Congratulations!

You have bought a great, innovative product from Showtec.

The Showtec LED Pixelfloor brings excitement to any venue. Whether you want simple plug-&-play action

or a sophisticated DMX show, this product provides the effect you need.

You can rely on Showtec, for more excellent lighting products.

We design and manufacture professional light equipment for the entertainment industry.

New products are being launched regularly. We work hard to keep you, our customer, satisfied.

For more information: iwant@showtec.info

You can get some of the best quality, best priced products on the market from Showtec.

So next time, turn to Showtec for more great lighting equipment.

Always get the best -- with Showtec !

Thank you!

Showtec

Showtec LED Pixelfloor™Product Guide

Warning ...............................................................................................................................................................................2

Safety Instructions .........................................................................................................................................................2

Operating Determinations ..........................................................................................................................................4

Rigging ............................................................................................................................................................................4

Return Procedure..........................................................................................................................................................5

Claims..............................................................................................................................................................................5

Description of the device.................................................................................................................................................6

Overview ........................................................................................................................................................................6

Backside .........................................................................................................................................................................7

Installation...........................................................................................................................................................................8

Set Up and Operation .......................................................................................................................................................8

Maximum Loads............................................................................................................................................................8

Level Surface .................................................................................................................................................................9

Rigging ............................................................................................................................................................................9

Maximum and Minimum Height ..............................................................................................................................10

Connecting LED Pixelfloor ........................................................................................................................................10

Setup example LED Pixelfloor ...................................................................................................................................10

Setup example combination of Klingnet fixtures..................................................................................................11

How to make a Data Cable ..........................................................................................................................................12

Software for controlling VIDEO over the LED Pixelfloor (Arkaos or DMT)...............................................................13

Maintenance....................................................................................................................................................................13

Troubleshooting ...............................................................................................................................................................14

No Light.........................................................................................................................................................................14

Product Specification .....................................................................................................................................................15

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure

that all parts are present, and have been received in good condition. Notify the dealer immediately and

retain packing material for inspection if any parts appear damaged from shipping or the carton itself

shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be

returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Your shipment includes:

• Showtec LED Pixelfloor with clear cover

• 1 x AC Power Plug

• User manual

LED Expected Lifespan

LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration

of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular

optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is

significantly reduced. If improving your lifespan expectancy is of a higher priority, place care in providing

for lower operational temperatures. This may include climatic-environmental and the reduction of overall

projection intensity.

Safety Instructions

Every person involved with the installation, operation and maintenance of this device has to:

-be qualified

-follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to

follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to

warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

CAUTION! Be careful with your operations.

With a dangerous voltage you can suffer

a dangerous electric shock when touching the wires!

CAUTION!

Keep this device away from rain and moisture!

Unplug mains lead before opening the housing!

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-

observance of this manual or any unauthorized modification to the device.

Never let the power-cord come into contact with other cables! Handle the power-cord and all

connections with the mains with particular caution!

Never remove warning or informative labels from the unit.

Never use anything to cover the ground contact.

Never leave any cables lying around.

Do not insert objects into air vents.

Do not connect this device to a dimmerpack.

Do not open the device and do not modify the device.

Never use the device during thunderstorms, unplug the device immediately.

Never look directly into the light source.

Do not switch the device on and off in short intervals, as this would reduce the system’s life.

Do not shake the device. Avoid brute force when installing or operating the device.

Only use device indoor, avoid contact with water or other liquids.

Avoid flames and do not put close to flammable liquids or gases.

Always allow free air space of at least 50 cm around the unit for ventilation.

Always disconnect power from the mains, when device is not used or before cleaning! Only

handle the power-cord by the plug. Never pull out the plug by tugging the power-cord.

Make sure that the device is not exposed to extreme heat, moisture or dust.

Make sure that the available voltage is not higher than stated on the rear panel.

Make sure that the power-cord is never crimped or damaged. Check the device and the power-

cord from time to time.

Make sure that the core diameter of extension cords and power cords is sufficient for the required

power consumption of the device.

The cable insert or the female part in the device must never be strained. There must always be

sufficient cable to the device. Otherwise, the cable may be damaged which may lead to deadly

electrical shocks.

If the external cable is damaged, it has to be replaced by a qualified technician.

If the top surface is obviously damaged, it has to be replaced. So that its functions are not

impaired, due to cracks or deep scratches.

