Rollei Actioncam 9s Plus Manuel utilisateur

Actioncam

9s Plus

Touch

Display

ANLEITUNG AUF DEUTSCH

USER MANUAL IN ENGLISH

www.rollei.de

ENGLISH

Before the First Use

Read the operating instructions and the safety instructions carefully before using

the device for the ﬁrst time.

Keep the operating instructions together with the device for future use. If other people use this device, make

this manual available to them. If you pass on the device to a third party, this manual belongs to the device

and must be supplied with it.

Explanation of symbols

The following symbols are used in this manual, on the camera or on the packaging.

Products marked with this symbol comply with all relevant community regulations of the

European Economic Area.

Products marked with this symbol are operated with direct current.

What‘s in the Box

1x Rollei Actioncam 9s Plus

1x Remote control 2.4 GHz

1x Underwater protective housing

1x Exchangeable lithium-ion battery

1x Bike mount

7x Brackets

1x Helmet holder

4x Velcro straps

2x Adhesive stickers

4x Cable ties

1x Metal cable

1x Micro-USB cable

1x Lens cleaning cloth

1x User manual

ENGLISH

Attention

1. This product is a delicate product, do not drop or hit it anywhere.

2. Do not place the camera near to streng magnetism, such as magnets and motors.Avoid to place the

product near anything emitting strong radio waves, a strong magnetic ﬁeld may cause the product to

malfunction or damage the image and sound.

3. Do not place the camera at high temperatures or direct sunlight.

4. Use brand microSD memory cards as ordinary cards do not guarantee the proper use.

5. Da not use microSD memory cards in or near magnetic places to avoid lass of data.

6. During the charging process, if there is overheating, smoke or odor, unplug the power immediately and

stop charging to avoid ﬁre.

7. Keep away the camera and its accessories from children to avoid choking or electric shocks.

8. Store the product in a cool and dry place.

9. Da not use the camera when it is low power or in charging.

10. Do not attempt to open or modify the camera housing in any way as this will invalidate the warranty.

Technical Data

Model Rollei Actioncam 9s Plus

Chip Icatch V39

Sensor resolution 12 M resolution

Lens Wide angle lens | aperture F = 2.8 | focal length f: 2.7 mm

Video resolution 4K 3840 x 2160 at 60/30 fps

2.7K 2704 x 1520 at 30 fps

1080p 1920 x 1080 at 120/60/30 fps

720p 1280 x 720 at 240/120/60 fps

Still image resolution 20 M*: 5120 x 3840 4:3

16 M*: 4640 x 3480 4:3

14 M*: 4320 x 3240 4:3

10 M: 3648 x 2736 4:3

8 M: 3264 x 2448 4:3

5 M: 2592 x 1944 4:3

2 M: 1600 x 1200 4:3

Display 2“ touchscreen display and 1.4“ selﬁe display

Data format Video: MOV (H.264) I Photo: JPG

Memory microSD memory card up to 64 GB

Connectors Micro-USB, Micro HDMI, 1/4“ thread

Waterprooﬁng Camera body waterproof up to 7 meters, in underwater housing

waterproof up to 30 meters

Microphone Built-in microphone

Additonal Features White balance, webcam function, electronic image stabilization

ENGLISH

Technical Data

Modes Video: Normal, Slow Motion, Loop Recording, Time Lapse, Fast Motion

Photo: Single shots, Continuous shots, Self-timer, Time-lapse, Long time

exposure

WiFi iEEE 802.11 / b / g / n 2.4 GHz

Max. transmission power 10 dBm

Battery life Up to 85 min. at 4K resolution

Power Li-Ion battery 3.7 V / 1,000 mAh / 3.7 Wh

Input DC 5 V 2 A

Operating temperature -10° – 60° C

Size | Weight 6.55 x 4.38 x 2.65 cm | 129 g / 109 g (incl. / excl. battery)

