Siemens 7MF8*23 Series Guide de l'administrateur

Pressure transmitter

SITRANS P300

Compact Operating Instructions •08/2011

SITRANS

English..................................................................................................................................................................4

Български ..........................................................................................................................................................34

Čeština ...............................................................................................................................................................65

Suomi .................................................................................................................................................................94

Slovenčina ........................................................................................................................................................124

Slovenščina ......................................................................................................................................................154

A5E03434761-01, 08/2011 3

SITRANS

Pressure transmitter

SITRANS P300 (7MF8.23.. 7MF8.24.. 7MF8.25..)

Compact Operating Instructions

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage to property. The

notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices referring only to property damage

have no safety alert symbol. These notices shown below are graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.

CAUTION

without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.

NOTICE

indicates that an unintended result or situation can occur if the relevant information is not taken into account.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will be used. A notice warning of

injury to persons with a safety alert symbol may also include a warning relating to property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific task in accordance with

the relevant documentation, in particular its warning notices and safety instructions. Qualified personnel are those who, based on their

training and experience, are capable of identifying risks and avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products

and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage,

installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any

problems. The permissible ambient conditions must be complied with. The information in the relevant documentation must be observed.

4 A5E03434761-01, 08/2011

Introduction

Purpose of this documentation

These instructions are a brief summary of important features, functions and safety information, and contain all information

required for safe use of the device. It is your responsibility to read the instructions carefully prior to installation and

commissioning. In order to use the device correctly, first review its principle of operation.

The instructions are aimed at persons who mechanically assemble the device, connect it electrically, and start it up.

To achieve optimum usage of the device, read the detailed version of the manual on the electronic data medium.

See also

Instructions and Manuals (http://www.siemens.com/processinstrumentation/documentation)

History

This history establishes the correlation between the current documentation and the valid firmware of the device.

Currently released versions of these instructions:

Edition Firmware identifier nameplate System integration Installation path for PDM

08/2011 HART: FW: 29.03.07

PA/FF: FW: 0300.01.08

PDM 6.01); Dev. Rev. 3

DD Rev. 2

SITRANS P300

1) up to SP05 Hotfix 5

Purpose

Overview

Depending on the version, a transmitter measures corrosive, non-corrosive and hazardous gases, vapors and liquids.

You can use the transmitter for the following types of measurement:

● Gauge pressure

● Absolute pressure

With appropriate parameter settings and the necessary add-on parts (e.g. flow orifices and remote seals), the pressure

transmitter can also be used for the following measurements:

● Level

● Volume

● Mass

The output signal is a load-independent direct current of 4 to 20 mA which is linearly proportional to the input pressure.

The "Intrinsically-safe" version of the transmitter can be installed in hazardous areas (zone 1). The devices have an EC type

examination certificate and comply with the appropriate harmonized European CENELEC directives.

Operate the device in accordance with the specifications in Section Technical data (Page 25).

For additional information, please refer to the operating instructions for the device.

Checking the consignment

1. Check the packaging and the device for visible damage caused by inappropriate handling during shipping.

2. Report any claims for damages immediately to the shipping company.

3. Retain damaged parts for clarification.

4. Check the scope of delivery by comparing the shipping documents with your order for correctness and completeness.

SITRANS P300 (7MF8.23.. 7MF8.24.. 7MF8.25..)

A5E03434761-01, 08/2011 5

WARNING

Using a damaged or incomplete device

Danger of explosion in hazardous areas.

● Do not use any damaged or incomplete devices.

Nameplate layout

Overview

The nameplate bearing the Order No. and other important information, such as design details and technical data, is on the

enclosure.





 

,,*([Q/,,&777

  

  







3('6(3

,3 

' .DUOVUXKH

6,75$163

0DGH LQ )UDQFH

)1U

):   +: 

0)%$%$=

① Product name/manufacturer ⑧ Group (gas, dust)

② Product information ⑨ Maximum surface temperature (temperature

class)

③ Technical data ⑩ Hardware identifier

④ Certification information ⑪ Firmware identification

⑤ Characteristics for hazardous area ⑫ Order No. (machine-readable product code)

⑥ Category for operating area ⑬ Serial number

⑦ Type of protection

Figure 1 Example of nameplate: Product and approval information

FW: aa.bb. cc Firmware for HART

aa. Device type

bb. Document revision

cc FW edition

FW: aaaa.bb. cc Firmware for PROFIBUS

aaaa. Profile revision (0300 = 3.00)

bb. Document revision

cc FW edition

HW: xx. yy. zz Hardware

xx Serial number

yy. Connection board product version

zz Compatibility mark

SITRANS P300 (7MF8.23.. 7MF8.24.. 7MF8.25..)

