Acmeda RF400 Series Manuel utilisateur
AUTOMATE EL MOTORS / WALL MOUNTED REMOTE
PROGRAMMING INSTRUCTIONS
Electronic Limit Tubular Motor
Electronic
Electronic Limit + Built-in Receiver
433MHz CE
All controls support 433MHz
All controls support 230V/50Hz
These instructions show how to install, program and use Acmeda’s electronic limit tubular motors:
• Automate EL S45
• Automate Q EL S45 (quiet motor)
• Automate EL S60 (with collision control technology)
• Automate EL A50 (for open awnings)
• Automate EL A50/C (for cassette awnings)
• Automate C EL (Curtain motor)
These motors can be controlled with Automate RF 400 series remote devices:
• Automate RF401 (single channel)
• Automate RF415 (15 channel)
RF400 series Remote Control
1
2
3
AC
1
2
3
1
2
3
AC
1
2
3
1
2
3
AC
1
2
3
Only use
Acmeda tail
CIRCUIT INSTALLATION
Page. 1
OCT 2014
PROGRAMMING A SINGLE CHANNEL WALL MOUNTED REMOTE IN 5 SIMPLE STEPS
SINGLE CHANNEL RF401 REMOTE OVERVIEW
UP
STOP
DOWN
BEFORE YOU BEGIN:
PLACE CR2450 (3V) BATTERY INTO REMOTE AND CHECK
ALL MOTORS ARE SWITCHED OFF WHEN PRESSING
BUTTON SEQUENCE ALWAYS PRESS AND RELEASE
EACH BUTTON
STEP 1 PAIRING A MOTOR TO A REMOTE
a. Switch Motor Power On (motor will beep)
b. Ensure pairing commences within 10 seconds aer motor
has completed beeps and jolts
c. Press UP + STOP at the same me, twice
d. Press UP buon once
Motor will beep when each buon is pressed and to conrm pairing it will beep 3 mes and jolt.
STEP 2 CHECK DIRECTION
Press UP or DOWN buons and ensure blind is moving in correct direcon.
If working correctly proceed to Step 3.
Press and release buons.
UP/DOWN
TO CORRECT BLIND DIRECTION
Press buon on motor head for 5 seconds to change orientaon of blind.
Motor beeps & jolts to conrm change of direcon.
Check blind direcon again before proceeding to Step 3.
For instructional purposes, the following options have been shown:
Easy-Lock Chain Winder 'AC' Installation Brackets.
Top Fix installation.
'AC' BracketCover Caps
40mm Motor - Somfy.
Somfy Drive & Crown Wheels.
INSTALLATION
ROLLER BLINDS 40mm MOTORISATION
ENSURE 'NOTCH' OF CROWN WHEEL
LOCKS WITHIN GAP OF MOTOR HEAD.
ASSEMBLY INSTRUCTIONS
STEP 1:
Install Crown Wheel onto40mm Motor. Ensure 'notch' of Crown
Wheellocks within gap of Motor Head.
STEP 2:
Install Drive Wheelonto40mm Motor.
NOTE:
* For Elero Motors, use 'O' ring supplied by Elero to lock Drive Wheel to
40mm Motor.
* For Gaposa Motors, use Gaposa Retaining Clipto lock Drive Wheel
to40mm Motor.
* For Selve Motors, use plastic retaining clip supplied by Selve to lock
Drive Wheelto 40mm Motor.
STEP 3:
Mount 40mm Motor Disk Adaptor onto Motor headwith Counter
Sunk Screws.
ONLY USE WITH GAPOSA
Page 57
a. Press UP + STOP buons at the same me
b. Press UP buon once
c. Press UP + STOP buons at the same me
UP & STOP (x1) UP (x1) UP & STOP (x1)
a. Set desired upper limit posion, using the UP buon.
Press DOWN to readjust blind to desired posion.
b. When a more accurate seng is required put motor in
stepping mode by pressing UP+STOP at the same me while
motor is moving UP/DOWN
c. Once blind is at desired posion press STOP for 5 seconds
unl motor jolts.
Motor will jolt to conrm limit.
UP/DOWN STOP
(for 5 secs)
UP & STOP (x2) UP (x1)
Page. 2
STEP 3 PUT MOTOR IN LIMIT SETTING MODE
STEP 4 SET UPPER LIMIT
LCD SCREEN
UP
STOP
DOWN
FIFTEEN CHANNEL RF415 REMOTE OVERVIEW
a. Set desired lower limit posion using the DOWN buon.
Press UP to readjust blind to desired posion.
b. When a more accurate seng is required put motor in
stepping mode by pressing UP+STOP at the same me
while motor is moving UP/DOWN
c. Once blind is at desired posion, press STOP for 5 seconds unl motor jolts.
Motor will jolt to conrm limit.
