Sharp IG-DX10A Manuel utilisateur

ENGLISH

Plasmacluster Ion Generator

OPERATION MANUAL

IG-DX10A

Device of this mark is a trademark of Sharp

Corporation.

Plasmacluster is a registered trademark or a

trademark of Sharp Corporation.

ENGLISH

HD 離子簇抗菌機

使用說明書

中文

請仔細閱讀並妥善保存這本手冊。

本技術標示的數字，是將已裝置 HD 離子產生器的 HD 離

子簇抗菌機貼近牆壁的位置，並設置為最大風量運轉，

在適用面積的房間中央附近（距離地面高度 1.2m)，測

出空氣中的離子數量為 25000/cm3。

Read and keep this manual carefully.

此標誌的裝置乃 Sharp 株式會社的商標。

Plasmacluster 乃 Sharp 株式會社的註冊商標或

商標。

*1 The number in this technology mark indicates an

approximate number of ions supplied into air 1 cm3,

which is measured around the center of a room with the

applicable floor area (at 1.2m height above the floor)

at the maximum wind volume, when plasmacluster ion

evolving equipment using the high-density plasmacluster

ion evolving unit is placed close to a wall.

IG-DX10A.EN.indd1IG-DX10A.EN.indd1 2011/11/0710:59:472011/11/0710:59:47

IG-DX10A.EN.indd2IG-DX10A.EN.indd2 2011/11/0710:59:482011/11/0710:59:48

ENGLISH

Thank you for purchasing this SHARP Plasmacluster Ion Generator.

Please read this manual carefully before using Plasmacluster Ion

Generator.

After reading, keep the manual in a convenient location for future

reference.

The information provided in this manual is subjected to change without notice.

E-1

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS ...............E-2

PARTS NAME ........................................................E-4

• MAIN UNIT/CONTROL PANEL............................................E-4

• BACK/BOTTOM/ACCESSORIES........................................E-5

INSTALLATION GUIDANCE .................................E-6

OPERATION ......................................................................E-8

CLEANING AND MAINTENANCE ............................. E-9

• FILTER.................................................................................E-9

•

MAIN UNIT/PLASMACLUSTER ION GENERATING UNIT

........E-10

PLASMACLUSTER ION GENERATING UNIT REPLACEMENT

.. E-11

HOW TO REPLACE PLASMACLUSTER ION GENERATING UNIT

.. E-12

SPECIFICATIONS..........................................................E-13

TROUBLESHOOTING..................................................E-14

• While IG-DX10A can inactivate suspended viruses and

other contaminants, it cannot create a completely sterilized

environment. SHARP does not guarantee its ability to prevent

microbial infection.

• The actual number of ions and the effect of inactivation,

purification, and beauty vary depending on the conditions of a

room (size, shape, whether an air conditioner or ventilation is

used, installation location of the product etc.) or usage (blowing

direction of ion etc.).

IG-DX10A.EN.indd3IG-DX10A.EN.indd3 2011/11/0710:59:482011/11/0710:59:48

E-2

IMPORTANT SAFETY INSTRUCTIONS

Please read instructions carefully before using this unit.

WARNING - To reduce the risk of electric shock, ﬁre or injury :

When using electrical appliances, basic safety precautions should be followed,

including the following:

• Do not damage or modify the AC adapter and cord. Also, do not use the AC adapter and

cord if it is damaged. (The damaged section could cause short-circuiting and electric

shock leading to ﬁre.)

• Do not remove the AC adapter and cord when your hands are wet. (Otherwise, it may

cause electric shock or injury.)

• Do not connect other appliances to the same socket using extension cord. (Otherwise, it

may cause ﬁre.)

• Do not use the product if the AC adapter is damaged, or the connection to the wall outlet

is loose. (Otherwise, it may cause electric shock and ﬁre.)

• Use only a 220 volt outlet.

• Use the AC adapter designed exclusively for this product, and insert the AC adapter

securely all the way into power socket until it stops.

• When cleaning the unit, stop the operation and pull out the AC adapter from the outlet.

• Periodically remove dust from the AC adapter.

• During thunder storm, stop the operation and pull out the AC adapter from the outlet in

order to avoid the possibility of excess voltage.

• If a defect is generated (burning smell, heat generation, discoloration, deformation etc.),

stop the operation and pull out the AC adapter. (Otherwise, it may cause ﬁre or electric

shock.) Contact the store you purchased this appliance from or Sharp Service Center.

• Do not modify the product. Also, no one other than an authorized service personnel

should take apart or repair the product. (Otherwise, it may lead to ﬁre, electric shock or

injury.) Contact the store you purchased the appliance from or Sharp Service Center.

