Conﬁguration and User’s Guide

SMART Board™ 600i3

Interactive Whiteboard System

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in

a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the manufacturer’s instructions, may cause harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his

own expense.

Trademark Notice

SMART Board, GoWire, smarttech and the SMART logo are trademarks or registered trademarks of SMART Technologies ULC in the U.S.

and/or other countries. Bluetooth is a trademark owned by Bluetooth SIG, Inc. and is used by SMART Technologies ULC under license. All

other third-party product and company names may be the trademarks of their respective owners.

stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART

Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part

of SMART.

Patent No. US6320597; US6326954; US6540366; US6741267; US7151533; US7184030; US7289113; and CA2058219. Other patents pending.

Printed in USA. 03/2009.

If you register your SMART product, we’ll notify you of new features and

software upgrades.

www.smarttech.com/registration.

Keep the following information available, in case you need to contact

Technical Support:

Serial Number

Date of Purchase

Registration Benefits

99-00915-20 B0 Important Information i

Important Information

Read This Section First

NOTE: If you own a SMART product other than a SMART Board™ 600i3 interactive whiteboard system, refer to

the installation guide that came with your product for relevant warnings and maintenance instructions.

In this document, “SMART Board 600i3 interactive whiteboard system” refers to the SMART Board 600 series

interactive whiteboard and its UF55/UF55w projector, accessories and optional equipment. Before you install and

use the SMART Board 600i3 interactive whiteboard system, read and understand the safety warnings and

precautions in this user’s guide, the projector user’s guide and the warnings document. These safety warnings

and precautions describe the safe and correct operation of the interactive whiteboard system and its

accessories, helping you prevent injuries and equipment damage. You must always ensure that the interactive

whiteboard system is being used correctly.

The UF55/UF55w projector included with your system is designed to work only with certain SMART Board

interactive whiteboard models. Contact your authorized SMART reseller for more information.

ii Important Information 99-00915-20 B0

Safety Warnings

WARNING • If the projector is mounted on the projector’s arm, the manufacturer recommends contacting

your authorized SMART reseller to exchange the lamp.

• Uncovering the lamp while the projector is mounted on a projector’s arm might lead to

product damage or personal injury from falling pieces of glass if the lamp is broken.

• Remove the projector from the projector’s arm before servicing the lamp. Complete the

procedure described in this document before following the instructions included in your

replacement lamp box.

• Avoid turning off the projector during the lamp ignition phase as this may lead to premature

lamp failure. Before turning the projector off, keep the lamp on for a minimum of 15 minutes

after turning it on to preserve the lamp life.

• This projector detects its own remaining lamp life. Replace the lamp when lamp life warning

messages appears.

• When the lamp is approaching the end of its life, the message “Lamp is approaching the end

of its useful life in full power operation” appears on the screen. Contact your

authorized SMART reseller or service center to change the lamp as soon as possible.

• Refer to the safety warnings and precautions published by the projector manufacturer.

• Never replace the lamp assembly with a previously-used lamp assembly.

• To prevent premature lamp failure or exposure to mercury, always handle the fragile lamp

assembly with care. Use gloves when touching the lamp. Do not touch the lamp with

your fingers.

• Do not attempt to service the projector other than performing routine lamp replacement.

Service should be performed only by an authorized service provider. Other than the lamp

module, there are no user-serviceable parts inside the unit.

• Replacing the lamp in a boom-mounted projector might result in a fall or injury.

• Do not remove any screws other than those specified in the lamp replacement instructions.

• The lamp used in the UF55/UF55w projector contains mercury. Recycle or dispose of it as

hazardous waste, in accordance with local regulations.

• If you continue to use the projector after the replacement message appears, the lamp might

shatter or burst, scattering glass throughout the projector head.

• If the lamp has shattered or burst, do not touch the glass fragments because they might

cause injury. Leave and then ventilate the area where the lamp shattered or burst. Wash

your hands thoroughly if you have come into contact with lamp debris. Thoroughly clean the

area around the projector, and discard any edible items placed in that area because they

might be contaminated.

• If the lamp has shattered or burst, call an authorized SMART reseller for instructions.

Do not attempt to replace the lamp.

• Wear protective eyewear while changing the lamp. Failure to do so can cause injury or loss

of eyesight if the lamp shatters or bursts.

