Smartro SC93 Manuel utilisateur

Instruction Manual

WIRELESS WEATHER STATION

Model: SC93

Time

Dual Alarm Weather

Forecast

°C/°F

Selectable

Snooze

Moon

Phase

In & Out

Temp

In & Out

Humidity

1. Preface.........................................................................................1

2. Attention.......................................................................................1

3. Package Content..........................................................................2

4. Product Specication...................................................................2

4.1 Color Weather Station..............................................................2

4.2 Wireless Remote Sensor..........................................................3

5. Know Your Device........................................................................5

5.1 Screen......................................................................................5

5.2 Main Unit..................................................................................6

5.3 Wireless Remote Sensor..........................................................7

6. Preparation..................................................................................8

7. Initial Time Setup..........................................................................9

8. Dual Alarm Setting......................................................................10

8.1 How to Check Your Alarms.....................................................10

8.2 Activate/Deactivate the Alarm Function..................................10

8.3 Manual Setting of the Alarms..................................................10

8.4 Turn off the Alarm Tone..........................................................11

8.5 Snooze Function.....................................................................11

9. Weather Station and Remote Sensor Pairing & Manual Signal Reception..12

9.1 Weather Station and Remote Sensor Pairing.........................12

9.2 Loop Mode.............................................................................13

9.3 Manual Signal Reception........................................................14

10. Temperature & Humidity...........................................................15

10.1 °C/°F Selection.....................................................................15

10.2 How to Set Temperature & Humidity Alert............................15

10.3 Temperature & Humidity Trend.............................................17

10.4 How to Check Maximum/Minimum Temperature/Humidity...17

11. Weather Forecast.....................................................................18

11.1 Weather Forecast Statement................................................18

11.2 The Symbols of Weather Forecast........................................18

12. Moon Phase.............................................................................19

13. Air Pressure..............................................................................19

13.1 Air Pressure Trend Display...................................................19

13.2 How to Check Air Pressure History.......................................19

14. Backlight..................................................................................20

15. Troubleshooting.......................................................................21

16. After-sales Support...................................................................23

17. Waste Disposal........................................................................24

Content

1. Preface

2. Attention

Thank you for choosing this device from SMARTRO.

Before You Start Using It

● Make sure to read the instruction manual carefully. This information

will help you to familiarize yourself with your new device, to learn all of

its functions and get advice in the event of problems.

● Following the instructions will prevent damage to your device.

● We shall not be liable for any damage that occurs as a result of

not-following of these instructions.

● Please keep this instruction manual for future reference.

●Please follow the instructions for operation.

● Please use the original or manufacturer specied attachments or

accessories.

● Do not disassemble the product, so as to avoid safety hazards.

●Do not place any items on top of the product that may damage

the product.

● Do not place the product near water source or in a damp place.

●Please terminate use immediately upon damage, which is

caused as a result of improper use or repair by a non-factory

approved technician.

3. Package Content

● Color Weather Station*1

● Wireless Remote Sensor*1

● DC Power Adapter*1

● Instruction Manual*1

●Do not place the product in places that are exposed to direct

sunlight and high temperature such as radiator, electric heater,

stove, etc.

●Keep the product away from strong electromagnetic waves,

strong static electricity, or moisture and condensation.

● Children below 10 years of age should be supervised by an

adult, if/when using this product.

● Clean your device with a soft damp cloth. Do not use solvents or

scouring agents.

4. Product Specication

4.1 Color Weather Station

●Tabletop stand/ wall mount

●Weather forecast

●Indoor & outdoor temperature

Indoor temperature measurement range: 0°C(32°F) ~ +50°C

(122°F)

Outdoor temperature measurement range: -40°C (-40°F) ~ +70°C

(158°F)

●Indoor humidity measurement range: 1%RH~99%RH

●Barometric pressure

●Maximum & minimum records

●Dual alarm with snooze function

●Air pressure trend

●Temperature/ humidity alert

●Moon phase

●Alternative 12/24 hour format

●Calendar

●°C/°F switchable

●Adjustable backlight display

●Low battery indicator

●Power supply:

Battery: 2 x AA batteries (not included)

