Runxin 73605 Manuel utilisateur

Multi-functional Flow Control Valve for

Water Treatment Systems

73605(Old Model No.:F92A)

73605B(Old Model No.:F92B )

73605/41206L(Old Model No.:F92A/F70EL)

73605B/41206L(Old Model No.:F92B/F70EL)

Instruction Manual

Please read this manual in details before using the valve and

keep it properly in order to consult in the future. 0WRX.466.043

International Patent No.：WO 2006/007772

China Patent No：ZL02220153.X，

ZL200420078956.5

American Patent No.：7549446

Indian Patent No.：232582

Russian Patent No.：2349819

South Korea Patent No.：10-0914137

Mexico Patent No.：268581

Australian Patent No.：2005263257

Philippine Patent No.：1-2006-502553

Taiwan Patent No.：M287896

MODEL73605 73605B 73605/41206L 73605B/41206L

Before the valve put into use, please fill in the below content so as to

help us to refer in the future.

Softener System Configuration

Tank Size：Dia. mm，Height mm；

Resin volume L；Brine Tank Capacity L；

Hardness of Raw water mmol/L；

Pressure of Inlet Water MPa；

Control Valve Model ；Number ；

The Specification of Drain Line Flow Control ；

Injector No. .

Water Source: Ground-water□ Filtered Ground-water □Tap water □

Other .

Parameter Set

Parameter

Unit

Factory Default

Actual

Value

On-line Program

C-01(Interlock

Program)

Data Clear

d-01(Close)

Control Mode

A-01/02/03/04/05/06

A-01

Water Treatment

Capacity(A-01/02/03/04/05)

50.00 m3

Regeneration Start-up Time

（A-01/03/05）

02∶00

Operation Days(A-06)

Regeneration Index (A-03/04)

0.65

Resin Volume (A-03/04)

Raw Water Hardness(A-03/04)

mmol/

1.2

MODEL73605 73605B 73605/41206L 73605B/41206L

Backwash Interval Times

F-00

Backwash Time

min:se

10:00

Brine & Slow Rinse Time

min:se

60:00

Fast Rinse Time

min:se

10:00

Brine Tank Refill Time

min:se

05:00

Interval Regeneration Days

Output Mode b-01(02)

b-01

If there is no special requirement when product purchase, we choose

8468062 drain line flow control and 8468055 brine line flow control, 6309

injector for the standard configuration.

MODEL73605 73605B 73605/41206L 72605B/41206L

Catalogue

Notice .........................................................................................................3

1. Product Overview...................................................................................4

1.1. Main Application & Applicability ………………………………4

1.2. Product Characteristics……………………………………. 4

1.3. Service Condition…………………………………………..6

1.4. Product Structure and Technical Parameters………………….7

1.5. Installation…………………………………………………….8

2. Basic Setting & Usage .........................................................................10

2.1. The Function of PC Board……………………………………10

2.2. Basic Setting & Usage………………………………………11

3. Application..........................................Hiba! A könyvjelző nem létezik.

3.1. Softener Flow Chart……………………………………………

Hiba! A könyvjelző nem létezik.

3.2. The Function and Connection of PC Board…………………16

A. Signal Output.........................................................................17

B. Interlock.................................................................................20

C. One in Service One Standby.................................................20

D. Remote Handling Input.........................................................21

E. Interlock System....................................................................21

F. Series System........................................................................21

3.3. System Configuration and Flow Rate Curve ………………….22

3.4. Parameter Settlement………………………………………… 24

3.5. Parameter Enquiry and Setting……………………………..25

3.6. Trial Running…………………………………………………29

3.7. Trouble-Shooting ………………………………………………..31

3.8. Spare Part and Part No………………………………………..35

4. Warranty Card......................................................................................41

MODEL73605 73605B 73605/41206L 72605B/41206L

Notice

To ensure normal operation of the valve, please consult with

professional installation or repairing personnel before use it.

If there are any of pipeline engineering and electric works, there must

be finished by professional at the time of installation.

Do not use the control valve with the water that is unsafe or unknown

quality.

Depending on the changing of working environment and water

requirement, each parameter of softener should be adjusted accordingly.

When the water treatment capacity is too low, please check the resin. If

the reason is shortage of resin, please add; if the resin is turn to

reddish brown or broken, please replace.

Test water periodically to verify that system is performing satisfactorily.

Sodium used in the water softening process should be considered as

part your overall dietary salt intake. Contact doctor if you are on a low

sodium diet.

Ensure that there is solid salt all the time in the brine tank in the course

of using, when this valve is used for softening. The brine tank should be

added the clean water softening salts only, at least 99.5% pure,

forbidding use the small salt.

Do not put the valve near the hot resource, high humidity, corrosive,

intense magnetic field or intense librations environment. And do not

leave it outside.

Forbidden to carry the injector body. Avoid using injector body as

support to carry the system.

Forbidden to use the brine tube or other connectors as support to carry

the system.

Please use this product under the water temperature between 5～

MODEL73605 73605B 73605/41206L 73605B/41206L

50℃，water pressure 0.15～0.6MPa. Failure to use this product under

such conditions voids the warranty.

If the water pressure exceeds 0.6Mpa, a pressure reducing valve must

be installed before the water inlet. While, if the water pressure under

0.15MPa, a booster pump must be installed before the water inlet.

It is suggested to install PPR pipe, corrugated pipe or UPVC pipe,

instead of TTLSG pipe.

Do not let children touch or play, because carelessness operating may

cause the procedure changed.

When the attached cables of this product and transformer are changed,

they must be changed to the one that is from our factory.

MODEL73605 73605B 73605/41206L 73605B/41206L

1.Product Overview

1.1.Main Application & Applicability

Used for softening or demineralization water treatment systems

Be suitable for

Residential softening system

Ion exchange equipment

Boiler softening water system

RO pretreatment softening system, etc.

