Shure AD2 Manuel utilisateur

AD2

Handheld Transmitter

AD2 Axient Digital Handheld Transmitter User Guide

Version: 6 (2019-D)

Shure Incorporated
2/27
Table of Contents
AD2Handheld Transmitter 3
WARNING 3
AD2 Handheld Transmitter 3
Features 3
Performance 3
Design 4
Power 4
Included Components 4
Choice of (1) of the following Shure microphone car
tridges: 4
Optional Accessories 4
Optional Shure microphone cartridges: 4
AD2 Transmitter Overview 5
Transmitter Controls 6
Home Screen Display 7
Locking the Interface 7
Battery Installation 7
Setting the AA Battery Type 8
Installing the Battery Contact Cover 8
Shure SB900A Rechargeable Battery 11
Shure SB900A Runtime 11
Checking Battery Info 11
Important Tips for Care and Storage of Shure Recharge
able Batteries 11
AA Batteries and Transmitter Runtime 12
Menu Parameters 13
Tips for Editing Menu Parameters 13
Menu Map 14
Menu Parameter Descriptions 14
Radio Menu 14
Audio Menu 14
Utilities Menu 15
IR Sync 15
Setting the Frequency Manually 16
Updating Firmware 17
Firmware Versioning 17
Updating the Transmitter 17
RF Mute 18
Safe Start 18
Input Overload 19
Tone Generator 19
Matching Audio Levels with Offset 20
Specifications 20
Frequency Bands and Transmitter RF Power 22
LICENSING INFORMATION 25
Australia Warning for Wireless 25
Certifications 25
Information to the user 26

Shure Incorporated

3/27

•

◦

•

AD2

Handheld Transmitter

WARNING

Battery packs may explode or release toxic materials. Risk of fire or burns. Do not open, crush, modify, disassemble, heat

above 140°F (60°C), or incinerate.

Follow instructions from manufacturer

Only use Shure charger to recharge Shure rechargeable batteries

WARNING: Danger of explosion if battery incorrectly replaced. Replace only with same or equivalent type.

Never put batteries in mouth. If swallowed, contact your physician or local poison control center

Do not short circuit; may cause burns or catch fire

Do not charge or use battery packs other than Shure rechargeable batteries

Dispose of battery packs properly. Check with local vendor for proper disposal of used battery packs.

Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like

Note: Use only with the included power supply or a Shure-approved equivalent.

WARNING: Danger of explosion if incorrect battery replaced. Operate only with AA batteries.

AD2 Handheld Transmitter

AD series hand-held transmitters deliver impeccable audio quality and RF performance with wide-tuning, High Density (HD)

mode, and encryption. The transmitter features durable metal construction, AA or SB900A rechargeable power (with dockable

charging), and black or nickel finish options.

Features

Performance

20 Hz to 20 kHz range with flat frequency response

Automatic input staging optimizes gain setting

AES 256-bit encryption-enabled for secure transmission

>120 dB dynamic range

100 meter (300 feet) line-of-sight operating range

Selectable modulation modes optimize performance for spectral efficiency or audio quality:

Standard – optimal coverage, low latency

High density – dramatic increase in max system channel count

Switchable Power Levels = 2/10/35 mW (region dependent)

Built-in tone generator and RF markers to facilitate range-testing

Shure Incorporated

4/27

•

Design

Interchangeable Shure microphone cartridges

Backlit LCD with easy to navigate menu and controls

Rugged metal construction

Menu and power lockout

Power

Up to 8 hours continuous use with 2 x AA alkaline batteries

Shure SB900A lithium-ion rechargeable battery provides extended battery life, precision metering, and zero memory effect

External charging contacts for docked charging

Included Components

Zipper Bag 95B2313

Euro-Threaded Adapter 31B1856

Swivel Adapter, black 90F4046

AA Alkaline Battery (2) 80B8201

Battery Contact Cover WA618

Choice of (1) of the following Shure microphone cartridges:

SM58 (RPW112) KSM9 Nickel (RPW188)

BETA 87C (RPW122) BETA 87A (RPW120)

BETA 58A (RPW 118) KSM9 Black (RPW184)

KSM8 Black (RPW174) KSM8 Nickel (RPW170)