• Do not insert fingers or foreign object such as pin and wire in power supply input

terminal, air outlet, and air inlet. (Otherwise, it may cause electric shock, injury or

abnormal operation.)

• Do not use the product within baby’s reach.

• This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety.

• Children should be supervised to ensure they do not play with the appliance.

IG-DX10A.EN.indd4IG-DX10A.EN.indd4 2011/11/0710:59:482011/11/0710:59:48

ENGLISH

E-3

CAUTIONS CONCERNING OPERATION:

• Do not pull on the cord when unplugging the AC adapter. (Otherwise, it may cause ﬁre

or electric shock.)

• Pull out the AC adapter from an outlet when the product is not used (otherwise, it may

cause electric shock, electric leakage, or ﬁre due to insulation deterioration).

• Do not use the product at the following places.

• Humid or dusty place

• Place exposed to oil smoke or steam

• Places where hair spray or chemicals are used such as barber shops or hair salons, or

cleaners. (Otherwise, it may cause electric shock or damage.)

• Do not climb on the main unit or lean over the main unit. (Otherwise, it may cause injury

or damage.)

• Do not swing around the product by holding the handle. (Otherwise, it may cause injury

or damage.)

• Do not use silicone-containing products* near the unit.

The ﬂuororesin or silicone could get stuck inside the unit, preventing it from producing

Plasmacluster ions.

If this happens, remove the dust from the electrode section of the Plasmacluster Ion

Generating Unit. (See E-10)

* Hair care products (split end coatings, hair mousses, hair treatments, etc.), cosmetics,

antiperspirants, antistatic agents, waterproofing sprays, polishes, glass cleaners,

chemicalimpregnated clothes, wax, etc.

IG-DX10A.EN.indd5IG-DX10A.EN.indd5 2011/11/0710:59:482011/11/0710:59:48

UNIT

FILTER

CLEAN

RESET

Press 3s.

E-4

MAIN UNIT

PARTS NAME

Louver

Louver Adjustment Dial

Louver

Air Inlet

Operation Light (blue)

Operation Button

Unit Replacing Light

(red)

Plasmacluster Ion Sign

Filter Reset Button

Filter Clean Light (orange)

CONTROL PANEL

Operation Button

Air Outlet

(See E-8)

(See E-11)

(See E-9)

(During operation, the center part of

main unit is lighting blue.)

IG-DX10A.EN.indd6IG-DX10A.EN.indd6 2011/11/0710:59:482011/11/0710:59:48

ENGLISH

E-5

BACK

BOTTOM

ACCESSORIES

Unit Cover

Power Supply Input Terminal

Filter (black)

Unit Cleaning

Brush (black)

Use the unit cleaning brush

only for cleaning the unit.

Plasmacluster Ion

Generating Unit

•AC Adapter •Stand

•Unit Cleaning

Brush

Plug

AC Adapter Unit

Unit Connection

Plug

(See E-12)

IG-DX10A.EN.indd7IG-DX10A.EN.indd7 2011/11/0811:23:102011/11/0811:23:10

E-6

Precautions on installation

Connecting power supply

INSTALLATION GUIDANCE

Be sure to place the product at the stable place.

• Be sure to place the product on a ﬂat surface.

• Operating temperature : 0

°C

to 35

°C

• Do not block the air inlet and the air outlet.

• If this Plasmacluster Ion Generator cause interference to radio or television reception,

try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the distance between the product and radio/TV receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

If you use the product for a long time at the same place, the wall, ﬂoor, or carpet

around the main unit may become dirty.

• It is recommended to move the installation location of the main unit sometimes or

clean up the surroundings or the surface on which the main unit is installed periodi-

cally. (Laying a mat under the unit is effective to prevent the floor from becoming

dirty.)

• Under factory setting, the Auto Restart Function is set to “OFF”.

< Auto Restart Function >

Even if the AC adapter is pulled out or the

breaker trips, or power outage is generated

during the operation, the operation is

restarted in the last operation mode if the

power supply is resumed.

To set

Press the Operation Button for 5 seconds or

→All lights light up for 5 seconds

To cancel

Press the Operation Button for 5 seconds

or more

→All lights blink 5 times

AC Adapter

IG-DX10A.EN.indd8IG-DX10A.EN.indd8 2011/11/0710:59:492011/11/0710:59:49

ENGLISH

E-7

How to place

When you put the product on a high place, please use stand.

Sends ions throughout the room to purify

and deodorize air, as well as moisturize

skin.

Suggested usage area

On desks or shelves.

Works against allergens on the floor and

odors in carpets.

Suggested usage area

In bedrooms, children's rooms, on

living room tables.

Ions are propelled forward to purify the air

around you and eliminate odors and static

electricity.

Suggested usage area

Facing shoe closets, on shelves,

around computer equipment.

