Royal Sovereign Quick Ready APL-340U Manuel utilisateur

Royal Sovereign International, Inc.

APL-340U

QUICK READYTM/MC

PROFESSIONAL

OFFICE LAMINATOR

Owner's Manual

Please read and retain these instructions.

To register your product, please go to www.royalsovereign.com USA.

Click the Customer Support Tab then Registration Tab.

www.royalsovereign.com

Because our products are subject to continuous improvement,

Royal Sovereign reserves the right to modify product design and

specifications without notice and without incurring any obligation. E&OE

Page en Français 9

LAMINATOR

APL-340U

SAFETY INSTRUCTIONS

The safety recommendations outlined in this section should be read and understood before operating this machine. When

using this machine follow these basic safety precautions to reduce risk of fire, electric shock or injury. Keep this information

for future reference.

1. To prevent the possibility of a fire or injury, do not allow foreign articles inside the machine.

2. Do not attempt to laminate items that exceed total recommended material thickness.

3. Insert pouch film with the sealed end first.

4. To prevent the possibility of electric shock, do not immerse the laminator in water or permit liquids inside the machine.

5. Because the laminator creates heat, keep out of the reach of children.

6. Do not cut pouches before inserting them into the laminator. This will cause the laminator to jam.

7. Do not laminate leaves, flower, clothes, etc.

8. If the room temperature is low (under 64°F), the ready light may take longer to come on.

9. When unplugging the power plug, grip the plug to pull it out. Pulling the cord may result in electric shock, fire, or

damage to the machine.

10. Do not use the machine if the cord is damaged. This may result in electric shock, fire, or other hazards.

11. Do not place objects on the power cord and do not bend it excessively. This may result in electric shock, fire or other

hazards.

12. When not using the machine for long periods of time, unplug the power cord from the outlet.

Box Contents 5

Parts 5

Features 5

Operation 6

Troubleshooting 7

Specifications 7

Warranty 8

Contact Information 8

Page en Français 9

CONTENTS

APL-340U

BOX CONTENTS

Laminator and pouch film

PARTS

FEATURES

Four Roller System

The four roller system provides precise heat and pressure to ensure high quality lamination.

Hot and Cold Lamination

The laminator can easily be adjusted to handle both hot and cold lamination pouch film.

Temperature Control

Individual settings for different film thicknesses from 3-7 mil.

Reverse Functions

The machine has both a manual and automatic reverse function.

Auto-Reverse

When a jam occurs the motor reverses until the material exits the machine.

Automatic Roller Cooling Function

After lamination when the machine is turned off, the rollers will continue to rotate until the rollers temperature reaches

177.8℉, this is to protect the rollers.

Reverse ButtonPower & Reverse Light Temperature Control Button

Cover

Front OpeningPower Button

OPERATION

Hot Lamination

Before laminating important or unique documents, always test a pouch through the laminator using a similar document.

1. Place the machine on a flat, sturdy surface and press the power button to turn on the machine.

2. The machine is preset to the 3mil setting. To change the setting, press the temperature control button. The machine will take

approximately 1 minute to warm-up. When the proper temperature is reached, the blinking light will glow steady.

3. Place the item to be laminated into the laminating pouch.

4. Insert the pouch film into the front opening of the laminator. Make sure to place the sealed end of the pouch film in first. All sized

pouches should be placed in the center of the front opening to pass through the sensor.

5. The document or photo will then exit out the back of the machine.

6 .If the item is not completely laminated, repeat step 4.

NOTE:

After inserting the pouch into the laminator, if the laminated item does not pass through all 4 rollers within approximately

8 seconds the automatic reverse function will turn on sending the item out of the front of the machine. If you need to

reverse an item after it is inserted into the rollers press the reverse button and the item will exit the front opening.

NOTE: Laminated items exiting the machine may be too hot to touch.

NOTE: Laminated items will be hot and will easily bend. To keep the item flat, place on a flat surface and allow it to cool.

Cold Lamination

1. Place the machine on a flat, sturdy surface and press the power button to turn on the machine.

2. Press the temperature setting button until the Cold lamination setting is lit. If the machine was previously used in hot

mode, allow approximately 40 minutes to cool down. When the proper temperature is reached, the light will glow steady.

