Royal Sovereign LAMINATORS
OWNER'S MANUAL
RSC-1650H/1650C
PLEASE READ AND SAVE INSTRUCTIONS
- 1 -
TOPICS PAGE
INSTRUCTION --------------------------------------------------------------
-
3
SAFETY PRECAUTIONS -----------------------------------------------------
-
3
CHARACTERISTICS ----------------------------------------------------------
-
4
SPECIFICATIONS --------------------------------------------------------------
-
4
NAMES OF MAJOR PARTS OF MACHINE-----------------------------------
-
5
SETTING UP FILM ------------------------------------------------------------
-
6
HANGING FILM ---------------------------------------------------------------- 7
CONTROL OF ROLLER PRESSURE ---------------------------------------
-
8
INSTRUCTIONS FOR CONTROL PANEL ---------------------------------
-
9
1.FUNCTIONS OF CONTROL PANEL ---------------------------------
-
10
2.HOW TO USE BUTTONS ----------------------------------------------
-
10
LAMINATING STEPS ------------------------------------------------------------ 11
METHOD FOR USING CUTTER -----------------------------------------------
-
12
1.CROSS CUTTER -----------------------------------------------------------
-
12
IMPORTANT SAFETY CONCERNS ---------------------------------------- 13
MAINTENANCE --------------------------------------------------------------------
-
13
IT'S NOT OUT OF ORDER ----------------------------------------------------
-
14
ASSEMBLY PARTS -------------------------------------------------------------
-
14
WARRANTY ----------------------------------------------------------------------- 15
TABLE OF CONTENTS
- 2 -
Thank you for purchasing a Royal Sovereign Roll Laminator. It has been designed and
manufactured to provide years of continuous service in the professional environment.
To insure high quality lamination, please read this instruction manual thoroughly. This
manual will provide you with complete operating and maintenance information.
The safet
y
recommendations outlined in this section are to be read, understood and
followed before operating machine.keep this information for future refrence. Failure to.
com
p
l
y
an
y
of the followin
g
safet
y
p
rocedures could result in serious
p
ersonal in
j
ur
y
.
1. To prevent the possibility of electrical shock, do not immerse machine in water or
permit liquids to spill inside.
2. Do not allow articles of clothing (neckties, scarves, papers, etc.) near front or rear
machine openings as they could get caught by rollers and be pulled inside, causing
personal injury.
3. Do not insert sharp objects into front or rear machine openings.Do not place anything
in feed tray openings of machine other than appropriate laminating materials or pouches
4. Do not attempt to laminate items that exceed total recommended material thickness.
5. Do not operate machine for any other purposes than its intended use.
6. Do not operate machine if electrical plug or power cord is damaged.
7. Turn off the power when unattended or not in use. Unplug machine before moving it or
when it is not in use for an extended period of time.
8. This machine is intended for indoor use only.
9. Do not alter or extend electric plug. Plug is configured for appropriate electrical supply.
10. The socket-outlet shall be installed mear the equipment and shall be easily accessible.
SAFETY PRECAUTIONS
INSTRUCTION
- 3 -
RS Roll Laminator Line is advanced laminators with time transcendental desi
g
n, utilizin
g
the
latest in laminatin
g
technolo
gy
.
It is desi
g
ned for
y
ou to set temperature and speed as necessar
y
. Also
y
ou can laminate
an
y
thin
g
at hi
g
h speed,re
g
ardless of thickness of material and t
y
pe of film.It is also desi
g
ned
for convenient use by anyone through the simple procedure of adjusting film tension in
accordance with the thickness of film and materials to be laminated.
