Ruijie RG-AP820(AR) Access Point

Hardware Installation and Reference Guide

Document Version: V1.0

Date: 2022.02.11

All rights are reserved in this document and this statement.

Any reproduction, excerption, backup, modification, transmission, translationor commercial use of this document

or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks

is prohibited.

Trademark and are owned by Ruijie Networks.

All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.

Disclaimer

The products, services, or features you purchase are subject to commercial contracts and terms. Some or all of

the products, services or features described in this document may not be within the scope of your purchase or

use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement

or guarantee for the content of this document.

Due to product version upgrades or other reasons, the content of this document will be updated from time to

time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.

This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder

any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface

Intended Audience

This document is intended for:

Network engineers

Technical support and servicing engineers

Network administrators

Technical Support

Ruijie Networks Website: https://www.ruijienetworks.com/

Technical Support Website: https://ruijienetworks.com/support

Case Portal: https://caseportal.ruijienetworks.com

Community: https://community.ruijienetworks.com

Technical Support Email: [email protected]

Skype: [email protected]

Conventions

1. Signs

The signs used in this document are described as follows:

Warning

An alert that calls attention to important rules and information that if not understood or followed can result in

data loss or equipment damage.

Caution

An alert that calls attention to essential information that if not understood or followed can result in function

failure or performance degradation.

Note

An alert that contains additional or supplementary information that if not understood or followed will not lead to

serious consequences.

Specification

An alert that contains a description of product or version support.

2. Note

The manual offers configuration information (including model, port type and command line interface) for

indicative purpose only. In case of any discrepancy or inconsistency between the manual and the actual version,

the actual version prevails.

Hardware Installation and Reference Guide Product Introduction

1 Product Introduction

RG-AP820(AR) is an IEEE 802.11ax-compliant AR series wireless access point (AP) released by Ruijie

Networks for indoor high-density scenarios in the higher education, government, general education, finance,

and business sectors.

The RG-AP820(AR) complies with the IEEE 802.11ax, 802.11ac Wave 2, 802.11ac Wave 1, and 802.11n

protocols. It adopts the tri-radio design and can provide a maximum wireless access rate of 3.267 Gbps, which

breaks through the bottleneck in wireless performance.

The RG-AP820(AR) integrates Ruijie's exclusive AI Radio design. The extra intelligent radio card provides better

access experience and real-time full-band security protection for users in the Wi-Fi 6 environment.

Important factors such as the wireless network security, radio control, mobile access, Quality of Service (QoS),

seamless roaming, and expansion of the Internet of Things (IoT) module are fully taken into account for the RG-

AP820(AR). Therefore, this AP can be used together with Ruijie's access controllers (ACs) and WIS to

implement STA data forwarding, security, access control, and IoT application extension.

Moreover, the RG-AP820(AR) supports local power supply and power over Ethernet (PoE), which can be

selected based on power supply conditions. In addition, this AP can be mounted onto a wall or ceiling, making

the AP especially applicable to large campuses, conference centers, plazas, or other densely populated

scenarios.

1.1 RG-AP820(AR)

Specifications

Hardware Specifications

RF Design

Tri-radio design:

Radio 1: 2.4 GHz/5 GHz, 2 ×2 MIMO

Radio 2: 5 GHz, 2 ×2 MIMO

Radio 3: 2.4 GHz/5 GHz, 2 ×2 MIMO

Transmission

Protocol

Standard IEEE 802.11ax protocol and tri-radio dual-band design, which allows

the AP to work in IEEE 802.11ax and IEEE 802.11a/b/g/n/ac modes

simultaneously

Operating Bands

IEEE 802.11b/g/n/ax: 2.4 GHz to 2.483 GHz

IEEE 802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.47 GHz to 5.725 GHz, and

