Siemens SIMATIC PC 670 V2 Manuel utilisateur

Preface, Table of Contents

Introduction 1

Documentation 2

Installing Drivers 3

Other Software 4

Browsing Through the CD 5

General Information 6

Appendix

SIMATIC PC

Panel PC 670V2 and

PC 870 V2

Installation Using the

Docu & Drivers CD 06/2004

Installation Guide

Release 06/04

This Installation Guide is valid for units with the following

order numbers:

Panel PC 670 V2: 6AV772x-xxxxx-0Ax0

6AV773x-xxxxx-0Ax0

Panel PC 870 V2: 6AV774x-xxxxx-0Ax0

6AV775x-xxxxx-0Ax0

Safety Guidelines

This manual contains notes which you should observe to ensure your own personal safety, as well

as to protect the product and connected equipment. These notices are marked as follows according

to the level of danger:

Danger

indicates an imminently hazardous situation which, if not avoided, will result in death or serious

injury.

Warning

indicates a potentially hazardous situation which, if not avoided, could result in death or serious

injury.

Caution

used with the safety alert symbol indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury.

Caution

used without the safety alert symbol indicates a potentially hazardous situation which, if not

avoided, may result in property damage.

Notice

indicates that unwanted events or status can occur if the relevant information is not observed.

Note

draws your attention to particularly important information about the product, proper handling of the

product, or to a particular part of the documentation.

Qualified Personnel

Equipment may be commissioned and operated only by qualified personnel. Qualified personnel

within the meaning of the safety notices in this manual are persons who are authorized to

commission, ground and identify equipment, systems and circuits in accordance with safety

engineering standards.

Correct Usage

Please note the following:

Warning

The device may only be used for the application cases specified in the catalog and the technical

description and may only be used in combination with third-party equipment and components

recommended or approved by Siemens.

Startup must not take place until it is established that the machine which is to accommodate this

component is conforms with the guideline 98/37 EC.

Appropriate transport, storage, installation, and assembly as well as careful operation and

maintenance are required to ensure that the product operates flawlessly and safely.

Trademarks

The registered trademarks of the Siemens AG can be found in the preface.

Masthead

Editor and Publisher: A&D PT1

The transmission and reproduction of this documentation and the exploitation and

communication of its contents are not permitted without express authority. Offenders

will be liable

of the granting of a patent or registration of a utility model or design.

We have checked the content of this publication for compliance with the described

hardware and software. However, discrepancies cannot be excluded, with the result

that we cannot guarantee total compliance. The information in this publication is,

however, checked regularly, and any necessary corrections are included in the

following editions. We welcome any suggestions for improvement.

Siemens AG

Bereich Automation & Drives

Geschäftsgebiet SIMATIC HMI

Postfach 4848, D-90327 Nürnberg

Siemens AG 2003

Technical data subject to change.

Siemens Aktiengesellschaft Release 08/03

Panel PC 670V2/ 870V2 – Installation Guide – Installation Using the Docu & Drivers CD 04/2004 iii

1 Preface

About this manual

This Installation Guide is not enclosed with the delivery of the SIMATIC

Panel PC 670V2/ 870V2.

Note

This Installation Guide is only valid for the Panel PC 670V2/ 870V2 ordered

from Siemens AG and supplied without an operating system.

Notation

Different font formats simplify orientation within the text:

Motor on The text on the screen of the operating unit is displayed in

typewriter font.

Output Inputs and outputs on the screen of the operating unit are

displayed in italic typewriter font.

File →Edit Menu items, dialog names, tab controls and buttons of the

operating system and the application are displayed in italic

font.

The complete path is always described with menu items.

Trademarks

The following names are registered trademarks of the Siemens AG:

• SIMATIC®

• SIMATIC HMI®

• SIMATIC Panel PC®

• HMI®

• ProTool®

• ProTool/Lite®

• ProTool/Pro®

The remaining trademarks in this publication may be trademarks whose use by

third parties for their own purposes could violate the rights of the owner.

