8845-100 Quickstart Guide
Last Updated: July 2022
Safetrust Inc. | safetrust.com
sales@safetrust.com
Sheet metal screw
SCR PTP, 2X6MM BLUE, ZINC CR3
For mounting to wall
Nylon wall plugs
Used to brace the
screws inside the wall
#6-32 x .375” phillips
flat head screw
Option 2: Secures the top
and bottom casing together
Optical tamper
reflective post
Adhered to the surface
where the sensor is being
mounted
Safetrust Inc. | safetrust.com
sales@safetrust.com
Mounting Template:
How to use
Inside the box you will find a folded
piece of paper which includes the
mounting template. Begin by trimming
the template along the thicker dotted
line, being mindful not to cut the other
dotted lines in the diagram.
Then tape the template to the installation
site, ensuring you remove the cut out
piece from the template where the
reflective tamper post will be mounted.
*The diagram in this document is not to scale and cannot be
substitued for the official mounting template.
Safetrust Inc. | safetrust.com
sales@safetrust.com
For a wall mounted installation, begin by pre-drilling your holes and insert the nylon
screw plugs provided to support the weight of the reader. Once secured to the
wall, you can fix the black plate to the wall using the screws (SCR PTP, 2X6MM
BLUE, ZINC CR3) provided.
Safetrust Inc. | safetrust.com
sales@safetrust.com
The next step is to connect the wires as per the wiring table above.
Ground
Relay In*
Relay Out*
Red LED
Tamper
Green LED
Wiegand D0/Data
Wiegand D1/Clock/F2F
12VDC
OSDP TX+ / RS-485(A) / D0
OSDP TX+ / RS-485(B) / D1
Beeper
Black
Grey
Blue
Brown
Purple
Orange
Green
White
Red
Aqua
Pink
Yellow
Wire Colors
*Low voltage