DC power adapter: 5V 500mA

4.2 Wireless Remote Sensor

●Tabletop stand/ wall mount/ hanging hole

●3 channels available

●Low battery indicator

●°C/°F switchable

●Power supply: 2 x AA batteries (not included)

●Range of transmission: 200 feet in open area

●Outdoor temperature measurement range: -40°C (-40°F) ~

+70°C (158°F)

●Outdoor humidity measurement range: 1%RH~99%RH

3 4

5. Know Your Device

A1: Weather forecast

A2: Air pressure

A3: Time

A4: Indoor temperature and humidity

A5: Outdoor temperature and humidity

A6: Moon phase icon

A7: Date

A8: Temperature alert

A9: Humidity alert

A10: Dual alarm

B1: SNOOZE/LIGHT

B2: Button

: Time setting (long press 2s to set)

: Alarm setting (long press 2s to set)

PRESSURE: review history record

▲: For setup preferences

▼: For setup preferences

: Maximum/ Minimum values : Select temperature unit

: Switch channel

B3: Alarm switch

B4: Temperature/humidity alert

B5: Sensor

B6: Battery compartment

B7: Fold-out tabletop stand

B8: Power supply socket

B9: Wall-mount hole

5.1 Screen

5.2 Main Unit

C1: Temperature

C2: Humidity

C3: Transmission signal light

C4: "°C/°F" button

C5: "TX" button

C6: Channel switch knob

C7: Battery compartment

C8: Hanging hole

C9: Wall-mount hole

6. Preparation

●Open weather station battery compartment cover, insert 2 x

AA batteries, ensure correct battery polarities [ "+" and "–" ]. And

connect the DC adapter to power the weather station.

●The screen will light up, and the device will make a beeping

sound. The weather station starts to detect indoor temperature and

humidity.

●The receiver will start to make a connection with the outdoor

remote sensor, a reception RF antenna symbol in the "OUT"

display area will icker on the screen. This procedure will takes 3

minutes at most.

●Open the wireless remote sensor battery compartment cover.

Choose a same channel as the weather station. Insert 2 x AA

batteries, ensure correct battery polarities [ "+" and "–" ].

●After the unit has made a connection with the outdoor remote

sensor, the detected temperature and humidity will display on the

screen.

● For specic pairing operation of the weather station and remote

sensor, please refer to 9.1 Weather Station and Remote Sensor

Pairing on page 12.

5.3 Wireless Remote Sensor

7. Initial Time Setup

● Long press " " key for two seconds.

● The year display "2020" starts to ash. Press "▲" or "▼" to set

the correct year.

● Press " " to conrm your setting.

● The month display starts to ash. Press "▲" or "▼" to set the

correct month.

● Press " " to conrm your setting.

● The date display starts to flash. Press "▲" or "▼" to set the

correct date.

●Press " " to conrm your setting.

● "M" and "D" will be ashing, press "▲" or "▼" to set the date

display to Month/Date or Date/Month.

●Press " " to conrm your setting.

● The time displays either in 12 or 24 hour format. Press "▲" or

"▼" to choose 12hr or 24hr.

●Press " " to conrm your setting.

● The hour display starts to flash. Press "▲" or "▼" to set the

correct hour.

● Press " " to conrm your setting.

● The minute display starts to ash. Press "▲" or "▼" to set the

correct minute.

●Press " " to conrm your setting.

● The weather icon display starts to ash. Press "▲" or "▼" to set

the weather of the day. Please set the weather icon according to

the real-time weather condition outside.

● Press " " to conrm your setting and complete the setup.

8. Dual Alarm Setting

Note:

During the setup, if there is no operation of buttons within 20

seconds, the weather station will save the current setting and

automatically return to normal display from manual setting mode.

8.1 How to Check Your Alarms

Press " " key.

Press 1x: Display time of alarm 1

Press 2x: Display time of alarm 2

Press 3x: Display current time

8.2 Activate/Deactivate the Alarm Function

●When the switch of alarm 1 or alarm 2 on the back of the

weather station is moved to "ON" position, the symbol " " or " "

will appear on the screen. The alarm function is activated.

