Salus RT500BC Manuel utilisateur

Instruction Manual

Model No RT500BC

Programmable Digital

Thermostat with RF Boiler Control

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 1

PRODUCT COMPLIANCE

This product complies with the essential requirements

of the following EC Directives:

•Electro-Magnetic Compatibility Directive 2004/108/EC

•Low Voltage Directive 2006/95/EEC

•EC Marking Directive 93/68/EEC

•R&TTE Directive 99/5/EC

SAFETY INFORMATION

These instructions are applicable to the Salus Controls model stated on the

front cover of this manual only, and must not be used with any other make

or model.

These instructions are intended to apply in the United Kingdom only, and

should be followed along with any other statutory obligations.

This accessory must be fitted by a competent person, and installation must

comply with the guidance provided in the current editions of BS7671 (IEE

Wiring Regulations) and Part ‘P’ of the Building Regulations. Failure to

comply with the requirements of these publications could lead to

prosecution.

Always isolate the AC Mains supply before opening or removing the

unit from the wall or wall box.

When fitting batteries don’t mix old and new batteries together. Do

not use rechargable batteries.

Please leave these instructions with the end user where they should be kept

in a safe place for future reference.

RT500BC INSTRUCTION MANUAL

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 2

INTRODUCTION

A programmable room thermostat is a

device that combines the functions of

both a room thermostat and heating

controller into a single unit. The

programmable thermostat is used to

switch the heating system in your home

on and off as needed. It works by

controlling the temperature according to

a series of programmed settings that take

effect at different times of the day.

The RT500 programmable room thermostat from Salus Controls is a stylish and

accurate 5/2 or 7 day programmable electronic thermostat with a large, easy to

read display. This programmable thermostat has been specifically designed to

be used for both Volt Free and AC heating applications. This programmable

thermostat can replace most common residential thermostats and is designed

to be used with electric, gas or oil heating boilers. Unlike ordinary single unit

design thermostats, this is a new type of thermostat separating the operational

functions into two units.

The RF Boiler Control is used for wiring connections and heat on/off control. The

RT500 provides the user interface and temperature sensing / control. The two

units are linked together by a Radio Frequency (RF) signal.

Features

•Volt free switching option

•5/2 or 7 day programming flexibility

•Built-in start up programming for quick installation

•Frost protection

•Large, easy to read display with blue backlight

•Burner on symbol

•Easy to use programming

•User friendly

RT500BC INSTRUCTION MANUAL 3

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 3

INSTALLATION

Please read the important safety information at the start of this manual

before you begin to install the device.

The RT500 programmable room thermostat is easily installed using the

Industry Standard back plate supplied with the unit – this is used purely for

mounting purposes, as no wiring is needed for the RT500. The back plate

can be mounted directly to the wall surface.

The ideal position to locate the RT500 is about 1.5m above floor level. It

should be mounted in a location where the thermostat is accessible,

reasonably lit and free from extremes of temperature and draughts. Do not

mount the thermostat on an outside wall, above a radiator or in a location

where it may be subjected to direct sunlight.

To ensure trouble free operation of the Radio Frequency (RF) signal, always

ensure that the programmable thermostat is mounted away from any

possible sources of interference (such as radios, TV sets, computers, etc.),

and is not mounted on or in close proximity to large metal objects. Installing

the RT500 in enclosed areas such as cellars and basements is not

recommended.

CONNECTING THE RT500 BOILER CONTROL

NOTE: All electrical installation work should be carried out by a

suitably qualified electrician or other competent person.

If you are not sure how to install the Boiler Control consult either with a

qualified electrician, heating engineer or your boiler / heating system

supplier for advice on how to continue.

RT500BC INSTRUCTION MANUAL

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 4

RT500BC INSTRUCTION MANUAL 5

INSTALLING THE RF BOILER CONTROL

1. Remove the front panel

from the boiler.

2. Pull out the mechanical timer.

3. Do not remove link wire.

4. Connect the electrical plug.

5. Push fit boiler control

into housing.

6. Replace the front panel

ensuring a good seal is made.

7. Power up the boiler and check

the correct operation.