5.725 GHz to 5.820 GHz (Note: The operating band varies in different countries.)

Spatial Streams

Six spatial streams per device

Transmission

Rate

Maximum access rate of the AP: 3.267 Gbps

Radio 1: 2.4 GHz, 0.575 Gbps/5 GHz L, 1.2 Gbps

Hardware Installation and Reference Guide Product Introduction

Radio 2: 5 GHz/5 GHz H, 1.2 Gbps

Radio 3: 2.4 GHz, 0.4 Gbps/5 GHz, 0.867 Gbps

Modulation

Technologies

OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16-QAM@24 Mbps,and64-

QAM@48/54 Mbps

DSSS: DBPSK@1 Mbps, DQPSK@2 Mbps, and [email protected]/11 Mbps

MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, and 1024QAM

OFDMA

Receiver

Sensitivity

IEEE 802.11b: –96 dBm (1 Mbps), –93 dBm (5 Mbps), –89 dBm (11 Mbps)

IEEE 802.11a/g: –91 dBm(6 Mbps), –85 dBm (24 Mbps), –80 dBm(36 Mbps), –74

dBm(54 Mbps)

IEEE 802.11n: –90 dBm (MCS0), –70 dBm (MCS7), –89 dBm (MCS8), –68 dBm

(MCS15)

IEEE 802.11ac: 20 MHz: –88 dBm (MCS0), –63 dBm (MCS9)

IEEE 802.11ac: 40 MHz: –85 dBm (MCS0), –60 dBm (MCS9)

IEEE 802.11ac: 80 MHz: –85 dBm (MCS0), –60 dBm (MCS9)

IEEE 802.11ax: 80 MHz: –82 dBm (MCS0), –57 dBm (MCS9), –52 dBm (MCS11)

Transmit Power

≤ 100 mW (20 dBm) (The transmit power varies based on the regulations in

different countries and regions.)

Adjustable Power

Granularity

1 dBm

Dimensions

(W ×D ×H)

220 mm ×220 mm ×48.85 mm (8.66 in. ×8.66 in. ×1.92 in.) (height of theAP

only, excluding the mounting bracket)

Antenna

Built-in antenna

Weight

0.75 kg (1.65 lb.)

Service Ports

LAN 1/LAN 2 port can be used as an uplink 1 Gbps copper port. (LAN 1 port

supports IEEE 802.3af PoE power supply and is compatible with IEEE 802.3at

PoE power supply.) LAN 3 port can be used as a downlink 1 Gbps copper port.

LAN 3 port allows the AP to power external devices (12 V/2 W). (The port can be

connected to Ruijie's IoT module.)

Management Port

1 console port

USB Port

USB 2.0 port

Reset Button

Supported

Anti-theft Lock

Kensington lock and security screw

Hardware Installation and Reference Guide Product Introduction

Status LED

One LED (It supports red, green, blue, orange, and blinking mode, blinks when

an STA is connected, and can be muted.)

Power Supply

Local power supply: DC 48 V/0.6A (Note: The power adapter needs to be

purchased separately.)

PoE+, supporting IEEE 802.3af power supply and compatible with 802.3at power

supply

Overall Power

Consumption

< 20 W

Bluetooth

Bluetooth 5.0, supporting Apple iBeacon protocol, applicable to various Bluetooth

applications, such as shake and Bluetooth positioning applications

Environment

Operating temperature: –10°C to +50°C (14°F to 122°F)

Storage temperature: –40°C to +70°C (–40°F to +158°F)

Operating humidity: 5% to 95% (non-condensing)

Storage humidity: 5% to 95% (non-condensing)

Mounting Mode

Ceiling/wall-mountable

IP Rating

IP41

Safety Regulation

Compliance

GB4943.1, EN/IEC 60950-1

EMC Certification

GB9254.1, EN301 489

Health Standard

EN 62311

Radio

Regulations

Radio Transmission Equipment Type Approval, EN300 328, and EN301 893

Caution

The weight indicates the total weight of the AP and mounting bracket.