●When the switch of alarm 1 or alarm 2 on the back of the weather

station is moved to "OFF" position, the symbol " " or " " will

disappear from the screen. The alarm function is deactivated.

8.3 Manual Setting of the Alarms

Please make sure the alarm switches are moved to "ON" before

manually setting the alarms.

11 12

●Press and hold " " key for two seconds, the hour of alarm 1

starts to ash.

● Press "▲" or "▼" keys to set the required hour.

●Press " " to conrm your setting.

● The minute of alarm 1 starts to ash. Press "▲" or "▼" to set the

required minute.

●Press " " to conrm your setting.

● The hour of alarm 2 starts to ash. Press "▲" or "▼" to set the

required hour.

●Press " " to conrm your setting.

● The minute of alarm 2 starts to ash. Press "▲" or "▼" to set the

required minute.

●Press " " to save and complete the setup.

8.4 Turn off the Alarm Tone

The alarm will ring for 2 minutes, pressing any button except

"SNOOZE/LIGHT" will stop the tone. The alarm will repeat at the

same time the next day.

8.5 Snooze Function

Proceed as follows to activate snooze function.

9.1 Weather Station and Remote Sensor Pairing

Weather station:

—Connect the weather station to power supply.

—Select a channel that permanently displays on the weather

station. Press " " button to select CH1, CH2 or CH3.

—After the weather station is powered on, the RF signal icon

located on the upper left side of the "OUTDOOR" column

will flash for 3 minutes. This indicates that the weather station

is in synchronization mode and waiting for the remote sensor to

connect.

—If the RF signal icon stops ashing after 3 minutes, long press

"SENSOR" button on the back of the weather station to activate the

weather station synchronization mode. The RF signal icon will

ash again.

●While the alarm is ringing, touch "SNOOZE/LIGHT" to activate

the snooze function. When the snooze function is activated, " "

or " " will keep ashing on the display. The alarm will ring again in

5 minutes.

●When the snooze function is activated, press any button except

"SNOOZE/LIGHT" to exit the snooze mode.

●If alarm 2 rings during the snooze mode of alarm 1, the snooze

function of alarm 1 will automatically be deactivated.

Note:

During the setup of the alarms, if there is no operation of buttons

within 20 seconds, the weather station will save the current setting

and automatically return to normal display from manual setting

mode.

9. Weather Station and Remote Sensor

Pairing & Manual Signal Reception

13 14

Wireless Remote Sensor:

—Select a same channel with the weather station for the remote

sensor. Open the battery compartment of the remote sensor to

select channel with numbered knobs (1, 2, and 3).

—Insert 2 x AA batteries in the remote sensor. The indicator

will light up once to indicate that the wireless remote sensor is

sending out signals. Please ensure that the weather station is in

synchronization mode so that it can receive the signals sending

from the remote sensor.

—When the weather station successfully receives signals from

the remote sensor, the temperature and humidity detected by the

remote sensor will display on "OUTDOOR" column of the weather

station.

—The weather station can connect up to 3 wireless remote sensors

at the same time. If multiple sensors are used simultaneously,

please repeat 9.1 Weather Station and Remote Sensor Pairing

to connect other remote sensors. Please make sure these sensors

are on different channels.

—Press " " button on the weather station to view the readings of

each channel.

9.2 Loop Mode

This mode is applicable in the event that multiple wireless remote

sensors are used simultaneously.

— Press " " button on the weather station until " " is displaying

in the top left corner of outdoor temperature area. In this mode, the

outdoor readings will display from CH1 to CH3 automatically every

5 seconds.

—To see the temperature and humidity on a fixed channel, just

press " " button until " " disappears. Once it disappears, the

outdoor readings will stop cycling.

9.3 Manual Signal Reception

If there is no outdoor temperature showing on weather station or

there is no change in the temperature and humidity for a long time,

it indicates that the weather station fails to receive signals from

wireless remote sensor, please take the following operations:

—Please ensure that the channels of the weather station and

sensor are same.

—Long press "SENSOR" button on the back of the weather station

to receive signals manually. A flashing RF antenna symbol will

display beside the channel. This means that the weather station is

in a receiving state.

