DIGITAL TIME CLOCK INSTRUCTIONS
When the selector is in the “AUTO” position,
boiler functioning is automatically controlled
on the basis of the temperature levels and
time periods set. The second selector must
be in the “RUN” position to start. The pro-
gramming procedure is described below:
- Setting the time
Set the selector to the ““ position.
Press “h” to change the hour on the
display, or “m” to change the minutes.
To set the day, press the “1…7” button
until the arrow is pointing to the correct
day (1 = Monday… 7 = Sunday).
- Setting the program
The time clock has 8 on times and 8 off
times. To make it easier to use, the time
clock is supplied with 3 on times and 3 off
times already set for each day of the
week, as shown below:
To select programmes other than those
already set, move the selector to position
“P”; “0:001” will appear on the display, in
which the first three digits indicate the
hour and minutes, while the fourth digit
identifies the program number.
Odd-numbered programs identify reque-
sts for operation (day temperature), in
which case the light bulb symbol will
appear on the display, while even-numbe-
red programs identify drops in tempera-
ture (night). Use the “1…7” key to select
the day of the week (from 1 to 7) or days
(1 ÷ 5, 6 - 7; 1 ÷ 6 or every day if the pro-
gram is to be repeated every day of the
week). Set the hour and minutes with the
“h” and “m” buttons.
Press “P” to store the operation in
memory and go on to the next program.
Repeat the same procedure to set the
remaining programs.
When finished programming, set the
selector to “RUN” position.
- Deleting one or more
programs
The on and off time must be deleted for
each program to be deleted.
Set selector (2) to position “P”. Select the
desired program with button (3), then
press button (4) to delete the day setting
(the triangular symbols for the days
should go away). If part of the program is
deleted, when you set selector (2) back
to the “RUN” position an error will appear
in the clock display, referring to the pro-
gram which is incorrect.
To delete all programs, put the selector in
position “P” and press buttons (3) and (5)
at the same time.
- Setting the SKIP function
The SKIP function deactivates programs
for the next day and resumes regular
programming 24 hours later.
This function is useful if you will be out all
day and don’t need heating. To start this
function, press button (7), which is acti-
ve only when selector (2) is in “RUN”
position.
Once you have selected the SKIP func-
tion, it will go into effect at 0:00 of the
next day for 24 hours. You cannot turn it
off once it has started, so regular pro-
gramming will not resume until 24 hours
have passed.
8
TIME PROGRAMMER
Program Time Operating mode
1 06,00 ON
2 09,00 OFF
3 12,00 ON
4 14,00 OFF
5 18,00 ON
6 22,00 OFF
Note: No program is set from 7 through 17
or
1 Manual/automatic
operation selector
2 Program/schedule
setting selector
3 Program button
4 Day of the week button
5 Hour button
6 Minute button
7 SKIP button
8 Reset button