Deodorizes clothing and hanging laundry,

inhibits proliferation of mold on walls.

Suggested usage area

Against walls, in bathrooms, in rooms

where laundry is hung to dry, beside beds.

Standing:

Sends ions upwards

Flat:

Sends ions forwards

Standing:

Sends ions forwards

Sideways:

Sends ions upwards

[ ]

IG-DX10A.EN.indd9IG-DX10A.EN.indd9 2011/11/0710:59:492011/11/0710:59:49

UNIT

FILTER

CLEAN

RESET

Press 3s.

OPERATION

To change the operation mode

< To change wind direction > < To use a stand >< How to carry >

Press

E-8

During the operation, Plasmacluster Ion Sign (blue) is lighting.

For the horizontal louver at the

back, adjust angle by rotating the

adjustment dial (x2).

For the vertical louver, adjust

the orientation manually.

Install it so that the center

of the stand comes to the

center of the main unit.

(Use the stand as occasion

demands.)

Have hands on the

handle and hold it with

both hands.

LOW

HIGH

FULL POWER

'OFF'

• Reduce the operation sound at “LOW”

operation and release high-density

Plasmacluster ions quietly.

•

Increase the concentration of

Plasmacluster ion in order to enhance the

effectiveness of the Plasmacluster ion.

• Please use this operation when you are

nervous about pollution of air.

• When you come back home from outside

• During or after using vacuum cleaner

•

When you want to remove an odor rapidly

• Remove odor after cooking or when

drying clothes in a room

If you want to operate the product in

silence

If you want to operate the product at

strong air ﬂow rate

Increase the concentration of

Plasmacluster ion to approx. 1.5 times

of “HIGH” at strong air ﬂow rate

Power ‘OFF’.

Lighting

IG-DX10A.EN.indd10IG-DX10A.EN.indd10 2011/11/0710:59:502011/11/0710:59:50

Table des matières

Autres manuels Sharp Purificateur d'air

Sharp

Sharp KI-N50 Manuel utilisateur

Sharp

Sharp IG-CL15B Manuel utilisateur

Sharp

Sharp FP-G50J Manuel utilisateur

Sharp

Sharp FP-F40E Manuel utilisateur

Sharp

Sharp FU-60SE-P Manuel utilisateur

Sharp

Sharp UA-PF40E Manuel utilisateur

Sharp

Sharp FP-J30M Manuel utilisateur

Sharp

Sharp Plasmacluster KC-840E Manuel utilisateur

Sharp

Sharp FZ-C70HFE Manuel utilisateur

Sharp

Sharp FP-K50U Manuel utilisateur

Sharp

Sharp IG-A10EK-W Manuel

Sharp

Sharp UA-PE30U Manuel utilisateur

Sharp

Sharp FP-F60U-W Manuel utilisateur

Sharp

Sharp Plasmacluster FU-A80E Manuel utilisateur

Sharp

Sharp Plasmacluster FP-JM40E Manuel utilisateur

Sharp

Sharp FU-Z31E Manuel utilisateur

Sharp

Sharp Plasmacluster FP-P40CX Manuel utilisateur

Sharp

Sharp Plasmacluster FU-W25AW Manuel utilisateur

Sharp

Sharp FP-J40E Manuel utilisateur

Sharp

Sharp IG-DC2A Manuel utilisateur

Sharp

Sharp IG-ETC1A Manuel utilisateur

Sharp

Sharp IG-DM1A Guide de démarrage rapide

Sharp

Sharp FP-E50TA Manuel utilisateur

Sharp

Sharp FU-60SE-TA Manuel utilisateur

Manuels Purificateur d'air populaires d'autres marques

IKEA

IKEA UPPÅTVIND Manuel utilisateur

Nash

Nash AP-1 PureSmart Manuel utilisateur

LG PH-U450 Series Manuel utilisateur

DeLonghi

DeLonghi DDSX 220WFA Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuel utilisateur

Philips

Philips AC2721 Manuel utilisateur

Hitachi

Hitachi EP-A3000 Manuel utilisateur

TruSens

TruSens Z-2000 Manuel utilisateur

Motorola

Motorola MBP87SN Manuel utilisateur

Beko

Beko ATP 7100I Manuel utilisateur

Carrier

Carrier INFINITY 1620 Manuel utilisateur

AtmosAir

AtmosAir P2002 Manuel utilisateur

Winix

Winix NK300 Manuel utilisateur

Friedrich

Friedrich C-90A Instructions d'utilisation et d'installation

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuel utilisateur

Base aire

Base aire 555 Pro Manuel utilisateur

Champion

Champion CP25 Manuel utilisateur

vollara

vollara Air & Surface Pro+ Manuel utilisateur