If device is dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do

not switch it on immediately. The arising condensation water might damage your device. Leave

the device switched off until it has reached room temperature.

If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

For adult use only. Light effect must be installed out of the reach of children. Never leave the unit

running unattended.

For replacement use fuses of same type and rating only.

The user is responsible for correct positioning and operating of the LED Pixelfloor. The

manufacturer will not accept liability for damages caused by the misuse or incorrect installation

of this device.

This device falls under protection class I. Therefore it is essential to connect the yellow/green

conductor to earth.

Protect the power cord from being walked on or pinched particularly at plugs.

Acrylic cover might be slippery when it’s wet. Please keep the acrylic cover dry all the time.

Acrylic cover and rubber adjustable feet are designed to absorb impact force. It is normal to feel

dance floor bounced back when jumping on it.

Repairs, servicing and electric connection must be carried out by a qualified technician.

WARRANTY: Till one year after date of purchase.

Operating Determinations

•This device is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

•The minimum distance between light-output and the illuminated surface must be more than 0.8 meter.

•The maximum ambient temperature ta= 45°C must never be exceeded.

•The relative humidity must not exceed 50 % with an ambient temperature of 45° C.

•If this device is operated in any other way, than the one described in this manual, the product may

suffer damages and the warranty becomes void.

•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.

You endanger your own safety and the safety of others!

Improper installation can cause serious damage to people and property !

Rigging

Please follow the European and national guidelines concerning rigging, trussing and all other

safety issues.

Do not attempt the installation yourself !

Always let the installation be carried out by an authorized dealer !

Improper installation can cause serious damage to people and property !

Connection with the mains

Connect the device to the mains with the power-plug.

Always pay attention, that the right color cable is connected to the right place.

International

EU Cable

UK Cable

US Cable

BROWN

RED

YELLOW/COPPER

FASE

BLUE

BLACK

SILVER

NUL

YELLOW/GREEN

GREEN

EARTH

Make sure that the device is always connected properly to the earth!

CAUTION ! EYEDAMAGES !.

Avoid looking directly into the light source.

(meant especially for epileptics) !

Return Procedure

Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.

Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned

without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.

Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.

Be prepared to provide the model number, serial number and a brief description of the cause for the

return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the

customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace

product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.

Note: If you are given an RMA number, please include the following information on a piece of paper

inside the box:

1) Your name

2) Your address

3) Your phone number

4) A brief description of the symptoms

Claims

The client has the obligation to check the delivered goods immediately upon delivery for any short-

comings and/or visible defects, or perform this check after our announcement that the goods are at their

disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be

reported to the carrier upon receipt of merchandise.

It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is

damaged due to shipping. Transportation damage has to be reported to us within one day after receipt

of the delivery.

Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with

a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless

otherwise agreed in writing.

Complaints against us must be made known in writing or by fax within 10 working days after receipt of the

invoice. After this period complaints will not be handled anymore.

Complaints will only then be considered if the client has so far complied with all parts of the agreement,

regardless of the agreement of which the obligation is resulting.

Description of the device

Features

The LED Pixelfloor is designed for the more demanding user:

Klingnet is developed in collaboration with Arkaos, ensuring powerful tools and state-of-art functionalities

in combination with easy set-up.

•Plug & Play with Klingnet protocol

•Quick setup due to deck brackets

•Liquid resistant CAT5 connections

•Bright colors

•The Pixelfloor P25 is a one square meter LED tile working on the Klingnet-protocol.

•Simple to integrate these dance floors in a setup with strips and battens.

•Klingnet allows you to display visuals across all fixtures in the right proportions, regardless their position.

•The Pixelfloor P25 has a 25mm pixelpitch and a wide viewing angle of 120 degrees.

•The power and data connections are liquid resistant and made for daisy chain setup.

•Coupling the floors is very easy with 2 special connection brackets which are included.

•New and revolutionary concept which makes pixel control easy and affordable.

