UA-PN1E

Air Purifier

Operation manual

ENGLISH

CONTENTS

IMPORTANT SAFETY

INSTRUCTIONS......................... 1

PART NAMES............................ 4

BEFORE FIRST USE................. 6

CARE AND MAINTENANCE ..... 7

FILTER REPLACEMENT........... 8

TROUBLESHOOTING............... 9

SPECIFICATIONS.................... 10

Please read before operating your new Air Purifier

The air purifier draws in room air through the Air Inlet, circulates it through

a Pre-Filter, a Dust Collection and Deodorizing Integrated Filter inside the product,

and then discharges it through the Air Outlet. The Dust Collection and Deodorizing

Integrated Filter can remove dust particles and absorb odours as they pass through

the filter.

Some odours absorbed by the filters will break down over time, causing additional

odours. Depending on usage conditions, and especially if the product is used in

environments significantly more severe than a normal household, these odours

may become noticeable sooner than expected. If these odours persist, replace the

filters.

NOTE

• The air purifier is designed to remove air-suspended dust and the odours.

The air purifier is not designed to remove harmful gases such as carbon

monoxide contained in cigarette smoke.

The air purifier may not completely remove an odour if the source of the odour

is still present.

Thank you for purchasing this SHARP Air

Purifier. Please read this manual carefully

before using the product. This manual

should be kept in a safe place for handy

reference.

Plasmacluster

Plasmacluster treats

the air similar to the

way nature cleans the

environment by emitting

a balance of positive and

negative ions.

“Plasmacluster” and “Device of a cluster of grapes”

are trademarks of Sharp Corporation.

* The number in this technology mark indicates an

approximate number of ions supplied into air of

1 cm3, which is measured around the centre of a

room applicable floor area (at 1.2 m height above

the floor) when the product is placed on the floor

and is operating with MAX mode.

EN-1

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS

Always follow basic safety precautions when using electrical

appliances, including the following:

WARNING – Always observe the following to reduce the risk of

electrical shock, fire, or injury:

• Read all instructions before using the product.

• Use only a 220 - 240 volt outlet.

• Use only the AC adapter of the product.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge

if they have been given supervision or instruction

concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall

not be made by children without supervision.

• If the power cord is damaged, it must be replaced by

the manufacturer, its service agent, a Sharp authorized

Service Centre or similarly qualified persons in order to

avoid a hazard. Contact the nearest Service Centre for any

problems, adjustments, or repairs.

• Do not repair or disassemble the product yourself.

• Be sure to remove the AC adapter before performing

maintenance, when removing and attaching and replacing

the filter and when not using for a long time. Failure to do

so can cause a short circuit resulting in electrical shock or

fire.

• Do not use the product if the power cord or AC adapter is

damaged or if the connection to the wall outlet is loose.

• Periodically remove dust from the AC adapter.

• Do not insert fingers or foreign objects into the Air Inlet or Air

Outlet.

• When removing the AC adapter, always hold the AC adapter

and never pull on the cord. Failure to do so can cause a short

circuit resulting in electrical shock or fire.

EN-2

• Be careful not to damage the power cord. Failure to do so can

cause electric shock, heat generation, or fire.

• Do not remove the AC adapter when your hands are wet.

• Do not use this product near gas appliances or fireplaces.

When the product is operated with gas appliances in same

room, Ventilate a room periodically, otherwise it may cause

Carbon monoxide poisoning.

• Do not operate the product in rooms where aerosol insecticides

are present. Do not operate the product in rooms where there

is oily residue, incense, sparks from lit cigarettes, or chemical

fumes in the air.

• Keep the product away from water. Do not operate the product

in places where it may get wet, such as a bathroom.

• Do not expose the product to water. Doing so can cause a short

circuit or electrical shock.

• Be cautious when cleaning the product. Strong corrosive

cleansers can damage the exterior.

NOTE – What to do if the product interferes with radio or TV

reception

If the air purifier interferes with radio or television reception, try

one or more of the following measures:

• Adjust or reposition the receiving antenna.

• Increase the distance between the product and the radio or TV.

• Connect the equipment into an outlet on a circuit different from

that of the radio or TV receiver.

• Consult the dealer or a qualified radio or TV technician.

CAUTIONS CONCERNING OPERATION

• Do not block the Air Inlet or Air Outlet.

