PARTS CHECKLIST
N° DESCRIPTION PART NUMBER
1 BUTTON HEAD PLASTIC SCREW M3 X 10MM SKH07-111
2 MAIN FRAME LITTLE 6 UP SKH03-011-U
3 HALF FRAME SPACER SKH01-102
4 MOTOR (SKY HERO X2806 950KV*) SKH04-007 (*)
5 MOTOR FRAME BLACK SKH01-005-BK
6 WASHER M3 SKH07-111
7 BUTTON HEAD SCREW M3 X 6MM SKH07-111
8 ESC (40 AMP 6S SimonK Opto*) SKH04-003 (*)
9 INSERT ARM BLACK SKH01-004-BK
10 ARMS SET LITTLE 6 (2FR 2MID 2R) SKH03-065
11 HEX NUT NYLSTOP M3 SKH07-111
12 SOCKET HEAD SCREW M3 X 10MM SKH07-111
13 TUBE FRONT LITTLE6 SKH03-065
14 TUBE MIDDLE LITTLE6 SKH03-065
15 TUBE REAR LITTLE6 SKH03-065
16 BUTTON HEAD SCREW M4 X 40MM SKH07-111
17 KNURL BUTTON LONG M4 SKH07-111
18 MAIN FRAME LITTLE 6 DOWN SKH03-011-D
19 ZENMUSE PLATE LITTLE 6 SKH08-009
20 WASHER M4 SKH07-111
21 HEX NUT NYLSTOP M4 SKH07-111
22 STANDOFF LITTLE SKH07-111
23 LANDING SUPPORT LEFT SKH01-101
24 LANDING SUPPORT RIGHT SKH01-101
25 BUTTON HEAD SCREW M4 X 12MM SKH07-111
26 CAM PLATE LITTLE 6 SKH03-013
27 DAMPER SKH07-111
28 CLIPS SKH07-111
29 GROMET SKH07-111
30 CANOPY LITTLE 6 SKH05-055
31 PROP NUT SKH04-002
32 PROP SHAFT WASHER SKH04-002
33 11’’ CLOCKWISE PROPELLER SKH04-008-L6
34 11’’ COUNTERCLOCKWISE PROPELLER SKH04-008-L6
35 SOCKET HEAD SCREW M3 X 8MM SKH04-002
36 PROP SHAFT AXIS SKH04-002
37 BATTERY STRAP SKH08-003
Q
24
1
6
6
12
24
24
6
6
1
42
42
2
2
2
12
10
1
1
10
4
2
1
1
4
1
3
2
2
1
6
6
3
3
24
6
1
