Sharp UA-PE30E Manuel utilisateur

UA-PE30E

Operation manual

Air Purifier

EN FRDE ITES PL NL

Thank you for purchasing this SHARP Air

Puriﬁer. Please read this manual carefully

before using the product.

This manual should be kept in a safe place for

handy reference.

CONTENTS

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS ................1

OPERATION PRINCIPLE .......................................4

PART NAMES .........................................................5

BEFORE FIRST USE..............................................6

OPERATION ...........................................................7

CARE AND MAINTENANCE ..................................8

TROUBLESHOOTING..........................................10

SPECIFICATIONS.................................................10

EN-1

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS

Always follow basic safety precautions when using electrical appliances,

including the following:

WARNING

Always observe the following to reduce the risk of electrical shock, fire, or injury:

OPERATION

• Read all instructions before using the product.

• Use only a 220 - 240 volt outlet.

• Do not use the product if the power cord or plug is damaged or if the connection

to the wall outlet is loose.

• Periodically remove dust from the plug.

• When removing the power plug, always hold the plug and never pull on the cord.

Failure to do so can cause a short circuit resulting in electrical shock or fire.

• Be careful not to damage the power cord. Failure to do so can cause electric

shock, heat generation, or fire.

• Do not remove the plug when your hands are wet.

• Be sure to remove the power plug before performing maintenance, when

removing and attaching and replacing the filter and when not using for a long

time. Failure to do so can cause a short circuit resulting in electrical shock or fire.

• If the power cord is damaged, it must be replaced by the manufacturer, its service

agent, a Sharp authorized Service Centre or similarly qualified persons in order to

avoid a hazard.

Contact the nearest Service Centre for any problems, adjustments, or repairs.

• Do not repair or disassemble the product yourself.

• Do not insert fingers or foreign objects into the Air Inlet or Air Outlet.

• Do not expose the product to water.

Doing so can cause a short circuit or electrical shock.

• This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of

the appliance in a safe way and understand the hazards involved. Children shall

not play with the appliance. Cleaning and user maintenance shall not be made by

children without supervision.

INSTALLATION

• Do not use this product near gas appliances or fireplaces.

When the product is operated with gas appliances in same room, Ventilate a room

periodically, otherwise it may cause Carbon monoxide poisoning.

• Do not operate the product in rooms where aerosol insecticides are present.

Do not operate the product in rooms where there is oily residue, incense, sparks

from lit cigarettes, or chemical fumes in the air.

• Keep the product away from water.

Do not operate the product in places where it may get wet, such as a bathroom.

EN-2

MAINTENANCE

• Be cautious when cleaning the product.

Strong corrosive cleansers can damage the exterior.

CAUTION

OPERATION

• Do not block the Air Inlet or Air Outlet.

• Always operate the product in an upright position.

• When moving the product, use the handle on the back of the product.

• Do not move the product when it is in operation.

• If the product is on easily damaged flooring, an uneven surface, or thick-piled

carpet, lift it up when moving.

• Do not operate the product without the filters properly installed.

INSTALLATION

• Do not place the product near or on hot objects, such as stoves or heaters, or

where it may come into contact with steam.

MAINTENANCE

• Clean the exterior with a soft cloth only.

Do not use volatile fluids or detergents.

The product surface may be damaged or cracked with Benzine paint thinner or

polishing powder.

• Do not scrub the Back Panel hard during its maintenance.

• Do not wash and reuse the HEPA filter.

Doing so will not improve filter performance and can also cause electric shock or

operating malfunctions.

NOTE

What to do if the product interferes with radio or TV reception

If the air purifier interferes with radio or television reception, try one or more of the

following measures:

• Adjust or reposition the receiving antenna.

• Increase the distance between the product and the radio or TV.

• Connect the equipment into an outlet on a circuit different from that of the radio or

TV receiver.

• Consult the dealer or a qualified radio or TV technician.

EN-3

ENGLISH

INSTALLATION

• Avoid locations where furniture, fabrics, or other objects can come in contact with

the product and interfere with the intake and outtake of air.

• Avoid locations where the product is exposed to condensation or drastic changes

in temperature. Appropriate room temperature is between 0 – 35 ºC.

• Place the product on a level and stable surface with sufficient air circulation.

Strong wind or dust through the window may prevent the product’s air purifying

performance and efficacy.

When placed on heavy carpet, the product may vibrate slightly.

• Avoid locations that generate grease or oily smoke. Doing so can cause the

product exterior to crack.

• The dust collecting ability of the product is effective even when the product is

as close to 3 cm from the wall, the surrounding walls and floor may get dirty.

