SCAN 87 Guide de l'utilisateur

ASSEMBLY AND INSTRUCTIONS MANUAL SCAN 87

SCAN

UK - ASSEMBLY AND INSTRUCTIONS MANUAL

SCAN

You have purchased a product by one of Europe’s leading manufacturers of

wood-burning stoves, and we are sure that you will have years of pleasure from your

purchase.

To make the best possible use of your stove, it is important that you

follow our advice and instructions. Read through this Assembly and Instruction

Manual carefully before you start to assemble your stove.

CONGRATULATIONS

ON YOUR NEW SCAN

WOOD-BURNING STOVE

SCAN 87

FLOOR

SCAN 87

WALL

TABLE OF CONTENTS

¬¬

TECHNICAL DATA 4

Installation 4

Safety 4

Technical data and dimensions 5

Dimension sketch and minimum distances 6

Type plate 8

Product registration number 8

¬¬

ASSEMBLY 9

Tools needed for mounting of the stove 9

Loose parts 9

Additional accessories 9

Disposal of packaging 9

Fresh air intake 9

Closed combustion system 10

Existing chimney and pre-fabricated element chimney 10

Connection between built-in stove and steel chimney 10

Requirements for chimney 11

Distance to furniture 11

Safety distance 11

Removal of packaging 12

Fitting the slingbar 14

Removal of transport safety 14

Door (Self-closing) 15

Mounting of wall-hung model 16

Mounting of external air supply on the wall ﬁtting 18

Height adjustment of stove 19

Fitting the ﬂue connection piece 21

Disassembly of top plate in top outlet 23

Mounting of cleansing lid 23

Heat-storage system 24

Mounting of combustion chamber 25

Load-bearing foundation 27

Floor plate 27

¬¬

INSTRUCTIONS FOR USE 28

CB-technology (Clean Burn) 28

Primary air 28

Secondary air 28

Bafﬂe plate 28

Ash container 28

¬¬

INSTRUCTIONS FOR HEATING 30

Environmentally-friendly ﬁring 30

Lighting 30

Continuous operation 31

Warning about over-ﬁring 31

Using the stove in various weather conditions 31

Firing in the spring or autumn 31

The function of the chimney 31

Chimney ﬁre 32

General notes 32

¬¬

HANDLING OF THE FUEL 33

Selecting wood/fuel 33

Preparation 33

Storing 33

Moisture 33

Use of the following as fuel is illegal 33

Caloriﬁc value of the wood 33

¬¬

MAINTAINANCE 34

Sweeping the chimney and cleaning the stove 34

Checking the stove 34

Servicing 34

Combustion chamber lining 34

Gaskets 34

Painted surfaces 34

Removal of bafﬂe plates and combustion chamber lining 35

Disposal of stove parts 35

Cleaning the glass 36

¬¬

TROUBLESHOOTING 37

¬¬

WARRANTY 38

TECHNICAL DATA

INSTALLATION

¬ The house owner is responsible for ensuring that installation and assembly are in accordance with national and local building

regulations as well as the information provided in this Assembly and Instruction Manual

¬ When you install any kind of ﬁreplace or stove, you must inform the local building and housing authorities. In addition you are

obliged to have the installation inspected and approved by a local chimney sweep prior to commissioning

¬ To ensure best-possible functionality and safety for your installation, we advise you to call a professional ﬁtter. Your Scan

Dealer will be able to recommend a qualiﬁed ﬁtter in your area. For information on Scan Dealers, please go to

www.scan-stoves.com

SAFETY

Any changes made to the product by the dealer, ﬁtter or user could result in the product and safety functions not functioning as

intended. The same applies to the ﬁtting of accessories or extra equipment not supplied by Scan A/S. This could also be the case

if parts that are necessary for the operation and safety of the stove are dismantled or removed.

YOU GET THE BEST USE OF

THE STOVE BY USING

A TOP-DOWN

LIGHTING METHOD

SEE

"INSTRUCTIONS FOR HEATING"

PLEASE NOTE!