Contents

1Introduction ......................................................................... 1–2

1.1 General Information.......................................................................... 1–2

1.2 Conditions for Installation ................................................................. 1–3

1.2.1 BIOS versions .................................................................................. 1–3

1.2.2 Service packs ................................................................................... 1–3

1.2.3 Partitions........................................................................................... 1–3

1.3 Starting the Docu & Drivers CD ....................................................... 1–5

2Documentation.................................................................... 2–1

2.1 Documents ....................................................................................... 2–2

2.2 Dimensioned Drawing ...................................................................... 2–2

2.3 SIMATIC ........................................................................................... 2–3

2.4 Softkey Labeling Strips Templates................................................... 2–4

3Installing Drivers................................................................. 3–1

3.1 Panel PC 670 V2.............................................................................. 3–2

3.1.1 Panel PC 670 V2 with Windows 2000.............................................. 3–2

3.1.2 Panel PC 670 V2 with Windows XP................................................. 3–4

3.2 Panel PC 870 V2.............................................................................. 3–6

3.2.1 Panel PC 870 with Windows 2000 ................................................... 3–6

3.2.2 Panel PC 870 with Windows XP ...................................................... 3–8

3.3 Panel PC with Raid System ........................................................... 3–10

4Other Software .................................................................. 4–11

5Browsing Through the CD................................................ 5–13

6General Information............................................................ 5–1

7Appendix.................................................................................. a

Introduction Release 06/04

1 Introduction

1.1 General Information

All the information below relates to the following SIMATIC Panel PCs with a touch

front or key front:

PC 670V2 Raid 6AV772x-xxxxx-0AA0

6AV773x-xxxxx-0AA0

PC 870V2 2HDD/ Raid 6AV774x-xxxxx-0AA0

6AV775x-xxxxx-0AA0

In the case of a Panel PC 670V2/ 870V2 without an operating system installed,

drivers which are not part of the scope of delivery must be installed later. To

complete the installation, various conditions must be fulfilled and are explained

below.

Information concerning driver installation for the following operating systems is

provided for:

• Microsoft Windows 2000

• Microsoft Windows XP

No detailed information is provided on installation of the operating system itself.

The information applies to the operating system languages English and German.

Enclosed with the Simatic Panel PC 670V2/ 870V2 is the "PC 670V2/ 870V2

Documentation & Drivers" CD 06/2004 (order number: A5E00325673). All the

necessary drivers are included on it.

Note

Connect an external mouse and PS/2 keyboard for the following installation

procedures.

Release 06/04 Introduction

1.2 Conditions for Installation

1.2.1 BIOS versions

Ensure that at least the following BIOS versions are installed on the PC:

Panel PC 670 V2: V02.01.06 or later

Panel PC 870 V2: V04.01.01 or later

1.2.2 Service packs

Before installing the Service Pack, check whether the Service Pack language

corresponds to the language of the operating system installed.

The following Service Packs are required:

• Windows 2000

SP4 or later

• Windows XP

SP1 or later

1.2.3 Partitions

It is recommended to create the following partitions on the hard disk:

• Windows 2000

– Drive C:

Size: 10 Gbyte, Format: FAT 32 or NTFS, active status

– Drive D:

Size: Rest, Format: NTFS

• Windows XP

– Drive C:

Size: 10 Gbyte, Format: FAT 32 or NTFS, active status

– Drive D:

Size: Rest, Format: NTFS

Install the operating system required according to the installation instructions

provided by Microsoft. Select the standard configuration. During the operating

system installation, ignore the Network Installation menu option. The network card

is installed at a later date. (Refer to Ch. 3).

Introduction Release 06/04

Notice

When installing the operating system on the Panel PC 670 V2 with Raid using an original, boot-

capable Windows installation CD, the IRQ11 reservation should be disabled.

Proceed in the following order:

1. Call in the BIOS Setup menu by pressing “F2” while the PC is booting.

2. Select menu options Advanced -> PCI-Configuration -> PCI/PNP ISA IRQ Resource

Exclusion -> IRQ 11 and define Available.

3. Select YES in Advanced -> Reset Configuration Data.

4. Save the BIOS Setup settings and exit from BIOS. Restart the system.

Release 06/04 Introduction

1.3 Starting the Docu & Drivers CD

The interactive operator menu of the Docu & Drivers CD is started after activating

the "CDStart.exe" program.

First, select the required user language, whereby the languages "German" and

"English" are available.

