Roland VersaUV LEF2-300 Manuel d'utilisation
Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be sure to read
through this manual completely and store it in a safe location.
• Unauthorized copying or transferal, in whole or in part, of this manual is prohibited.
• The specications of this product and the contents of this operation manual are subject to change without notice.
• This manual and the product have been prepared and tested as much as possible. If you nd any misprints or errors,
please inform Roland DG Corporation.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur through
use of this product, regardless of any failure to perform on the part of this product.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur with
respect to any article made using this product.
R1-200214
Regular Maintenance Guide
This document contains information that is not included in the LEF2-300 Regular Maintenance Guide and is specic to the LEF2-300D
(LEF2-300 + D-KIT). Read this document together with the LEF2-300 Regular Maintenance Guide.
The D-KIT is an option that extends the height limit of the LEF2-300 to 200mm. This option can be selected at the time that a new
LEF2-300 unit is purchased.
1
Contents
Contents..............................................................................................................................................................................................1
1. Introduction ..................................................................................................................3
Spacer Table Attachment/Removal...........................................................................................................................................4
Attaching the Spacer Table..........................................................................................................................................4
Removing the Spacer Table.........................................................................................................................................7
2. Regular Maintenance...................................................................................................9
Maintenance That Must Be Performed Daily....................................................................................................................... 10
Printing Tests and Normal Cleaning...................................................................................................................... 10
Head Refreshing Method.......................................................................................................................................... 18
Manual Cleaning ........................................................................................................................................................................... 25
Manual Cleaning Method ......................................................................................................................................... 25
Company names and product names are trademarks or registered trademarks of their respective holders.
http://www.rolanddg.com/Copyright © 2020 Roland DG Corporation
2
3
1.Introduction
1. Introduction
Spacer Table Attachment/Removal ..............................................................................................4
Attaching the Spacer Table..................................................................................................4
Removing the Spacer Table .................................................................................................7
4
1.Introduction
Spacer Table Attachment/Removal
Attach or remove the spacer table according to the thickness of the object to be printed on.
• Thickness of object to be printed on is 0 to 100mm (0 to 3.94in.): Attach
• Thickness of object to be printed on is 100 to 200mm (3.94 to 7.87in.): Remove
The spacer table does not have a suction function. When using the spacer table, turn o the vacuum function in the
printer settings.
Attaching the Spacer Table
CAUTION Sharp components
Take care to prevent injury from touching the sharp edges of the spacer table.
Procedure
A Turning on the sub power
B Press [SETUP].
[SETUP] starts to ash.
C Press [DOWN] or [▼] to move the at table to the lowest and frontmost (forward) position.
D Open the front cover.
E Remove any installed positioning jigs.
F Temporarily tighten the screws in the 4 locations shown in the gure.
Make a space between the screw heads and the table of approximately 2 mm (78.7 mil) (1).
Spacer Table Attachment/Removal
5
1.Introduction
G Check the front and rear positions of the spacer table.
The side with a notch at the xing location is the rear side, and the side without a notch is the front
side.
H Hold the left and right sides of the spacer table, and place the spacer table in the position
shown in the gure.
1: Holding locations
I Slide the spacer table until it hits the screw.
IMPORTANT
Move the spacer table slowly to prevent damage to the screw threads.
Spacer Table Attachment/Removal
6
1.Introduction
J Tighten the rear screws.
IMPORTANT
Do not touch the head gap sensor.
K Press [▲] to move the at table backwards about 100 mm (3.94 in).
L Tighten the front screws.
M Press and hold [SETUP] to go back to the initial state.
Spacer Table Attachment/Removal
7
1.Introduction
Removing the Spacer Table
CAUTION Sharp components
Take care to prevent injury from touching the sharp edges of the spacer table.
Procedure
A Turning on the sub power
B Press [SETUP].
[SETUP] starts to ash.
C Press [DOWN] or [▼] to move the at table to the lowest and frontmost (forward) position.
D Remove the screws securing the rear side of the spacer table.
E Press [▲] to move the at table backwards about 100 mm (3.94 in).
F Remove the screws securing the front side of the spacer table.
Spacer Table Attachment/Removal
8
1.Introduction
G Hold the left and right sides of the spacer table to remove the spacer table.
1: Holding locations
H Press and hold [SETUP] to go back to the original screen.
