Silicon Laboratories CP2120 Manuel utilisateur

CP2120-EK

CP2120 EVALUATION KIT USER’SGUIDE

1. Kit Contents

The CP2120 Evaluation Kit contains a CP2120 evaluation board and a power supply. The following supporting

documents can be downloaded from www.silabs.com:

CP2120 Data Sheet

AN311: CP2120 Porting Guide

2. CP2120 Hardware Interface

The evaluation board is connected to a SPI master and to SMBus devices as shown in Figure 1.

1. Connect the SPI Master’s SPI bus lines to the CP2120. If The CP2120 is the only SPI slave device on the

SPI bus, then the CS pin can be tied low.

2. Connect the CP2120’s INT pin to a port pin of the SPI Master.

3. Connect the CP2120 to SMBus devices through the SMBus lines.

Please refer to "4. Evaluation Board" on page 2 for more information about these steps.

Figure 1. System Connections

3. CP2120 Operation

Once connected as shown in Figure 1, the SPI Master issues commands to the CP2120 across the SPI bus. The

CP2120 responds to commands by initiating an SMBus transfer with SMBus slave devices, reading from or writing

to internal registers, or interfacing with general purpose input/output (I/O) port pins. When an SMBus transaction

completes, the CP2120 pulls the INT pin low, which signals the SPI Master that the command has been processed.

SPI Master CP2120

SMBus

Device

SMBus

Device

SMBus

Device

SCK

MISO

MOSI

INT

SPI Bus

SDA

SCL

SMBus

CP2120-EK

2 Rev. 0.1

4. Evaluation Board

The CP2120 evaluation board comes with a CP2120 device pre-installed for system evaluation and development.

Numerous I/O connections are provided to facilitate prototyping using the evaluation board. Refer to Figure 2 for

the locations of the various I/O connectors.

J1 Power Connector

J2 SPI Master Interface

J3 SMBus Interface

J4 MISO-MOSI Connector

J6 SMBus SDA Pullup Connector

J7 SMBus SCL Pullup Connector

J9 LED Connector

J10 General Purpose I/O Interface

Figure 2. CP2120 Evaluation Board

D7 D0D1D2D3D4D5D6

POWER

J10

SILICON LABORATORIES

SA-TB51PCB

CP2120-EK

Rev. 0.1 3

4.1. J2—SPI Master Interface

Connector J2 provides the SPI Master access to the CP2120 SPI, control, and reset lines. Table 1 shows the

pinout of the J2 header.

4.2. J3—SMBus Interface

Connector J3 provides the CP2120 access to the SMBus. Table 2 shows the pinout of the J3 header.

Note: All pins labeled SCL are tied together, and all pins labeled SDA are tied together. Multiple connections to SCL and SDA

signals are provided to allow multiple devices to connect to the evaluation board.

Table 1. Pinout for J2

Pin 1 SPI Bus—SCLK

Pin 2 SPI Bus—MISO

Pin 3 SPI Bus—MOSI

Pin 4 SPI Bus—CS

Pin 5 INT

Pin 6 Not Used

Pin 7 RST

Pin 8 GND

Pin 9 Not Used

Pin 10 Not Used

Table 2. Pinout for J3

Pin 1 SMBus—SCL

Pin 2 SMBus—SDA

Pin 3 SMBus—SCL

Pin 4 SMBus—SDA

Pin 5 SMBus—SCL

Pin 6 SMBus—SDA

Pin 7 SMBus—SCL

Pin 8 SMBus—SDA

Pin 9 GND

Pin 10 GND

CP2120-EK

4 Rev. 0.1

4.3. J4—SPI MISO/MOSI Connector

Some SPI master systems tie together the MISO and MOSI SPI data lines. The CP2120 evaluation board allows

developers to connect these two signals through a resistor by placing a header on J4.

Note: When operating the SPI bus with a header on J4, only drive the MOSI pin whenever data is being transmitted to the

CP2120. When the SPI bus is idle, or when the CP2120 is transmitting data, the SPI master must set its MOSI pin into

an open-drain state to avoid port pin contention.