TECHNICAL DATA AND DIMENSIONS

The stove can take logs up to 50 cm (vertically placed).

Intermittent operation in this context means normal use of

a wood-burning stove. In other words, you should let the ﬁre

die down until only the embers are left before refueling.

This stove is produced in accordance with type approval for

the product, which also covers the product’s Assembly and

Instruction Manual.

The Declaration of Performance (DoP) is available from

www.scan-stoves.com

Test in compliance with EN 13240

CO Emission at 13% O20,07 %

CO Emission at 13% O2929 mg/Nm3

Dust @ 13% O227 mg/Nm3

Nox@ 13% O296 mg/Nm3

Efﬁciency 84 %

Energy efﬁciency index 112

Energy efﬁciency class A+

Nominel output 11,5 kW

Chimney temperature EN 13240 168 °C

Temperature in ﬂue conn. piece 202 °C

Amount of smoke 12,9 g/sec

Sub-pressure EN 13240 12,7 Pa

Recommended sub-pressure in

connecting piece 18 Pa

Required combustion air supply 38 m3/h

Fuel Wood

Fuel consumption 3,2 kg/h

Amount of fuel 2,55 kg

Amount of fuel, max. 4,8 kg

Surface treatment Senotherm

Max. wood length 40 cm*

Weight Scan 87 approx. 273 kg

Weight Scan 87 wall-hung approx. 250 kg

Connecting piece internal diameter 194 mm

Connecting piece external diameter 198 mm

Fresh air connection piece external diameter 125 mm

Approval type Intermittent fuelling**

Materials

Stainless steel plate

Cast iron

Ceramic stone/vermiculite

Glass

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087001.idw

90087001

Målskitse - fritstående

13-07-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

549

628

632

1886

630

154*

1712

533*

1832***

100

254

699

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087002.idw

90087002

Målskitse - fritstående (afstand til brændbart)

16-10-2019 KEN

Scan 87

VÆGT:

AREAL:

N/A

500

1300**

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087004.idw

90087004

Målskitse - væghængt (afstand til brændbart)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

1300**

500

350

900

360°

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087006.idw

90087006

Opstillingstegning (afstand til brændbart materiale)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

913

647

300

1289

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087003.idw

90087003

Målskitse - væghængt

13-07-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

628

680

138*

1317

1437***

154*150

304

699

549

240

1491

DIMENSION SKETCH AND MINIMUM DISTANCES

Scan 87 - freestanding Scan 87 - wall-hung Flammable ceiling and ﬂoor

All distances are in mm.

All distances are minimum distances

* Connection of fresh-air intake Ø 125 mm

** Min. distance to furniture/ﬂammable material

*** Height to the beginning of ﬂue connecting piece at top outlet

Floor plate

X / Y according to national laws and regulations

Flammable material

Radiation zone

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087005.idw

90087005

Opstillingstegning (afstand til brændbart materiale)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

50*

800

304*

680*

1146

900

360°

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087006.idw

90087006

Opstillingstegning (afstand til brændbart materiale)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

913

647

300

1289

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087008.idw

90087008

Opstillingstegning (afstand til brandmur)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

768

1148

150

494

1520

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087007.idw

90087007

Opstillingstegning (afstand til brandmur)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

500

304

680

1480

1693

800

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087007.idw

90087007

Opstillingstegning (afstand til brandmur)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

500

304

680

1480

1693

800

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087007.idw

90087007

Opstillingstegning (afstand til brandmur)

02-02-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

500

304

680

1480

1693

800

MINIMUM DISTANCES

Flammable material

Fire wall, e.g. 50 mm Jøtul Firewall, 110 mm brick

or other material with corresponding ﬁreproof and

insulating abilities

All distances are in mm.