UP/DOWN STOP
(for 5 secs)
a. Set desired favorite posion using UP or DOWN buons.
a. Press STOP for 5 secs unl motor conrms posion.
To conrm limit motor will jolt.
To send blind to favourite posion press STOP buon for 5 secs.
UP/DOWN STOP
(for 5 secs)
CANCEL LIMITS RETURN TO FACTORY SETTINGS
a. Press UP + STOP at the same me and release.
b. Press DOWN buon once.
c. Press UP + STOP at the same me and release.
UP/STOP DOWN (x1) UP/STOP
a. Press UP + STOP at the same me and release.
b. Press STOP buon once.
c. Press UP + STOP at the same me and release.
UP/STOP STOP (x1) UP/STOP
PROGRAMMING A 15 CHANNEL WALL MOUNTED REMOTE IN 5 SIMPLE STEPS
BEFORE YOU BEGIN:
PLACE CR2450 (3V) BATTERY INTO REMOTE
AND CHECK ALL MOTORS ARE SWITCHED OFF
WHEN PRESSING BUTTON SEQUENCE ALWAYS
PRESS AND RELEASE EACH BUTTON
Motor will beep when each buon is pressed and to conrm pairing it will beep 3 mes and jolt.
a. Switch Motor Power On (motor will beep)
b. Ensure pairing commences within 10 seconds aer motor
has completed beeps and jolts
c. Press P2 twice
d. Press UP once
CHANNEL
SELECTION
P2
P2 (x2) UP (x1)
Page. 3
STEP 5 SET LOWER LIMIT
FOR AUTOMATE Q S45 & S60 MOTOR ONLY SET FAVOURITE POSITION
STEP 1 PAIRING A MOTOR TO A REMOTE
STEP 2 CHECK DIRECTION
Press UP or DOWN buons and ensure blind is moving in correct direcon.
If working correctly proceed to Step 3.
Press and release buons.
UP/DOWN
TO CORRECT BLIND DIRECTION
Press buon on motor head for 5 seconds to change orientaon of blind.
Motor beeps & jolts to conrm change of direcon.
Check blind direcon again before proceeding to Step 3.
For instructional purposes, the following options have been shown:
Easy-Lock Chain Winder 'AC' Installation Brackets.
Top Fix installation.
'AC' BracketCover Caps
40mm Motor - Somfy.
Somfy Drive & Crown Wheels.
INSTALLATION
ROLLER BLINDS 40mm MOTORISATION
ENSURE 'NOTCH' OF CROWN WHEEL
LOCKS WITHIN GAP OF MOTOR HEAD.
ASSEMBLY INSTRUCTIONS
STEP 1:
Install Crown Wheel onto40mm Motor. Ensure 'notch' of Crown
Wheellocks within gap of Motor Head.
STEP 2:
Install Drive Wheelonto40mm Motor.
NOTE:
* For Elero Motors, use 'O' ring supplied by Elero to lock Drive Wheel to
40mm Motor.
* For Gaposa Motors, use Gaposa Retaining Clipto lock Drive Wheel
to40mm Motor.
* For Selve Motors, use plastic retaining clip supplied by Selve to lock
Drive Wheelto 40mm Motor.
STEP 3:
Mount 40mm Motor Disk Adaptor onto Motor headwith Counter
Sunk Screws.
ONLY USE WITH GAPOSA
Page 57
P2 (x1) UP (x1) P2 (x1)
a. Set desired upper limit posion, using the UP buon.
Press DOWN to readjust blind to desired posion.
b. When a more accurate seng is required put motor in
stepping mode by pressing UP+STOP at the same me while
motor is moving UP/DOWN
c. Once blind is at desired posion press STOP for 5 seconds unl motor jolts.
Motor will jolt to conrm limit.
UP/DOWN STOP
(for 5 secs)
UP/DOWN STOP
(for 5 secs)
Refer Page 3 for instrucons.
P2 (x1) P2 (x1)DOWN (x1) P2 (x1) P2 (x1)STOP (x1)
Page. 4
a. Press P2 buon once
b. Press UP buon once
c. Press P2 buon once
STEP 3 PUT MOTOR IN LIMIT SETTING MODE
STEP 4 SET UPPER LIMIT
a. Set desired lower limit posion using the DOWN buon.
Press UP to readjust blind to desired posion.
b. When a more accurate seng is required put motor in
stepping mode by pressing UP+STOP at the same me
while motor is moving UP/DOWN
c. Once blind is at desired posion, press STOP for 5 seconds unl motor jolts.
Motor will jolt to conrm limit.
STEP 5 SET LOWER LIMIT
CANCEL LIMITS RETURN TO FACTORY SETTINGS
a. Press P2 buon once
b. Press DOWN buon once
c. Press P2 buon once
a. Press P2 buon once
b. Press STOP buon once
c. Press P2 buon once
FOR AUTOMATE Q S45 & S60 MOTOR ONLY SET FAVOURITE POSITION