Adobe Acrobat Reader is required in order to view instructions and technical

drawings. For simpler operation, it can be installed using the operator menu.

Note

After the language selection, a message appears indicating the Panel PCs for

which the drivers contained on the CD can be used. It is essential to pay attention

to this message.

Introduction Release 06/04

Click on the "Next" button to access the next selection menu on the

Docu & Drivers CD.

The individual menu options are explained in the following chapters.

2 Documentation

Click on the "Documentation" button in the Docu & Drivers CD selection menu to

call in the Documents menu:

This provides access to manuals, drawings and templates:

Panel PC 670 V2:

• Quickstart

• Operating instructions

• Dimensioned Drawing

Panel PC 870 V2:

• Quickstart

• Operating instructions

• Dimensioned Drawing

PC 670V2/ 870V2 HMI Device:

• Operating instructions

• Dimensioned Drawing

• Softkey Labeling Strips Templates

PC 670V2/ 870V2 HMI Device:

• SIMATIC NET PROFIBUS Networks (manual)

Note

Documentation on the Raidcontroller and Raid software is available in the Raid

Menu which can be called in by using the “Driver installation” button in the Main

Menu. Further information on the Raid system is provided in the Section “3.3 Panel

PC with Raid System”.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Siemens Écran tactile

Siemens

Siemens SIMATIC Panel PC IL 77 Manuel utilisateur

Siemens

Siemens SIMATIC PC 670 Document technique

Siemens

Siemens Panel PC 670 Document technique

Siemens

Siemens SIMATIC HMI TP 170A Document technique

Siemens

Siemens Simatic PC Panel PC 870 Manuel d'installation

Siemens

Siemens SIMATIC HMI Manuel utilisateur

Siemens

Siemens SIMATIC LS120 Manuel utilisateur

Siemens

Siemens SIMATIC WinCC V11 Guide de l'utilisateur

Siemens

Siemens SIMATIC OP 77B Manuel utilisateur

Siemens

Siemens TP27 Document technique

Siemens

Siemens SIMATIC INOX Series Guide de l'administrateur

Siemens

Siemens Climatix POL8T1.4X/STD Manuel de l'opérateur

Siemens

Siemens SIMATIC WinCC V11 Guide de l'utilisateur

Siemens

Siemens SIMATIC Panel PC IL 77 Manuel utilisateur

Siemens

Siemens PC 677B Manuel utilisateur

Siemens

Siemens SIMATIC HMI TP1200 Comfort Manuel utilisateur

Siemens

Siemens UP 588 Manuel utilisateur

Siemens

Siemens SIMATIC HMI TP27 Document technique

Siemens

Siemens LAE10 Manuel utilisateur

Siemens

Siemens Climatix POL8T2.70/STD Manuel de l'opérateur

Siemens

Siemens SIMATIC 677 Manuel utilisateur

Siemens

Siemens 670 V2 Manuel utilisateur

Siemens

Siemens SIMATIC TP 270 Manuel utilisateur

Siemens

Siemens SIMATIC 870 V2 Manuel utilisateur

Manuels Écran tactile populaires d'autres marques

FlowLine

FlowLine Data loop Manuel utilisateur

ALPEX

ALPEX AEx-8 P Series Manuel utilisateur

Ltech

Ltech E5S Manuel utilisateur

Harman

Harman AMX MODERO S MSD-701-L2 Manuel utilisateur

Acnodes

Acnodes PC 1150 Manuel utilisateur

AIS

AIS IP10IA99 series Manuel utilisateur

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manuel utilisateur

YASKAWA

YASKAWA TP 610C Manuel utilisateur

B&R

B&R Power Panel C Series Manuel utilisateur

Beijer Electronics

Beijer Electronics X2 control Manuel utilisateur

AXIOMTEK

AXIOMTEK GOT321W-521 Manuel utilisateur

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manuel utilisateur

Qomo

Qomo QIT1386 Manuel utilisateur

DFI

DFI KS104-CD Manuel utilisateur

AMX

AMX AXP-PPC Mode d’emploi

Sartorius

Sartorius X3 PR 5410 Manuel utilisateur

AMX

AMX Modero X Series Manuel utilisateur

Advantech

Advantech TPC-30 Series Manuel utilisateur