Box content 1x Rollei Actioncam 9s Plus, 1x remote control 2.4 GHz, 1x underwater

protective housing for depths of up to 30 m, 1x exchangeable lithium-

ion battery, 1x bike mount, 7x brackets, 1x helmet holder, 4x velcro

straps, 2x adhesive stickers, 4x cable ties, 1x metal cable, 1x micro-USB

cable, 1x lens cleaning cloth, 1x user manual

Technical details are subject to change without notice. Misprints and errors excepted. Reproduction of these operating

instructions – even in part – is not permitted. *interpolated

Components

Selﬁe / front display

Lens

Built-in speaker

Micro-HDMI slot

Micro-USB slot

1/4“ tripod connection

Battery compartment and microSD slot

Mode button

Built-in microphone

Shutter / select button

Power / WiFi button

Operation indicator

Charging indicator

Touch display screen

ENGLISH

Waterproof Case

– Insert Camera into Waterproof Case

1. Ensure the case is clean.

2. Insert the camera and make sure the lens ﬁts neatly in the lens cavity.

3. Close the locking clamps.

4. The camera can be mounted using the accessories provided.

Battery

Before using the device for the ﬁrst time, you must fully charge the battery.

– Charging the Battery

1. Connect the camera to a computer or USB power supply (DC 5V 2A).

2. The charging status light turns on while the battery is charging.

3. The charging status light turns off when the battery is fully charged.

– Changing the Battery

1. Hold the camera so that you can see the camera display and slide the battery cover to the right to

open the battery compartment.

2. Remove the battery.

3. lnsert the new battery so the contacts line up with those of the camera.

Note: Operation is also possible while charging (e.g. via a power bank).

Getting Started

– Turn On: Press and hold the power / WiFi button for 3 seconds.When the camera is turned on, the

Operation Indicator turns on.

– Turn Off: Press and hold the power / WiFi button for 3 seconds.

Modes of the Camera

The Rollei 9s Plus offers various photo and video modes. In the following we give you a short explanation of

how they work. On the following pages you can ﬁnd detailed descriptions how to change the settings for each

mode.

–

“Normal” video mode: You can record a single video with normal speed.

– “Seamless” video mode: Here you can record in a loop.The loop recording can be set in an interval of 1 or 5

minutes. After this interval, a new recording is made and saved in each case. If the memory card is full, the

recordings made so far will be overwritten.

– “V-Timelapse” video mode: In timelapse video mode the camera takes pictures every 0.5 seconds up

to every minute and creates a video out of that. You can choose the video length from 5 minutes up to 30

minutes or endless.

– “SlowMotion” video mode: The camera records a sequence and replays it in slowmotion.

– “FastMotion” video mode: Here the camera replays the video faster than recorded, from double time

up to 15 times faster. Compared to time-lapse video mode, these recordings are a little slower.

– “Single” photo mode: You can take a single shot.

– “Burst” photo mode: This allows you to take 3 shots/1s, 7 shots/2s, 15 shots/4s, 30 shots/8s.

– “P-Timelapse” photo mode: In timelapse photo mode the camera takes pictures every 0.5 seconds up to

every minute for 5 to 30 minutes or unlimited.

– “CountDown” photo mode: You can set a timer on 2 or 10 seconds delay.

– “LongExp” long exposure photo mode: It uses a long-duration shutter speed to sharply capture the

stationary elements of images.

– Date Stamp: You can add a watermark to your pictures or videos, either with just the date or with date and

time.

ENGLISH

Touch Function

You can use the rear touch screen to access the functions of the camera.

– Swipe to the left or right to change between the video mode and

the photo mode.

In the video or photo mode you can access the playback mode via the

symbol in the left lower corner (1) and the settings with the symbol in

the right lower corner (3). To access the mode menu, touch the lower

middle part (2).

– Swipe up to access the mode menu of video and photo.

– Swipe down to open shortcuts to lock and power off for quick

operations.

– To unlock touch the display and swipe from left to right, following

the arrows, or press the shutter / select button.

1 2 31 2 3
