SCX-4500W

Wireless LAN Model

Basic Model :SCX-4500

DIGITAL LASER PRINT The keynote of Product

Slim Size 3 in 1 MFP (SCX-4500W)

- Printing Speed : 16PPM(A4), 17PPM(Ltr)

- Printing Resolution : 600 x 600dpi

- Interface : USB 2.0

- OPE : Touch Sensor

- Scanner : FLAT-BED CIS(600dpi)

- Scan Resolution(Optiacl) : 600 x 2,400dpi

- Paper Input Capacity : 100 sheets

- Paper Output Capacity : 30 sheets

- Engine Life : 50,000 Pages

- Toner : Initial(1K) / Sales(2K)

SCX-4500W

- Basic function : Wireless LAN

The SCX-4500W is the prouduct that added wireless function in comparison with the SCX-4500.

This manual describes the difference between the SCX-4500 and the SCX-4500W.

If you want to know more information for SCX-4500W, please consult the service manual of the SCX-4500.

ELECTRONICS

Samsung Electronics Co.,Ltd. February. 2008

Printed in Korea.

VERSION NO. : 1.00 CODE : 4500-W0SEE

GSPN (Global Service Partner Network)

North America : service.samsungportal.com

Latin America : latin.samsungportal.com

CIS : cis.samsungportal.com

Europe : europe.samsungportal.com

China : china.samsungportal.com

Asia : asia.samsungportal.com

Mideast & Africa : mea.samsungportal.com

-Product Description (SCX-4500W)

Contents

- Exploded Views & Parts List (SCX-4500W)

1. Product Description (SCX

1. Product Description (SCX-

-4500W)

4500W)

HARNESS-LSU

5. Designer’s request

COVER-SCAN OPE

6. Changed the silk printing

COVER-FRONT

COVER-SCAN LOWER

COVER-SCAN UPPER

CBF HARNESS-WLAN

3. Changed items by adding

Module-wireless LAN

MODULE-WIRELESS

LAN

4. Changed CIS

CBF-HARNESS CRUM

COVER-REAR

Old COVER-LEFT/REAR

and new COVER-

LEFT/REAR can be

assembled only in pairs.

COVER-LEFT

PBA-MAIN

2. Changed items by new

Main board

TAPE-DOUBLE FACE

SHEET-SCAN

DIFFUSION

HOLDER-LED MAIN

BELT-TIMING GEAR

CONTACT IMAGE

SENSOR

PBA-OPE

1. Changed items by adding

OPE wireless LED

RemarksChanged items

Subject

Product Description

Service Manual

1-1

Samsung Electronics

1.1 Changed items by adding OPE wireless LED

1. PBA

1. PBA-

-OPE, JC92

OPE, JC92-

-02023A (New part)

02023A (New part)

LOGAN

LOGAN-

-W

LOGAN

喃Added LED to indicate the wireless LAN working

Product Description

Service Manual

1-2

Samsung Electronics

2. HOLDER

2. HOLDER-

-LED MAIN, JC61

LED MAIN, JC61-

-02008A (Modified)

02008A (Modified)

After

Before

喃Added one hole for wireless indicator LED

Product Description

Service Manual

1-3

Samsung Electronics

3. SHEET

3. SHEET-

-SCAN DIFFUSION, JC63

SCAN DIFFUSION, JC63-

-01468A (Modified)

01468A (Modified)

After

Before

喃Changed the black printing at back side

Product Description

Service Manual

1-4

Samsung Electronics

4. TAPE

4. TAPE-

-DOUBLE FACE

DOUBLE FACE 0203

0203-

-001841

001841 (Modified)

(Modified)

After

Before

喃Added one hole for wireless indicator LED

Product Description

Service Manual

1-5

Samsung Electronics

1.2 Changed items by new Main board

1. PBA

1. PBA-

-MAIN, JC92

MAIN, JC92-

-02010A (New part)

02010A (New part)

Logan

Logan-

-W

Logan

喃PBA-MAIN (JC92-02010A)

Product DescriptionProduct DescriptionProduct Description

Service Manual

1-6

Samsung Electronics

2. COVER

2. COVER-

-REAR (Modified), COVER

REAR (Modified), COVER-

-LEFT (New part)

LEFT (New part)

After

Before

喃COVER-REAR : Common part

喃COVER-LEFT : Two slide cores 喈using JC63-01383B for wireless model

jv}lyTylhy

jv}lyTslm{

FRYHU0OHIW#=#MF960346;6D

FRYHU0UHDU#=#MF96034769D FRYHU0OHIW#=#MF960346;6E

FRYHU0UHDU#=#MF96034769D

Orjdq Orjdq0Z

Product Description

Service Manual

1-7

Samsung Electronics
