Roland TrueVIS VG-640 Manuel utilisateur

Thank you very much for purchasing this product.

To ensure correct and safe usage with a full understanding of this product's performance, please be sure to read

through this manual completely and store it in a safe location.

Unauthorized copying or transferral, in whole or in part, of this manual is prohibited.

The contents of this manual and the specications of this product are subject to change without notice.

This manual and the product have been prepared and tested as much as possible. If you nd any misprints or

errors, please inform Roland DG Corp.

Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage that may occur through use

of this product, regardless of any failure to perform on the part of this product.

Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage that may occur with respect

to any article made using this product.

R2-160322

Setup Guide

Company names and product names are trademarks or registered trademarks of their respective holders.

http://www.rolanddg.com/

Contents

Contents........................................................................................................1

1.Installation Environment.............................................................................2

Deciding On an Installation Site ................................................................................................. 2

Temperature and Humidity .......................................................................................................... 3

Installation Space ............................................................................................................................. 3

2.Included Items............................................................................................4

3.Assembly and Ink Filling ............................................................................5

Checks before Operations............................................................................................................. 5

Step 1: Assembling the Stand and Attaching the Printer.................................................. 6

Step 2: Installing the Media Holders........................................................................................10

Step 3: Installing the Drain Bottle.............................................................................................13

Step 4: Removing the Retainers................................................................................................14

Step 5:

Adjusting the Ink Tube and Axing a Label (Only When Using Four Colors)....

Step 6: Connecting the Cables ..................................................................................................16

Step 7: Initial Settings ...................................................................................................................17

Step 8: Ink Filling.............................................................................................................................19

4.Installing the Cutting Tool .........................................................................26

Step 1: Assembling the Cutting Tool .......................................................................................26

Step 2: Installing the Cutting Tool ............................................................................................27

5.Network Settings ......................................................................................29

Step 1: Make the Network Settings for the Computer......................................................29

Step 2: Make the Network Settings on the Printer.............................................................31

Step 3: Make the Port Settings for the Software RIP..........................................................34

This document is the setup guide for both the VG-640 and the VG-540. This document uses the following

notation to distinguish between the two models where necessary.

VG-640 — 64-inch model

VG-540 — 54-inch model

Also, most of the gures in this document depict the VG-640.

Deciding On an Installation Site

Install the machine in a quiet, stable location oering good operating conditions. An unsuitable location can

cause accidents, re, faulty operation, or breakdown.

WARNING Install the machine in a location that is level, stable, and able to bear the

weight of the machine.

The total weight of the machine may reach over 290 kg (639.3 lb.) for the 64-inch

model, 260 kg (573.1 lb.) for the 54-inch model. Installation in an unsuitable

location may cause a major accident, including tip over, fall, or collapse.

WARNING Never install this machine outside or in any location where exposure to

water or high humidity may occur.

Current leakage may cause electrical shock, electrocution, or combustion and

re.

WARNING Never install the machine close to any ammable object or in a gas-lled

location.

Combustion or explosion may occur.

WARNING Install the machine in a clean, brightly lit location.

Working in a location that is dark or cluttered may lead to an accident, such

as becoming caught in the machine as the result of an inadvertent stumble.

WARNING Position the machine so that the power plug is within immediate reach

at all times.

This is to enable quick disconnection of the power plug in the event of an emer-

gency. Install the machine next to an electrical outlet. Also, provide enough

empty space to allow immediate access to the electrical outlet.

CAUTION Ensure adequate ventilation for the work area.

Failing to perform ventilation may result in a health hazard or danger of com-

bustion due to ink fumes.

Unsuitable Installation Sites

Locations subject to large uctuations in temperature or humidity

Locations subject to shaking or vibration

Locations where the oor is tilted, not level, or unstable

Dusty locations

Locations exposed to direct sunlight

Locations near air-conditioning or heating equipment

Locations exposed to water or moving air

Locations exposed to considerable electrical or magnetic noise or other forms of electromagnetic

energy

1. Installation Environment

Temperature and Humidity

Maintain the specied temperature and humidity even when the machine is not in use. Failure to do so may

result in malfunction.

Installation Space

The space shown in the gure is required in order to use this machine.