KSM9HS Black (RPW186) KSM9HS Nickel (RPW190)

Optional Accessories

SB900A Rechargeable lithium-ion battery SB900A

Radome Color ID Kit for AD2 WA617M

Microphone stand adapter WA371

Optional Shure microphone cartridges:

SM58 (RPW112)

Shure Incorporated

5/27

SM86 (RPW114)

SM87A (RPW116)

BETA 58A (RPW118)

BETA 87A (RPW120)

BETA 87C (RPW122)

VP68 (RPW124)

KSM9 Nickel (RPW188)

KSM9HS Nickel (RPW190)

KSM9 Black (RPW184)

KSM9HS Black (RPW186)

AD2 Transmitter Overview

①Microphone Cartridge

See Optional Accessories for a list of compatible cartridges.

②Display

View menu screens and settings. Press any control button to activate the backlight.

③Infrared (IR) Port

Align with the receiver IR port during an IR Sync for automated transmitter programming.

④Menu Navigation Buttons

Use to navigate through parameter menus and change values.

⑤Battery Compartment

Requires Shure SB900A rechargeable battery or 2 AA batteries.

⑥AA Battery Adapter

Remove to accommodate a Shure SB900A battery.

⑦On/Off Switch

Powers the unit on or off.

⑧Battery Door

Latch to secure batteries.

⑨Handle

Unscrew to access controls and batteries.

Shure Incorporated

6/27

•

Transmitter Controls

Use to navigate through parameter menus and change values.

exit Acts as a 'back' button to return to previous menus or parameters without confirming a value change

enter Enters menu screens and confirms parameter changes

∨∧ Use to scroll through menu screens and to change parameter values

Tip: Use the following shortcuts for quick setup:

Hold the ∧button while powering on to lock or unlock the transmitter controls.

Hold the exit button while powering on to enter the Safe Start menu.

Shure Incorporated

7/27

◦

Home Screen Display

The home screen shows transmitter information and status.

There are four pieces of information that you can choose to see on the home screen. Use the arrow buttons to select one of

the following choices:

Name

Frequency Setting

Group (G) and Channel (C)

Device ID

The following icons indicate transmitter settings:

Battery runtime in hours and minutes or bar display

Key: Displayed when encryption is enabled

Lock: Displayed when controls are locked. Icon will flash if

access is attempted to a locked control (power or menu).

STD: Standard Transmission Mode

HD: High Density Transmission Mode

RF Mute Engaged: Displayed when RF output is muted

Locking the Interface

Lock transmitter interface controls to prevent accidental or unauthorized changes to parameters. The lock icon appears on the

home screen when the interface lock is enabled.

From the Utilities menu, navigate to Locks and select one of the following lock options:

None: The controls are unlocked

Power: The power switch is locked

Menu: The menu parameters are locked

All: The power switch and menu parameters are locked

Press enter to save.

Tip: To quickly unlock a transmitter: Press enter twice, select None, and press enter.

Shure Incorporated

8/27

•

◦

Battery Installation

①Accessing the Battery

Compartment Unscrew the cover on the transmitter as shown to access the battery compartment.

②Installing Batteries

AA Batteries: Place batteries (note polarity markings) and AA Adapter as shown. Close

the door to secure the batteries.

Shure SB900A Battery: Place battery as shown (note polarity markings). Remove the

AA adapter and stow it in the door. Close the door to secure the battery.

Note: If using AA batteries, set the battery type using the transmitter menu.

Setting the AA Battery Type

To ensure accurate display of transmitter runtime, set the battery type in the transmitter menu to match the installed AA battery

type.

Note: If a Shure SB900A rechargeable battery is installed, selecting a battery type is not necessary and the battery type will display Shure.

Navigate to the Utilities and select Battery.

Use the ▼▲ buttons to select the installed battery type:

Alkaline = Alkaline

NiMH = Nickel Metal Hydride

Lithium = Lithium Primary

Press enter to save.

Shure Incorporated

9/27

Installing the Battery Contact Cover

Use battery contact covers to prevent reflections from the battery contacts during broadcasts or live performances.

Remove the transmitter handle.

Pull gently on the antenna cover to remove. Install a battery contact cover in its place.

Reinstall the transmitter handle.

Shure Incorporated

10/27
