OWNER'S MANUAL
Model No. RHD-2201
English
LAMINATOR
Please read instructions carefully before use.
Introduction 3
Package Contents 3
Safety Precautions 4
Parts 5
Features Guide 7
Operating Instructions 8
Maintenance 10
Trouble Shooting Guide 10
Warranty 12
Contents Page
TABLE OF CONTENTS
2
RHD-2201
INTRODUCTION
PACKAGE CONTENTS
Power Code
Manual
Cleaning Paper
Main Body
3
RHD-2201
Thank you for purchasing the RHD-2201 Pouch laminator. It has been designed
and manufactured to provide years of continuous service. For high quality
lamination, please read this instruction manual thoroughly. This manual will
provide you with complete operating and maintenance information.
SAFETY PRECAUTIONS
4
Failure to comply with any of the following safety procedures
could result in serious injury.
Keep this information for future reference.
WARNING
1. Insure the unit is plugged into a properly grounded outlet with the correct voltage.
2. Only licensed electricians should service or repair the electrical wiring.
3. Keep flammable and wet objects away from the machine.
4. Place machine on a flat sturdy surface.
5. Avoid excessive sunlight, humidity and temperatures.
6. Unplug the machine when moving it or when it's not in use.
7. Keep out of reach of children.
8. Only authorized maintenance and service technician are permitted to make
repairs to the machine.
9. When cleaning the machine, don't use flammable sprays or materials.
10. Do not touch the rollers or allow foreign objects inside the machine.
RHD-2201
5
RHD-2201
PARTS
Metal cover Cover Roller Operation paneEntrance
Exit Power cord Power switch
6
Detail for the operation panel
Power : It starts after pushing button, and it is set temperature 90ºC and speed
6step(75mic+80g) when the start.
Please push the power button when shut off. It is set the temperature
60ºC and speed 2step automatically, then it is stop automatically after for
a while.
HOT : After pushing Cold function and Stand By function then pushing HOT
button that is set up the temperature 90ºC and speed 6 step automatically.
Please control the temperature and speed on it’s requred film specification
referring to the manual “Film Termperature and Speed chart”
Cold : Please push the cold button when the lamination of cold film.
Temp : It can be controled 40ºC ~ 160ºC in unit of 1ºC
In case of wide range of temperature, please push the button
continuously.
Speed : It can be controled 1~9 step in units of 1step
(Please refer to the manual “Film Termperarure and Speed Chart”)
Start lamp : When not ready, light on and off repeatably
When ready, the lamp light on
Reverse : In case of wrong inserting and rolled film, the machine has a reverse
function
Stand By : It is set up the temperature 80ºC and speed 2step automatically.
(please use this function when you stop the machine for a while)
T-Check : In case of changing temperature and starting the machine, the present
temperature of roller can be checked.
RHD-2201
Temperature window Ready lamp Speed window
Temperature control button
Temperature check button
Speed control button
Cold lamination button
Reverse button Power On/Off
Stand By Button
Hot lamination button
7
FEATURES GUIDE
1. 6 Rollers Product : High quality and fast speed with 6 Rollers laminator.
2. Hot and Cold function : There are Hot and Cold function that can be used
both hot and cold film
3. Use different film : Hot film, Cold film, Thinflex film, Foam board, Foil
4. Temperature and Speed Control Function : It can be controled the
temperature 40~160ºC in unit of 1ºC and 1~9 step in unit of 1step.
It can be controled temperature and speed on it's required specification of
various film lamination.
5. Reverse Function : In case of wrong inserting and rolled film, the machine
has a reverse function
6. Stand By Function : The machine can be staying in 80ºC of temperature
continuously that the user who frequently use the machine can reduce the
ready time for saving eletronic power.
7. Fast Speed : Maximum speed is 2700mm / min, and 1~9 step can be
controled for it's condition of lamination.
8. Preventing Overheat Function : When the wong condition of termperature
sensor, heating system is automatically stopped for safety.
9. FND Display : It can be seen it's speed and temperature condition at day and
night through the FND window.
10. Present Temperature Function : The user can check the present
termperature.
11. Automatical shutting off function : It can be shut off the power supply
automatically after the use.
