Studiobeam MSR-575

ORDERCODE 30708

Congratulations!

You have bought a great, innovative product from Showtec.

The Showtec Studiobeam brings excitement to any venue.

You can rely on Showtec, for more excellent lighting products.

We design and manufacture professional light equipment for the entertainment industry.

New products are being launched regularly. We work hard to keep you, our customer, satisfied.

For more information: [email protected]

You can get some of the best quality, best priced products on the market from Showtec.

So next time, turn to Showtec for more great lighting equipment.

Always get the best -- with Showtec !

Thank you!

Showtec

Showtec Studiobeam™Product Guide

Warning..…...................................................................................…………………………………………..

Safety-instructions………………………………………………………………………………………….….

Operating Determinations……………………………………………………………………………………..

Installing the Studiobeam with a Clamp/Hook………………………………………………………………

Rigging…………………………………………………………………………………………………………..

Description..…..............................................................................……….……………………………….…

Features……………………….………………………………………………………….………………….….

Installation...............................................................................…...……………………….…………….…..

Installing the Lamp ........................................................………………………………………..…………

Lens Identification......................................................……………………………………………………...

Installing a Lens......................................................………………………………………………………...

Removing a Lens......................................................…………………………………………………..…..

Color Frame Retaining Clip.............................……………………………………………………………...

Set Up and Operation.....................................................................……..……………………………….…

Maintenance...................................................................................………..………….…….………………

Cleaning the Rflector...................................................................…………………….…………………..

Changing the Lamp........................................................................…………………….…………………

Replacing the Fuse........................................................................…………………….…………………

Troubleshooting............................................................................………………….………………….…..

No Light............................................………………….……………………………………………………..

Product Specifications.................................................................……………….…….…………………..

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

SAFETY INSTRUCTIONS

Every person involved with the installation, operation and maintenance of this device has to:

-be qualified

-follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to follow

the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-observance of

this manual or any unauthorized modification to the device.

•Never let the power-cord come into contact with other cables! Handle the power-cord and all

connections with the mains with particular caution!

•Never remove warning or informative labels from the unit.

•Do not open the device and do not modify the device.

•Do not insert objects into air vents.

•Never use anything to cover the ground contact.

•Never look directly into the light source.

•Never leave any cables lying around.

•Never use the device during thunderstorms, unplug the device immediately.

•Do not connect this device to a dimmerpack.

•Do not switch the device on and off in short intervals, as this would reduce the lamp’s life.

•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).

•Do not shake the device. Avoid brute force when installing or operating the device.

•Do not operate the device without a lens installed.

•Only use device indoor, avoid contact with water or other liquids.

•Only operate the fixture after having checked that the housing is firmly closed and all screws are

tightly fastened.

•Only operate the device after having familiarized with its functions.

•Avoid flames and do not put close to flammable liquids or gases.

•Always hang the device with the color frame retaining clip in the locked position.

•Always replace the lamp, when it is damaged or deformed due to the heat.

•Always keep case closed while operating.

•Always allow free air space of at least 50 cm around the unit for ventilation.

CAUTION!

Keep this device away from rain and moisture!

mains lead before o

enin

the housin

CAUTION! Be careful with your operations.

With a dangerous voltage you can suffer

a dan

erous electric shock when touchin

the wires!

•Always disconnect power from the mains, when device is not used, before cleaning or when

replacing lamp! Only handle the power-cord by the plug. Never pull out the plug by tugging the

power-cord.

•Make sure that the device is not exposed to extreme heat, moisture or dust.

•Make sure that the available voltage is not higher than stated on the rear panel.

•Make sure that the power-cord is never crimped or damaged. Check the device and the power-cord

from time to time.

•Make sure that no side forces can impact on the truss system.

•Make sure that the core diameter of extension cords and power cords is sufficient for the required

power consumption of the device.

•The Studiobeam must be installed onto truss systems via the mounting bracket.

•The cable insert or the female part in the device must never be strained. There must always be

sufficient cable to the device. Otherwise, the cable may be damaged which may lead to deadly

electrical shocks.

•If the external cable is damaged, it has to be replaced by a qualified technician.

•If the lens or glass is obviously damaged, it has to be replaced. So that its functions are not

impaired, due to cracks or deep scratches.

