SIIG US2322 Manuel utilisateur

USB 2.0 DataLink Adapter

Quick Installation Guide

04-0336A

System Requirements

•USB equipped computer with one available

USBport(USB2.0recommended)

•Windows 98SE/ME/2000/XP/Server 2003

Package Contents

•(1)USB2.0DataLinkAdapter

•(1)DriverCD

•This Quick Installation Guide

Serial # Sticker

Forfutureproductreturnorexchange,thisserial#is

required. Pleasekeepitforyourreference.

SoftwareInstallation

Windows 98SE

1. InsertthedriverCD,ClickStart,thenRun.Type

D:\setup.exe, then OK. (Change D: to match

yourCD-ROMdriveletter)

2. ClickNext,Install,thenFinish.

3. Insert the USB 2.0 DataLink Adapter and the

drivers will automatically install.

Windows ME/XP/2000/2003

No driver installation is needed, simply connect the

USB 2.0 DataLink Adapter into a USB port and the

driver will install automatically.

To Verify Successfull Installation

1. Check Device Manager to verify successfull

installation.

Windows98SE/ME:FromthemainDesktop,right

clickMyComputer,thenclickProperties. Click

DeviceManagertab.

Windows 2000/XP/2003: Right click My

Computer, then click Manage. Click Device

Manager.

2. Click Disk drives, and OTI Thunderbird...

shouldbedisplayed.

Using Superlink Software Utility

Youcantransferfilesbetweenthetwosystemsthrough

theSuperLinkapplication software.

Starting SuperLink

This program must be executed on both computers

connectedto theUSB 2.0DataLinkAdapter.

1. DoubleclickMyComputer

2. Double click Removable Drive F: (Default

drive).

3. DoubleclickSuperLink icon.

Figure 1: SuperLink Utility

Data Transfer

To transfer files between systems, simply drag and

drop files between the two systems using the Local

Host and Remote Host windows of the SuperLink

utility.

Disabling Read Only

Insomecases,youmayneedtodisableReadOnlyon

bothsystemsbeforetransferringdata.

1. AttheSuperLinkwindow,clickSystem,then

clickSetup.

2. Uncheck Share as Read Only, then click OK.

Technical Support

QUESTIONS? SIIG’s Online Support has the answers!

Simply visit our Web site at www.siig.com and click

Support. Our online support database is updated daily

with new drivers and solutions. The answers to your

problems could be just a few clicks away.

If you can't find answers or solutions to your questions,

you have an option to submit the problems online to one

of our technical support analysts and we will promptly

respond to you with answers or solutions.

The 5-year manufacturer warranty supplied with this

product is offered by SIIG, Inc. If you should happen to

encounter any problems with this product, please follow

the procedures below.

1. If it is within the store's return policy period,

return the product to the store where you

purchased from.

2. Ifyourpurchasehaspassedthestore'sreturnpolicy

period, contact SIIG. See SIIG's Limited 5-year

Warranty for more information.

Online Product Registration

Please visit www.siig.com, click Support, then

Blank Page

LIMITED5YEARWARRANTY

The Company warrants to the original buyer of this product that the

hardware is free of defects in materials and workmanship for a period

of five years from the date of purchase from a reseller or dealer.

If the product has been modified without written approval by the

Company, or the failure is a result of misuse, abuse or misapplication

as determined by the Company, the warranty is void and the Company

has no obligation to repair or replace the product.

Follow these steps to have the defective product repaired or replaced.

Step 1: Go to www.siig.com, click Support, then RMA to submit

the problem. A Technical Support Analyst will troubleshoot the

problem. If the product is determined to be defective, our RMA

department will issue you an RMA number. If you don't have

Internet access, contact our RMA department at (510)413-5333.

Step 2: Ship the product.

- Properly pack the product for shipping. All software, cable(s) and

other accessories that came with the original package must be

included.

- Clearly write your RMA number on the top of the returned

package. SIIG will refuse to accept any shipping package,

and will not be responsible for a product returned

without an RMA number posted on the outside of the

shipping carton.

- You are responsible for the cost of shipping the product to SIIG at

the following address:

SIIG, Inc. RMA # _______________

6078 Stewart Avenue

Fremont, CA 94538

Step 3: SIIG will ship the repaired or replaced product via Ground in

the U.S and International Economy outside of the U.S at no cost to

the customer.

USB 2.0 DataLink Adapter is a trademark of SIIG, Inc. All other names

used in this publication are for identification only and may be

trademarksoftheirrespectivecompanies.

PRODUCT NAME MODEL NUMBER

USB 2.0 DataLink Adapter US2322

FCC RULES: TESTED TO COMPLY WITH FCC PART 15,

CLASS B OPERATING ENVIRONMENT: FOR HOME OR

OFFICE USE

FCCCOMPLIANCESTATEMENT:

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device

must accept any interference received, including interference

that may cause undesired operation.

THE PARTY RESPONSIBLE FOR

PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Ave.

Fremont, CA 94538-3152

Online Store

SIIG offers all of our products online at our company store.

Visit us at http://onlinestore.siig.com to find our complete

lineofproducts,includinghardtofinditemsandaccessories

(power adapters, cables, upgrade kits, etc.).