12. Cover Roller : There is special cover on the roller to help the clean.
13. Button Sound : The user know it's condition through the button sound.
14. Accuracy : The temperature and speed are very accurate by Microprecessor.
15. Stability : Heating can be transmitted to the roller very stablely by using
Quartz and High-sensor heater.
16. Simplicity : It's simple and fascinate design can be used in every place and
simply set up.
17. Safety : It is guranteed by the perfect after-service.
RHD-2201
8
OPERATING INSTRUCTIONS
1. Place the machine on a flat sturdy surface.
2. Insure the unit is plugged into a properly grounded outlet with the correct
voltage power plug and outlet.
3. Turn the laminator ON located on the rear of the machine.
4. Push on POWER button.
5. Press the HOT FILM or COLD FILM button according to the film you are using
for lamination.
6. If you are laminating several items and need hot lamination for some and cold
lamination for some we recommend you laminate the cold pouch items first to
save time.
7. Choose appropriate laminating thickness and speed using the FND controller,
Please see below temperature and speed table which is standard for
RHD-2201.
* Materials to be laminated :
80g = Thin paper such as paper for fax machine or magazine.
120g = Copy paper
200g = Pictures, Catalogues
* NOTE : The weight of paper may vary depending on manufacturers therefore
it is recommended to adjust proper temperature and speed
accordingly.
• We recommend you use Royal Sovereign laminating film.
• The above table is based on Royal Sovereign's film.
RHD-2201
Finishing lamination
(Please turn off the machine when rollers are cooled down)
> Power Off
> Use for Hot Button
Starting lamination
> Power On
> Use for Cold Button
9
8. Please wait until " Ready Lamp" is steadily lit.
(If materials are laminated while Ready Lamp is blinking, lamination results
may not be good enough).
9. Once the ready lamp is steadily lit place the lamination pouch with the sealed
end first into the entrance of the laminator.
10. The laminated item will exit the rear of machine.
11. If an item gets jammed press the "Reverse" button to clear the jam.
12. For periods in between jobs set the laminator to "pre-heat" to conserve
electricity.
13. Repeat the above steps until all of your lamination is completed.
When lamination is completed turn the power off
RHD-2201
Make sure that you place the laminating pouch
with the sealed end first into the entrance of the
laminator.
Only laminate whole pouches,
DO NOT cut or alter pouches
in anyway before laminating.
Set temperature according to
pouch film thickness.
FILM SETTINGS -Based on 25˚C-
Film Thickness
75 mic (3 mil)
100 mic (4 mil)
125 mic (5 mil)
150 mic (6 mil)
175 mic (7 mil)
200 mic (8 mil)
250 mic (10 mil)
THINFLEX
FOIL
90
90
90
95
95
95
100
100
100
105
105
105
110
110
110
115
115
115
125
125
125
120
120
125
120
125
125
6
5
4
7
6
4
7
6
4
7
6
4
6
5
4
6
5
4
6
5
4
4
3
3
4
4
3
80
120
200
80
120
200
80
120
200
80
120
200
80
120
200
80
120
200
80
120
200
80
120
200
80
120
200
Paper(g) Temp(˚C) Speed
10
MAINTENANCE
TROUBLE SHOOTING GUIDE
Using Cleaning Paper :
1. Turn the laminator ON located on the rear of the machine.
2. Please wait until " Ready Lamp" is steadily lit.
Once the ready lamp is steadily
lit place the cleaning paper in the entrance of the machine. Once the paper
has exited the machine fold the cleaning paper so that the inside is now
facing out and again place the paper in the entrance of the machine.
3. Continue repeating step 2 until the paper exits the machine and is not dirty.
* NOTE : Rollers should be cleaned after 10 laminations.
Do not use regular paper to clean the rollers it must be plain coated
white paper.
4.
Do not apply any cleaning fluids to the rollers, certain fluids may cause damage.
5. Do not clean rollers with sharp or pointed objects.
6. Use a damp cloth with water to clean the body of the machine.
7. Store machine in a dry clean area.
RHD-2201
Motor doesn't work. 1. Check if the power cord is plugged in.
2. Check if the power is on.
Problem Possible Solution