•Pixel pitch: 25 mm

•Pixel quantity: 1600 pixels

•Klingnet-protocol controlled

•LED Light source: RGB 5050SMD LED

•Luminance: 1000 nits

•Refresh rate: 2000 Hz

•Viewing angle: 120 degrees

•RJ45 waterproof connectors for Kling-Net in/out connection

•Connection: CAT-5

•IP-Rating: IP-40

•Housing: Lightweight aluminum extrusion casing

•Finish: Black powder coat

•Dimensions: 1000 x 1000 x 110mm

•Max Load: 750Kg/m2

•Power supply: AC 100-230V / 50-60Hz

•No PSU/ Junctionbox needed

•Power consumption: 350W

•Weight: 40 kg

Optional accessories: 42281 Spare bracket

42282 Spare powercable

42283 Pixelfloor Data Cable

Overview

Fig. 1

Backside

Fig. 2

1 2 3 4 5

1) Data OUT

2) Data IN

3) Power OUT

4) Power IN

5) Special Powercable

2 1

4 3

Fig. 3

Installation

Remove all packing materials from the LED Pixelfloor. Check that all foam and plastic padding is

removed. Connect all cables.

Do not supply power before the whole system is set up and connected properly.

Always disconnect from electric mains power supply before cleaning or servicing.

Damages caused by non-observance are not subject to warranty.

Set Up and Operation

Follow the directions below, as they pertain to your preferred operation mode.

Before plugging the unit in, always make sure that the power supply matches the product specification

voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

Damages caused by non-observance are not subject to warranty.

Before attaching the device, make sure the installation surface can hold

a minimum point load of ten times the device's weight.

Maximum Loads

Uniformly Distributed Load 750 Kg/m2

Point Load F1 350 Kg

Point Load F2 210 Kg

Fig. 4

The point load should be applied to a minimum area of 12 cm x 27 cm, approximately the area of the

sole of a foot. The point load is placed as shown in Fig 4.

Only 1 point load per m2is allowed.

Note

1. Please make sure that the LED Pixelfloor is properly aligned and completely leveled.

2. Before applying loads, please make sure that their exact weight and size are within the loading

specifications.

3. There is no clear definition on the impact force for a stage as used in entertainment market.

Normal walking or dancing on dance floor is OK, but jumping is not guaranteed.

The LED Pixelfloor has 2 RJ45 connection cables. One is for Kling-Net input and the other is for Kling-Net

output. You can daisy-chain the LED Pixelfloor to another Kling-Net device depending on the number of

pixels you want in a specific setup.

•Make sure that the installation surface can hold a minimum 10 times the pixelfloor's weight.

•Make sure no combustible or flammable materials are nearby.

•Consider component replacement and routine maintenance access, when choosing your installation

location.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Show Tec Matériel de DJ

Show Tec

Show Tec DB-1-4/RDM Manuel utilisateur

Show Tec

Show Tec DJ Switch 10 Manuel utilisateur

Show Tec

Show Tec FX Blaster XL V1 Manuel utilisateur

Show Tec

Show Tec Single DP-1 Manuel utilisateur

Show Tec

Show Tec Polar 340 WashFX Manuel utilisateur

Show Tec

Show Tec Polar 300 Hybryd Manuel utilisateur

Show Tec

Show Tec StageBeam 300/500W Fresnel V2 Manuel utilisateur

Show Tec

Show Tec ACT Fresnel 150 RGBAL V1 Manuel utilisateur

Show Tec

Show Tec Pixel Square 25 COB Manuel utilisateur

Show Tec

Show Tec LED Powerline 64 Manuel utilisateur

Show Tec

Show Tec SM-8/2 Manuel utilisateur

Show Tec

Show Tec Performer 2000 RGBAL V1 Manuel utilisateur

Show Tec

Show Tec Shogun Club G-40 Manuel utilisateur

Show Tec

Show Tec Parcan 16 GU10D socket V1 Manuel utilisateur

Show Tec

Show Tec Shogun DJ RG-100 Manuel utilisateur

Show Tec

Show Tec Candela Pix 50 Manuel utilisateur

Show Tec

Show Tec eventbar 12/3 Manuel utilisateur

Show Tec

Show Tec Performer Profile Mini MKII 3200K Manuel utilisateur

Show Tec

Show Tec Performer 1500 Fresnel Q6 Manuel utilisateur

Show Tec

Show Tec LED Wall Wash Manuel utilisateur

Show Tec

Show Tec Performer Profile IP Q4 Manuel utilisateur

Show Tec

Show Tec Performer Profile Zoom 150 Q6 Manuel utilisateur

Show Tec

Show Tec Compact Par 7 Tri Manuel utilisateur

Show Tec

Show Tec cameleon bar 24/1 UV Manuel utilisateur

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