4.4. J6 and J7—SMBus Pullup Connectors

Connectors J6 and J7 give developers the option of adding pullup resistors to the SMBus’s SDA and SCL lines.

Removing shorting blocks from these headers disconnects the pullups from the SMBus lines.

Note: The SMBus lines need pullups to VDD in order to function properly. If the headers are removed from J6 and J7, remem-

ber to add pullups to VDD elsewhere on the SMBus.

4.5. J9—LED Connector

Connector J9 allows the CP2120’s General Purpose I/O pins to be connected to the array of LEDs on the

evaluation board. Once a header has been placed connecting a pin on the side closest to the CP2120 to its

corresponding pin on the side of the jumper closest to the LEDs. To use one of the LEDs, place a shorting block on

the J9 pin closest to the LED, connecting the corresponding J9 pin on the side of the connector closer to the

CP2120. See Figure 3 for an example of this connection. Writing a 0 to the connected general purpose I/O pin will

turn on the LED, and writing a 1 to that pin will turn off the LED.

Figure 3. Controlling the LEDs

Shorting Block placed on

GPIO1, with GPIO1

configured to be Digital

Output and set to ‘0’

GPIO0

GPIO1

GPIO2

GPIO3

GPIO4

GPIO5

GPIO6

GPIO7

CP2120

To Control an LED using the CP2120:

Add Shorting Block to LED’s

corresponding port pin

Configure port pin to Digital Output

To turn on LED: Set port pin to ‘0’

To turn off LED: Set port pin to ‘1’

CP2120-EK

Rev. 0.1 5

4.6. J10—General Purpose I/O Interface

Connector J10 enables off-board access to the CP2120’s eight general purpose I/O pins, as well as the Edge-

Triggered Interrupt Source pin. Table 3 shows the pinout for this header.

Table 3. Pinout for J10

Pin 1 GPIO Pin 0

Pin 2 GPIO Pin 1

Pin 3 GPIO Pin 2

Pin 4 GPIO Pin 3

Pin 5 GPIO Pin 4

Pin 6 GPIO Pin 5

Pin 7 GPIO Pin 6

Pin 8 GPIO Pin 7

Pin 9 Edge Triggered Interrupt Source

Pin 10 GND

CP2120-EK

6 Rev. 0.1

5. Schematic

CP2120-EK

Rev. 0.1 7

NOTES:

CP2120-EK

8 Rev. 0.1

CONTACT INFORMATION

Silicon Laboratories Inc.

400 West Cesar Chavez

Austin, TX 78701

Tel: 1+(512) 416-8500

Fax: 1+(512) 416-9669

Toll Free: 1+(877) 444-3032

Email: [email protected]

Internet: www.silabs.com

Silicon Laboratories and Silicon Labs are trademarks of Silicon Laboratories Inc.

Other products or brandnames mentioned herein are trademarks or registered trademarks of their respective holders.

The information in this document is believed to be accurate in all respects at the time of publication but is subject to change without notice.

Silicon Laboratories assumes no responsibility for errors and omissions, and disclaims responsibility for any consequences resulting from

the use of information included herein. Additionally, Silicon Laboratories assumes no responsibility for the functioning of undescribed features

or parameters. Silicon Laboratories reserves the right to make changes without further notice. Silicon Laboratories makes no warranty, rep-

resentation or guarantee regarding the suitability of its products for any particular purpose, nor does Silicon Laboratories assume any liability

arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation conse-

quential or incidental damages. Silicon Laboratories products are not designed, intended, or authorized for use in applications intended to

support or sustain life, or for any other application in which the failure of the Silicon Laboratories product could create a situation where per-

sonal injury or death may occur. Should Buyer purchase or use Silicon Laboratories products for any such unintended or unauthorized ap-

plication, Buyer shall indemnify and hold Silicon Laboratories harmless against all claims and damages.