Please place the product at a distance from the wall. The wall directly behind the

air outlet may become dirty over time. When using the product for an extended

period of time at the same location, periodically clean the walls adjacent to it.

MAINTENANCE

• Follow the instructions in this manual for proper filter care and maintenance.

EN-4

OPERATION PRINCIPLE

The air puriﬁer draws in room air through the Air Inlet, circulates it through a

Pre-Filter and a HEPA Filter inside the product, and then discharges it through the Air

Outlet. The HEPA Filter can remove 99.97% of dust particles as small as 0.3 microns

that pass through the ﬁlter.

Some odours absorbed by the ﬁlter will break down over time, causing additional

odours. Depending on usage conditions, and especially if the product is used in

environments signiﬁcantly more severe than a normal household, these odours may

become noticeable sooner than expected. If these odours persist, replace the ﬁlter.

NOTE

• The air puriﬁer is designed to remove air-suspended dust.

The air puriﬁer is not designed to remove harmful gases such as carbon monoxide contained

in cigarette smoke.

Please read before operating your new Air Purifier

HEPA Filter

Back Panel

(Pre-Filter)

Filtration System

Pre-Filter

Pre-Filter traps dust and other large airborne particles.

HEPA Filter

HEPA Filter traps 99.97% of particles as small as 0.3 microns.

EN-5

ENGLISH

PART NAMES

1Main Unit 8HEPA Filter

2Air Outlet 9Back Panel (Pre-Filter)

3Fan Speed Lamps (Green) 10 Air Inlet

4Fan Speed MODE Button 11 Handle

5REPLACE FILTER Button, Lamp (Orange) 12 Power Cord

6Power ON/OFF Button 13 Power Plug

7Quick Clean Button, Lamp (Green)

FRONT

BACK

13 12

EN-6

BEFORE FIRST USE

• To maintain the quality of the ﬁlter, it is installed in the product and packaged in a plastic

bag.

Always be sure to remove the

power plug from the wall outlet.

1Remove the Back Panel (Pre-

Filter).

Upper Tabs

Pull

2Take out the filter from the

plastic bag.

3Place the filter within the

product.

Do not install the ﬁlter backwards or the

product will not operate properly.

4Replace the Back Panel to the

product.

Push

Bottom Tabs

Push

EN-7

ENGLISH

OPERATION

By continuously discharging strong airﬂow cycles in 60 minutes, the product eﬀectively removes

airborne dust, pollen, mold and allergens from the air as they are drawn through the ﬁlter system.

If the product is unplugged or if there is a power failure, the product will resume operation with the

previous settings after power is restored.

START

QUICK CLEAN

START

FAN SPEED

AUTO RESTART

POWER ON/OFF

STOP

• Unless the power plug has been

unplugged, the operation starts in the

previous mode it was operated in.

• When the operation ﬁnishes, the

product will return to the prior operation

mode.

It is possible to change to the other

modes or turn the product OFF while

operating in this mode.

MED SLEEPMAX

NOTE

SLEEP

• The product will operate very quietly

with low fan speed.

NOTE

ON (default)

(with the product OFF)

Press for

3 sec.

Lighting

OFF

(with the product OFF)

Press for

3 sec.

Flashing

• If the Fan Speed Lamps illuminate for 10 seconds, the setting is completed.

EN-8

CARE AND MAINTENANCE

Wipe with a dry, soft cloth.

For stubborn stains or dirt, use a soft cloth dampened with warm water.

NOTE

• Do not use volatile ﬂuids.

Benzine, paint thinner, polishing powder, etc. , may damage the surface.

• Do not use detergents.

Detergent ingredients may damage the product.

MAIN UNIT

Always be sure to remove the

power plug from the wall outlet.

• To maintain optimum performance of this air puriﬁer, please clean the product including

the ﬁlter periodically.

Tag

HEPA FILTER

Gently remove dust from the HEPA Filter with a vacuum

cleaner attachment or similar tool.

NOTE

• Do not WASH in water and DRY in the sunlight.

• Perform maintenance only on the side with the tag.

Do not clean the opposite side; otherwise, the ﬁlter will be

damaged.

The ﬁlter is fragile, be careful not to apply too much force.

NOTE How to clean hard to remove dirt

Back Panel

Back Panel 1. Add a small amount of kitchen detergent to water

and soak for about 10 minutes.

2. Rinse oﬀthe kitchen detergent with clean water.

3. Completely dry the ﬁlter in a well-ventilated area.

BACK PANEL (Pre-Filter)

Gently remove dust from the Back Panel, using a vacuum

cleaner attachment or similar tool.

NOTE

Do not apply excessive pressure, when scrubbing the Back

Panel.
