1. Introduction

1.1. General Features

The AirPrime AR7582 embedded modules are designed for the automotive industry. It support LTE,

WCDMA and GSM air interface standards. It also have Global Navigation Satellite System (GNSS)

capabilities including GPS, GLONASS, Galileo, BeiDou, and QZSS

The AirPrime AR7582 embedded modules are based on the Qualcomm MDM9628 wireless chipset

and support the following bands.

Table 1. AirPrime AR758x Series Embedded Modules

Product

Description

Band Support

Target

Region1

AR7582

LTE-CA / WCDMA / GSM /

GPRS / EDGE embedded

module

LTE: B2, B4, B5, B7*, B12, B13*, B17

WCDMA: B2, B4, B5, B6

GSM/GPRS/EDGE: 850/1900

North America

(Canada, US,

Mexico)

1 Other regions or operators which use the same frequency bands may also be supported, subject to review and

confirmation by Sierra Wireless.

* Optional band

1.2. Power

The AirPrime AR7582 are powered via a single regulated DC power supply, 3.7V nominal.

Table 2. Power Supply Requirements

Power Supply

Min

Typ

Max

Units

Main DC Power Input Range (VBATT)

3.4

3.7

4.2

Power Supply

Ripple

0 to 1kHz

200

mVpp

>1kHz

mVpp

Peak Current

AR758x

2000

3000

Table 3. Power Supply Pads

Pad

Name

Direction

Function

If Unused

EA2

VBATT

Input

Power Supply Input

Must Be Used

EB2

VBATT

Input

Power Supply Input

Must Be Used

EC2

VBATT

Input

Power Supply Input

Must Be Used

1.3. RF

This section presents the WWAN RF interface of the AirPrime AR7582. The specifications for the

LTE, GSM and WCDMA interfaces are defined.

41110461XXXX Rev 0.12 January 16, 2017 10

Hardware Integration Guide

Introduction

1.3.1. GSM RF Interface

This section presents the GSM RF Specification for the AirPrime AR7582.

1.3.1.1. GSM TX Output Power

The GSM Maximum Transmitter Output Power of the AirPrime AR7582 are specified in the following

table.

Note: All values presented in the table below are preliminary.

Table 4. Conducted TX (Transmit) Max output Power Tolerances –GSM/EDGE Bands

Band

Standard 1

(dBm)1

Standard 2

(dBm)2

TX Power @

Room (dBm)

TX Power @

Class A (dBm)3

Notes

GSM 850

33±2dB

33±2.5dB

33±2dB

33±2.5dB

GMSK mode,

connectorized(Class 4;

2 W, 33 dBm)

EGSM

900

33±2dB

33±2.5dB

33±2dB

33±2.5dB

GSM

1800

30±2dB

30±2.5dB

30±2dB

30±2.5dB

GMSK mode,

connectorized(Class 1;

1 W, 30 dBm)

GSM

1900

30±2dB

30±2.5dB

30±2dB

30±2.5dB

GSM 850

27±3dB

27±4dB

27±2.5dB

27±3.5dB

8PSK mode,

connectorized(Class

E2; 0.5 W, 27 dBm)

EGSM

900

27±3dB

27±4dB

27±2.5dB

27±3.5dB

GSM

1800

26±3dB

26±4dB

26 ±2.5dB

26±3.5dB

8PSK mode,

connectorized(Class

E2; 0.4 W, 26 dBm)

GSM

1900

26±3dB

26±4dB

26 ±2.5dB

26±3.5dB

1 Per 3GPP TS 51.010-1 Requirement for Normal condition.

2 Per 3GPP TS 51.010-1 Requirement for Extreme conditions

3 Test at Class A extreme condition

1.3.1.2. GSM RX Sensitivity

The GSM Receiver Sensitivities of the AirPrime AR758x Series are specified in the following table.

Table 5. Conducted RX (Receive) Sensitivity –GSM/EDGE Bands

GSM/EDGE Bands

Limit (dBm)1

Room

Typical

(dBm)

Class A

(Extreme)

Typical (dBm)2

Class A

Limit (dBm)

GSM 850

2% BER CS

-102

-108,5

-108

-103

10% BLER

GMSK CS1

-104

-108

-107

-105

10% BLER

EDGE MCS5

-98

-103.5

-102

-99

PCS 1900

2% BER CS

-102

-108.5

tbd

-103

10% BLER

GMSK CS1

-104

-108.5

-107.5

-105

10% BLER

EDGE MCS5

-98

-103.5

-102

-99

1 Per 3GPP specification

2 Test at Class A extreme condition

Table des matières

Autres manuels Sierra Wireless Modem

Sierra Wireless

Sierra Wireless Bell 313U Manuel utilisateur

Sierra Wireless

Sierra Wireless AirLink MP595 Manuel utilisateur

Sierra Wireless

Sierra Wireless Compass 597 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirLink MP890 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime MC8775 Manuel utilisateur

Sierra Wireless

Sierra Wireless PinPoint X Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime WP7601 Guide de configuration rapide

Sierra Wireless

Sierra Wireless Telstra Elite Mode d’emploi

Sierra Wireless

Sierra Wireless AirCard 710 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRCARD 595U Manuel utilisateur

Sierra Wireless

Sierra Wireless AirCard 580 WAN Manuel utilisateur

Sierra Wireless

Sierra Wireless Raven X HSDPA Manuel utilisateur

Sierra Wireless

Sierra Wireless Telstra ultimate mobile broadband usb modem Manuel utilisateur

Sierra Wireless

Sierra Wireless MP 881W Manuel utilisateur

Sierra Wireless

Sierra Wireless AirCard 580 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirLink RV50 Series Manuel utilisateur

Sierra Wireless

Sierra Wireless 302 Manuel utilisateur

Sierra Wireless

Sierra Wireless USB 308 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirCard 503 Manuel utilisateur

Sierra Wireless

Sierra Wireless MP 875 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirCard 326U Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPath 300 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirLink GL7 00 Series Manuel utilisateur

Sierra Wireless

Sierra Wireless AirLink MP Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur

Zoom

Zoom 1070 Series Manuel utilisateur
