• Two compact dual bracket designs are available:
- The standard (under) roll configuration ensures the
blind skin can be fitted close to the window.
- The reverse (over) roll configuration provides a self
pelmet effect. Both dual brackets can be installed
with either same side or opposite end controls and
have universal mounting options.
• An optional patented integrated levelling device
makes it easy to adjust shades after mounting.
• Two standard linking systems are available:
- The standard connector set minimises the
intermediate gap on linked configurations.
- The optional aligner link maximises flexibility during
installation with a fine adjustment option for aligning
the level of the blinds.
• Both linking options have 15 degree play. This
provides an allowance for slightly misaligned
installations.
• An independent linking option is available for
configurations that require multiple operation.
• A 45 and 90 degree linking mechanism is also
available for bay and corner windows.
• A sleek (84mm projection) and contemporary head
box and fascia system are available in both an
anodised and powder coated finish (white, black or
magnolia) with colour coded endcaps.
• Both the head box and fascia system can be installed
in both reveal and face fit positions and have a snap
lock cover and plastic outlets for easy installation and
quiet operation.
• To obtain room darkening, the head box system can
be installed with side channels, available in matching
powder coated colours (white, black or magnolia) or
anodised finish.
Standard Dual Roller
Linked Blinds
Headbox System