3. Place the document to be laminated on the non-adhesive side of the cold film with the document face down, sealed end first.

4. Insert the document to be laminated into the front opening of the machine.

5. Remove paper liner from the cold film slowly while the document is being inserted into the machine.

6. The document or photo will exit out the back of the machine.

NOTE:

After inserting the pouch into the laminator, if the laminated item does not pass through all 4 rollers within approximately

8 seconds the automatic reverse function will turn on sending the item out of the front of the machine. If you need to

reverse an item after it is inserted into the rollers press the reverse button and the item will exit the front opening.

APL-340U

Symptom Solution

Motor does not work. Check to make sure machine is plugged in. Check to make sure the power

button is turned on.

Pouches are not laminating correctly.

Make sure that the machine is set to the correct setting. The setting should be

the same as the thickness of the pouch you are using. ie. 3 mil pouch film

should be set to 3 mil setting.

The machine is beeping and the pouch is returning

out of the front of the machine.

The automatic reverse function has turned on to retrieve the item. The item you

are laminating may be jammed or too large to pass the rollers. Wait for the

pouch to exit the front of the machine. You can try laminating again after 8

seconds.

The rollers are moving, but the laminated item is not. Hold down the reverse button until the entire pouch has exited the front of the

machine. You can try laminating again after 8 seconds.

TROUBLESHOOTING

If you are still having complications, please contact Royal Sovereign’s Service Center at 1-800-397-1025.

SPECIFICATIONS

Model APL-340U

Dimensions 22" x 9.8" x 6.5" / 560 x 250 x 165(mm)

Maximum laminating width 13.4" / 340mm

Film thickness 3~7 mil / 75~175 micron

Number of rollers 4

Cold mode Yes

Heating system Quartz type

Ready time Approximately 1 minute

Motor type AC motor

Laminating speed 20" per min / 520 mm per min

Weight 13.2lbs/6kg

Voltage/Cycle 120V, 60Hz

Power consumption 1,330W

LIMITED ONE YEAR WARRANTY

This warranty applies to repair or replacement of product found to be defective in material or workmanship for one year

from the date of the original purchase. This warranty is extended only to the original purchaser.

This warranty does not apply to damage resulting from abuse, misuse, or improper maintenance of damage that is

attributable to acts of nature. Royal Sovereign International, Inc. (and its affiliated companies) is not liable for incidental or

consequential damages of any nature. This limitation would not apply if you live in those areas that do not permit the

exclusion or limitation of incidental or consequential damages.

Defective products for warranty repair or replacement cannot be returned without a Return Authorization number. Please

go to www.royalsovereign.com USA-Customer Support Tab to make a request for an Office Product Return Authorization.

For Canadian customer service: www.royalsovereign.ca/support/service-policy.

Defective products must be returned to Royal Sovereign International Consumer Return Department, freight prepaid, with

proof of purchase and Return Shipping and Handling payment (check or money order). Upon repair or replacement the

product will be returned to the customer.

Return defective product to the following address with a detailed description of the problem. If possible, pack in original

carton. Please prepay shipping charges.

ROYAL SOVEREIGN INTERNATIONAL, INC. RS CANADA INC.

2 Volvo Drive Rockleigh, NJ 07647 USA 5610 Timberlea Blvd, Mississauga, L4W 4M6, CANADA

TEL : +1) 800-397-1025 FAX : +1) 201-750-1022 TEL : +1) 905-461-1095 FAX : +1) 905-461-1096

www.royalsovereign.com TF: +1) 866 961-6673

www.royalsovereign.ca

Royal Sovereign International, Inc.

APL-340U

QUICK READY

TM/MC

PROFESSIONNEL

PLASTIFIEUSE DE BUREAU

Manuel du Propriétaire

Lisez et conservez ces instructions pour utilisation ultérieure.

Pour enregistrer votre produit, veuillez vous rendre à www.royalsovereign.com – É-U Cliquez sur l’onglet

Customer Support (Service à la clientèle) - ensuite Registration (Enregistrement).

www.royalsovereign.com

Parce que nos produits font constamment l'objet d'améliorations,

Royal Sovereign se réserve le droit de modifier

le modèle et la fiche technique sans avis ni obligation du fabricant. E&OE

Page en Français 9

LAMINATOR