• Do not place the product near or on hot objects, such as stoves

or heaters, or where it may come into contact with steam.

• Always operate the product in an upright position.

• Do not move the product when it is in operation.

• If the product is on easily damaged flooring, an uneven surface,

or thick-piled carpet, lift it up when moving.

• Do not operate the product without the filters properly installed.

EN-3

ENGLISH

• Do not wash and reuse the Dust Collection and Deodorizing

Integrated Filter. Doing so will not improve filter performance

and can also cause electric shock or operating malfunctions.

• Clean the exterior with a soft cloth only. Do not use volatile

fluids or detergents. The product surface may be damaged or

cracked with Benzine paint thinner, alcohol or polishing powder.

• Do not scrub the Pre-Filter hard during its maintenance.

• Do not use the AC adapter for other products.

• Do not get or lean on the product.

INSTALLATION GUIDELINES

• Avoid locations where furniture, fabrics, or other objects can

come in contact with the product and interfere with the Air Inlet

and Air Outlet.

• Avoid locations where the product is exposed to condensation

or drastic changes in temperature. Appropriate room

temperature is between 0 – 35 ºC.

• Place the product on a level and stable surface with sufficient

air circulation. Place the product in the centre of the room for

better air circulation. When placed on heavy carpet, the product

may vibrate slightly.

• Avoid locations with grease, oil smoke, alcohol, hypochlorous

acid, or chemicals in the air. Doing so can cause the product

exterior to crack.

• The surrounding walls and floor of the product may become

dirty over time. When using the product for an extended period

of time at the same location, periodically clean the walls and

floor adjacent to it.

• Do not use fluororesin or silicone-containing products

(cosmetics, hair care products, etc.,) near the product. The

fluororesin or silicone could get stuck inside the product,

preventing it from producing Plasmacluster ions.

FILTER GUIDELINES

• Follow the instructions in this manual for proper filter care and

maintenance.

EN-4

PART NAMES

1 2

NOTE

• When using for the first time, please

remove the plastic bag from the Dust

Collection and Deodorizing Integrated

Filter. (Page 6)

BACK SIDE

1Operation Panel 8Power code

2Night Light

Power Lamp (Blue)

• The lamp lights up while the AC

adapter is connected to the outlet.

3Air Outlet

4Air Inlet

5Dust Collection and Deodorizing

Integrated Filter 10

AC Adapter

• Shape of adapter depends on

country.

6Pre-Filter

7Bottom Cover 11 AC Adapter Terminal

EN-5

ENGLISH

NOTE

• In LOW mode, the lamps on the Operation Panel lights up dimly.

POWER ON/OFF AND SETTING MODE

LOW MED MAX POWER

OFF

NOTE

• Plasmacluster ion will become

always ON when after

disconnecting and connecting

the AC adapter again.

PLASMACLUSTER ION ON/OFF

ON OFF

Press for 3 sec.

NIGHT LIGHT ON/OFF

The rear

lights up.

OPERATION PANEL

1Power ON/OFF and Mode Button

2Night Light Button

3Plasmacluster Ion Lamp (Blue)

4Mode Lamps (White)

EN-6

BEFORE FIRST USE

1Turn the product upside

down.

2Remove the Bottom Cover.

3Remove the Pre-Filter

( 1 ) and the Dust

Collection and Deodorizing

Integrated Filter ( 2 ).

Always be sure to remove

the AC Adapter from the

wall outlet.

4Remove the Plastic Bag.

5Attach the Dust Collection

and Deodorizing Integrated

Filter.

Tag

6Attach the Pre-Filter.

Click

7Attach the Bottom Cover.

Click

EN-7

ENGLISH

NOTE About Pre-Filter

• Do not apply excessive pressure when scrubbing the Pre-Filter.

• How to clean hard to remove dirt.

1. Add a small amount of kitchen detergent to water and soak

for about 10 minutes.

2. Rinse off the kitchen detergent with clean water.

3. Completely dry the filter in a well ventilated area.

CARE AND MAINTENANCE

Always be sure to remove

the AC Adapter from the

wall outlet.

MAIN BODY

AIR INLET / PRE-FILTER

Wipe with a dry, soft cloth.

Remove the dust gently with a cleaning tool such as a vacuum

cleaner.