6 A5E03434761-01, 08/2011

Transportation and storage

To guarantee sufficient protection during transport and storage, observe the following:

● Keep the original packaging for subsequent transportation.

● Devices/replacement parts should be returned in their original packaging.

● If the original packaging is no longer available, ensure that all shipments are properly packaged to provide sufficient

protection during transport. Siemens cannot assume liability for any costs associated with transportation damages.

CAUTION

Insufficient protection during storage

The packaging only provides limited protection against moisture and infiltration.

● Provide additional packaging as necessary.

Special conditions for storage and transportation of the device are listed in "Technical data" (Page 25).

Notes on warranty

The contents of this manual shall not become part of or modify any prior or existing agreement, commitment or legal

relationship. The sales contract contains all obligations on the part of Siemens as well as the complete and solely applicable

warranty conditions. Any statements regarding device versions described in the manual do not create new warranties or

modify the existing warranty.

The content reflects the technical status at the time of publishing. Siemens reserves the right to make technical changes in

the course of further development.

Safety instructions

Prerequisites for safe use

This device left the factory in good working condition. In order to maintain this status and to ensure safe operation of the

device, observe these instructions and all the specifications relevant to safety.

Observe the information and symbols on the device. Do not remove any information or symbols from the device. Always

keep the information and symbols in a completely legible state.

Warning symbols on the device

Symbol Explanation

Consult operating instructions

Laws and directives

Observe the test certification, provisions and laws applicable in your country during connection, assembly and operation.

These include, for example:

● National Electrical Code (NEC - NFPA 70) (USA)

● Canadian Electrical Code (CEC) (Canada)

Further provisions for hazardous area applications are for example:

● IEC 60079-14 (international)

● EN 60079-14 (EC)

SITRANS P300 (7MF8.23.. 7MF8.24.. 7MF8.25..)

A5E03434761-01, 08/2011 7

Conformity with European directives

The CE mark on the device is a sign of conformity with the following European directives:

Electromagnetic Compatibility

EMC

2004/108/EC

Directive of the European Parliament and of the Council on the

approximation of the laws of the Member States relating to electromagnetic

compatibility and repealing Directive 89/336/EEC.

Atmosphère explosible ATEX

94/9/EC

Directive of the European Parliament and the Council on the approximation

of the laws of the Member States concerning equipment and protective

systems intended for use in potentially explosive atmospheres.

Pressure Equipment Directive

PED

97/23/EC

Directive of the European Parliament and of the Council on the

approximation of the laws of the Member States concerning pressure

equipment.

The standards applied can be found in the EC declaration of conformity for the device.

Incorrect device modifications

WARNING

Improper device modifications

Danger to personnel, system and environment can result from modifications to the device, particularly in hazardous areas.

● Only carry out modifications that are described in the instructions for the device. Failure to observe this requirement

cancels the manufacturer's warranty and the product approvals.

Requirements for special applications

Due to the large number of possible applications, each detail of the described device versions for each possible scenario

during commissioning, operation, maintenance or operation in systems cannot be considered in the instructions. If you need

additional information not covered by these instructions, contact your local Siemens office or company representative.

Note

Operation under special ambient conditions

We highly recommend that you contact your Siemens representative or our application department before you operate the

device under special ambient conditions as can be encountered in nuclear power plants or when the device is used for

research and development purposes.

Use in hazardous areas

Qualified personnel for hazardous area applications

Persons who install, assemble, commission, operate and service the device in a hazardous area must have the following

specific qualifications:

● They are authorized, trained or instructed in operating and maintaining devices and systems according to the safety

regulations for electrical circuits, high pressures and aggressive as well as hazardous media.

● They are authorized, trained, or instructed in carrying out work on electrical circuits for hazardous systems.

● They are trained or instructed in maintenance and use of appropriate safety equipment according to the pertinent safety

regulations.

WARNING

Unsuitable device for the hazardous area

Danger of explosion.

● Only use equipment that is approved for use in the intended hazardous area and labelled accordingly.

SITRANS P300 (7MF8.23.. 7MF8.24.. 7MF8.25..)

8 A5E03434761-01, 08/2011