• Cleaning a boom-mounted projector may result in a fall or injury.

WARNING • Use only replacement lamps approved by SMART Technologies. Contact your authorized

SMART reseller for replacement parts.

• Turn the projector off and wait 30 minutes for the lamp to cool completely before removing

the old lamp assembly.

• Do not stare (or allow children to stare) directly into the beam of light created by the

projector. Instruct children not to look in the direction of, or stare at, this beam of light.

Encourage users to keep their back to the projector when working at the interactive

whiteboard. Before they turn to face the audience, users should step sideways, out of the

projector’s beam.

• Do not climb (or allow children to climb) on any part of

your wall-mounted SMART Board interactive

whiteboard system.

• Do not open or disassemble the projector as this may

cause electric shock.

• Ensure that any cables extending across the floor to your

SMART product are properly bundled and marked to

prevent a trip hazard.

• To reduce the risk of fire or electric shock, do not expose

any component of your SMART Board interactive

whiteboard system to rain or moisture.

• When mounting the projector on a framed wall, you must

attach both the mounting bracket and safety tether to a

stud to safely support the projector’s weight. If you use only drywall anchors, the drywall can

fail, resulting in product damage and possible personal injury.

• If you remove the bolt supporting the limit strap, the projector’s arm will be free to swing.

Make sure that the bolt is tightened, and never remove it from the unit without supporting the

projector’s arm first.

• Two people are required to mount the projector and the interactive whiteboard on a wall

because they might be too heavy for one person to maneuver onto their

wall-mounting brackets.

• Climbing on the interactive whiteboard or projector arm could result in personal injury or

product damage. Do not climb on, hang from or suspend objects from the UF55/UF55w

projector’s arm.

• Make sure that an electrical socket is near to your SMART product and remains easily

accessible during use.

• Two people are required to re-mount the projector.

99-00915-20 B0 Important Information iii

WARNING • Failure to follow the installation instructions shipped with your SMART product could result in

personal injury and damage to the product.

CAUTION • Never operate this unit immediately after moving it from a cold location to a warm location.

When the unit is exposed to such a change in temperature, moisture may condense on the

lens and crucial internal parts. Allow the system to reach room temperature before operation

to prevent possible damage to the unit.

• In a high altitude location where the altitude is over 6000' (1828.8 m), where the air is thin,

cooling efficiency is reduced, so use the projector with the fan mode set to High.

• Do not place in hot locations, such as near heating equipment. Doing so could cause a

malfunction and shorten the life of the projector.

• Before you clean the UF55/UF55w projector, put the system into Idle mode by pressing the

power button twice on the ECP or remote, and allow the bulb to cool for 30 minutes.

• Do not allow liquids or commercial solvents of any kind to flow into the projector base or

head. Do not use spray cleaners or solvents near any part of the projector, as it may damage

or stain the unit.

• Cycling power to the projector repeatedly can lock or damage the interactive whiteboard

system. After you turn off the system, wait at least 15 minutes for cooling before starting the

system.

• Do not connect your serial cable directly to the projector’s RS-232 serial interface. The

extended control panel’s (ECP’s) RS-232 serial interface is the only recommended

connection point.

• You must connect the USB cable that came with your SMART Board interactive whiteboard

to a computer that has a USB compliant interface and that bears the USB logo. In addition,

the USB source computer must be compliant with CSA/UL/EN 60950 and bear the CE mark

and CSA and/or UL Mark(s) for CAS/UL 60950. This is for operating safety and to prevent

damage to the SMART Board interactive whiteboard.

IMPORTANT • Using the UF55/UF55w projector system near a TV or radio may cause interference to the

images or sound. If this happens, move the TV or radio away from the projector.

• Securing the pen tray can provide theft deterrence for the interactive whiteboard.

The screws that secure the interactive whiteboard to the wall are located directly behind the

pen tray. The pen tray must be removed before you can remove the interactive whiteboard.

When you secure the pen tray, you also secure the interactive whiteboard.

• The SMART Board 600i3 interactive whiteboard system does not include speakers. Consult

your authorized SMART reseller to determine your audio output options.

• If you have peripheral devices that do not use a 4-pin mini-DIN connector or an RCA

composite video jack, or if your device has an audio connection that does not use RCA

jacks, you may need to purchase third-party adapters.