—
Laminating Length Measurement
yes
no
Remote switch
9 step (digital)
DC Geared Motor
2 Roller
Laminating Paper Counting
Gross Weight
no
Dimension(W×D×H,mm）
Unit Weight
Gross Demension(W×D×H,mm）
1960×650×1210（77.2“×25.6”×47.4“）
230Kg(500ibs)
2100×875×1250（82.7“×34.1”×49.2“）
300Kg(660ibs)
Power auto-off
no
no
Foot switch yes
Stand-by mode
Mount Lamination
Reverse
yes(15mm)
yes
Hot Lamination
Photo Lamination yes
Transport Type
Cooling System
no
no
Speed Control
Driving Motor
Ready time(min) 10
Heating Method Warm Roller
Temp` Select
Temp`Control
9 step
digital
120V/60Hz
Power Consumption(Watts) 1700
Max. Laminating Width(mm) 1650(65") 1650(65")
Power Supply 120V/60Hz
Laminating Thickness(micron)
Laminating Speed(mm/min)
25,50,75,80,100,…
5000(16.4ft/min)
RSC-1650C
no
100
Description RSC-1650H
SPECIFICATIONS
CHARACTERISTIC
- 4 -
NO
1
2
3
4
5
6
7
8
9
10
11
12
13
○
TAKE-UP BOBBIN
IDLE BAR
HOT ROLLER
TABLE-FRONT
UPPER ROLLER
○
○
X
TAKE-UP SWITCH
○
○
PART NAME
FRAME-GUIDE,PAPER
RSC-1650H RSC-1650H
NAMES OF MAJOR PARTS OF MACHINE
CONTROL PANEL
○
FOOT SWITCH
○
ASS'Y-STAND
PRESSURE LEVER
TENSION CONTROL KNOB
SAFETY COVER
○
REMOCON SWITCH ○
○
○
○
6
11 32
4
9
10
5
7
1
8
12
13
- 5 -
1. Set the glossy side of upper/lower film to face the heat.
( Glossy side is PET film and matte side is thermal polymer laminating film.)
2. Like picture 1, insert core into the left side of upper/lower film shaft.
3. Like picture 2 and 3, insert core into the right side of upper/lower film.
4. Like picture 4 and 5, adhere core closely.
(Make the right/left direction of fixing screw consistent.)
5. Locate film in the middle, and then fasten core fixing screw.
SETTING UP FILM
주 름 방 지 부
열 판
주 름 방 지 부
열 판
표 시 창
L
C
D
버 튼 부
COLD FILM
PAPER BAC
K
- 6 -
1. Set up cold film below the upper bar of the machine.
(Set the same as methord of the HOT film for protect paper of lower part)
2. Set the pressure lever to the 15mm, open mode.
3. Insert a piece of wide cardboard (guiding paper/carrier) between the rollers.
4. Pull the film from the upper roller passing over the upper idle bar to the upper roller and put it
on the upper roller.
5. Put the paper back of the film to the bobbin at take-up bar to rewind the paper back.
6. Allow some of the film with melted resin to stick to the Guiding Paper.
7. Place the film from lower shaft beneath the film from the upper roller which is already meiting.
and unwind films of both rollers 30~40cm(1~1.3ft) for loosing the tension.
8. Set the pressure lever to the 1mm.
9. Set speed at 1 and press the RUN button. The films will be fed into the machine and will come
out from the rear site of machine.
10. Check the status of lamination and place the pressure lever at lamination mode.
HANGING FILM
TAKE UP DEVICE
PAPER BACK
COLD FILM
UPPER IDLE BAR
LOWER IDLE BAR
HOT ROLLER
PAPER BACK
- 7 -
1. For setting, pull the pressure lever out and turn the lever to following the indication
2. OPEN/15mm(Board) : For laminating 15mm thick board (RSC-1650H/1650C)
3. 10~13mm(Board) : For laminating 10~13mm thick board
4. 5~7mm(Board) : For laminating 5~7mm thick board
5. 1mm(Hard Board) : For laminating 1mm thick board
6. Laminating : For laminating 32~250micron thick film
CONTROL OF ROLLER PRESSURE
***Methods of controlling pressure of the roller**
- 8 -
We designed this machine standing by user’s convenience. You can manipulate speed and
temperature .
***Terms***
INSTRUCTIONS FOR CONTROL PANEL
6 1
4
2
6
2
1
3
3
5
- 9 -
1. FUNCTIONS OF CONTROL PANEL
RUN/STOP BUTTON : Run or stop the rollers
SPEED BUTTON : Increase or decrease speed
LED OF SPEED : Display or speed
LED OF TEMP. : Display temperature
TEMP.BUTTON : Increase or decrease temperature
REVERSE BUTTON : To make the rollers run backward
2.HOW TO USE BUTTONS
Push the button in order to run rollers and push
button to stop it.
SPEED BUTTON
Push the SPEED button to increase the speed,push the speed
button to decrease the speed.
TEMP. BUTTON
Push the TEMP. button to increase the temperature,push the
TEMP. button to decrease.
REVERSE BUTTON
Stay pressing REVERSE button to have . The roller run backward.
RUN / STOP BUTTON
1
2
3
4
5
6
1
2
5
6
RUN
REV
STOP
- 10 -