•If device is dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not

switch it on immediately. The arising condensation water might damage your device. Leave the

device switched off until it has reached room temperature.

•If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

•For adult use only. Light effect must be installed out of the reach of children. Never leave the unit

running unattended.

•For replacement use lamps and fuses of same type and rating only.

•Allow time to cool down, before replacing lamp.

•The user is responsible for correct positioning and operating of the Studiobeam. The manufacturer

will not accept liability for damages caused by the misuse or incorrect installation of this device.

•This device falls under protection class I. Therefore it is essential to connect the yellow/green

conductor to earth.

•To ensure the longest and most efficient use of the lamp always wait 15 minutes before re-applying

power after a shutdown. Failure to do so could result in premature aging of the lamp and failure to

the electronics that drive it.

•Replace the lamp if it becomes defective or worn out, or before usage exceeds the maximum service

life.

•During the initial start-up some smoke or smell may arise. This is a normal process and does not

necessarily mean that the device is defective.

•Repairs, servicing and electric connection must be carried out by a qualified technician.

•WARRANTY: Till one year after date of purchase.

CAUTION ! EYEDAMAGES !.

Avoid looking directly into the light source.

(

meant es

eciall

for e

ile

tics

)

OPERATING DETERMINATIONS

This device is not designed for permanent operation. Consistent operation breaks will ensure that the device

will serve you for a long time without defects.

The minimum distance between light-output and the illuminated surface must be more than 2 meters.

The maximum ambient temperature ta= 45°C must never be exceeded.

The relative humidity must not exceed 50 % with an ambient temperature of 45° C.

If this device is operated in any other way, than the one described in this manual, the product may suffer

damages and the warranty becomes void.

Any other operation may lead to dangers like short-circuit, burns, electric shock, lamp explosion, crash etc.

You endanger your own safety and the safety of others!

Installing the Studiobeam with a Clamp

You can choose an appropriate mounting clamp (ordercode 70109S / 70109B) from Showtec to securely

mount your Studiobeam to the trussing system. Once it has been mounted, adjust the mounting position of

the Studiobeam.

1. Tightly fasten the hook to the yoke with the provided yoke bolt and lock washer.

2. Place the clamp on the truss system, then tighten the pipe bolt to secure it.

3. Adjust the desired inclination-angle via the yoke and fix the yoke locking knob.

4. Pull the safety-cable through the hole on the housing and over the truss system.

Insert the end in the carabine and tighten the safety screw.

Rigging

Please follow the European and national guidelines concerning rigging, trussing and all other safety issues.

Do not attempt the installation yourself !

Always let the installation be carried out by an authorized dealer !

Procedure:

•If the Studiobeam is lowered from the ceiling or high joists, professional trussing systems have to be

used.

•Use a clamp to mount the Studiobeam, with the mounting-bracket, to the trussing system.

•The Studiobeam must never be fixed swinging freely in the room.

•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or

safety-cable.

•When rigging, derigging or servicing the Studiobeam, always make sure, that the area below the

installation place is blocked and staying in the area is forbidden.

The Studiobeam can be placed on a flat stage floor or mounted to any kind of truss by a clamp.

Improper installation can cause serious damage to people and property !

Connection with the mains

Connect the device to the mains with the power-plug.

Always pay attention, that the right color cable is connected to the right place.

Wire Color Pin International

Brown Fase / Live L

Blue Nul / Neutral N

Yellow / Green Earth / Ground

Make sure that the device is always connected properly to the earth!

Description of the device

Features

The Studiobeam MSR-575 is a Studiobeam from Showtec with RGB-Mix.

• Lamp: MSR 575 240V/575W (80915 / 80915O / 80923)

• Electronic ballast ensuring maximum and stable light output

• 4 lenses included: VNSP, NSP, MFL, WFL

Overview

Fig. 1

Installation

Installing the Lamp

The Showtec Studio Beam uses a MSR 575W (ordercode 80915 / 80915O / 80923) bulbs as manufactured

by all popular manufacturers. Use only the appropriate lamp for your unit.

Note that, product versions that use other lamps, may be offered in the future. Check your product

specification label for information.

Always disconnect from electric mains power supply before changing lamps.

The lamp has to be replaced when it is damaged or deformed due to the heat.

Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the

device was not designed for.

Damages caused by non-observance are not subject to warranty.