All distances are minimum distances

* Half-insulated chimney / shielded ﬂue pipe (The requirements to the chimney and the ﬂue pipe in terms of safety distances must be met)

Minimum distance to ﬂammable materials

Minimum distance to ﬂammable wall protected by a ﬁre wall

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

DK-5492 Vissenbjerg©

TG.NR:

EMNE:

C:\Working Folder\Designs\Scan 87\90087033.idw

90087033

Scan 87 typeskilt

20-10-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

Typeplate

PRODUCT REGISTRATION NUMBER

All Scan wood-burning stoves are provided with a product registration number. Please make a note of this number at the rear

page of this manual; you will always need to quote it when contacting your dealer or Scan A/S.

The product registration number is located at the rear of the stove.

Type plate

Product

registration number

Product registration number

TYPE PLATE

All Scan wood-burning stoves are ﬁtted with a type plate that speciﬁes the approval standards and the distance to ﬂammable

materials.

The type plate is located at the rear of the stove.

ASSEMBLY

TOOLS NEEDED FOR MOUNTING OF THE STOVE

¬ Spirit level ¬ Combo wrench 10 mm

¬ Cutting nippers ¬ 3 allen keys (2,5 mm, 4 mm & 5 mm)

LOOSE PARTS

In the stoves combustion chamber you will ﬁnd the following loose parts:

¬ Glove ¬ 1 connecting piece for fresh air inlet

¬ 1 ﬂue connection piece 180 mm (int. ﬂue pipe) ¬ 1 ﬂue connection piece 190/200 mm (int./ext. ﬂue pipe)

¬ Seal for the connecting piece ¬ Dekor plate for top plate

¬ Top back plate ¬ Screw M5x16 mm (Only used in Norway)

¬ Bafﬂe plates ¬2 pins for bafﬂe plates

¬ Slingbar

ADDITIONAL ACCESSORIES

¬ Small shaped ﬂoor plate in glass ¬ Large shaped ﬂoor plate in glass

¬ Heat accumulating stones (6 items approx. 100 kg) ¬ Cleansing lid for rear outlet

¬ Fresh air adapter rear (wall-hung)

DISPOSAL OF PACKAGING

Your Scan stove may come supplied with the following packaging:

Wood packaging The wood packaging can be reused and after final use can be incinerated as a CO2neutral

product or sent for recycling

Foam Send for recycling or waste disposal

Plastic bags Send for recycling or waste disposal

Stretch/plastic ﬁlm Send for recycling or waste disposal

FRESH AIR INTAKE

In a well-insulated house, the air used up by the burning process has to be replaced. This particularly applies to houses with

mechanical ventilation. There are different ways of making sure that an air exchange takes place. The most important thing is to

ensure that there is a supply of air to the room where the wood stove is located. The external wall vent must be located as close

to the wood stove as possible, and you must be able to close it when you are not using the wood stove.

National and local building regulations must be followed with regard to the connection of fresh-air intake.

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 87\90087011.idw

90087011

Scan 87 produktregistreringsnummer

04-11-2021 KEN

Scan 87

VÆGT:

AREAL:

N/A

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

TG.NR:

EMNE:

C:\Working Folder\Designs\Scan 87\90087010.idw

90087010

Scan 87 friskluft

04-11-2021 KEN

Scan 87

VÆGT:

AREAL:

537,44 kg

48038358 mm^2

NAVN:

STI:

DIMENSION:

MATERIALE: DATO: SIGN:

Krog Iversen & Co A/S

TG.NR:EMNE:

C:\Working Folder\Designs\Scan 68\90068058.idw

90068058

klargøring til vægbeslag

12-05-2015 hms

Scan 68

VÆGT:

AREAL:

N/A

EXISTING CHIMNEY AND PRE-FABRICATED ELEMENT CHIMNEY

If you intend to connect your stove to an existing chimney, it makes sense to contact an authorised Scan dealer, or a local chim-

ney sweep, for advice. These experts will also let you know if your chimney needs renovating.

¬ When connecting a pre-fabricated element chimney, follow the manufacturer’s connection instructions for the

relevant chimney type.

CONNECTION BETWEEN BUILT-IN STOVE AND STEEL CHIMNEY

Your Scan dealer, or local chimney sweep, can advise you on choosing a make and type of steel chimney. This ensures that the

chimney will match your wood-burning stove.