1,000 mm (39.4 in)

4,500 mm (177.2 in) (64-inch model)

4,000 mm (157.5 in) (54-inch model)

3,500 mm (137.8 in) (64-inch model)

3,000 mm (118.2 in) (54-inch model)

Unit space

Work space

2,000 mm (78.7 in)

During operation: Temperature 20 to 32°C (68 to 90°F), humidity: 35 to 80%RH (no condensation)

During non-operation: Temperature 5 to 40°C (41 to 104°F), humidity: 20 to 80%RH (no condensation)

The following items are included with the machine. Make sure they are all present before proceeding.

Power cord (1)

Arms

(1 each for right and left) Casters (2) Stand legs

(1 each for right and left)

Stand stay (1) Shafts (2)

Media holders/retaining

screws

(1 each for right and left)

Shaft clamps (2)

Middle pinch rollers * **

(The quantity varies de-

pending on the model.)

Media clamps*

(1 each for right and left)

Replacement wiper (1) Drain bottles (2) Tray pad (3) Hexagonal

wrench (1) Pipe (1)

TR cleaning liquid pouches

(2) Blade holder (1) Blade (1) Pin (1) Bolts (40) Washers

(22)

Replacement blades for

separating knife (1) Cable clamp (1) Tweezers (1) Cleaning

liquid (1)

Cleaning

sticks

Setup Guide (this docu-

ment) (1)

Read this rst (1)

User's Manual (1)

Inkjet printer mainte-

nance guide (1)

Cartridge-slot label (for

4 colors) (2) *** Software RIP (1)

* The media clamps and the middle pinch rollers are installed on the machine.

** (6) for the 64-inch model and (5) for the 54-inch model.

*** With the factory default settings, these labels are axed to the platen at the location where the front

cover opens.

2. Included Items

Checks before Operations

CAUTION Unloading and emplacement are operations that must be performed by

8 persons or more.

Tasks that require undue effort when performed by a small number of persons

may result in physical injury. Also, if dropped, such items may cause injury.

Completed Drawing

Necessary Tools

Hexagonal wrench

(large) Pipe*

* Use this when the hexagonal wrenches are too small to easily tighten bolts.

3. Assembly and Ink Filling

Step 1 : Assembling the Stand and Attaching the Printer

Procedure

A Place the caster on the stand leg.

Place the stand leg with the tabletop plate facing down, and then place the caster on top of the stand

leg. The casters have no particular front and rear orientation.

Tabletop plate

B Lightly tighten the bolts in the 4 upper locations and then in the 4 locations on the sides.

For the 4 upper locations, rst tighten the bolts in the narrow slots. In this way you can attach the caster

in the correct position.

Use washers in the 4 locations on the sides.

Tighten

temporarily

Bolts: 8

Washers: 4

NarrowWide

Tighten the

bolt here rst.

3. Assembly and Ink Filling

C Fully tighten the bolts in the 4 upper locations and then in the 4 locations on the sides.

Use the pipe when tightening the bolts in the upper locations. When tightening the bolts fully, tighten

them securely. Loose bolts may cause the stand to wobble.

Tighten fully

Bolts: 8

Washers: 4

Pipe

Assemble the opposing stand leg by following the same procedure from step Ato step C.

E Position the stand legs parallel to each other and separated by approximately 1,800 mm

(70.9 in.) for the 64-inch model or approximately 1,500 mm (59.1 in.) for the 54-inch model.

Position the legs so that the L-shaped brackets face the inside and the bent side of the tabletop plate

faces down for each leg.

About 1,800 mm (70.9 in.) (64-inch model)

About 1,500 mm (59.1 in.) (54-inch model)

Set this part on the bottom.

F Place the stand stay on the stand legs.

Place the stand stay so that its inside touches the L-shaped brackets and the stand legs in order to make

the 2 stand legs parallel.

Position the surface

with attachment holes

toward the casters.

3. Assembly and Ink Filling

G Lightly tighten the bolts in the order of 1, 2.

Use a washer for each bolt.

Tighten

temporarily

Bolts: 6

Washers: 6

H Fully tighten the bolts in the order of 1, 2.

Before tightening the bolts, check once more that the 2 stand legs are parallel. If the inside of the stand

stay is touching the L-shaped brackets and the stand legs, the stand legs will be parallel.

When tightening the bolts fully, tighten them securely. Loose bolts may cause the stand to wobble.

Tighten fully

Bolts: 6

Washers: 6