Product Appearance

The RG-AP820(AR) provides three RF ports and three Ethernet ports. LAN 1/LAN 2 port can be used as an

uplink 1 Gbps copper port. LAN 1 port supports PoE/802.3at/802.3af power supply. LAN 3/IoT port can be

connected to Ruijie's IoT module for power supply (12 V/0.25 A, MAX: 2 W). In addition, there are one console

port, one power socket for an external power adapter, one USB port, and one reset hole. The following figures

show the appearance of the RG-AP820(AR).

Hardware Installation and Reference Guide Product Introduction

Description

①LED

②Kensington Lock

③USB port

④Reset button

⑤Console port

⑥LAN 3/IoT port

⑦LAN 2 port

⑧LAN 1/PoE port

⑨Input port for the 48 V DC adapter

RG-AP820(AR) LED and Button

In fit mode

Frequency

Meaning

Status

–

The AP is NOT receiving power or the AP is in Do Not Disturb mode,

which can be disabled by software.

Off

3 Hz

uBoot program initialization is in progress.

Blinking green

–

Main program initialization is in progress.

Steady green

3 Hz

Initialization is complete, but there is no Ethernet activity.

Blinking red

–

Initialization is complete, and the AP is establishing a CAPWAP

connection with an AC.

Steady orange

3 Hz

Program upgrade is in progress. Do not power off the AP.

Blinking orange

–

Normal operation, but no wireless clients are associated with the AP.

Steady blue

3 Hz

Normal operation, and at least one wireless client is associated with

the AP.

Blinking blue

3 Hz blinking

for 2 periods

and off for 2

periods

The AP is being located.

Blinking red

Hardware Installation and Reference Guide Product Introduction

Reset button

Pressed for less than 2s

Reboot the

device.

Pressed for more than 3s

Restore default

settings.

In fat mode

Frequency

Meaning

Status

–

The AP is NOT receiving power or the AP is in Do Not Disturb mode,

which can be disabled by software.

Off

3 Hz

uBoot program initialization is in progress.

Blinking green

–

Main program initialization is in progress.

Steady green

3 Hz

Initialization is complete, but there is no Ethernet activity.

Blinking red

–

Normal operation, but no wireless clients are associated with the AP.

Steady blue

3 Hz

Normal operation, and at least one wireless client is associated with

the AP.

Blinking blue

Reset button

Pressed for less than 2s

Reboot the

device.

Pressed for more than 3s

Restore default

settings.

Caution

Hz indicates the number of times the indicator blinks in a second. For example, 3 Hz indicates that the

indicator blinks 3 times per second.

Power Supply

The RG-AP820(AR) can be powered by a DC adapter or PoE+.

Caution

To power the RG-AP820(AR) by using a DC adapter, use an adapter with specifications recommended by Ruijie.

(For details about the adapter specifications, see Section 2.2.5 and Appendix C.)

To power the RG-AP820(AR) by using PoE+, ensure that the device at the other end of the Ethernet cable

supports IEEE 802.3at power supply.

Heat Dissipation Solution

The RG-AP820(AR) adopts the fan-free design.

Caution

Maintain sufficient clearance around the AP for air circulation.

Hardware Installation and Reference Guide Preparing for Installation

2 Preparing for Installation

2.1 Safety Precautions

Caution

To avoid personal injury and device damage, carefully read the safety precautions before you install the AP.

The following safety precautions may not cover all possible dangers.

2.1.1 General Safety Precautions

Do not expose the AP to high temperature, dusts, or harmful gases. Do not install the AP in an inflammable

or explosive environment. Keep the AP away from EMI sources such as large radar stations, radio stations,

and substations. Do not subject theAP to unstable voltage, vibration, and noises.

Keep the site where the AP is installed dry, so it is not recommended to install the AP near the ocean. Keep

the AP at least 500 meters away from the ocean and do not face it towards the sea breeze.

The installation site should be free from water flooding, seepage, dripping, or condensation. The installation

site should be selected according to network planning, communications equipment features, and

considerations such as climate, hydrology, geology, earthquake, electrical power, and transportation.