1.2.Product Characteristics

Simple structure and reliable sealing

It adopts hermetic head faces with high degree pottery and

corrosion resistance for opening and closing. It combines with Service,

Backwash, Brine & Slow Rinse, Brine Refill and Fast Rinse.

Up-flow Regeneration

Up-flow regeneration, salt and water savings. No hard water pass

and hard water pass options.

Soft Water Refill

System also in service when in brine tank refill (Means soft water

flows in outlet), save the regeneration time and regenerate more

efficient.

Big Water Flow Rate

Flow Rate will be not lower 4.7m3/h when pressure drop is 0.1MPa.

Historical Record can be Enquired

Can enquiry soft edition, maximum flow rate after being used, totally

using days, regeneration times after being used and all data records can

be clear.

Manual function

MODEL73605 73605B 73605/41206L 73605B/41206L

Realize regeneration immediately by pushing manual button at

any time.

Long outage indicator

If outage overrides 3days, the time of day indicator 12:12 will flash to

remind people to reset new time of day. The other set parameters do not

need to reset. The process will continue to work after power on.

Buttons lock

No operations to buttons on the controller within 1 minute, button

lock indicator light on which represent buttons are locked. Before

operation press and hold the and buttons for 3 seconds to unlock.

This function can avoid incorrect operation.

Technicist or manufacturers can choose regeneration control

mode via getting authority

When control valve get connected with power, press button ,

and orderly to enter into enquiry and set menu which is available for

technicist or manufacture. Six control mode listed in table one can be

chose in regeneration control mode menu.

Mode

Name

Instruction

A-01

Meter

Delayed

Regenerate on the day although the available

volume of treated water drops to zero (0).

Regeneration starts at the regeneration time.

A-02

Meter

Immediate

Regenerate immediately when the available

volume of treated water drops to zero(0).

A-03

Intelligent

Meter

Delayed

Meter Delayed Regeneration type, but by setting

Resin Volume, Feed Water Hardness,

Regeneration Factor, the controller will calculate

the System Capacity.

A-04

Intelligent

Meter

Immediate

Meter Immediately Regeneration Type, but by

setting Resin Volume, Feed Water Hardness,

Regeneration Factor, the controller will calculate

the System Capacity.

A-05

Surplus

When the available volume of treated water not

MODEL73605 73605B 73605/41206L 73605B/41206L

Signal output

There is a signal output connector on main control board. It is for

controlling external wiring. (Refer to Figure7to Figure 13).

There are two kinds of output modes. b-01 Mode: Turn on start of

regeneration and shut off end of regeneration; b-02 Mode: Signal

available only intervals of regeneration cycles(Motor running

moment).(Regeneration sequence 1 as example), show as following:

Interlock function

Set program function of “Interlock c-01” to realize only one valve in

regeneration but the other valves are in service while several valves

parallel or series connection in system. (Application refer to Figure 14)

One in service one standby

Set program function of “One in service one standby” to realize

continuously water supply while the outlet of two valves connected with

Runxin specialized tee valve, this is called one in service one standby.

(Application refer to Figure 15)

Remote Handling Connector

This connector can receive 5~24VDC external signal, used together

Water

Comparing

more than average day water capacity of

previous 7 days, regeneration starts at the

regeneration time.

A-06

Time Type by

Day

Service days count down to zero(0),regeneration

stars at the regeneration time.

MODEL73605 73605B 73605/41206L 73605B/41206L

with PLC, and computer etc. to control the valve remotely. (Application

refer to Figure 16)

Maximum interval regeneration days (Not available for A-06)

Under the situation of service reaching the setting days and the

volume not yet, it could enter into regeneration process forcibly when

current time is the same as regeneration time.

All parameters can be modified

According to the water quality and usage, the parameters in the

process can be adjusted.

1.3.Using condition

Valve should be used under the below conditions

Item

Requirement

Working

conditions

Working

pressure

0.15MPa～0.6MPa

Water

temperature

5℃～50℃

Working

environment

Environment

temperature

5℃～50℃

Relative

humidity

≤95%（25℃）

Electrical

Facility

AC100～240V/50～60Hz

Inlet water

quality

Water turbidity

Up-flow regeneration＜2FTU

Water hardness

First Grade Na+＜6.5mmol/L；Second

Grade Na+＜10mmol/L

Free chlorine

＜0.1mg/L

Iron2+

＜0.3mg/L

CODMn

＜2mg/L（O2）

In the above table, First Grade Na+ represents First Grade Na+

Exchanger. Second Grade Na+ represents Second Grade Na+

Exchanger.

When the water turbidity exceeds the conditions, a filter should be

installed on the inlet of control valve.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Runxin Unité de contrôle

Runxin

Runxin 53520 Manuel utilisateur

Runxin

Runxin F71B1 Manuel utilisateur

Runxin

Runxin 51240B (F112BS) Manuel utilisateur

Runxin

Runxin F79A-LCD Manuel utilisateur

Runxin

Runxin 55504 Manuel utilisateur

Runxin

Runxin 63504 Manuel utilisateur

Runxin

Runxin 63504 Manuel utilisateur

Runxin

Runxin F56A Manuel utilisateur

Runxin

Runxin 53515 Manuel utilisateur

Runxin

Runxin F104 A Manuel utilisateur

Runxin

Runxin N74Q1 Manuel utilisateur

Runxin

Runxin F139 Manuel utilisateur

Runxin

Runxin 63518 Manuel utilisateur

Runxin

Runxin 17603 Manuel utilisateur

Runxin

Runxin 63510 Manuel utilisateur

Runxin

Runxin 51215 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