Once a month

When it gets dirty

Pre-Filter

Bottom Cover

EN-8

Always be sure to remove

the AC Adapter from the

wall outlet.

Dust Collection and Deodorizing Integrated Filter

Clean only the tagged surface.

Do not clean up the opposite

surface. The filter is fragile, so

be careful not to give too much

pressure.

Remove the dust on the

filter.

FILTER REPLACEMENT

LIFE OF FILTER

Filter life varies depending on the room

environment, usage conditions, and

location of the product.

Lifespan of the Dust Collection and

Deodorizing Integrated Filter and

replacement suggestions are based on

purifying a room in which 5 cigarettes are

smoked per day and the product’s dust

collection and deodorizing performance

has declined to half the level of a new

filter.

We recommend replacing the filter

more frequently if the product is used

in conditions significantly more severe

(PM2.5 etc.,) than a normal household.

• The life of the Dust Collection and

Deodorizing Integrated Filter is about

1 year after opening.

Tag

Dust Collection

and Deodorizing

Integrated Filter

NOTE

• Do not wash the filter. Do not expose to sunlight. (Otherwise these filter may

lose efficacy.)

• Some odours absorbed by the filter will break down over time, causing additional

odours. Depending on usage conditions, and especially if the product is used in

environments significantly more severe than a normal household, these odours may

become noticeable sooner than expected. Replace the filter in those cases or if dust

is unable to be removed after maintenance.

Whenever dust accumulates, or when odour emanates from the air outlet.

Table des matières

Langues :

Autres manuels Sharp Purificateur d'air

Sharp

Sharp KC-D60EU-W Manuel utilisateur

Sharp

Sharp KC-A60TA Manuel utilisateur

Sharp

Sharp FU-S51E Manuel utilisateur

Sharp

Sharp Plasmacluster FP-P60CX Manuel utilisateur

Sharp

Sharp IG-CL15A Manuel utilisateur

Sharp

Sharp UA-HG60E Manuel utilisateur

Sharp

Sharp Plasmacluster FP-R45CX Manuel utilisateur

Sharp

Sharp Plasmacluster FP-J80M Manuel utilisateur

Sharp

Sharp KC-A60Y Manuel utilisateur

Sharp

Sharp FP-JM30E Manuel utilisateur

Sharp

Sharp HIGH-DENSITY 7000 Manuel utilisateur

Sharp

Sharp FP-FM40Y Manuel utilisateur

Sharp

Sharp FU-S63E Manuel utilisateur

Sharp

Sharp FU-Y30EU-W Manuel utilisateur

Sharp

Sharp KC-D61R Manuel utilisateur

Sharp

Sharp KC-G60SA Manuel utilisateur

Sharp

Sharp FP-JC2 Manuel utilisateur

Sharp

Sharp KC-A50EU Manuel utilisateur

Sharp

Sharp FPF30UH Manuel utilisateur

Sharp

Sharp Plasmacluster KC-C150U Manuel utilisateur

Sharp

Sharp KC-D60E Manuel utilisateur

Sharp

Sharp FP-JM30B Manuel utilisateur

Sharp

Sharp IG-GC2EU Manuel utilisateur

Sharp

Sharp FP-J30J Manuel utilisateur

Manuels Purificateur d'air populaires d'autres marques

IKEA

IKEA UPPÅTVIND Manuel utilisateur

Nash

Nash AP-1 PureSmart Manuel utilisateur

LG PH-U450 Series Manuel utilisateur

DeLonghi

DeLonghi DDSX 220WFA Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuel utilisateur

Philips

Philips AC2721 Manuel utilisateur

Hitachi

Hitachi EP-A3000 Manuel utilisateur

TruSens

TruSens Z-2000 Manuel utilisateur

Motorola

Motorola MBP87SN Manuel utilisateur

Beko

Beko ATP 7100I Manuel utilisateur

Carrier

Carrier INFINITY 1620 Manuel utilisateur

AtmosAir

AtmosAir P2002 Manuel utilisateur

Winix

Winix NK300 Manuel utilisateur

Friedrich

Friedrich C-90A Instructions d'utilisation et d'installation

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuel utilisateur

Base aire

Base aire 555 Pro Manuel utilisateur

Champion

Champion CP25 Manuel utilisateur

vollara

vollara Air & Surface Pro+ Manuel utilisateur
