial CD

1 RJ-45 connection element

2 Decals for marking the area under surveillance

1 Quick start guide

1 Instructions for use

Safety instructions

Damage due to failure to comply with these instructions for use will

void the warranty! We assume no liability for consequential damage!

We assume no liability for property damage or personal injury due to

improper handling or failure to observe the safety notices!

Children and persons with limitations

DANGER TO LIFE AND RISK

OF ACCIDENT FOR INFANTS AND CHILDREN!

Never leave children unsupervised with the packaging

material. The packaging material poses a suﬀocation hazard. Pack-

aging materials are not toys. Children frequently underestimate the

dangers.

Always keep children away from the product. This device may be

used by children aged 8 years and up, as well as by persons with

reduced physical, sensory or mental capacities, or lacking experi-

ence and/or knowledge, when supervised or instructed in the

safe use of the device and they understand the associated risks.

11GB

Do not allow children to play with the device. Cleaning and user

maintenance must not be performed by children without supervision.

DANGER TO LIFE! During installation keep children away from

the area in which you are working. A large number of screws and

other small parts are included within the scope of delivery. These

may prove life-threatening if swallowed or inhaled.

Damage

Never use the product if it is damaged in any way.

Contact your service centre or a professional if the product is dam-

aged, requires repairs, or for any other problems with the product.

Ensure all electrical connections and cable connections to other

devices comply with the applicable guidelines and with the instruc-

tions for use.

Be sure not to overload socket and extension cables. This can lead

to ﬁre or electric shock.

Please note the temperature and humidity during operation and

storage to ensure proper camera operation. These are speciﬁed in

the technical data. Moist, very cold or hot environments or storage

can damage the camera.

The camera is suitable for outdoor use, the power supply may only

be used indoors.

Avoid major shock. This can damage the electronic circuit.

Cordless systems are exposed to interference of telephones,

Mikrowaves, as well as other electronic devices operating in the

2.4 GHz range (impacts of interference include poor image quality

or transmission problems).

Maintain a minimum distance of 3 metres during installation and

operation.

Do not open the camera. This is a maintenance-free camera. Open-

ing the product will void the warranty.

Be sure not to damage any wires during installation.

12 GB

AC Adaptor

If defective, the power supply must be replaced with an identical

or equivalent type (identical electrical supply data).

Only plug the power supply into easy to access sockets so it can

easily be unplugged in the event of an emergency.

Do not touch the power supply with wet hands. Otherwise there is

a risk of electric shock.

Only use the power supply in dry indoor spaces.

Never unplug the device by the cable. Always touch the device by

the housing.

Please remember the power supply will continue to draw a small

amount of electricity even without the camera being operated so

long as the power supply is plugged into the socket. To completely

disconnect the power supply it must be unplugged from the mains

socket.

DANGER TO LIFE! Never open the power supply. Otherwise

there is a risk of electric shock.

Never cover the power supply.

Immediately unplug the power supply if you notice unusual noises

or smoke.

Position the cable so as to avoid a trip hazard.

Protect all plug connectors from moisture.

Application

Do not use the camera in explosive environments, e.g. at tank

plants, or in dusty environments.

Observe applicable national laws if you intend to use this camera

to photograph or watch people.

Areas under camera surveillance must be marked. The respective

decals are included, please again observe the labelling require-

ments of the respective country.

Table des matières

Langues :

Autres manuels Smartwares Caméra de sécurité

Smartwares

Smartwares CS89T Manuel utilisateur

Smartwares

Smartwares CS96C Manuel utilisateur

Smartwares

Smartwares C724IP Manuel utilisateur

Smartwares

Smartwares CS89C Manuel utilisateur

Smartwares

Smartwares CS96DVR Manuel utilisateur

Smartwares

Smartwares C706IP Manuel utilisateur

Smartwares

Smartwares CIP-39220 Manuel utilisateur

Smartwares

Smartwares DVR721C Manuel utilisateur

Smartwares

Smartwares CMS-30400 Manuel utilisateur

Smartwares

Smartwares CIP-39901 Manuel utilisateur

Smartwares

Smartwares CIP-37363 Manuel utilisateur

Smartwares

Smartwares 10.021.37 Manuel utilisateur

Smartwares

Smartwares 271723 Manuel utilisateur

Smartwares

Smartwares DVR528S Manuel utilisateur

Smartwares

Smartwares CIP-39220 Manuel utilisateur

Smartwares

Smartwares CMS-30300 Manuel utilisateur

Smartwares

Smartwares CIP-39311 Manuel utilisateur

Smartwares

Smartwares CS89T Manuel utilisateur

Smartwares

Smartwares CIP-39902 Manuel utilisateur

Smartwares

Smartwares CIP-37183 Manuel utilisateur

Smartwares

Smartwares C924IP Manuel utilisateur

Smartwares

Smartwares DVR728S Manuel utilisateur

Smartwares

Smartwares CIP-39218KL Manuel utilisateur

Smartwares

Smartwares C935IP Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