RF Boiler Control

LED indicator for learning / output status

Recessed button for ID learning

Max. ambient temperature 55

Transmitter link via radio frequency

Current rating 5A (resistive) @ 230V AC

Connections:

1 - Neutral input

2 - Live input

3 - Common input

4 - Normally open output

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 5

BOILER CONTROL WIRING TERMINALS

Terminal Identifier Description

1 N Neutral

2 L Live feed (230V AC)

3 COM Linked Live feed

4 N.O. Switched Live (Normally Open [N.O.] contact)

TYPICAL WIRING INSTALLATION

RT500BC INSTRUCTION MANUAL

Boiler Control Boiler

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 6

RT500BC INSTRUCTION MANUAL 7

RT500 THERMOSTAT DEFAULT SETTINGS

Changes to the default settings should only be made by the Engineer

carrying out the installation or other qualified person.

The installer should select the “jumper”

positions required if changes need to be

made to the factory default settings. The

“jumpers” are found on the rear of the

RT500.

Jumper Function

Program Jumper for 5-2 (factory default setting) or 7

individual days programming.

Span Movable jumper for selecting temperature span

of ± 0.5°C (factory default setting) or ± 1.0°C

1,2,3,4,5 Removable jumpers for altering the RF address

code when used in conjunction with the

teaching mode of the boiler control.

NOTE:

The Reset button must be pressed after changing jumper positions.

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 7

RT500BC INSTRUCTION MANUAL

CHANGING THE BATTERIES ON THE RT500

1. Open the front flap on the right hand side of the unit ,

this reveals the SET & SELECT buttons

2. On the bottom right hand side pull the small flap down

which will reveal the batteries as shown above.

3. Remove the old batteries

4. Now insert the new batteries, insert bottom battery with

the“+” end first followed by the top battery “ – “first .

Note:

When changing the batteries the RT500 will save your settings for 10

sec, after 10 seconds your settings will be lost

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 8

RF ID CODE SETTING

Normally, the RT500 can link with the Boiler Control the ID code setting. If

there is another unit being used nearby, e.g. in the next house, your Boiler

Control may be triggered by the other RT500. You can change the RF ID

Code to help prevent this problem.

Each Boiler Control can only respond to RF transmissions from a RT500

with the same RF ID code setting.

To adjust the RF ID code of the RT500,

remove one or more of the jumper

caps located on the back of the unit

(labelled 1 to 5 as shown in this

picture): Then follow the steps below

to resync the RF communication.

RT500BC INSTRUCTION MANUAL 9

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 9

SYNCHRONISING THE BOILER CONTROL

(a) RT500 programmable room thermostat RF Sync mode

- Press and hold "SELECT" to enter ID transmission;

ID code is set by 5 position jumper switches;

- TX sends ID code for 10 minutes.

- during 10 minutes synchronisation, LCD shows "Sy" on

temperature digits and the timer will count down.

- during 10 minutes synchronisation, pressing any key can interrupt ID

code transmission and LCD will return to normal mode, i.e.

temperature and clock.

(b) Boiler Control RF Sync mode

- Press and hold "SYNC" button on the boiler control for a few seconds to

enter ID learning mode, LED flashes.

- Until ID is captured and memorized into EEPROM (within max 12

minutes), LED stops flashing and stays ON (relay close) or OFF (relay

open) if ID is never captured, LED will keep flashing to alert user to

re-sync, until 12 minutes timeout.

To pair the RT500 to the Boiler Module simply press and hold the sync

button on the Boiler module for 3 seconds, at the same time press and

hold Select on the RT500 for 3 seconds, after 3 seconds at the same time

release both the sync button on the boiler module and the select button on

the RT500.

If the Boiler Control successfully receives a signal from the RT500 during the

pairing operation, the Boiler Control will store the new RF address code into

its internal memory. The LED will flash twice if the code is stored correctly,

or 4 times if this was unsuccessful. The Boiler Control will then exit pairing

mode and the LED will go out.

RT500BC INSTRUCTION MANUAL

Salus RT500BC Boiler Control 026_89 21/01/2012 18:18 Page 10
