PARTS CHECKLIST
N° DESCRIPTION PART NUMBER
1 BUTTONHEADPLASTICSCREWM3X10MM SKH07-110
2 MAINFRAMELITTLESPYDERUP SKH03-005-U
3 HALFFRAMESPACER SKH01-102
4 STANDOFFLITTLE SKH07-110
5 BUTTONHEADSCREWM3X6MM SKH07-110
6 FRAMESPACERBLACK SKH01-002-BK
7 MOTOR(SKYHEROX2806950KV*)SKH04-007(*)
8 MOTORFRAMEBLACK SKH01-005-BK
9 WASHERM3 SKH07-110
10 ESC(20AMP4SSimonKOpto*)SKH04-008(*)
11 TUBEFRONTLITTLESPYDER SKH03-064
12 TUBEREARLITTLESPYDER SKH03-064
13 INSERTARM30MM SKH01-004
14 SOCKETHEADSCREWM3X10MM SKH07-110
15 HEXNUTNYLSTOPM3 SKH07-110
16 BUTTONHEADSCREWM4X50MM SKH07-110
17 BUTTONHEADSCREWM4X40MM SKH07-110
18 KNURLBUTTONLONGM4 SKH07-110
19 HEXNUTNYLSTOPM4 SKH07-110
20 WASHERM4 SKH07-110
21 MAINFRAMELITTLESPYDERDOWN SKH03-005-D
22 ZENMUSESPACER SKH07-110
23 LANDINGSUPPORTLEFT SKH01-101
24 LANDINGSUPPORTRIGHT SKH01-101
25 PROPNUT SKH04-002
26 PROPSHAFTWASHER SKH04-002
27 10’’CLOCKWISEPROPELLER SKH04-005-L
28 10’’COUNTERCLOCKWISEPROPELLER SKH04-005-L
29 SOCKETHEADSCREWM3X8MM SKH04-002
30 PROPSHAFTAXIS SKH04-002
31 DAMPER SKH07-110
32 CAMPLATELITTLESPYDER SKH03-006
33 CANOPYLITTLESPYDER SKH05-044
34 CLIPS SKH07-110
35 GROMET SKH07-110
36 BATTERYSTRAP SKH08-003
37 MAINLOWERFRAMEOPTIONNALLITTLESPYDER SKH08-008
38 BUTTONHEADSCREWM3X10MM SKH08-008
39 SPACERFOROPTIONNALDEVICEPLATELITTLESPYDER SKH08-008
40 DEPORTEDDEVICEMOUNTINGPLATELITTLESPYDER SKH08-008
41 ZENMUSEPLATELITTLESPYDER SKH08-008
(*) INCLUDEDINFCRVERSION
OPTIONNALPARTS
QTY
20
1
2
1
16
2
8
16
2
2
4
28
28
4
4
6
2
4
1
4
1
1
3
1
1
1
1
1
1
14
4
1
3