• Wipe the exterior of the projector using a lint-free cloth.

iv Important Information 99-00915-20 B0

99-00915-20 B0 Important Information v

Other Precautions

To ensure operating safety and to avoid product damage, observe the following precautions.

• Turn off the product before cleaning it.

• Use a soft cloth moistened with a mild detergent to clean the projector housing.

• Do not use abrasive cleaners, waxes or solvents to clean the unit.

• Disconnect the power plug from the AC outlet if the product is not being used for a long period of time.

• Do not block the ventilation slots and openings on the unit.

• Do not place the interactive whiteboard system near any appliance that generates a strong magnetic field.

• Do not place the interactive whiteboard system in direct sunlight.

• Do not set up or use the interactive whiteboard in an area with excessive levels of dust, dirt, humidity

or smoke.

• Do not add extra weight or apply pressure to the UF55/UF55w projector boom, the wall-mounted interactive

whiteboard or its pen tray. SMART Technologies designed the brackets to support only the weight of the

components during normal use.

• To reduce the risk associated with a leaking battery in your projector’s remote control:

– use only a coin-cell type battery

– orient the battery’s plus (+) and minus (-) terminal according to the markings on the remote control

– do not leave the battery in the remote control for an extended period

– do not heat, disassemble, short or recharge the battery, or expose it to fire or high temperatures

– avoid eye and skin contact if the battery has a leak

– dispose of the exhausted battery and product components in accordance with applicable regulations

• If the interactive whiteboard system requires replacement parts, make sure that the service technician uses

replacement parts specified by SMART Technologies, or parts with the same characteristics as the original.

Transporting the SMART Board 600i3 Interactive Whiteboard System

If you need to ship any part of your SMART Board 600i3 interactive whiteboard system, repack it with the original

packaging. If the original packaging is no longer available, you may purchase replacement packaging from your

authorized SMART reseller.

If you prefer to use your own packaging materials, make sure that you adequately protect the unit. Ship the

interactive whiteboard in an upright position to deter shippers from placing heavy objects on it.

vi Important Information 99-00915-20 B0

99-00915-20 A0 Table of Contents vii

Table of Contents

Important Information i

Read This Section First................................................................................................................................... i

Safety Warnings............................................................................................................................................. ii

Other Precautions .......................................................................................................................................... v

Transporting the SMART Board 600i3 Interactive Whiteboard System ......................................................... v

Table of Contents vii

About Your SMART Board 600i3 Interactive Whiteboard System 1

SMART Board 600i3 Interactive Whiteboard System Features ..................................................................... 2

Standard Accessories .................................................................................................................................... 4

Optional Accessories ..................................................................................................................................... 4

Installing Your SMART Board 600i3 Interactive Whiteboard System 7

Environmental Requirements......................................................................................................................... 8

Before Installing Your SMART Board 600i3 Interactive Whiteboard System ................................................. 9

After Installing Your SMART Board 600i3 Interactive Whiteboard System .................................................. 10

Focusing the Image...................................................................................................................................... 11

Performing an Image Alignment................................................................................................................... 12

Securing the Pen Tray and the Interactive Whiteboard ............................................................................... 16

Connecting Your SMART Board 600i3 Interactive Whiteboard System 19

Installing SMART Notebook Software .......................................................................................................... 19

Connecting the Cables to the UF55/UF55w Projector ................................................................................. 20

Using Your SMART Board 600i3 Interactive Whiteboard System 27

Turning the System On and Off and Selecting an Input............................................................................... 27

Using Your Interactive Whiteboard............................................................................................................... 28

Using Your UF55/UF55w Projector .............................................................................................................. 28

Troubleshooting Your SMART Board 600i3 Interactive Whiteboard System 33

System Warning Lights ................................................................................................................................ 33

Errors ........................................................................................................................................................... 34

Interactive Whiteboard Indicators and Controls ........................................................................................... 36

Maintaining Your SMART Board 600i3 Interactive Whiteboard System 37

Preventing Damage to Your Interactive Whiteboard .................................................................................... 37

Cleaning Your Interactive Whiteboard.......................................................................................................... 37

Cleaning the Pen Tray ................................................................................................................................. 38

Cleaning the UF55/UF55w Projector ...........................................................................................................39

Locating Your Projector Serial Number ........................................................................................................ 40

