Skytech AF-4000HAT Manuel utilisateur
Model: AF-4000HAT (Home Automation Transmitter)
DESCRIPTION: The AF-4000HAT is a simple transmitter compatible with home automation systems to turn ON and OFF
a gas re feature. The home automation system sends an ON command to close the dry contacts of the AF-4000HAT.
The transmitter receives the command then it sends a wireless RF signal to the gas re feature to turn it ON. When the
home automation systems sends a command to turn OFF the AF-4000HAT transmitter sends a wireless RF signal to turn
OFF the gas re feature.
This AF-4000HAT is designed to operate with the following Skytech Products Group control modules: AF-4000MOD-1,
AF-4000MOD## SERIES, VCS-4000MODTC, VCS-4000MODS01,VCS-4000S-1TC, AF-5000MOD-1, VCS-5000MODTC,
VCS-ECOMOD, VCS-ECOMODODS, VCS-ECOMODPVI.
Low voltage wire (not provided) from the Home Automation System must connect directly to the AF-4000HAT transmitter
and must be located within 20-feet of the control module.
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
NOT ATTEMPT TO INSTALL OR OPERATE THIS PRODUCT
CONTENTS
Fig. 1 Basic Operation of the AF-4000HAT System
OFF AUTO
ACTIVE
OFF
HOME AUTOMATION LINK
Fig. 2 Contents: (1) HAT transmitter, (1) Face plate (1) Bolt bag with screws
and slide button (4) AA Batteries (not shown)
Skytech AF-4000HAT
Pool/Home
Automation
System
ACTIVE
OFF
HOME AUTOMATION LINK
Wireless RF Signal
Low Voltage
Wire
(Dry Contact Switch)
Gas Logs / Gas Fireplace
Or
Outdoor Gas Fire Feature
REV. 3-8-16 Page 1
fire-parts.com
INSTALLATION
Step 1: Find a suitable location to install the
transmitter into a plastic junction box within
20-feet of the re feature.
Step 2: Install the (4) AA batteries into the
transmitter. Fig. 4
Step 3: Run low voltage wire from the Home
Automation System to the junction box. Fig. 5
Step 4: Insert the low voltage wire into the
back of the transmitter securing each wire
into separate tabs and tightening the screws
to hold each wire. NOTE: Wires are not
polarity sensitive. Gently tug the wires to
ensure they are secure. See g. 5.
Step 5: Secure the transmitter into the face
plate by snapping it into place. Fig 6.
Step 6: Install the transmitter into the
junction box, attach slide button and
installation is complete. See g. 7.
Fig. 6 Securing transmitter to face plate.
Fig. 5 Inserting thermostat wire.
Skytech AF-4000HAT
Fig. 7. Installing transmitter into junction box.
WALL
Plastic Switch Box
Transmitter
Wall Cover Plate
ACTIVE
OFF
HOME AUTOMATION LINK
Transmitter
Slide Button
DESCRIPTION OF TRANSMITTER POSITIONS
ACTIVE
OFF
HOME AUTOMATION LINK
ACTIVE - Position enables the user to operate the appliance with a home
automation system including a hand held remote control.
OFF - Sends a wireless RF signal to turn OFF the appliance and ignores
any commands from the Home Automation System. It will allow the
appliance to be operated with a hand held remote (if applicable).
Fig. 3. Transmitter positions.
REV. 3-8-16 Page 2
Requires 4-AA 1.5V
alkaline batteries
Battery cover slides on/off
Slide Switch
to OFF or
AUTO
OFF | AUTO
Fig. 4 Installing AA batteries.
fire-parts.com
LEARNING THE AF-4000HAT TO THE CONTROL MODULE
Skytech AF-4000HAT
NOTE: The AF-4000HAT is designed to operate with AF-4000MOD-1, AF-4000MOD## SERIES, VCS-4000MODTC,
VCS-4000MODS01,VCS-4000S-1TC, AF-5000MOD-1, VCS-5000MODTC, VCS-ECOMOD, VCS-ECOMODODS, VCS-
ECOMODPVI.
Step 1: Ensure the control module REMOTE/OFF switch in the
REMOTE position. See g. 8.
Step 2: Slide AF-4000HAT switch to the ACTIVE position. See Fig.9
Step 3: Press and release the LEARN button on the control module and
listen for a “beep”. See g. 9.
Step 4: Slide the AF-4000HAT switch to the OFF position. See g. 11.
The module will emit several beeps indicating the
AF-4000HAT is now programmed and will operate with the
Home Automation System when the switched is placed back
in the ACTIVE position as shown in g. 9.
Learn Button
AUX
POWER
PEN
MODULE
Fig. 10 Learn button on control module.
ACTIVE
OFF
HOME AUTOMATION LINK
Fig. 9 AF-4000HAT switch
to ACTIVE position.
ACTIVE
OFF
HOME AUTOMATION LINK
Fig. 11 AF-4000HAT switch
to OFF position.
IMPORTANT NOTE: The AF-4000HAT only controls ON/OFF of gas re feature; not the Hi/Lo operation. The control
modules can “learn” more than one transmitter, which may have Hi/Lo control allowing the use of a hand held
transmitter in conjunction with the AF-40000HAT. Check with your dealer to nd out which wireless hand held transmitter
can be used with your system.
Remote/Off
SI
ADJ.
IPI
POWER
Learn AUX
REV. 3-8-16 Page 3
Fig. 8 Remote switch position.
fire-parts.com
Skytech AF-4000HAT REV. 3-8-16 Page 4
FCC REQUIREMENTS
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
FOR TECHNICAL U.S. INQUIRIES CANADIAN INQUIRIES
SERVICE CALL: (855) 498-8324or (260) 459-1703 (877) 472-3923
For Sales: (888) 672-8929
Website: skytechpg.com
MANUFACTURED EXCLUSIVELY FOR SKYTECH II, INC
SPECIFICATIONS
BATTERIES: Transmitter (4) AA 1.5 Volts, Alkaline
FCC ID No.’s: Transmitter – K9LAF4HAT
O p e r a t i n g F r e q u e n c y : 3 0 3 . 8 M H Z
Canadian IC ID No.’s: transmitter – 2439-AF4HAT
TROUBLESHOOTING
If you encounter problems with your AF-4000HAT, the problem may be with either the re feature or the home automation
system. Review all installation manuals to ensure all connections are properly made.
• Make sure the AA batteries are installed correctly and are fully charged.
• Be sure the AF-4000HAT transmitter is installed within 20-feet of the re feature.
• Ensure the transmitter is not installed in a tightly enclosed metal box. This will affect the operating distance.
• Check the wires connected to the transmitter. Ensure the wires are snug and not loose as shown in gure 5.
• Make sure the AF-4000HAT transmitter is communicating to the control module (see learning transmitter to module on
page 3).
• Keep the AF-4000HAT transmitter from exceeding temperatures of 130°F. Battery life will be shortened when
exposed to high temperatures.
• Change batteries at least once a year. If using outdoors batteries may need changed more often due to weather.
• If the AF-4000HAT transmitter is not sending a signal check to ensure the switch is in the ACTIVE position.
fire-parts.com