Caution

Install and remove the AP properly by following instructions in the installation guide.

2.1.2 Handling Safety

Pay attention to the following points when moving the AP:

Do not frequently move theAP after the AP is installed.

Cut off all the power supplies and unplug all power cords before moving or handling the AP.

2.1.3 Electric Safety

Observe local regulations and specifications during electric operations. Only personnel with relevant

qualifications can perform such operations.

Check whether there are potential risks in the work area. For example, check whether the power supply is

grounded, whether the grounding is reliable, and whether the ground is wet.

Find the position of the indoor emergency power switch before installation. Cut off the power switch in case

of accidents.

Confirm the preceding items when you cut off the power supply.

Do not place the device in a wet position, and keep the device away from liquid.

Keep the AP far away from grounding or lightning protection devices for power equipment.

Keep the AP away from radio stations, radar stations, high-frequency high-current devices, and microwave

ovens.

Hardware Installation and Reference Guide Preparing for Installation

Caution

Improper or incorrect electric operations may cause a fire, electric shock, and other accidents, and lead to

severe and fatal personal injury and device damage.

Direct or indirect contact with high voltage or mains power supply through wet objects may cause fatal

dangers.

2.2 Installation Environment Requirements

The RG-AP820(AR) must be used indoors. Install theAP indoors to ensure its normal operation and prolong the

service life. The installation site must meet the following requirements.

2.2.1 Installation Requirements

Install the AP in an open environment. If the AP is installed in a closed environment, ensure that the

environment has proper ventilation and heat dissipation.

Ensure that the installation location is sturdy enough to support the weight of theAP and its accessories.

Ensure that the dimensions of the installation location for the AP are proper with sufficient clearance around

the AP for heat dissipation. The installation location must be at least 2 m away from base station antennas

to prevent mutual interference.

2.2.2 Ventilation Requirements

Reserve sufficient clearance around the AP for heat dissipation when installing the AP, because the AP adopts

a fan-free design.

2.2.3 Temperature and Humidity Requirements

To ensure the normal operation and prolonged service life of the AP, maintain an appropriate temperature and

humidity in the equipment room. An equipment room with too high or too low temperature and humidity for a

long period may damage the device.

In an environment with high humidity, the insulating material may have poor insulation or even leak electricity.

Sometimes it is also prone to changes in the mechanical properties and causes rusting of metal parts.

In an environment with low relative humidity, the insulating strip may dry and shrink, static electricity may

occur and damage the internal circuits of the AP.

Too high temperatures can accelerate the aging of insulation materials, greatly reducing the reliability of the

AP and severely affecting its service life.

The following table describes the temperature and humidity requirements for the RG-AP820(AR).

Operating Temperature

Operating Humidity

–10ºC to +50ºC (14°F to 122°F)

5% to 95%

2.2.4 Cleanliness Requirements

Dust poses a major threat to the AP. Indoor dust falling on the device may be adhered by static electricity,

causing poor contact of metallic joints. Such electrostatic adhesion may occur more easily when the relative

humidity is low, not only affecting the service life of the AP, but also causing communication faults. The following

table describes the requirements for the dust content and granularity in the equipment room.

Table des matières

Autres manuels Ruijie Point d'accès sans fil

Ruijie

Ruijie RG-AP130(L) Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-RAP6260 Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP680-IO Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP680-AR Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-RAP6262 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-RAP2260 Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP130(W2) V2 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP840-L Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RAP6260-D Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-RAP52-OD Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP630 IDA2 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP180 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie AP850-AR Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP680 CD Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee Series Dimensions

Ruijie

Ruijie RG-AP180P-L Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-RAP2260(G) Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP720-L Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP680P-L Manuel d'installation et d'exploitation

Ruijie

Ruijie HA3515-DG Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-AP110-L Manuel utilisateur

Ruijie

Ruijie RG-AP680 CD Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-EAP602 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-RAP1260 Manuel d'installation et d'exploitation

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