If you want external combustion

air via a wall, remove the cover

plate at the rear of the stove with

a pair of cutting pliers

External

combustion air

via wall

External

combustion air

via ﬂoor

CLOSED COMBUSTION SYSTEM

You should use the closed combustion system for the wood-burning stove if you live in a newly-built, airtight home.

External combustion air is connected through a ventilation pipe via the wall or ﬂoor.

We recommend mounting a valve in the ventilation pipe in order to avoid condensate in the stove and the pipe system, when the

stove is not in use. It can also be an advantage to insulate the ventilation pipe.

Minimum Ø 125 mm ventilation pipe, maximum length: 6 metres with a maximum of one bend. We recommend smooth steel

pipes.

Connecting piece for fresh air inlet is loose in the stove.

If the external combustion air is connected at the rear, the dismounted plate must be mounted on the hole for external air in the

bottom of the stove. For wall-mounted model (wall) a special fresh air adapter (accessory) is used.

NOTE: if the stove has a fresh air connexion or closed combustion, the ventilation pipe must be open, when the stove is in use!

Table des matières

Autres manuels SCAN Poêle à bois

SCAN

SCAN 80 Manuel utilisateur

SCAN

SCAN Basic1 Manuel utilisateur

SCAN

SCAN 67 Guide de l'utilisateur

SCAN

SCAN 65 Guide de l'utilisateur

SCAN

SCAN 22 Manuel utilisateur

SCAN

SCAN Scan 83-8 Guide de l'utilisateur

SCAN

SCAN 68-1 Guide de l'utilisateur

SCAN

SCAN DSA 8 Manuel utilisateur

SCAN

SCAN 46 Manuel utilisateur

SCAN

SCAN 41 Guide de l'utilisateur

SCAN

SCAN 1006-B Guide de l'utilisateur

SCAN

SCAN ANDERSEN 8 Manuel utilisateur

SCAN

SCAN SCAN 68 Series Guide de l'utilisateur

SCAN

SCAN SCAN 4 Manuel utilisateur

SCAN

SCAN Andersen 10 Manuel utilisateur

SCAN

SCAN 47-2 Manuel utilisateur

SCAN

SCAN 55 Manuel utilisateur

SCAN

SCAN 37-2 Manuel utilisateur

SCAN

SCAN 5-2 Manuel utilisateur

SCAN

SCAN 1010 Series Guide de l'utilisateur

SCAN

SCAN 1003 Series Guide de l'utilisateur

SCAN

SCAN 45 Mini Manuel utilisateur

SCAN

SCAN 3 Manuel utilisateur

SCAN

SCAN Andersen 4 Manuel utilisateur

Manuels Poêle à bois populaires d'autres marques

Plamen

Plamen ECO MINIMAL 50 Manuel utilisateur

Austro Flamm

Austro Flamm KOKO Manuel utilisateur

RAIS

RAIS 800 Manuel utilisateur

Henley

Henley Arklow Manuel utilisateur

Jøtul

Jøtul F 500 Manuel utilisateur

Englander

Englander BLUE RIDGE 100 Manuel utilisateur

WoodPro

WoodPro WS-TS-1500 Manuel utilisateur

Contura

Contura C 586W Manuel utilisateur

Nordpeis

Nordpeis N-20 T Manuel utilisateur

Palazzetti

Palazzetti EVA Guide de configuration

Lopi

Lopi 1250 Republic Manuel utilisateur

Panadero

Panadero CAPRI 3V Manuel de programmation

RAIS

RAIS RONDO 92 Manuel utilisateur

RAIS

RAIS attika NEXO 100 GAS Manuel utilisateur

ADURO

ADURO 15-3 Guide de l'utilisateur

Pacific energy

Pacific energy SUPER 27 SPECTRUM Manuel utilisateur

Avalon

Avalon Olympic 11190 Manuel utilisateur

Ventis

Ventis HES350 Manuel utilisateur
