Salus VS05 Manuel utilisateur

Dial Thermostat

Models: VS05

INSTALLER / USER MANUAL

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 1

02 VS05 Installer Manual

Contents

1 x Installer / User manual VS05Fixing screws

Contents

Introduction.

Product Compliance.

Safety information.

Mounting position and

installation.

System grouping and

communication.

User interface.

LED indication.

Box Contents

Icons used in this manual:

Safety

Important info

Your benet

For latest PDF installation

guide please go to

www.salus-controls.com

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 2

Product Compliance & Safety Information

We hope you enjoy this product...

VS05 Installer Manual 03

INTRODUCTION

Thank you for purchasing the SALUS room

thermostatVS05. TheVS05 is a 230V dial

thermostat which oers simple temperature

control of your heating system.

SALUS recommends that you use your VS05

with the SALUS KL10 wiring centre and VS10

digital room thermostat.TheVS10 can be used

as a group control thermostat to control groups

of VS05’s. Please see pages 6 and 7.

Product Compliance

This product is CE compliant and meets the

following EC Directives Electro-Magnetic

Compatibility directive 2004/108/EC

Low voltage Directive 2006/95/EC

Safety Information

Use in accordance with the regulations

The SALUSVS05 is to be used for room

control of hot water heating systems

inside the house.

Installation

This product must be tted by a competent

person, and installation must comply with the

guidance, standards and regulations applicable

to the city, country or state where the product

is installed. Failure to comply with the

requirements of the relevant guidance,

standards and regulations could lead to injury,

death or prosecution.

Always isolate the AC mains supply

before installing or working on any components

that require 230V AC 50Hz supply.

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 3

Product Compliance & Safety Information

Sources of danger

The thermostat must be disconnected from

mains supply before removing the cover.

230V AC

Emergency

Switch o the voltage to the individual

thermostat wiring centre or complete system.

Installer parameter settings

The SALUSVS05 is equipped

with installer parameters. See page 13.

For the installer

Please enter any parameter

changes in the installer notes section.

04 VS05 Installer Manual

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 4

VS05 Installer Manual 05

Installation –Thermostat Mounting

Not to be positioned on an exterior wall.

Mounting position and installation

To ensure trouble free operation and ecient control, the unit is best positioned in

a draft free area and at 130cm from the oor. Do not position the thermostat near

any heat source, behind curtains, direct sunlight or an area of high humidity.

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 5

06 VS05 Installer Manual

System Overview Grouping and Communication

Power and Switching Cable - used to

power thermostats and drive output.

Grouping and Communication cable.

While the thermostats can function as standalone,

installing this optional inexpensive communication cable

allows the thermostats to communicate with the SALUS

VS10 congured as a group control thermostat and used

with the SALUS KL10 WC (both sold separately).

The VS05 will follow instructions from the VS10 bringing

central control of features such asTime Control, Holiday &

Party functions as well as Frost Control.TheVS05 can leave

or re-enter group control at the slide of a switch. VS10 Group ControlThermostat

(sold separately )

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 6

Group 2 – For Example upstairs

VS05 Installer Manual 07

System Overview Grouping and Communication

The maximum number of groups per KL10 wiring centre is two. The group selection

communication cable must correspond to the group terminals on the KL10WC.

Please refer to note 5 and the KL10 installation guide.

Group 1 – For Example Down stairs

SALUS KL10 Wiring Centre

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 7

08 VS05 Installer Manual

Installation –Thermostat Mounting

60mm

Wall Mounting

For wall mounting, mark and mount

the rear case to the wall.TheVS05 is

suitable for wall boxes with a centre

hole distance of:

Gently remove front housing.

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 8

VS05 Installer Manual 09

Installation –Terminal Connections

Understanding your terminal connections

Rear of VS05

Power Terminals 230 Vac

Used for supplying power to the

unit and switched output.

Sensor Terminals

Can be used for external Air or

Floor sensor.

Communication Terms 12VDC

Two wire twisted pair

can be used for grouping

functions between VS10 and VS05.

Also required for Heat/Cool

changeover.

3 2 1

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 9

10 VS05 Installer Manual

Installation –Thermostat Connections

While theVS05 can function on

its own, installing this optional,

inexpensive communication

cable allows theVS05 to

communicate with the SALUS

VS10 (sold separately).

Optional

communication

connection 12VDC

For more detail refer to note 5 on the wiring centre installation guide.

iT600 VS05 Installer - User Manual 005_Layout 1 08.12.2014 13:32 Strona 10