Appendix A: Replacing Your UF55/UF55w Projector Lamp 41

Replacing the Projector Lamp...................................................................................................................... 41

viii Table of Contents 99-00915-20 A0

Appendix B: Remotely Managing Your SMART Board 600i3 Interactive Whiteboard System 51

Programming Commands for Your SMART Board 600i3 Interactive Whiteboard System Settings.............51

Command Inventory.....................................................................................................................................54

Hardware Environmental Compliance 63

Waste Electrical and Electronic Equipment Regulations (WEEE Directive).................................................63

Restriction of Certain Chemicals (REACH Directive) ................................................................................... 63

Restriction of Certain Hazardous Substances (RoHS) Directives................................................................63

Batteries .......................................................................................................................................................63

Packaging ....................................................................................................................................................63

China’s Electronic Information Products Regulations ..................................................................................64

U.S. Consumer Product Safety Improvement Act........................................................................................64

Customer Support 65

Online Information and Support ................................................................................................................... 65

Training ........................................................................................................................................................65

Technical Support.........................................................................................................................................65

Shipping and Repair Status..........................................................................................................................65

General Inquiries.......................................................................................................................................... 65

Registration ..................................................................................................................................................65

Warranty.......................................................................................................................................................66

Index 67

Table des matières

Autres manuels SMART Board Tableau blanc interactif

SMART Board

SMART Board 685ix Manuel utilisateur

SMART Board

SMART Board Board X800 Series Manuel utilisateur

SMART Board

SMART Board Board 600 Series Manuel utilisateur

SMART Board

SMART Board M600 series Manuel utilisateur

SMART Board

SMART Board Board 800 series Manuel utilisateur

SMART Board

SMART Board 885ix-SMP Manuel utilisateur

SMART Board

SMART Board 600i4 Manuel utilisateur

SMART Board

SMART Board Board 600i6 Manuel utilisateur

SMART Board

SMART Board Board 2000i Manuel utilisateur

SMART Board

SMART Board SBID8055i-G5-SMP Manuel de service

SMART Board

SMART Board 400 series Guide de configuration

SMART Board

SMART Board 8070i-G4-SMP Manuel d'utilisation

SMART Board

SMART Board SBID 8055i Manuel utilisateur

SMART Board

SMART Board SB880i5-SMP Manuel utilisateur

SMART Board

SMART Board M600ix3 Manuel utilisateur

SMART Board

SMART Board Board 600iv Manuel utilisateur

SMART Board

SMART Board 880-SMP Manuel utilisateur

SMART Board

SMART Board D685ix Manuel utilisateur

SMART Board

SMART Board 480i6 Manuel utilisateur

SMART Board

SMART Board SB660 64" Manuel utilisateur

SMART Board

SMART Board SB685ix2 Manuel utilisateur

SMART Board

SMART Board 800i6 Manuel utilisateur

SMART Board

SMART Board Board 800ix2 Manuel utilisateur

SMART Board

SMART Board Board 800 series Manuel utilisateur

Manuels Tableau blanc interactif populaires d'autres marques

SMART

SMART KAPP42 Manuel utilisateur

HitachiSoft

HitachiSoft StarBoard FX-TRIO-88W Manuel utilisateur

Buhl

Buhl LyteBoard Manuel utilisateur

SMART

SMART SBX880 Manuel utilisateur

Legamaster

Legamaster e-SCREEN ETX Manuel utilisateur

Seneca

Seneca eno Manuel utilisateur

BenQ

BenQ RP840G Manuel utilisateur

SMART

SMART Sympodium IC-150 Manuel utilisateur

Olivetti

Olivetti OLIBOARD Manuel utilisateur

Turning Technologies

Turning Technologies MOBIVIEW Manuel utilisateur

Panasonic

Panasonic UB-5335 Manuel utilisateur

Dukane

Dukane ITP84 Manuel utilisateur

Bretford

Bretford EDUIMS Guide de configuration

Panasonic

Panasonic Panaboard UB-5315 Manuel utilisateur

Plus

Plus M-11S Manuel utilisateur

TRIUMPH BOARD

TRIUMPH BOARD ULTRA SLIM Manuel utilisateur

Returnstar Interactive Tech

Returnstar Interactive Tech IQBoard DVT V7.0 Manuel utilisateur

AVer

AVer CP series Manuel utilisateur
