Distance to furniture: 800 mm
Krog Iversen & Co. A/S - DK-5492 Vissenbjerg
Technical info
Emission (% CO at 13% O2): 0.1%
Efficiency: 71%
Rated output: 6 kW
Chimney temperature: 334 oC
Flue outlet flow: 7.1 g/sec
Recommended low pressure in conn. piece: 18 Pa
Recommended fuel: Wood
Amount of fuel: 2,1 kg
Min./max. (information from the factory): 3-9 kW
Weight, stove with convection: 136 kg
Weight, stove with soap stone: 240 kg
Connection piece, int. diameter: 135 mm
Connection piece, ext. diameter: 148 mm
Warranty conditions
All SCAN wood-burning stoves and inserts are made of first-class
material and are subject to a strict quality control before they leave
the factory. However, if an error should occur, we back all SCAN
wood-burning stoves and inserts with an extensive, five-year limited
warranty.
See also the General Instructions for Installation delivered with your
stove for more details.
* To the middle of the rear outlet
** Height to the beginning of the flue pipe at top outlet
***Connection piece to fresh-air intake
Distance to flammable materials
(mm):
You can choose between sev-
eral floor plates in different
shapesanddimensionsforyour
stove. Furthermore, you can
have a specially made, shaped
floor plate for the SCAN 55,
which is to be placed in front of
the stove. Please contact your
local authorities concerning the
security distances needed.
1028
500 414
177
150
849
966
175
175
609
*
**
***
175
450
Declaration of Conformity
Manufacturer:
Krog Iversen & Co. A/S
DK - 5492 Vissenbjerg
Product:
SCAN 55
Description of product:
Room heater for closed operation
This product complies with the requirements
of the directive
CPD 89/106/EEC
Applied to harmonized standard EN 13240
Signature: _____________________________
Managing director Henning Krog Iversen
SCAN 55
