Simu TSA 4 Manuel d'installation

Hz Key Chain Transmitters 2 and 4 channels

Read all instructions carefully before use.

Hz Key Chain Trans

1) Program the motor using a

standard transmitter as per the

quick reference guide

2) Press the programming button

on the standard transmitter until

the motor jogs up/down

3) Touch the programming

contact on the back of the Key

Chain Transmitter with a metal

conductor (paper clip). The LED

on the front will start to flash

Programming

Contact

Paper

Clip Flashing LED

4) Press the desired front button

while the LED is still flashing. The

motor will jog. This button will now

control the motor.

Repeat steps 1 through 4 for other buttons to other motors if desired.

Note: Only program one motor per button. The 2 channel key chain can be used

to control 2 motors maximum and the 4 channel can control 4 motors maximum

Programming Instructions

PGR

PROGRAMMING

Hz Key Chain Transmitters 2 and 4 channels

Read all instructions carefully before use.

Hz Key Chain Trans

Programming Instructions

REPLACING THE BATTERY

LOCKING/UNLOCKING TSA 4

A - Enabling the locking function - Once a locking code has been entered the TSA 4 will automatically lock the buttons after 2

minutes without a command to prevent unintended operation. The buttons can be unlocked as per section B.

1) Press the lock button

for 5 seconds

2) Enter a 4 key code 3) Validate the code by

pressing the lock button

4) Enter the same 4

key code again

5) Validate the code by

pressing the lock button

ATTENTION - The battery must be installed correctly with regards to the polarity. The battery must be installed with the + side facing away from the

transmitter board. Do not expose battery to high temperatures or water. Do not throw batteries in fire or water. Dispose of batteries correctly

B - Unlocking the remote - After unlocking the remote, the buttons will remain active for 2 minutes before locking again.

1) Enter your 4 key

code

2) Validate the code by

pressing the lock button

3) The transmitter buttons are unlocked for normal use for 2 minutes.

After 2 minutes the transmitter will automatically lock the buttons again

C - Disable the automatic lock function

1) Press the lock button

for 5 seconds

2) After 5 seconds the locking

LED will go out. The locking

Function is now disabled.