—Press "TX" button on wireless remote sensor to send out signals

manually and a red light will ash.

Note:

●In the case of using only one sensor, when the channel of the

weather station is not same as the channel of the sensor, there

would be no outside temperature showing on the weather station.

●The wireless sensor can be placed anywhere (indoor or outdoor)

you want to measure the temperature remotely.

15 16

10. Temperature & Humidity

10.1 °C/°F Selection

Weather station:

Press "°C/°F" button on the weather station to choose the

temperature display unit.

Sensor:

Open the battery compartment cover and press "°C/°F" button to

choose the temperature display unit on the sensor.

10.2 How to Set Temperature & Humidity Alert

Press "ALERT" on the back of the weather station to activate or

deactivate the temperature and humidity alert. The icon " " will

appear or disappear on the screen.

Choose the channel you want to start setting the temperature and

humidity alert as follows:

●Long press "ALERT" until " "and the outdoor temperature are

ashing. Press "▲" or "▼" to set the required maximum outdoor

temperature. Press " ALERT" to conrm your setting.

●When " " and the outdoor temperature are ashing, press "▲"

or "▼" to set the required minimum outdoor temperature. Press

"ALERT" to conrm your setting.

●When " " and the outdoor humidity are flashing, press "▲"

or "▼" to set the required maximum outdoor humidity. Press

"ALERT" to conrm your setting.

●When " " and the outdoor humidity are ashing, press "▲" or

"▼" to set the required minimum outdoor humidity. Press " ALERT"

to conrm your setting.

●When " " and the indoor temperature are ashing, press "▲"

or "▼" to set the required maximum indoor temperature. Press

"ALERT" to conrm your setting.

●When " " and the indoor temperature are ashing, press "▲"

or "▼" to set the required minimum indoor temperature. Press

"ALERT" to conrm your setting.

●When " " and the indoor humidity are flashing, press "▲" or

"▼" to set the required maximum indoor humidity. Press "ALERT"

to conrm your setting.

●When " " and the indoor humidity are flashing, press "▲" or

"▼" to set the required minimum indoor humidity. Press "ALERT" to

conrm your setting.

●If you want to set the alert values of the other 2 channels, please

press " " to change the channel and repeat the steps above.

●When the temperature or humidity reaches the set value of

the alert, " " or " " and the temperature or humidity will start

ashing and a beep will arise for 5 seconds. Pressing any button

can temporarily stop the alarm, however " " or " " will still keep

ashing on the screen. The alert will restart in one minute unless

it is deactivated or the temperature and humidity return to the set

range. To completely end the alarm, please press "ALERT".

●If you want to measure the outdoor temperature, please place

the sensor outside away from direct sunlight and rain such as

under eaves or on a porch.

Autres manuels pour SC93

Table des matières

Autres manuels Smartro Station météorologique

Smartro

Smartro SC93 Manuel utilisateur

Manuels Station météorologique populaires d'autres marques

Auriol

Auriol AHFL 433 A1 Manuel utilisateur

NexSens

NexSens G2-HYDROMET Manuel utilisateur

Hyundai

Hyundai WS 2202 Manuel utilisateur

IROX

IROX HBVR761 UV-X Manuel utilisateur

La Crosse Technology

La Crosse Technology C86371 Manuel utilisateur

ADE

ADE WS 1711 Manuel utilisateur

Auriol

Auriol z29592 Manuel utilisateur

Auriol

Auriol 296289 Manuel utilisateur

Hyundai

Hyundai WS 2266 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-2210 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-811561 Manuel utilisateur

Ventus

Ventus W177 Manuel utilisateur

National Geographic

National Geographic VA Colour RC Manuel utilisateur

Renkforce

Renkforce 1208067 Manuel utilisateur

Levenhuk

Levenhuk Discovery Report WA40 Manuel utilisateur

Instant Transmission

Instant Transmission MA 10410 Manuel utilisateur

Lutron Electronics

Lutron Electronics PHB-318 Manuel utilisateur

WAREMA

WAREMA EWFS Weather station eco Manuel utilisateur