Procedure :

1. Disconnect from main power supply, and let the Studiobeam cool down for 15 minutes.

2. Loosen the knurled bolt on the back of the lamp housing and pull the housing straight out from the fixture.

3. Read lamp instructions. Do not touch the lamp bulb glass. Oil on hands shortens the lamp life. (If you

touch the bulb glass, wipe off the glass with a clean, lint-free towel and rubbing alcohol.).

4. Line up the flat sides of the lamp base with the brackets on either side of the socket (Fig. 3).

5. Insert the lamp pins into the small holes in the lamp socket. Be sure that the lamp is pushed all the way

down.

6. Put the lampcover back, by centering it on the reflector and the bolthole. Then fasten the knurled bolt

again.

Fig. 3

Lens Identification

Lenses for the Studiobeam are available in 4 versions. The type or beam angle can be identified by the lens

texture.

Fig. 4

Installing a Lens

1. When installing the lens, make sure the fixture is on a safe height. Please prevent people from walking

under the fixture, when replacing the lens !

2. Position the fixture with the frontside of the unit (Lens Side) facing you. Then tilt its head slightly (Fig. 5).

3. Position the lens rotation ring with the spring clip at the top of the fixture, below the retaining clip.

4. Hold the lens by its edge and position it so, that the convex side faces the back of the fixture (Fig. 6).

Note: Installing the lens with the convex side out, will not only impair the optics, but it will also make

removing the lens difficult.

5. From the top of the fixture, slide the lens behind the lens catchers and position its base behind the tabs

on the bottom of the lens rotation ring.

6. Gently push the top of the lens inwards, until it snaps behind the spring clip.

Fig. 5 Fig. 6

Removing a Lens

1. Studiobeam lenses get hot while the unit is in operation. Let thefixture cool down before handling the

lens.

2. Place the fixture on a flat, stable worksurface.

Pay Attention Never install or remove lenses when the unit is hanging.

3. Position the lens rotation ring with the spring clip at the front of the unit, directly below the retaining clip.

4. Tilt the front of the fixture down at least 45º.

5. Press the spring clip with your fingers to release the lens (Fig. 5).

6. Allow the lens to gently drop forward from under the clip.

7. When the lens drops, remove your finger, allowing the lens to slide forward until it rests on the lens

catchers (Fig. 7).

8. Carefully remove the lens from the fixture.

Fig. 7

Table des matières

Autres manuels Show Tec Équipement d'éclairage

Show Tec

Show Tec Scorpion Scan 260 Manuel utilisateur

Show Tec

Show Tec XB-Duomoon Manuel utilisateur

Show Tec

Show Tec Sunstrip Pro RGB Manuel utilisateur

Show Tec

Show Tec 42421 Manuel utilisateur

Show Tec

Show Tec Performer 60 LED V2 Manuel utilisateur

Show Tec

Show Tec Lite-8 Pro Manuel utilisateur

Show Tec

Show Tec phantom 75 LED Manuel utilisateur

Show Tec

Show Tec LED Tunnel Flower Manuel utilisateur

Show Tec

Show Tec Explorer 250 Wash Manuel utilisateur

Show Tec

Show Tec LED PowerBank 48 Manuel utilisateur

Show Tec

Show Tec LED Par 56 Ultra Bright RGB Manuel utilisateur

Show Tec

Show Tec Galactic RGB-6-751 V1 Manuel utilisateur

Show Tec

Show Tec Pixelstrip 40 V1 Manuel utilisateur

Show Tec

Show Tec LED Police Light V1 Manuel utilisateur

Show Tec

Show Tec Spectral PC 400Z IP V1 Manuel utilisateur

Show Tec

Show Tec Spectral M1500 Zoom Q4 MKII Manuel utilisateur

Show Tec

Show Tec Performer 3000 LED Manuel utilisateur

Show Tec

Show Tec Cameleon Bar 100 Manuel utilisateur

Show Tec

Show Tec Compact Par 7 Tri Manuel utilisateur

Show Tec

Show Tec Galactic GBC-120 Manuel utilisateur

Show Tec

Show Tec Parcan 36 V2 Manuel utilisateur

Show Tec

Show Tec LED Light Bar RGB Manuel utilisateur

Show Tec

Show Tec Followspot HMI 1200 Manuel utilisateur

Show Tec

Show Tec Phantom 1220 Zoombar Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
